Blockly 版本选择
在【兰州大学】Blockly创意趣味编程【全36讲】主讲教师：崔向平 周庆国中提到，在18年6月份之前的版本中，可以通过安装依赖库的方式，打开开发者工具的离线版本，但是新版本的Blockly移除了部分离线的依赖文件。
在Github仓库上，对于18年6月份之前的版本，我只找到了2017.10.23的版本是相对较新的blockly-update-20171023，可配套Closure Library v20180405使用开发者工具
但是这个版本的Blocks是有问题的：
这里搜集存档了一份整合修改过的版本：Blockly积木编程离线整合包
上手
参考 Blockly 中文文档 及 ./blockly/demos/code/index.html 文件，建立自己的工程文件demo.html
<!DOCTYPE html>
<html>
<head>
<meta charset="UTF-8">
<title>Title</title>
<script src="./blockly/blockly_compressed.js"></script>
<script src="./blockly/blocks_compressed.js"></script>
<script src="./blockly/python_compressed.js"></script>
<script src="./blockly/msg/js/zh-hans.js"></script>
<script src="./blockly/demos/code/msg/zh-hans.js"></script>
<script>
// category 栏翻译
for (var messageKey in MSG)
{
if (messageKey.indexOf('cat') == 0)
{
Blockly.Msg[messageKey.toUpperCase()] = MSG[messageKey];
}
}
</script>
<style>
html, body
{
height: 100%;
}
.content
{
visibility: hidden;
margin: 0;
padding: 1ex;
position: absolute;
direction: ltr;
}
</style>
</head>
<body>
<div id="blocklyDiv" style="height: 100%;"></div>
<xml id="toolbox" style="display: none">
<category name="%{BKY_CATLOGIC}" colour="%{BKY_LOGIC_HUE}">
<block type="controls_if"></block>
<block type="logic_compare"></block>
<block type="logic_operation"></block>
<block type="logic_negate"></block>
<block type="logic_boolean"></block>
<block type="logic_null"></block>
<block type="logic_ternary"></block>
</category>
<category name="%{BKY_CATLOOPS}" colour="%{BKY_LOOPS_HUE}">
<block type="controls_repeat_ext">
<value name="TIMES">
<shadow type="math_number">
<field name="NUM">10</field>
</shadow>
</value>
</block>
<block type="controls_whileUntil"></block>
<block type="controls_for">
<value name="FROM">
<shadow type="math_number">
<field name="NUM">1</field>
</shadow>
</value>
<value name="TO">
<shadow type="math_number">
<field name="NUM">10</field>
</shadow>
</value>
<value name="BY">
<shadow type="math_number">
<field name="NUM">1</field>
</shadow>
</value>
</block>
<block type="controls_forEach"></block>
<block type="controls_flow_statements"></block>
</category>
<category name="%{BKY_CATMATH}" colour="%{BKY_MATH_HUE}">
<block type="math_number"></block>
<block type="math_arithmetic">
<value name="A">
<shadow type="math_number">
<field name="NUM">1</field>
</shadow>
</value>
<value name="B">
<shadow type="math_number">
<field name="NUM">1</field>
</shadow>
</value>
</block>
<block type="math_single">
<value name="NUM">
<shadow type="math_number">
<field name="NUM">9</field>
</shadow>
</value>
</block>
<block type="math_trig">
<value name="NUM">
<shadow type="math_number">
<field name="NUM">45</field>
</shadow>
</value>
</block>
<block type="math_constant"></block>
<block type="math_number_property">
<value name="NUMBER_TO_CHECK">
<shadow type="math_number">
<field name="NUM">0</field>
</shadow>
</value>
</block>
<block type="math_round">
<value name="NUM">
<shadow type="math_number">
<field name="NUM">3.1</field>
</shadow>
</value>
</block>
<block type="math_on_list"></block>
<block type="math_modulo">
<value name="DIVIDEND">
<shadow type="math_number">
<field name="NUM">64</field>
</shadow>
</value>
<value name="DIVISOR">
<shadow type="math_number">
<field name="NUM">10</field>
</shadow>
</value>
</block>
<block type="math_constrain">
<value name="VALUE">
<shadow type="math_number">
<field name="NUM">50</field>
</shadow>
</value>
<value name="LOW">
<shadow type="math_number">
<field name="NUM">1</field>
</shadow>
</value>
<value name="HIGH">
<shadow type="math_number">
<field name="NUM">100</field>
</shadow>
</value>
</block>
<block type="math_random_int">
<value name="FROM">
<shadow type="math_number">
<field name="NUM">1</field>
</shadow>
</value>
<value name="TO">
<shadow type="math_number">
<field name="NUM">100</field>
</shadow>
</value>
</block>
<block type="math_random_float"></block>
</category>
<category name="%{BKY_CATTEXT}" colour="%{BKY_TEXTS_HUE}">
<block type="text"></block>
<block type="text_join"></block>
<block type="text_append">
<value name="TEXT">
<shadow type="text"></shadow>
</value>
</block>
<block type="text_length">
<value name="VALUE">
<shadow type="text">
