Q·1:
No module named 'Rhino' 成功安装但是还有红线说没有包的错误信息
Solution:
只要不影响使用都没关系!!
如果跑不起来可以看看路径,设置 PYTHONPATH
将 Rhino 的 System 文件夹路径添加到 PYTHONPATH 环境变量中:
在 Windows 上:
右键点击 “此电脑” -> “属性” -> “高级系统设置” -> “环境变量”
在 “系统变量” 中找到 PYTHONPATH,如果没有则新建一个
添加 Rhino 的 System 文件夹路径,例如 C:\Program Files\Rhino 7\System
同时检查下环境变量,加上好用。
或者 动态添加 RhinoCommon.dll 路径
在脚本中明确添加路径,并加载 RhinoCommon.dll
确保这个pip install pythonnet是安装成功的
Q2,如何检查python的路径,确保脚本运行目录与python解释器环境一致
which python # 在Unix系统上
where python # 在Windows系统上
import os
print("Current working directory:", os.getcwd())
import sys # 打印Python解释器路径
print("Python interpreter:", sys.executable)
import os # 打印脚本路径
print("Script path:", os.path.abspath(__file__))
# 打印sys.path
print("sys.path:", sys.path)
Q3:Rhino换成小写就不会报错,但是小写无法执行。System, grasshopper.Kernel
都无法引用的问题。
不能用小写,在 PyCharm 中不能直接安装 grasshopper.Kernel
和rhino包,因为不是一个标准的 Python 包,而是属于 Rhino 和 Grasshopper 的 API。为了在 Python 中使用这些 API,需要使用 Rhino 和 Grasshopper 提供的环境,如 RhinoScript 和 Rhino.Inside.如果安装了,卸载掉,安装好rhinoinside再引用加载它。System它是 .NET 框架的一部分
pip install rhinoinside
import rhinoinside
rhinoinside.load()
Q4:pycharm中如何查看当前python 是IronPython 还是CPython
import platform
import sys
def check_python_implementation():
implementation = platform.python_implementation()
if implementation == 'IronPython':
print("Current Python implementation: IronPython")
elif implementation == 'CPython':
print("Current Python implementation: CPython")
else:
print(f"Current Python implementation: {implementation}")
print("Python version:", sys.version)
print("Python executable:", sys.executable)
if __name__ == "__main__":
check_python_implementation()
或者
通过 PyCharm 的 Terminal 检查打开 PyCharm 的 Terminal:
在 PyCharm 界面下方,选择 Terminal 选项卡。
运行 Python 解释器:
在终端中输入 python 或 ipy,并按 Enter 键。
检查版本和实现:
在 Python 解释器的交互式命令行中运行以下命令:
import platform
platform.python_implementation()
Q5:AttributeError: module 'grasshopper' has no attribute 'Instances'
A5:在 Python 中使用 Rhino 和 Grasshopper 的 API,推荐使用 Rhino.Inside
框架,pip安装的包卸载掉,在A4的基础上找到电脑中安装的Grasshopper.dll,路径处理添加
grasshopper_dll_path = r"D:\software\Plug-ins\Grasshopper\Grasshopper.dll" # 确保路径正确
clr.AddReference(grasshopper_dll_path)
Q6: System.InvalidOperationException: DragDrop 注册失败。 ---> System.Threading.ThreadStateException: 在可以调用 OLE 之前,必须将当前线程设置为单线程单元(STA)模式。
A6:
thread = Thread(ThreadStart(runner))
thread.SetApartmentState(ApartmentState.STA) #设置线程为 STA 模式
thread.Start()
thread.Join()
Q7:Grasshopper.dll文件源码怎么看?
