threejs学习002-场景中添加几何体

<template>
	<div id="webgl" class="webgl"></div>

	<div id="toolbar" class="nameButton">
		<el-breadcrumb>
			<el-breadcrumb-item>创建3D场景</el-breadcrumb-item>
		</el-breadcrumb>
	</div>
</template>
<script setup>
import * as THREE from 'three';
import {getCurrentInstance, onMounted} from 'vue';
// 引入轨道控制器扩展库OrbitControls.js
import {OrbitControls} from 'three/addons/controls/OrbitControls.js';

const {proxy} = getCurrentInstance();

let scene = undefined;
let renderer = undefined;
let camera = undefined;

onMounted(() => {
	// 创建场景
	scene = new THREE.Scene();

	const axesHelper = new THREE.AxesHelper(1000);//设置坐标轴线段尺寸
	scene.add(axesHelper);

	// 创建几何体
	// const geometry = new THREE.BoxGeometry(100, 100, 100);
	// 这个立方体的每一个面都是有两个三角形组成的，如果我们把widthSegments 的值设置为2
	// 我们发现，在宽度方向上，立方体从宽度的中间被一分为二了，这就是分段数的意思。如果设置为3，则在宽度方向上被一分为三
	const geometry = new THREE.BoxGeometry(100, 100, 100, 2);
	// 材质
	const material = new THREE.MeshBasicMaterial({
		color: 0x0000ff,
		/* transparent: true,//开启透明
		opacity: 0.5,//设置透明度 */
		wireframe: true,//线条模式渲染mesh对应的三角形数据
	});
	// 模型
	const boxMesh = new THREE.Mesh(geometry, material);
	// 模型位置
	boxMesh.position.set(100, 100, 100);
	// 将模型 添加到 场景
	scene.add(boxMesh);

	// 圆形几何体
	// CircleGeometry接收四个参数，各参数定义如下
	// radius — 圆形的半径，默认值为1
	// segments — 分段（三角面）的数量，最小值为3，默认值为8。
	// thetaStart — 第一个分段的起始角度，默认为0。（three o’clock position）
	// thetaLength — 圆形扇区的中心角，通常被称为“θ”（西塔）。默认值是2*Pi，这使其成为一个完整的圆。
	const circleGeometry = new THREE.CircleGeometry(40, 22);
	const circleMaterial = new THREE.MeshLambertMaterial({
		color: 0x00ffff,//设置颜色
		wireframe: true,
	})
	const circleMesh = new THREE.Mesh(circleGeometry, circleMaterial);
	circleMesh.position.set(200, 0, 0);
	scene.add(circleMesh);

	// 创建圆锥缓冲几何体
	const coneGeometry = new THREE.ConeGeometry(50, 50, 32);
	const coneMaterial = new THREE.MeshLambertMaterial({
		color: 0x00ffff,//设置颜色
		// wireframe:true,//线条模式渲染mesh对应的三角形数据
	})
	const coneMesh = new THREE.Mesh(coneGeometry, coneMaterial)
	coneMesh.position.set(300, 0, 0);
	scene.add(coneMesh);

	// 圆柱
	const cylinderGeometry = new THREE.CylinderGeometry(40, 40, 100, 32);
	const cylinderMaterial = new THREE.MeshLambertMaterial({
		color: 0x00ffff,//设置颜色
	})
	const cylinderMesh = new THREE.Mesh(cylinderGeometry, cylinderMaterial)
	cylinderMesh.position.set(400, 0, 0);
	scene.add(cylinderMesh);

	// 边缘几何体
	const geometry1 = new THREE.CylinderGeometry(40, 40, 100, 32);
	const edges = new THREE.EdgesGeometry(geometry1);
	const line = new THREE.LineSegments(edges, new THREE.LineBasicMaterial({color: 0xffffff}));
	const material1 = new THREE.MeshLambertMaterial({
		color: 0x000fff,//设置颜色
	})
	const mesh1 = new THREE.Mesh(geometry1, material1)
	line.position.set(500, 0, 0);
	scene.add(line)
	mesh1.position.set(500, 0, 0);
	scene.add(mesh1)

	// 平面缓冲几何体
	const geometry2 = new THREE.PlaneGeometry(50, 50);
	const material2 = new THREE.MeshLambertMaterial({
		color: 0x00ffff,//设置颜色
	})
	const mesh2 = new THREE.Mesh(geometry2, material2)
	mesh2.position.set(600, 0, 0);
	scene.add(mesh2)

	// 球体
	const geometry3 = new THREE.SphereGeometry(50, 12, 16);
	const material3 = new THREE.MeshLambertMaterial({
		color: 0x00ffff,//设置颜色
		wireframe: true,
	})
	const mesh3 = new THREE.Mesh(geometry3, material3)
	mesh3.position.set(0, 0, 200);
	scene.add(mesh3)

	// 圆环
	const geometry4 = new THREE.TorusGeometry(100, 30, 16, 100);
	const material4 = new THREE.MeshLambertMaterial({
		color: 0x00ffff,//设置颜色
		wireframe: true,
	})
	const mesh4 = new THREE.Mesh(geometry4, material4)
	mesh4.position.set(0, 0, 400);
	scene.add(mesh4)

	// 聚光灯源
	const directionalLight = new THREE.SpotLight(0xffffff, 1, 100);
	directionalLight.position.set(100, 100, 100);
	const dirLightHelper = new THREE.DirectionalLightHelper(directionalLight, 5, 0xff0000);
	scene.add(dirLightHelper);

	// 创建相机  透视投影相机的四个参数fov, aspect, near, far构成一个四棱台3D空间，被称为视锥体，只有视锥体之内的物体，才会渲染出来，视锥体范围之外的物体不会显示在Canvas画布上。
	camera = new THREE.PerspectiveCamera(75, window.innerWidth / window.innerHeight, 30, 1000);

	//相机在Three.js三维坐标系中的位置
	// 根据需要设置相机位置具体值
	camera.position.set(300, 300, 500);
	camera.lookAt(boxMesh.position);//指向mesh对应的位置

	// 创建渲染器对象
	renderer = new THREE.WebGLRenderer({antialias: true, alpha: true});
	renderer.setClearAlpha(0);
	// 定义threejs输出画布的尺寸(单位:像素px)
	const width = window.innerWidth - 210; //宽度
	const height = window.innerHeight - 61; //高度
	renderer.setSize(width, height); //设置three.js渲染区域的尺寸(像素px)
	renderer.render(scene, camera); //执行渲染操作

	document.getElementById('webgl').appendChild(renderer.domElement);
})

</script>
<style>
.webgl {
	margin: 0;
}

.nameButton {
	position: fixed;
	top: 70px;
	left: 220px;
}
</style>
