5SHY4045L0004 IGCT Power Semiconductor Module

https://www.electricalplc.com/.../5shy4045l0004-igct.../

Product Overview

Brand: ABB

Part Number: 5SHY4045L0004

Type: IGCT Power Semiconductor Module (Integrated Gate-Commutated Thyristor)

Function: High-power switching device for medium-voltage drives and converters

The ABB 5SHY4045L0004 is a high-performance IGCT (Integrated Gate-Commutated Thyristor) module designed for efficient and reliable control of high-power electrical systems. It combines the high-power handling capability of a thyristor with the fast turn-off performance of a transistor, making it suitable for demanding industrial applications.

Key Features and Functions

High Power Handling

Supports very high current and voltage ratings

Capable of switching large electrical loads with minimal losses

Suitable for medium-voltage and high-power converters

Fast Switching

Rapid turn-on and turn-off capability

Low switching losses compared to traditional thyristors

Allows high-frequency operation in industrial systems

Robust and Reliable

Designed for long operational life under heavy electrical and thermal stress

High thermal cycling capability and low thermal resistance

Suitable for continuous operation in harsh industrial environments

Integrated Gate Unit Compatibility

Works with ABB gate drive units for precise switching control

Ensures synchronized and reliable turn-on/turn-off operation

Typical Technical Parameters*

(*Values may vary depending on exact production batch and application)

Parameter Typical Value

Device Type IGCT (Integrated Gate-Commutated Thyristor)

Voltage Class Up to several kV

Current Rating High-current operation

Cooling Method Liquid or air-cooled (application dependent)

Mounting Press-pack type

Gate Drive Compatible with ABB gate units

Operating Temperature –40°C to +125°C

Applications

Medium-Voltage Drives

For speed and torque control of large motors in heavy industry

High-Power Converters

Used in HVDC (High Voltage Direct Current) transmission systems

Static VAR Compensators (SVC)

For reactive power compensation in power grids

Pulp & Paper, Mining, and Steel Industries

Drives and converters for heavy machinery

Renewable Energy Systems

Power conversion in wind and hydroelectric plants
