一、需求分析

订单场景，订单状态分为

//    WHEN oms_order.order_state = 11 THEN '待支付'
//    WHEN oms_order.order_state = 12 THEN '订购成功'
//    WHEN oms_order.order_state = 21 THEN '订单已提交到厂家'
//    WHEN oms_order.order_state = 22 THEN '厂家已接受订单'
//    WHEN oms_order.order_state = 31 THEN '生产中'
//    WHEN oms_order.order_state = 32 THEN '生产完成'
//    WHEN oms_order.order_state = 41 THEN '车辆已发出'
//    WHEN oms_order.order_state = 42 THEN '车辆已到店'
//    WHEN oms_order.order_state = 51 THEN '已完成'
//    WHEN oms_order.order_state = 52 THEN '已取消'
//    WHEN oms_order.order_state = 53 THEN '已关闭'
//    WHEN oms_order.order_state = 62 THEN '已退款'

需求是向业务部门实时推送订单的状态，且每人每订单每个状态只能推送一次

二、技术背景

实时数据存储在阿里云Datahub上，由于实时数据使用DTS获取的业务库的binlog，所以会有大量的重复数据，且有历史数据，由于要对用户进行短信触达，所以数据要保证不重复且及时，就需要舍弃历史数据，并对操作数据去重。然后拼装成业务侧需要的json格式，在推送到指定的消息队列，下游通过订阅消费。

技术路线：Mysql=>DTS=>DataHub=>Flink(Blink,MapState,Enum,Ontimer)=>DatahubSink

三、技术实现

1、pom.xml

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>

    <groupId>com.gwm</groupId>
    <artifactId>blink_ae</artifactId>
    <version>1.0-SNAPSHOT</version>

    <properties>
        <scala.version>2.11.12</scala.version>
        <scala.binary.version>2.11</scala.binary.version>
        <blink.version>blink-3.3.0</blink.version>
        <java.version>1.8</java.version>
        <maven.compiler.source>1.8</maven.compiler.source>
        <maven.compiler.target>1.8</maven.compiler.target>
        <sdk.version>0.38.3-public</sdk.version>
    </properties>
    <dependencies>
        <!--        <dependency>-->
        <!--            <groupId>com.alibaba.blink</groupId>-->
        <!--            <artifactId>flink-core</artifactId>-->
        <!--            <version>${blink.version}</version>-->
        <!--            <scope>provided</scope>-->
        <!--            &lt;!&ndash;            <systemPath>${project.basedir}/lib/flink-core-blink-3.2.2.jar</systemPath>&ndash;&gt;-->
        <!--        </dependency>-->
        <!--        <dependency>-->
        <!--            <groupId>com.alibaba.blink</groupId>-->
        <!--            <artifactId>flink-streaming-java_${scala.binary.version}</artifactId>-->
        <!--            <version>${blink.version}</version>-->
        <!--            <scope>provided</scope>-->
        <!--            &lt;!&ndash;            <systemPath>${project.basedir}/lib/flink-streaming-java_2.11-blink-3.2.2.jar</systemPath>&ndash;&gt;-->
        <!--        </dependency>-->

        <!--打包udf自定义函数需要添加此依赖-->
        <!--        <dependency>-->
        <!--            <groupId>com.alibaba.blink</groupId>-->
        <!--            <artifactId>flink-table_${scala.binary.version}</artifactId>-->
        <!--            <version>${blink.version}</version>-->
        <!--            <scope>provided</scope>-->
        <!--            &lt;!&ndash;            <systemPath>${project.basedir}/lib/flink-table_2.11-blink-3.2.2.jar</systemPath>&ndash;&gt;-->
        <!--        </dependency>-->
        <!--        <dependency>-->
        <!--            <groupId>com.alibaba.blink</groupId>-->
        <!--            <artifactId>flink-table-common</artifactId>-->
        <!--            <version>${blink.version}</version>-->
        <!--            <scope>provided</scope>-->
        <!--            &lt;!&ndash;            <systemPath>${project.basedir}/lib/flink-table_2.11-blink-3.2.2.jar</systemPath>&ndash;&gt;-->
        <!--        </dependency>-->
        <!-- https://mvnrepository.com/artifact/com.alibaba.blink/flink-streaming-scala -->
        <!--        <dependency>-->
        <!--            <groupId>com.alibaba.blink</groupId>-->
        <!--            <artifactId>flink-streaming-scala_${scala.binary.version}</artifactId>-->
        <!--            <version>${blink.version}</version>-->
        <!--            <scope>provided</scope>-->
        <!--        </dependency>-->

        <!--        <dependency>-->
        <!--            <groupId>com.alibaba.blink</groupId>-->
        <!--            <artifactId>flink-java</artifactId>-->
        <!--            <version>${blink.version}</version>-->
        <!--            <scope>provided</scope>-->
        <!--        </dependency>-->
        <!--        <dependency>-->
        <!--            <groupId>com.alibaba.blink</groupId>-->
        <!--            <artifactId>flink-scala_${scala.binary.version}</artifactId>-->
        <!--            <version>${blink.version}</version>-->
        <!--            <scope>provided</scope>-->
        <!--        </dependency>-->
        <!-- https://mvnrepository.com/artifact/com.alibaba.blink/flink-jdbc -->
        <!--        <dependency>-->
        <!--            <groupId>com.alibaba.blink</groupId>-->
        <!--            <artifactId>flink-jdbc</artifactId>-->
        <!--            <version>${blink.version}</version>-->
        <!--            <scope>provided</scope>-->
        <!--        </dependency>-->

