1 简介

Smart Blur（智能模糊） 是一种基于边缘检测的图像滤波算法，能够在平滑图像的同时保留边缘信息。与传统的模糊算法（如高斯模糊）不同，Smart Blur 通过检测图像中的边缘区域，并在这些区域减少模糊强度，从而在平滑图像的同时更好地保留边缘和细节。

Smart Blur 广泛应用于图像去噪、图像增强和艺术效果处理等领域。

2 算法原理

Smart Blur 的核心思想是结合边缘检测和模糊滤波，根据图像的边缘信息动态调整模糊强度。具体步骤如下：

边缘检测：
1. 使用边缘检测算法（如 Sobel 或 Canny）检测图像中的边缘区域。
2. 生成边缘掩码（Edge Mask），标记边缘区域。
模糊滤波：
1. 对图像进行模糊滤波（如高斯模糊）。
2. 根据边缘掩码调整模糊强度：在边缘区域减少模糊强度，在非边缘区域增加模糊强度。
图像融合：
1. 将模糊后的图像与原始图像根据边缘掩码进行融合，得到最终结果。

3 代码实现

Smart Blur滤波的C语言代码实现如下

int SmartBlurOneChannel(unsigned char* srcData, int width, int height, int radius, int threshold)
{
        int len = sizeof(unsigned long) * width * height;
        int i, j;
        int gray = 0;
        unsigned char* tempData = (unsigned char*)malloc(sizeof(unsigned char) * height * width);
        memcpy(tempData, srcData, sizeof(unsigned char) * height * width);
        for (j = 0; j < height; j++)
        {
                for (i = 0; i < width; i++)
                {
                        len = i + j * width;
                        gray = tempData[len];
                        int low = CLIP3(gray - threshold, 0, 255);
                        int high = CLIP3(gray + threshold, 0, 255);
                        int sum = 0;
                        int count = 0;
                        for (int n = -radius; n <= radius; n++)
                        {
                                for (int m = -radius; m <= radius; m++)
                                {
                                        int x = CLIP3(i + m, 0, width - 1);
                                        int y = CLIP3(j + n, 0, height - 1);
                                        int pos = x + y * width;
                                        gray = tempData[pos];
                                        if (gray > low && gray < high)
                                        {
                                                sum += gray;
                                                count++;
                                        }
                                }
                        }
                        gray = count == 0 ? srcData[len] : sum / count;//sum / MAX2(count, 1);
                        srcData[len] = CLIP3(gray, 0, 255);
                }
        }
        free(tempData);
        return 0;
};

int mxSmartBlur(unsigned char* srcData, int nWidth, int nHeight, int nStride, int radius, int threshold)
{
        int ret = 0;
        if (srcData == NULL)
        {
                return ret;
        }
        if (radius == 0 || threshold == 0)
                return ret;
        unsigned char* yData = (unsigned char*)malloc(sizeof(unsigned char) * nWidth * nHeight);
        unsigned char* cbData = (unsigned char*)malloc(sizeof(unsigned char) * nWidth * nHeight);
        unsigned char* crData = (unsigned char*)malloc(sizeof(unsigned char) * nWidth * nHeight);
        unsigned char* pSrc = srcData;
        int Y, CB, CR;
        unsigned char* pY = yData;
        unsigned char* pCb = cbData;
        unsigned char* pCr = crData;
        for (int j = 0; j < nHeight; j++)
        {
                for (int i = 0; i < nWidth; i++)
                {
                        RGBToYCbCr(pSrc[2], pSrc[1], pSrc[0], &Y, &CB, &CR);
                        *pY = Y;
                        *pCb = CB;
                        *pCr = CR;
                        pY++;
                        pCb++;
                        pCr++;
                        pSrc += 4;
                }
        }
        SmartBlurOneChannel(yData, nWidth, nHeight, radius, threshold);
        pSrc = srcData;
        pY = yData;
        pCb = cbData;
        pCr = crData;
        int R, G, B;
        for (int j = 0; j < nHeight; j++)
        {
                for (int i = 0; i < nWidth; i++)
                {
                        YCbCrToRGB(*pY, *pCb, *pCr, &R, &G, &B);
                        pSrc[0] = B;
                        pSrc[1] = G;
                        pSrc[2] = R;
                        pY++;
                        pCb++;
                        pCr++;
                        pSrc += 4;
                }
        }
        free(yData);
        free(cbData);
        free(crData);
        return ret;
}