A7:Rhino 安装路径和 Grasshopper.dll
文件的位置一般在Rhino 安装目录的 System
文件夹中,没有的话需要去plugin里找。
使用ILSpy查看DLL源码
下载并安装ILSpy或dotPeek。
打开ILSpy或dotPeek。
加载Grasshopper.dll文件(路径通常为C:\Program Files\Rhino 7\Plug-ins\Grasshopper\Grasshopper.dll)
.gha文件也一样,也是.net的包,component源码包,用上面的方式打开。找需。。。
Q8,官方文档地址:调用Grasshopper组件的python开发文档
调用Grasshopper组件的Python开发文档通常涉及使用RhinoCommon和Grasshopper SDK。虽然没有专门针对Python的全面官方文档,但你可以参考以下资源和方法来开发和调用Grasshopper组件:Grasshopper Addons Index | Grasshopper Docs
- RhinoCommon API Documentation:
- RhinoCommon是Rhino的.NET SDK,Grasshopper也基于此。你可以使用Python for .NET(pythonnet)来调用这些API。
- RhinoCommon API Documentation
- Grasshopper SDK Documentation:
- Grasshopper SDK文档提供了有关创建和操作Grasshopper组件的信息。
- Grasshopper SDK Documentation
- Rhino3d instruction
- Rhino Developer Website:
- Rhino开发者网站提供了许多有用的示例、教程和文档。
- Rhino Developer Website
- GhPython:
- GhPython是用于在Grasshopper中编写Python脚本的组件。它使用了RhinoCommon和Grasshopper SDK。
- GhPython Documentation
Q9:搞个跑通的成功案例?
import sys
import clr
import System.Reflection
import rhinoinside
rhinoinside.load()
import System
import os
import Rhino
clr.AddReference("RhinoInside")
clr.AddReference("RhinoCommon")
# 指定 Grasshopper 程序集路径 # 加载 gha 文件与dll 同操作
grasshopper_dll_path = r"D:\software\Plug-ins\Grasshopper\Grasshopper.dll" # 确保路径正确
if not os.path.exists(grasshopper_dll_path):
raise FileNotFoundError(f"无法找到 Grasshopper 程序集: {grasshopper_dll_path}")
try:
# 添加 Grasshopper 程序集引用
clr.AddReference(grasshopper_dll_path)
import Grasshopper
import Grasshopper.Kernel
import Grasshopper.Kernel.Types
import Grasshopper.Kernel.Special as ghs
from Grasshopper.Kernel.Parameters import Param_Number
print("Grasshopper 程序集已成功加载")
except Exception as e:
print(f"加载 Grasshopper 程序集时出错: {e}")
# 测试 Grasshopper.Instances 是否可用
try:
gh_instances = Grasshopper.Instances
print("Grasshopper.Instances 已成功访问")
except Exception as e:
print(f"访问 Grasshopper.Instances 时出错: {e}")
# 加载 Grasshopper 文档并运行
def run_grasshopper_file(gh_file_path):
def runner():
# 初始化 Rhino
Rhino.RhinoApp.Initialized += lambda sender, e: print("Rhino initialized")
# 检查并启动 Grasshopper 插件
gh = Rhino.RhinoApp.GetPlugInObject("Grasshopper")
if gh is None:
print("Grasshopper is not available")
return
# 打开 Grasshopper 文件
if not gh.OpenDocument(gh_file_path):
print("Failed to open Grasshopper document")
return
# 获取当前活跃的 Grasshopper 文档
gh_doc = Grasshopper.Instances.ActiveCanvas.Document
if gh_doc is None:
print("Failed to load Grasshopper document")
return
# 运行 Grasshopper 文档中的所有组件
gh_doc.NewSolution(True)
#print(gh_doc.Objects) #System.Collections.Generic.List`1[Grasshopper.Kernel.IGH_DocumentObject]
print(f"You are opening the file: {gh_doc}") ##test 文件名字
# 获取结果
pass
from System.Threading import Thread, ThreadStart, ApartmentState
thread = Thread(ThreadStart(runner))
thread.SetApartmentState(ApartmentState.STA)
thread.Start()
thread.Join()
if __name__ == "__main__":
gh_file_path = r"D:\urFileFolder\test.gh" # 替换为你的 gh 文件路径
results = run_grasshopper_file(gh_file_path)
print("End of Grasshopper importing test")