        <dependency>
            <groupId>com.alibaba.blink</groupId>
            <artifactId>flink-streaming-java_${scala.binary.version}</artifactId>
            <version>${blink.version}</version>
<!--            <scope>provided</scope>-->
        </dependency>
        <!-- https://mvnrepository.com/artifact/com.alibaba.blink/flink-table-common -->

        <dependency>
            <groupId>com.alibaba.flink</groupId>
            <artifactId>datahub-connector</artifactId>
            <version>0.1-SNAPSHOT</version>
            <classifier>jar-with-dependencies</classifier>
<!--            <scope>provided</scope>-->
        </dependency>
        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>fastjson</artifactId>
            <version>1.2.34</version>
<!--            <scope>provided</scope>-->
        </dependency>
        <dependency>
            <groupId>org.postgresql</groupId>
            <artifactId>postgresql</artifactId>
            <version>42.1.1</version>
            <scope>provided</scope>
        </dependency>
<!--        <dependency>-->
<!--            <groupId>com.fasterxml.jackson.core</groupId>-->
<!--            <artifactId>jackson-databind</artifactId>-->
<!--            <version>2.11.2</version>-->
<!--            <scope>provided</scope>-->
<!--        </dependency>-->
<!--        <dependency>-->
<!--            <groupId>com.fasterxml.jackson.core</groupId>-->
<!--            <artifactId>jackson-core</artifactId>-->
<!--            <version>2.11.2</version>-->
<!--            <scope>provided</scope>-->
<!--        </dependency>-->
<!--        <dependency>-->
<!--            <groupId>com.fasterxml.jackson.core</groupId>-->
<!--            <artifactId>jackson-annotations</artifactId>-->
<!--            <version>2.11.2</version>-->
<!--            <scope>provided</scope>-->
<!--        </dependency>-->


    </dependencies>
<!--    <build>-->
<!--        <plugins>-->
<!--            <plugin>-->
<!--                <groupId>org.apache.maven.plugins</groupId>-->
<!--                <artifactId>maven-shade-plugin</artifactId>-->
<!--                <version>3.4.1</version>-->
<!--                <executions>-->
<!--                    <execution>-->
<!--                        <phase>package</phase>-->
<!--                        <goals>-->
<!--                            <goal>shade</goal>-->
<!--                        </goals>-->
<!--                        <configuration>-->
<!--                            <minimizeJar>true</minimizeJar>-->
<!--                            <filters>-->
<!--                                <filter>-->
<!--                                    <artifact>log4j:log4j</artifact>-->
<!--                                    <includes>-->
<!--                                        <include>**</include>-->
<!--                                    </includes>-->
<!--                                </filter>-->
<!--                                <filter>-->
<!--                                    <artifact>commons-logging:commons-logging</artifact>-->
<!--                                    <includes>-->
<!--                                        <include>**</include>-->
<!--                                    </includes>-->
<!--                                </filter>-->
<!--                                <filter>-->
<!--                                    <artifact>foo:bar</artifact>-->
<!--                                    <excludeDefaults>false</excludeDefaults>-->
<!--                                    <includes>-->
<!--                                        <include>foo/Bar.class</include>-->
<!--                                    </includes>-->
<!--                                </filter>-->
<!--                            </filters>-->
<!--                            <relocations combine.self="override">-->
<!--                                <relocation>-->
<!--                                    <pattern>org.glassfish.jersey</pattern>-->
<!--                                    <shadedPattern>com.alibaba.blink.shaded.datahub.org.glassfish.jersey</shadedPattern>-->
<!--                                </relocation>-->
<!--                            </relocations>-->
<!--                        </configuration>-->
<!--                    </execution>-->
<!--                </executions>-->
<!--            </plugin>-->
<!--        </plugins>-->
<!--    </build>-->
<!-- 添加依赖打包   -->
<!--    <build>-->

<!--        <plugins>-->
<!--                        <plugin>-->
<!--                            <groupId>org.apache.maven.plugins</groupId>-->
<!--                            <artifactId>maven-assembly-plugin</artifactId>-->
<!--                            <version>3.1.1</version>-->
<!--                            <configuration>-->
<!--                                <archive>-->
<!--                                    <manifest>-->
<!--                                        <mainClass>com.gwm.driver.AeCollectorData</mainClass>-->
<!--                                    </manifest>-->
<!--                                </archive>-->
<!--                                <descriptorRefs>-->
<!--                                    <descriptorRef>jar-with-dependencies</descriptorRef>-->
<!--                                </descriptorRefs>-->
<!--                            </configuration>-->
<!--                            <executions>-->
<!--                                <execution>-->
<!--                                    <id>make-assembly</id>-->
<!--                                    <phase>package</phase>-->
<!--                                    <goals>-->
<!--                                        <goal>single</goal>-->
<!--                                    </goals>-->

