3 slot packets 5 slot packets Encryption Slot offset Timing accuracy Role switch Hold mode Sniff mode
0 0 0 0 0 0 0 0
0 1 2 3 4 5 6 7
8 9 10 11 12 13 14 15
Park state Power control requests Channel quality driven data rate (CQDDR) SCO link HV2 packets HV3 packets ì-law log synchronous data A-law log synchronous data
1 1 1 1 1 1 1 1
0 1 2 3 4 5 6 7
16 17 18 19 20 21 22 23
CVSD synchronous data Paging parameter negotiation Power control Transparent synchronous data Flow control lag (least significant bit) Flow control lag (middle bit) Flow control lag (most significant bit) Broadcast Encryption
2 2 2 2 2 2 2 2
0 1 2 3 4 5 6 7
24 25
Reserved Enhanced Data Rate ACL 2 Mb/s mode
3 3
26 27 28 29 30 31
Enhanced Data Rate ACL 3 Mb/s mode Enhanced inquiry scan Interlaced inquiry scan Interlaced page scan RSSI with inquiry results Extended SCO link (EV3 packets)
3 3 3 3 3 3
2 3 4 5 6 7
32 33 34 35 36 37 38 39
EV4 packets EV5 packets Reserved AFH capable slave AFH classification slave BR/EDR Not Supported LE Supported (Controller) 3-slot Enhanced Data Rate ACL packets
4 4 4 4 4 4 4 4
0 1 2 3 4 5 6 7
40 41 42 43 44 45 46 47
5-slot Enhanced Data Rate ACL packets Sniff subrating Pause encryption AFH capable master AFH classification master Enhanced Data Rate eSCO 2 Mb/s mode Enhanced Data Rate eSCO 3 Mb/s mode 3-slot Enhanced Data Rate eSCO packets
5 5 5 5 5 5 5 5
0 1 2 3 4 5 6 7
48 49 50 51 52 53 54 55
Extended Inquiry Response Simultaneous LE and BR/EDR to Same Device Capable Reserved Secure Simple Pairing Encapsulated PDU Erroneous Data Reporting Non-flushable Packet Boundary Flag Reserved
6 6 6 6 6 6 6 6
0 1 2 3 4 5 6 7
56
Link Supervision Timeout Changed Event
7
0
57 58 59 60 61 62 63
Inquiry TX Power Level Enhanced Power Control Reserved Reserved Reserved Reserved Extended features
