简介
🅰️-Frame 是一个用来构建虚拟现实(VR)应用的网页开发框架。由WebVR的发起人Mozilla VR 团队所开发,是当下用来开发WebVR内容主流技术方案。WebVR是一个完全开源的项目,已成长为领先的VR社区。
A-Frame基于HTML,容易上手。但是A-Frame不仅仅是一个3D场景渲染引擎或者一个标记语言。其核心思想是基于Three.js来提供一个声明式、可扩展以及组件化的编程结构。
A-Frame支持主流VR头显如Vive, Rift, Daydream, GearVR,
Cardboard, 甚至可被用于增强现实(AR)。虽然A-Frame支持全谱,A-Frame的目标是定义具有位置跟踪和操控的完全身临其境和交互式VR体验,超出基本的360° 内容呈现。Mozilla VR团队正在使用A-Frame构建虚拟实境(Metaverse)项目的基础。
Metaverse由meta和verse组成,meta表示超越,verse表示现实世界,合起来就寓意超现实,技术上是VR、AR和移动互联网的融合。
教程
<html>
<head>
<script src="https://aframe.io/releases/1.1.0/aframe.min.js"></script>
</head>
<body>
<a-scene>
<!-- 资源管理系统
资产管理系统使浏览器缓存资源更容易(例如,图像,视频,模型),并且A-Frame框架将确保所有的资源都在渲染之前被获取到。
需要使用在线资源,可能会出现资源跨域
-->
<a-assets>
<img src="./images/ETH.png" id="box-bg">
<img src="./images/background.webp" id="sky-bg">
<img id="groundTexture" src="https://cdn.aframe.io/a-painter/images/floor.jpg">
<audio id="audio" src="https://cdn.aframe.io/basic-guide/audio/backgroundnoise.wav" autoplay
preload></audio>
</a-assets>
<!-- color="#4CC3D9" -->
<a-box src="#sky-bg" position="0 2 -5" rotation="0 45 45" scale="1 1 1"
animation__position="property: object3D.position.y; to: 2.2; dir: alternate; dur: 1500; loop: true">
</a-box>
<!-- 设置地面 (repeat)格子化效果 -->
<a-plane rotation="-90 0 0" width="30" height="30" src="#groundTexture" repeat="10 10"></a-plane>
<!-- 背景颜色 -->
<a-sky src="#sky-bg"></a-sky>
<!-- 光源 -->
<a-light type="ambient" color="#445451"></a-light>
<a-light type="point" intensity="2" position="2 4 4"></a-light>
<!-- 音频 -->
<a-sound src="#audio" autoplay="true" position="-3 1 -4"></a-sound>
<!-- <a-text value="Hello, A-Frame!" color="#BBB"
position="-0.9 0.2 -3"></a-text> -->
<a-camera>
<a-cursor></a-cursor>
</a-camera>
</a-scene>
</body>
</html>