<!--                                </execution>-->
<!--                            </executions>-->
<!--                        </plugin>-->
<!--        </plugins>-->
<!--    </build>-->
    <build>
        <plugins>
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-shade-plugin</artifactId>
                <version>3.2.0</version>
                <configuration>
                    <createDependencyReducedPom>false</createDependencyReducedPom>
                </configuration>
                <executions>
                    <execution>
                        <goals>
                            <goal>shade</goal>
                        </goals>
                        <configuration>
                            <transformers>
                                <transformer implementation="org.apache.maven.plugins.shade.resource.ManifestResourceTransformer">
                                    <manifestEntries>
                                        <Main-Class>com.gwm.driver.AeCollectorData</Main-Class>
                                        <X-Compile-Source-JDK>${maven.compiler.source}</X-Compile-Source-JDK>
                                        <X-Compile-Target-JDK>${maven.compiler.target}</X-Compile-Target-JDK>
                                    </manifestEntries>
                                </transformer>
                            </transformers>
                            <relocations combine.self="override">
                                <relocation>
                                    <pattern>org.glassfish.jersey</pattern>
                                    <shadedPattern>com.alibaba.blink.shaded.datahub.org.glassfish.jersey</shadedPattern>
                                </relocation>
                            </relocations>
                        </configuration>
                    </execution>
                </executions>
            </plugin>
        </plugins>
    </build>
</project>

2、Enum类

package com.gwm.pojo;

/**
 * @author yangyingchun
 * @version 1.0
 * @date 2023/2/24 8:53
 */
public enum OrderStage {
    //    WHEN oms_order.order_state = 11 THEN '待支付'
//    WHEN oms_order.order_state = 12 THEN '订购成功'
//    WHEN oms_order.order_state = 21 THEN '订单已提交到厂家'
//    WHEN oms_order.order_state = 22 THEN '厂家已接受订单'
//    WHEN oms_order.order_state = 31 THEN '生产中'
//    WHEN oms_order.order_state = 32 THEN '生产完成'
//    WHEN oms_order.order_state = 41 THEN '车辆已发出'
//    WHEN oms_order.order_state = 42 THEN '车辆已到店'
//    WHEN oms_order.order_state = 51 THEN '已完成'
//    WHEN oms_order.order_state = 52 THEN '已取消'
//    WHEN oms_order.order_state = 53 THEN '已关闭'
//    WHEN oms_order.order_state = 62 THEN '已退款'
    OrderStage11("待支付"),OrderStage12("订购成功"),
    OrderStage21("订单已提交到厂家"),OrderStage22("厂家已接受订单"),
    OrderStage31("生产中"),OrderStage32("生产完成"),
    OrderStage41("车辆已发出"),OrderStage42("车辆已到店"),
    OrderStage51("已完成"),OrderStage52("已取消"),
    OrderStage53("已关闭"),OrderStage62("已退款"),;

    private String chinese;

    //枚举类型的构造函数默认为private，因为枚举类型的初始化要在当前枚举类中完成。
    OrderStage (String chinese){
        this.chinese= chinese;
    }

    public String getChinese(){
        return chinese;
    }

}

3、Class对象

package com.gwm.pojo;

import com.gwm.utils.getString;

import java.io.Serializable;
import java.math.BigInteger;
import java.util.Date;

/**
 * @author yangyingchun
 * @version 1.0
 * @date 2023/2/20 13:31
 */
public class EventSuccessInfo implements Serializable {
    private String phone ;
    private String order_sn ;
    private String brand;
    private String car_model ;
    private String action_time ;
    private Double paid_amount ;
    private String name ;
    private String operation_flag ;
    private String order_time;
    private String order_state;

    public EventSuccessInfo() {
    }

    public EventSuccessInfo(String phone, String order_sn, String brand, String car_model, String action_time, Double paid_amount, String name, String operation_flag, String order_time, String order_state) {
        this.phone = phone;
        this.order_sn = order_sn;
        this.brand = brand;
        this.car_model = car_model;
        this.action_time = action_time;
        this.paid_amount = paid_amount;
        this.name = name;
        this.operation_flag = operation_flag;
        this.order_time = order_time;
        this.order_state = order_state;
    }

    public String getPhone() {
        return phone;
    }

    public void setPhone(String phone) {
        this.phone = phone;
    }

    public String getOrder_sn() {
        return order_sn;
    }

    public void setOrder_sn(String order_sn) {
        this.order_sn = order_sn;
    }

    public String getBrand() {
        return brand;
    }

    public void setBrand(String brand) {
        this.brand = brand;
    }

    public String getCar_model() {
        return car_model;
    }

    public void setCar_model(String car_model) {
        this.car_model = car_model;
    }

    public String getAction_time() {
        return action_time;
    }

    public void setAction_time(String action_time) {
        this.action_time = action_time;
    }

    public Double getPaid_amount() {
        return paid_amount;
    }

    public void setPaid_amount(Double paid_amount) {
        this.paid_amount = paid_amount;
    }

    public String getName() {
        return name;
    }

    public void setName(String name) {
        this.name = name;
    }

    public String getOperation_flag() {
        return operation_flag;
    }

    public void setOperation_flag(String operation_flag) {
        this.operation_flag = operation_flag;
    }

    public String getOrder_time() {
        return order_time;
    }

    public void setOrder_time(String order_time) {
        this.order_time = order_time;
    }

    public String getOrder_state() {
        return order_state;
    }

    public void setOrder_state(String order_state) {
        this.order_state = order_state;
    }

