MCU+FPGA+SDRM Device brief

AG16K PSoC

(MCU+FPGA+SDRAM) device

AG16K PSoC is AG16K(MCU) PSoC bonded with 64MBit 32-bit 166MHz SDRAM die . EQFP-176 and FBGA-256 package is provided as industrial grade, E176 package is pin-to-pin compatible with AG10KSDE176(MCU).

FPGA logic fabric is embedded within MCU hard-IP system, and all mcu internal IOs are connectable to device’s IO pad, and/or internal FPGA’s logic as user demands. MCU core, with usable code space up to 128 KByte RAM, is programmable through spiflash, and JTAG for testing purposes.

（MCU+FPGA+SDRAM）器件

AG16K PSoC是AG16K（MCU）PSoC与64MBit 32位166MHz SDRAM邦定组合。EQFP-176 和 FBGA-256封装作为工业级封装提供，E176 封装引脚对引脚兼容 AG10KSDE176（MCU）。

FPGA逻辑结构嵌入在MCU硬IP系统中，所有mcu内部IO都可连接到器件的IO板，跟内部FPGA的逻辑按与门/或门相连，以满足用户的需求。MCU 内核具有高达 128 KByte RAM 的可用代码空间，可通过 SPI Flash 和 JTAG 进行编程。

更多详情及技术资料，欢迎联系：kh_hsiah@126.com 或者 扫码查询：
