1.引入库
代码如下(示例):
\documentclass{article}
\usepackage{ctex}
% 更多表格设置见 texdoc booktab 三线表
% texdoc longtab 跨越长表格
% texdoc tabu 综合表格宏包
2.正文区
代码如下(示例):
% 正文区
\begin{document}
\begin{table}[h]
\caption{Analysis into the effects of different designs and hyperparameters for our propose model.}
\begin{subtable}[h]{0.45\textwidth}
\centering
\caption{Ablation on design of reconstruction and prediction model.}
\begin{tabular}{ccc}
\toprule
\small{\textbf{Reconstruction Model}} & \small{\textbf{MSE} ($\downarrow$)} \\
\midrule
\small{Pose-VQVAE-joint} & \small{0.0242} \\
\small{Pose-VQVAE-seperate} & \small{\textbf{0.0139}} \\
\hline \hline
\small{\textbf{Prediction Model}} & \small{\textbf{WER} ($\downarrow$)} \\
\midrule
\small{Transformer} & \small{80.36}\\
\small{CodeUnet} & \textbf{\small{78.21}}\\
\bottomrule
\end{tabular}
\label{abl:model_design}
\end{subtable}
\hfill
\begin{subtable}[h]{0.49\textwidth}
\centering
\caption{Ablation on the hyperparameters of training steps and length candidates.}
\begin{tabular}{cc|cc}
\toprule
\makecell[c]{\textbf{Training} \\ \textbf{Steps}} & \textbf{\small{WER}} ($\downarrow$) & \makecell[c]{\textbf{Length} \\\textbf{Candidates}} & \textbf{\small{WER}} ($\downarrow$) \\
\hline
\small{10} & \small{81.06} & \small{1} & \small{79.45}\\
\small{50} & \small{79.31} & \small{2} & \small{78.69}\\
\small{100} & \small{78.21} & \small{3} & \small{78.21}\\
\small{150} & \small{78.17} & \small{4} & \small{78.74}\\
\small{200} & \small{78.15} & \small{Gold} & \small{77.26} \\
\bottomrule
\end{tabular}
\label{abl:timesteps}
\end{subtable}
\label{tab:temps}
\end{table}
\end{document}