    @Override
    public String toString() {
        return "EventSuccessInfo{" +
                "phone='" + phone + '\'' +
                ", order_sn='" + order_sn + '\'' +
                ", brand='" + brand + '\'' +
                ", car_model='" + car_model + '\'' +
                ", action_time='" + action_time + '\'' +
                ", paid_amount=" + paid_amount +
                ", name='" + name + '\'' +
                ", operation_flag='" + operation_flag + '\'' +
                ", order_time='" + order_time + '\'' +
                ", order_state=" + order_state +
                '}';
    }
}

4、Main

package com.gwm.driver;

import com.alibaba.fastjson.JSON;
import com.alibaba.flink.connectors.datahub.datastream.source.DatahubSourceFunction;
import com.aliyun.datahub.client.model.RecordEntry;
import com.gwm.pojo.EventSuccessInfo;
import com.gwm.pojo.OrderStage;
import com.gwm.pojo.OrderState;
import com.gwm.utils.TimeToStampUtil;
import com.gwm.utils.getString;
import org.apache.flink.api.common.functions.FlatMapFunction;
import org.apache.flink.api.common.functions.MapFunction;
import org.apache.flink.api.common.functions.RichFilterFunction;
import org.apache.flink.api.common.restartstrategy.RestartStrategies;
import org.apache.flink.api.common.state.MapState;
import org.apache.flink.api.common.state.MapStateDescriptor;
import org.apache.flink.api.common.state.ValueState;
import org.apache.flink.api.java.utils.ParameterTool;
import org.apache.flink.configuration.Configuration;
import org.apache.flink.streaming.api.TimeCharacteristic;
import org.apache.flink.streaming.api.datastream.DataStream;
import org.apache.flink.streaming.api.datastream.DataStreamSource;
import org.apache.flink.streaming.api.datastream.KeyedStream;
import org.apache.flink.streaming.api.datastream.SingleOutputStreamOperator;
import org.apache.flink.streaming.api.environment.StreamExecutionEnvironment;
import org.apache.flink.streaming.api.functions.KeyedProcessFunction;
import org.apache.flink.util.Collector;
import org.apache.flink.util.StringUtils;
import scala.Tuple4;

import java.text.ParseException;
import java.text.SimpleDateFormat;
import java.util.Date;
import java.util.List;
import java.util.Properties;
import java.util.UUID;

/**
 * @author yangyingchun
 * @version 1.0
 * @date 2022/11/14 16:26
 */
public class OmsEventInfo {
//声明所有的链接信息
    private static String endPoint = "http://datahub.cn-XXXXXXXX-d01.dh.res.cloud.gwm.cn";
    //private static String endPoint ="public endpoint";//公网访问（填写内网Endpoint，就不用填写公网Endpoint）。
    private static String projectName = "oms";
    private static String topicSourceName =  "dts_oms_ols_order";
//    private static String topicSourceName =  "dts_oms_uat_ols_order";
    private static String accessId = "5jNE06XXXXXleYil";
    private static String accessKey = "Ehsl9n3XXXXXXXCFAaTbm47uHtWQP";
    //设置消费的启动位点对应的时间。TimeToStampUtil.timeToStamp("2021-12-21") 此时间至少为当前时间
//    private static Long datahubStartInMs = TimeToStampUtil.timeToStamp("2023-02-20");
    private static Long datahubStartInMs = System.currentTimeMillis();
    private static Long datahubEndInMs=Long.MAX_VALUE;
//时间格式化备用
    private static SimpleDateFormat sd = new SimpleDateFormat("yyyy-MM-dd HH:mm:ss");
    private static SimpleDateFormat sd1 = new SimpleDateFormat("yyyy-MM-dd");
//设置数据时间的对比值，这里主要为了实现数据的业务时间要大于等于起始时间，并且每天凌晨需要进行重置
    private static Date startDate;

    static {
        try {
            //初始化赋值
            startDate = sd1.parse(sd.format(new Date()));
        } catch (ParseException e) {
            e.printStackTrace();
        }
    }