<field name="TEXT">abc</field>
</shadow>
</value>
</block>
<block type="text_isEmpty">
<value name="VALUE">
<shadow type="text">
<field name="TEXT"></field>
</shadow>
</value>
</block>
<block type="text_indexOf">
<value name="VALUE">
<block type="variables_get">
<field name="VAR">{textVariable}</field>
</block>
</value>
<value name="FIND">
<shadow type="text">
<field name="TEXT">abc</field>
</shadow>
</value>
</block>
<block type="text_charAt">
<value name="VALUE">
<block type="variables_get">
<field name="VAR">{textVariable}</field>
</block>
</value>
</block>
<block type="text_getSubstring">
<value name="STRING">
<block type="variables_get">
<field name="VAR">{textVariable}</field>
</block>
</value>
</block>
<block type="text_changeCase">
<value name="TEXT">
<shadow type="text">
<field name="TEXT">abc</field>
</shadow>
</value>
</block>
<block type="text_trim">
<value name="TEXT">
<shadow type="text">
<field name="TEXT">abc</field>
</shadow>
</value>
</block>
<block type="text_print">
<value name="TEXT">
<shadow type="text">
<field name="TEXT">abc</field>
</shadow>
</value>
</block>
<block type="text_prompt_ext">
<value name="TEXT">
<shadow type="text">
<field name="TEXT">abc</field>
</shadow>
</value>
</block>
</category>
<category name="%{BKY_CATLISTS}" colour="%{BKY_LISTS_HUE}">
<block type="lists_create_with">
<mutation items="0"></mutation>
</block>
<block type="lists_create_with"></block>
<block type="lists_repeat">
<value name="NUM">
<shadow type="math_number">
<field name="NUM">5</field>
</shadow>
</value>
</block>
<block type="lists_length"></block>
<block type="lists_isEmpty"></block>
<block type="lists_indexOf">
<value name="VALUE">
<block type="variables_get">
<field name="VAR">{listVariable}</field>
</block>
</value>
</block>
<block type="lists_getIndex">
<value name="VALUE">
<block type="variables_get">
<field name="VAR">{listVariable}</field>
</block>
</value>
</block>
<block type="lists_setIndex">
<value name="LIST">
<block type="variables_get">
<field name="VAR">{listVariable}</field>
</block>
</value>
</block>
<block type="lists_getSublist">
<value name="LIST">
<block type="variables_get">
<field name="VAR">{listVariable}</field>
</block>
</value>
</block>
<block type="lists_split">
<value name="DELIM">
<shadow type="text">
<field name="TEXT">,</field>
</shadow>
</value>
</block>
<block type="lists_sort"></block>
</category>
<category name="%{BKY_CATCOLOUR}" colour="%{BKY_COLOUR_HUE}">
<block type="colour_picker"></block>
<block type="colour_random"></block>
<block type="colour_rgb">
<value name="RED">
<shadow type="math_number">
<field name="NUM">100</field>
</shadow>
</value>
<value name="GREEN">
<shadow type="math_number">
<field name="NUM">50</field>
</shadow>
</value>
<value name="BLUE">
<shadow type="math_number">
<field name="NUM">0</field>
</shadow>
</value>
</block>
<block type="colour_blend">
<value name="COLOUR1">
<shadow type="colour_picker">
<field name="COLOUR">#ff0000</field>
</shadow>
</value>
<value name="COLOUR2">
<shadow type="colour_picker">
<field name="COLOUR">#3333ff</field>
</shadow>
</value>
<value name="RATIO">
<shadow type="math_number">
<field name="NUM">0.5</field>
</shadow>
</value>
</block>
</category>
<sep></sep>
<category name="%{BKY_CATVARIABLES}" colour="%{BKY_VARIABLES_HUE}" custom="VARIABLE"></category>
<category name="%{BKY_CATFUNCTIONS}" colour="%{BKY_PROCEDURES_HUE}" custom="PROCEDURE"></category>
</xml>
</body>
<script>
// Construct the toolbox XML, replacing translated variable names.
// 构建 toolbox XML，替换翻译后的变量名。
var toolboxText = document.getElementById('toolbox').outerHTML;
toolboxText = toolboxText.replace(/(^|[^%]){(\w+)}/g,
function(m, p1, p2) {return p1 + MSG[p2];});
var toolboxXml = Blockly.Xml.textToDom(toolboxText);
var workspace = Blockly.inject(
'blocklyDiv',
{
toolbox: toolboxXml,
grid: // 栅格
{
spacing: 20,
length: 3,
colour: '#ccc',
snap: true
},
move: // 移动
{
scrollbars:
{
horizontal: true,
vertical: true
},
drag: true,
wheel: false
},
zoom: // 缩放
{
controls: true,
wheel: true,
startScale: 1.0,
maxScale: 3,
minScale: 0.3,
scaleSpeed: 1.2
},
media: './blockly/media/', // 图标及音效
trashcan: true
}
);
</script>
</html>
