Spring 源码第三弹！EntityResolver 是个什么鬼？

所以我们虽然在 Spring 的 XML 配置中看到的约束文件是一个在线地址，实际上约束文件是从本地 jar 中读取的。

2.两种解析器

---

EntityResolver 就是用来处理 XML 验证的。我们先来看下 EntityResolver 接口的定义：

public interface EntityResolver {

public abstract InputSource resolveEntity (String publicId,

String systemId)

throws SAXException, IOException;

}

接口中就只有一个方法，就是加载约束文件。在 Spring 中，EntityResolver 的实现类是 DelegatingEntityResolver：

public class DelegatingEntityResolver implements EntityResolver {

public static final String DTD_SUFFIX = “.dtd”;

public static final String XSD_SUFFIX = “.xsd”;

private final EntityResolver dtdResolver;

private final EntityResolver schemaResolver;

public DelegatingEntityResolver(@Nullable ClassLoader classLoader) {

this.dtdResolver = new BeansDtdResolver();

this.schemaResolver = new PluggableSchemaResolver(classLoader);

}

public DelegatingEntityResolver(EntityResolver dtdResolver, EntityResolver schemaResolver) {

this.dtdResolver = dtdResolver;

this.schemaResolver = schemaResolver;

}

@Override

@Nullable

public InputSource resolveEntity(@Nullable String publicId, @Nullable String systemId)

throws SAXException, IOException {

if (systemId != null) {

if (systemId.endsWith(DTD_SUFFIX)) {

return this.dtdResolver.resolveEntity(publicId, systemId);

}

else if (systemId.endsWith(XSD_SUFFIX)) {

return this.schemaResolver.resolveEntity(publicId, systemId);

}

}

return null;

}

@Override

public String toString() {

return "EntityResolver delegating " + XSD_SUFFIX + " to " + this.schemaResolver +

" and " + DTD_SUFFIX + " to " + this.dtdResolver;

}

}

在 DelegatingEntityResolver 类中：

1. 首先通过两种不同的后缀来区分不同的约束。

2. 然后定义了 dtdResolver 和 schemaResolver 两个不同的变量，对应的类型分别是 BeansDtdResolver 和 PluggableSchemaResolver，也就是 dtd 和 schema 的约束验证分别由这两个类来处理。

3. 在 resolveEntity 方法中，根据解析出来不同的后缀，分别交由不同的 EntityResolver 来处理。resolveEntity 解析中有两个参数，如果是 dtd 解析的话，publicId 是有值的，如果是 schema 解析，publicId 为 null，而 systemId 则始终指向具体的约束文件。

由于现在大部分都是 schema 约束，所以这里我们就来重点看下 PluggableSchemaResolver 类的实现：

public class PluggableSchemaResolver implements EntityResolver {

public static final String DEFAULT_SCHEMA_MAPPINGS_LOCATION = “META-INF/spring.schemas”;

private static final Log logger = LogFactory.getLog(PluggableSchemaResolver.class);

@Nullable

private final ClassLoader classLoader;

private final String schemaMappingsLocation;

@Nullable

private volatile Map<String, String> schemaMappings;

public PluggableSchemaResolver(@Nullable ClassLoader classLoader) {

this.classLoader = classLoader;

this.schemaMappingsLocation = DEFAULT_SCHEMA_MAPPINGS_LOCATION;

}

public PluggableSchemaResolver(@Nullable ClassLoader classLoader, String schemaMappingsLocation) {

Assert.hasText(schemaMappingsLocation, “‘schemaMappingsLocation’ must not be empty”);

this.classLoader = classLoader;

this.schemaMappingsLocation = schemaMappingsLocation;

}

@Override

@Nullable

public InputSource resolveEntity(@Nullable String publicId, @Nullable String systemId) throws IOException {

if (logger.isTraceEnabled()) {

logger.trace(“Trying to resolve XML entity with public id [” + publicId +

“] and system id [” + systemId + “]”);

}

if (systemId != null) {

String resourceLocation = getSchemaMappings().get(systemId);

if (resourceLocation == null && systemId.startsWith(“https:”)) {

resourceLocation = getSchemaMappings().get(“http:” + systemId.substring(6));

}

if (resourceLocation != null) {

Resource resource = new ClassPathResource(resourceLocation, this.classLoader);

try {

InputSource source = new InputSource(resource.getInputStream());

source.setPublicId(publicId);

source.setSystemId(systemId);

if (logger.isTraceEnabled()) {

logger.trace(“Found XML schema [” + systemId + "] in classpath: " + resourceLocation);

}

return source;

}

catch (FileNotFoundException ex) {

if (logger.isDebugEnabled()) {

logger.debug(“Could not find XML schema [” + systemId + "]: " + resource, ex);

}

}

}

}

return null;

}

private Map<String, String> getSchemaMappings() {

Map<String, String> schemaMappings = this.schemaMappings;

if (schemaMappings == null) {

synchronized (this) {

schemaMappings = this.schemaMappings;

if (schemaMappings == null) {

try {

Properties mappings =

PropertiesLoaderUtils.loadAllProperties(this.schemaMappingsLocation, this.classLoader);

schemaMappings = new ConcurrentHashMap<>(mappings.size());

CollectionUtils.mergePropertiesIntoMap(mappings, schemaMappings);

this.schemaMappings = schemaMappings;

}

catch (IOException ex) {

throw new IllegalStateException(

“Unable to load schema mappings from location [” + this.schemaMappingsLocation + “]”, ex);

}

}

}

}

return schemaMappings;

}

@Override

public String toString() {

return "EntityResolver using schema mappings " + getSchemaMappings();

}

}

1. 在这个类中，一上来先通过 DEFAULT_SCHEMA_MAPPINGS_LOCATION 变量定义了 spring.schemas 文件的位置。

2. getSchemaMappings 方法则是将 spring.schemas 文件中的内容读取成一个 Map 加载进来。

3. 在 resolveEntity 方法中，根据 systemId 找到文件路径，systemId 是 http\://www.springframework.org/schema/beans/spring-beans.xsd 格式，文件路径则是 org/springframework/beans/factory/xml/spring-beans.xsd，如果第一次没有加载到，就把用户的 https: 替换成 http: 再去加载。

4. 有了文件路径，接下来调用 ClassPathResource 去获取一个 Resource 对象，这块可以参考本系列第二篇，这里我就不再赘述。

5. 最后构造一个 InputSource 返回即可。

在上篇文章中，我们获取 EntityResolver 是通过 getEntityResolver 方法来获取的：

protected EntityResolver getEntityResolver() {

if (this.entityResolver == null) {

// Determine default EntityResolver to use.

ResourceLoader resourceLoader = getResourceLoader();

if (resourceLoader != null) {

this.entityResolver = new ResourceEntityResolver(resourceLoader);

}

else {

this.entityResolver = new DelegatingEntityResolver(getBeanClassLoader());

}

}

return this.entityResolver;

}

这里最终返回的是 ResourceEntityResolver，ResourceEntityResolver 继承自 DelegatingEntityResolver，当调用 resolveEntity 方法时，也是先调用父类的该方法，进行处理，如果父类方法处理成功了，就直接返回父类方法给出的结果，如果父类方法处理失败了，则在 ResourceEntityResolver 中通过资源的相对路径再次尝试加载。

3.小结

---

好啦，经过上面的介绍，相信大家对于 XMl 约束和 EntityResolver 都有一定的了解啦。