    ;

    public static void main(String[] args) throws Exception {

        ParameterTool params = ParameterTool.fromArgs(args);
        String configFilePath = params.get("configFile");
        Properties properties = new Properties();
//        properties.load(new StringReader(new String(Files.readAllBytes(Paths.get(configFilePath, new String[0])), StandardCharsets.UTF_8)));

        if (params.has("blink.job.startTimer")){
            datahubStartInMs = TimeToStampUtil.timeToStamp((String) properties.get("blink.job.startTimer"));
        }else {
            System.out.println("datahubStartInMs not set , use default parameter : System.currentTimeMillis");
        }
        if (params.has("blink.job.endTimer")){
            datahubEndInMs = TimeToStampUtil.timeToStamp((String) properties.get("blink.job.endTimer"));
        }else {
            System.out.println("datahubEndInMs not set , use default parameter : Long.MAX_VALUE");
        }
        if (params.has("blink.job.endPoint")){
            endPoint = (String) properties.get("blink.job.endPoint");
        }else {
            System.out.println("endPoint not set , use default parameter : http://datahub.cn-baoding-gwmcloud-d01.dh.res.cloud.gwm.cn");
        }

        if (params.has("blink.job.projectName")){
            projectName = (String)properties.get("blink.job.projectName");
        }else {
            System.out.println("projectName not set , use default parameter : OMS");
        }

        if (params.has("blink.job.topicSourceName")){
            topicSourceName = (String)properties.get("blink.job.topicSourceName");
        }else {
            System.out.println("topicSourceName not set , use default parameter : dts_oms_uat_ols_order");
        }

        if (params.has("blink.job.accessId")){
            accessId = (String)properties.get("blink.job.accessId");
        }else {
            System.out.println("accessId not set , use default parameter : 5jNE06TXXXXXXXXXXXXXX8SPHleYil");
        }

        if (params.has("blink.job.accessKey")){
            accessKey = (String)properties.get("blink.job.accessKey");
        }else {
            System.out.println("accessKey not set , use default parameter : Ehsl9n3xhk0XXXXXXXXXXXWvdxCFAaTbm47uHtWQP");
        }


//初始化环境入口
        StreamExecutionEnvironment env = StreamExecutionEnvironment.getExecutionEnvironment();
        env.setStreamTimeCharacteristic(TimeCharacteristic.EventTime);
        env.enableCheckpointing(3600000L);
//        env.getCheckpointConfig().setCheckpointingMode(CheckpointingMode.EXACTLY_ONCE);
//        env.getCheckpointConfig().enableExternalizedCheckpoints(CheckpointConfig.ExternalizedCheckpointCleanup.RETAIN_ON_CANCELLATION);
        env.setRestartStrategy(RestartStrategies.fixedDelayRestart(3, 2000L));
//并行度与datahub shard数据一致
        env.setParallelism(5);
//获取datastream
        DataStreamSource<List<RecordEntry>> aedata =  env.addSource(
                    new DatahubSourceFunction(
                            endPoint,
                            projectName,
                            topicSourceName,
                            accessId,
                            accessKey,
                            datahubStartInMs,
                            datahubEndInMs,
                            20L,
                            1000L,
                            1000
                    ));


//将datasteam转化为Class类，且增加一些其他相关信息
        DataStream<Tuple4<String, EventSuccessInfo, String, Long>> aecollectordataDataStream = aedata.flatMap(new FlatMapFunction<List<RecordEntry>, Tuple4<String, EventSuccessInfo, String, Long>>() {
            @Override
            public void flatMap(List<RecordEntry> value, Collector<Tuple4<String, EventSuccessInfo, String, Long>> out) throws Exception {
                for (RecordEntry recordEntry : value) {

                    String phone = getString.getString(recordEntry, "customer_phone");
                    String order_sn = getString.getString(recordEntry, "order_no");
                    String brand_name = getString.getString(recordEntry, "brand");
                    String car_model = getString.getString(recordEntry, "car_model");
                    String action_time = "null".equals(getString.getString(recordEntry, "update_time"))||"".equals(getString.getString(recordEntry, "update_time"))?null:
                            sd.format(new Date(Long.parseLong(getString.getString(recordEntry, "update_time"))/1000));
                    Double paid_amount = "null".equals(getString.getString(recordEntry, "paid_amount"))?null:
                            Double.parseDouble(getString.getString(recordEntry, "paid_amount"));
                    String name = getString.getString(recordEntry, "customer_name");
                    String operation_flag = getString.getString(recordEntry, "new_dts_sync_dts_after_flag");
                    String order_time = "null".equals(getString.getString(recordEntry, "order_time"))||"".equals(getString.getString(recordEntry, "order_time"))?null:
                            sd.format(new Date(Long.parseLong(getString.getString(recordEntry, "order_time"))/1000));
                    String order_state = getString.getString(recordEntry, "order_state"); //'订购成功'
                    String trans_order_state = null;

