前言

WebScene是符号化的3D地理空间内容，可以用于在直观的交互式3D环境中显示并分析地理信息。相对于传统的Geodatabase或者其他栅格，模型数据而言，更加利于分享和多平台显示。

示例如下：（新版CSDN好像嵌入不了网页了，大家可以自己嵌入在前端展示，或者浏览代码中的链接。）

https://arcg.is/0bbK45

<iframe width="500" height="400" frameborder="0" scrolling="no" allowfullscreen src="<https://arcg.is/0bbK45>"></iframe>

那么它究竟包括哪些内容呢？

从界面来看，大体上包括，Layer，Basemap，Ground，Slides(Presentation)

其实如果想知道更具体的内容，需要看WebScene的spec了。

WebScene spec

链接：https://developers.arcgis.com/web-scene-specification/

里面主要列举了WebScene可以包含的图层格式，底图的定义方法等，如果需要解析WebScene的JSON的话，有一定的参考意义。

operationalLayers

Basemap

关于Basemap的JSON例子：

{
  "baseMap": {
    "baseMapLayers": [
      {
        "id": "World_Imagery_5014",
        "title": "World Imagery",
        "layerType": "ArcGISTiledMapServiceLayer",
        "opacity": 1,
        "visibility": true,
        "url": "http://services.arcgisonline.com/ArcGIS/rest/services/World_Imagery/MapServer"
      },
      {
        "id": "World_Boundaries_and_Places_9730",
        "title": "World Boundaries and Places",
        "layerType": "ArcGISTiledMapServiceLayer",
        "isReference": true,
        "visibility": true,
        "url": "http://services.arcgisonline.com/ArcGIS/rest/services/Reference/World_Boundaries_and_Places/MapServer"
      }
    ],
    "title": "Imagery with Labels"
  }
}

使用ground.layers来表示elevationLayers

Presentation

就是幻灯片和幻灯片的表现了。

举个例子：

{
  "presentation": {
    "slides": [
      {
        "id": "slide_1",
        "title": {
          "text": "Slide 1"
        },
        "thumbnail": {
        },
        "description": {
          "text": "Slide description"
        },
        "baseMap": {
          "id": "basemap_3",
          "title": "Light Gray Canvas",
          "baseMapLayers": [
            {
              "url": "http://services.arcgisonline.com/ArcGIS/rest/services/Canvas/World_Light_Gray_Base/MapServer",
              "layerType": "ArcGISTiledMapServiceLayer",
              "isReference": false,
              "title": "World Light Gray Canvas Base",
              "id": "World_Light_Gray_Base_1486"
            },
            {
              "url": "http://services.arcgisonline.com/ArcGIS/rest/services/Canvas/World_Light_Gray_Reference/MapServer",
              "layerType": "ArcGISTiledMapServiceLayer",
              "isReference": true,
              "title": "World Light Gray Reference",
              "id": "World_Light_Gray_Reference_1486"
            }
          ]
        },
        "viewpoint": {
          "scale": 294288.68889219884,
          "targetGeometry": {
            "xmin": -6699655.673599025,
            "ymin": 2095589.1288518738,
            "xmax": -6233038.83376736,
            "ymax": 2562322.7919495814,
            "spatialReference": {
              "wkid": 102100
            }
          },
          "camera": {
            "position": {
              "x": -6409183.940944876,
              "y": 1696072.3376810949,
              "z": 140179.151083461,
              "spatialReference": {
                "wkid": 102100
              }
            },
            "heading": -11.142703441074717,
            "tilt": 74.27611784201275
          }
        },
        "visibleLayers": [
          {
            "id": "layerSphere"
          }
        ],
        "environment": {
          "lighting": {
            "datetime": 1426420800000,
            "directShadows": true
          }
        }
      }
    ]
  }
}

ArcGIS API for Python中的WebScene

我在这篇文章中介绍了ArcGIS API for Python：我的Python学习笔记(5): ArcGIS API for Python。以下为截图：

在ArcGIS API for Python中，Online和Portal中大部分的对象都属于Item，所以使用通用的content.get(itemId)的方式就可以获取到这个WebScene的对象，然后就可以查询其中的属性和调用API提供的各种方法。
Item本身从dict继承，是从POST请求返回的JSON格式WebScene而构建的:

self.con.post('content/items/' + itemid, self._postdata())

所以可以直接使用字典的方式查询id，extent等各种属性。
下面来进行简单的代码分析：
安装了包之后，可以从这个目录找到代码，我使用的是anaconda，env的名字是py35，所以路径如下，大家可以自行更改查找，或者使用pycharm和F12功能（设置为VS快捷键模式）
C:\Anaconda3\envs\py35\Lib\site-packages\arcgis-1.3.0-py3.5.egg\arcgis\gis\__init__.py

def get(self, itemid):
    """ Returns the item object for the specified itemid.


    =======================    =============================================================
    **Argument**               **Description**
    -----------------------    -------------------------------------------------------------
    itemid                     Required string. The item identifier.
    =======================    =============================================================

    :return:
        The item object if the item is found, None if the item is not found.
    """
    try:
        item = self._portal.get_item(itemid)
    except RuntimeError as re:
        if re.args[0].__contains__("Item does not exist or is inaccessible"):
            return None
        else:
            raise re

    if item is not None:
        return Item(self._gis, itemid, item)
    return None

大致画一个相关类图：

ArcGIS API for JavaScript中的Webscene

具体可以参考：https://developers.arcgis.com/javascript/latest/api-reference/esri-WebScene.html
由于WebScene很多内容都来自于Zurich R&D Center，所以JS API里面对WebScene的描述应该是最全面的了。

使用起来也很简单：

var scene = new WebScene({
  // autocasts as esri/portal/PortalItem
  portalItem: {
    id: "affa021c51944b5694132b2d61fe1057"  // ID of the WebScene on arcgis.com
  }
});

var view = new SceneView({
  map: scene,  // The WebScene instance created above
  container: "viewDiv"
});

scene.when(function() {
  // All layers and the basemap have been created
});
view.when(function() {
  // All layer and basemap resources have been loaded and are ready to be displayed
});

更多细节大家还是慢慢啃官方API-Reference吧。

照例还是画一个简图，就是做参考用，不要在意细节。

WebScene的RESTful服务endpoint

WebScene

POST如下URL来获取json:

https://www.arcgis.com/sharing/rest/content/items/91b46c2b162c48dba264b2190e1dbcff/data?f=json

可以看到数据主要分为，operationalLayers, baseMap, ground三类，展示效果有presentation，里面会引用上面各种图层的id。

SceneService

说到这里，就顺便说下SceneService的内容吧，毕竟是WebScene中最炫的数据格式。

首先，还是要看i3s-spec
https://github.com/Esri/i3s-spec

以这个WebScene为例（新版CSDN好像嵌入不了网页了，大家可以自己嵌入在前端展示，或者浏览代码中的链接。）