//通过枚举类赋值
                    switch (order_state) {
                        case "11":
                            trans_order_state= OrderStage.OrderStage11.getChinese();
                            break;
                        case "12":
                            trans_order_state= OrderStage.OrderStage12.getChinese();
                            break;
                        case "21":
                            trans_order_state= OrderStage.OrderStage21.getChinese();
                            break;
                        case "22":
                            trans_order_state= OrderStage.OrderStage22.getChinese();
                            break;
                        case "31":
                            trans_order_state= OrderStage.OrderStage31.getChinese();
                            break;
                        case "32":
                            trans_order_state= OrderStage.OrderStage32.getChinese();
                            break;
                        case "41":
                            trans_order_state= OrderStage.OrderStage41.getChinese();
                            break;
                        case "42":
                            trans_order_state= OrderStage.OrderStage42.getChinese();
                            break;
                        case "51":
                            trans_order_state= OrderStage.OrderStage51.getChinese();
                            break;
                        case "52":
                            trans_order_state= OrderStage.OrderStage52.getChinese();
                            break;
                        case "53":
                            trans_order_state= OrderStage.OrderStage53.getChinese();
                            break;
                        case "62":
                            trans_order_state= OrderStage.OrderStage62.getChinese();
                            break;

                    }

//业务对比的时间信息
                    Date add_time =
                            "null".equals(getString.getString(recordEntry, "order_time"))||"".equals(getString.getString(recordEntry, "order_time"))
                                    ?null
                                    :new Date(Long.parseLong(getString.getString(recordEntry, "order_time")) / 1000);
//                    startDate = sd1.parse(sd.format(new Date()));

                    System.out.println(order_state+"====startDate:"+startDate+"====paid_at:"+order_time+"=====phone:"+phone);
                    //这里有三个问题，
                    // 1、技术+业务：因为获取的是数据库操作日志，所以数据是重复的，（MA已经做了重复校验，确保不会重复发且无时效性）
                    // 2、技术：如果操作了历史数据，且用户的订单状态恰好还是订购成功时，也会触达，是不是要加限制，加的话加什么合适，
                    //    新增且当天（很多数据是获取不到时间的）？还是所有时间都推，再ma测加一个时间的控制条件
                    //    结论：空的也要，
                    // 3、业务：需要明确订购成功的规则，否则极易造成异常, order_state=12当前是订购成功 能复用吗

                    if (

//                           "12".equals(order_state)&&
//由于是binlog只获取插入或修改后的数据数据情况如下
//情况	标志位	 更新前标志		更新后标志
//1        I         	N		  		Y
//2		 U         	N		  		Y
//2        U         	Y		  		N
//3		 D         	N		  		Y
//3        D         	Y		  		N
                            "Y".equals(operation_flag)&&
//对比时间为空的去掉
                             !StringUtils.isNullOrWhitespaceOnly(order_time)&&
//业务时间字段要比初始化时间晚的数据才有意义
                             add_time.after(startDate)

                        ){
                        EventSuccessInfo eventSuccessInfo = new EventSuccessInfo(
                                phone
                                , order_sn
                                , brand_name
                                , car_model
                                , action_time
                                , paid_amount
                                , name
                                , operation_flag
                                ,order_time
                                ,trans_order_state
                        );
                        //                    System.out.println(eventSuccessInfo);
                        Tuple4<String, EventSuccessInfo, String, Long> tuple4
                                = new Tuple4<String, EventSuccessInfo, String, Long>(
                                "test_event_order_success"
                                ,eventSuccessInfo
                                , UUID.randomUUID().toString().replace("-","")
                                ,System.currentTimeMillis()
                        );
                        out.collect(tuple4);
                    }
                }
            }
        });

//为去重做准备
        KeyedStream<Tuple4<String, EventSuccessInfo, String, Long>, String> tuple4StringKeyedStream
                = aecollectordataDataStream.keyBy(x -> x._2().getPhone());

        //手机号去重逻辑 通过mapstate
        SingleOutputStreamOperator<Tuple4<String, EventSuccessInfo, String, Long>> map = tuple4StringKeyedStream.filter(new RichFilterFunction<Tuple4<String, EventSuccessInfo, String, Long>>() {
            //1.定义状态 进行手机号+订单状态+订单编号 去重
            private MapState<String,String> phoneState;
            @Override
            public void open(Configuration parameters) throws Exception {
                phoneState = getRuntimeContext().getMapState(new MapStateDescriptor<String,String>("phonestate", String.class,String.class));
            }
            @Override
            public boolean filter(Tuple4<String, EventSuccessInfo, String, Long> value) throws Exception {
                if (!phoneState.contains(value._2().getPhone()+value._2().getOrder_state()+value._2().getOrder_sn())){
                    phoneState.put(value._2().getPhone()+value._2().getOrder_state()+value._2().getOrder_sn(),value._2().getOrder_sn());
                    return true;
                }
                return false;
            }

        });

        //只要数据时间是当天的 ：通过flink定时器 定义每天零晨更新比较时间
        SingleOutputStreamOperator<Tuple4<String, EventSuccessInfo, String, Long>> process = map.keyBy(x -> x._2().getPhone()).process(new KeyedProcessFunction<String, Tuple4<String, EventSuccessInfo, String, Long>, Tuple4<String, EventSuccessInfo, String, Long>>() {
            //1.定义状态 进行手机号去重
            private ValueState<String> timeSate;
            @Override
            public void processElement(Tuple4<String, EventSuccessInfo, String, Long> value, Context ctx, Collector<Tuple4<String, EventSuccessInfo, String, Long>> out) throws Exception {
                //获取格林威治标准时间的第二天00:00:00即获取北京时间的第二天08:00:00
//                long ts = (ctx.timerService().currentProcessingTime() / (1000 * 60 * 60 * 24) + 1) * (1000 * 60 * 60 * 24);
                //获取北京时间的第二天00:00:00
                long ts = ( ctx.timerService().currentProcessingTime()/(1000*60*60*24) + 1) * (1000*60*60*24)- 8 * 60 * 60 * 1000;

//                long ts = 1677054000000L;
                //如果注册相同数据的TimeTimer，后面的会将前面的覆盖，即相同的timeTimer只会触发一次
                ctx.timerService().registerProcessingTimeTimer(ts);
                out.collect(value);
            }

            @Override
            public void onTimer(long timestamp, OnTimerContext ctx, Collector<Tuple4<String, EventSuccessInfo, String, Long>> out) throws Exception {

                //定时器设置，每天凌晨更新开始时间
                System.out.println(timestamp);
                System.out.println("定时器执行了：" + timestamp);
                startDate = sd1.parse(sd.format(new Date()));
//                startDate = sd1.parse("2023-02-01");
            }
        });

        SingleOutputStreamOperator<Tuple4<String, String, String, Long>> jsonString = process.map(new MapFunction<Tuple4<String, EventSuccessInfo, String, Long>, Tuple4<String, String, String, Long>>() {
            @Override
            public Tuple4<String, String, String, Long> map(Tuple4<String, EventSuccessInfo, String, Long> value) throws Exception {
                return new Tuple4<String, String, String, Long>(
                        value._1(),
                        JSON.toJSONString(value._2()),
                        value._3(),
                        value._4()
                );
            }
        });


//        jsonString.print();
//自定义输出sink
        jsonString.addSink(new EventOmsSuccessSink());


        env.execute("EventOrderSuccess===>");

    }
}

5、自定义sink

package com.gwm.sink;

import com.aliyun.datahub.client.DatahubClient;
import com.aliyun.datahub.client.DatahubClientBuilder;
import com.aliyun.datahub.client.auth.AliyunAccount;
import com.aliyun.datahub.client.common.DatahubConfig;
import com.aliyun.datahub.client.http.HttpConfig;
import com.aliyun.datahub.client.model.RecordEntry;
import com.aliyun.datahub.client.model.RecordSchema;
import com.aliyun.datahub.client.model.TupleRecordData;
import com.gwm.utils.ConfigPropUtils;
import org.apache.flink.configuration.Configuration;
import org.apache.flink.streaming.api.functions.sink.RichSinkFunction;
import org.apache.flink.types.Record;
import scala.Tuple4;

import java.util.ArrayList;
import java.util.List;

/**
 * @author yangyingchun
 * @version 1.0
 * @date 2023/2/20 14:00
 */
public class EventOmsSuccessSink extends RichSinkFunction<Tuple4<String, String, String, Long>> {
    // Endpoint以Region: 华东1为例，其他Region请按实际情况填写
    static String endpoint = ConfigPropUtils.get("gwm_datahub_endpoint");
    //private static String endPoint ="public endpoint";//公网访问（填写内网Endpoint，就不用填写公网Endpoint）。
    static String projectName = ConfigPropUtils.get("datahub_sink_projectname");
    static String topicSinkName =  ConfigPropUtils.get("datahub_sink_topic");
    static String accessId = ConfigPropUtils.get("gwm_accessId");
    static String accessKey = ConfigPropUtils.get("gwm_accessKey");
    static DatahubClient datahubClient;
    static RecordSchema recordSchema;
    static int retryTimes = 10;
    @Override
    public void open(Configuration parameters) throws Exception {
        super.open(parameters);
        datahubClient = DatahubClientBuilder.newBuilder()
                .setDatahubConfig(
                        new DatahubConfig(endpoint,
                                // 是否开启二进制传输，服务端2.12版本开始支持
                                new AliyunAccount(accessId, accessKey), true))
                //专有云使用出错尝试将参数设置为           false
                // HttpConfig可不设置，不设置时采用默认值
                .setHttpConfig(new HttpConfig()
                        .setCompressType(HttpConfig.CompressType.LZ4) // 读写数据推荐打开网络传输 LZ4压缩
                        .setConnTimeout(10000))
                .build();
        // 获取schema
        recordSchema = datahubClient.getTopic(projectName,topicSinkName ).getRecordSchema();
    }

    @Override
    public void invoke(Tuple4<String, String, String, Long> record, Context context) throws Exception {
        List<RecordEntry> recordEntries = new ArrayList<>();
        RecordEntry recordEntry = new RecordEntry();
        // 对每条数据设置额外属性，例如ip 机器名等。可以不设置额外属性，不影响数据写入
        recordEntry.addAttribute("key2", "value2");
        TupleRecordData data = new TupleRecordData(recordSchema);
        data.setField("event_name", record._1());
        data.setField("json_message", record._2());
        data.setField("unique_id", record._3());
        data.setField("etl_time", record._4());
        recordEntry.setRecordData(data);
        recordEntries.add(recordEntry);
        datahubClient.putRecords(projectName, topicSinkName, recordEntries);
    }
}

6、工具类

package com.gwm.utils;

import java.io.InputStream;
import java.util.Properties;

public class ConfigPropUtils {
    private static Properties props;
    static{
        try {
            props = new Properties();
            //"config.properties"放在classpath(类路径)下
            InputStream in = ConfigPropUtils.class.getClassLoader().getResourceAsStream("config.properties");
            props.load(in);
        } catch (Exception e) {
            e.printStackTrace();
        }
    }

    //根据配置文件中的key获取value

    public static String get(String key){
        return props.getProperty(key, null);
    }

}

package com.gwm.utils;

import com.aliyun.datahub.client.model.RecordEntry;
import com.aliyun.datahub.client.model.TupleRecordData;

/**
 * @author yangyingchun
 * @version 1.0
 * @date 2022/9/21 17:02
 */
public class getString {
    public static String getString(RecordEntry recordEntry, String field) {
        Object o = ((TupleRecordData)recordEntry.getRecordData()).getField(field);
        if (o == null)
            return "null";
        return o.toString();
    }
}

package com.gwm.utils;

import java.text.ParseException;
import java.text.SimpleDateFormat;
import java.util.Date;

/**
 * @author yangyingchun
 * @version 1.0
 * @date 2021/12/14 15:35
 */
public class TimeToStampUtil {
    public static Long timeToStamp(String timers) {
        Date d = new Date();
        long timeStemp = 0;
        try {
            SimpleDateFormat sf = new SimpleDateFormat("yyyy-MM-dd");
            d = sf.parse(timers);// 日期转换为时间戳
        } catch (ParseException e) {
// TODO Auto-generated catch block
            e.printStackTrace();
        }
        timeStemp = d.getTime();
        return timeStemp;
    }
}

7、配置文件config

gwm_datahub_endpoint=https://datahub.cn-XXXXXX-d01.dh.res.cloud.gwm.cn
datahub_sink_projectname=itsl
datahub_source_topic=event_info
datahub_source_topic1=event_info1
istl.datahub.oms_event=oms_event_info
datahub_scrm_topic=blink_scrm_new_user
datahub_sink_topic=oms_event_info
oneid.datahub_projectname=oneid
oneid.sink_topic_name.warehousing=etl_dts_vms_tt_warehousing_entry
oneid.sink_topic_name.vehicle=etl_dts_vms_tm_vehicle
oneid.accessId=CCxvVNXXXXmBLJEEKuSO
oneid.accessKey=0NMiKPoQTXXXX8OafeKssmUEzN1nahBOc7
gwm_accessId=5jNE06T8SPHXXXXXXleYil
gwm_accessKey=Ehsl9n3xhk0WvXXXXXXXdxCFAaTbm47uHtWQP
gwm_holo_url=jdbc:postgresql://holo-cn-XXXXXX-cn-baoding-gwmcloud-d01-internal.hologres.ops.cloud.gwm.cn:80/itsl_dev?tcpKeepAlive=true
postgresdriver=org.postgresql.Driver
gwm_odps_endpoint=http://service.cn-XXXXXXX-d01.odps.ops.cloud.gwm.cn/api
gwm_odps_project=itsl_dev
gwm_odps_driver=com.aliyun.odps.jdbc.OdpsDriver
gwm_odps_url=jdbc:odps:http://service.cn-XXXXXXX-d01.odps.ops.cloud.gwm.cn/api?project=ITSL_dev&charset=UTF-8&interactiveMode=true



kafka.topic=topic_name
bootstrap.servers=localhost:9092
zookeeper.connect=localhost:2181
group.id001=customer-001


##数仓相关
###############################ODS###############################
ods.datahub_projectname=itsl
ods.datahub_source_topic.event_info=event_info
###############################ODS###############################
###############################DWD###############################
dwd.datahub_projectname=itsl
dwd.datahub_source_topic.datahubsink=datahub_sink
###############################DWD###############################



##测试相关
testfile=E:\\software\\workspace\\blink_udx_3x-master\\src\\main\\resources\\testfile

四、测试运行

五、打包上线

1、打包

因为是BLINK打包是注意将以下两依赖不要打入包里

        <dependency>
            <groupId>com.alibaba.blink</groupId>
            <artifactId>flink-streaming-java_${scala.binary.version}</artifactId>
            <version>${blink.version}</version>
          <scope>provided</scope>
        </dependency>
        <!-- https://mvnrepository.com/artifact/com.alibaba.blink/flink-table-common -->
 <!-- datahub依赖要打入包里，具体获取方式参看：Blink-DataHub connector Maven依赖转化_大数据00的博客-CSDN博客 -->
        <dependency>
            <groupId>com.alibaba.flink</groupId>
            <artifactId>datahub-connector</artifactId>
            <version>0.1-SNAPSHOT</version>
            <classifier>jar-with-dependencies</classifier>
<!--            <scope>provided</scope>-->
        </dependency>
        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>fastjson</artifactId>
            <version>1.2.34</version>
             <scope>provided</scope>
        </dependency>
