森林结构及转化后的二叉树结构如图所示:
代码如下:
#ifndef _TREE_H
#define _TREE_H
#include <iostream>
using namespace std;
template <typename T>
class Tree;
template <typename T>
class TreeNode{
friend class Tree<T>;
public:
TreeNode() :m_data(T()), firstChild(NULL), nextSibling(NULL)
{}
TreeNode(T data) :m_data(data), firstChild(NULL), nextSibling(NULL)
{}
private:
T m_data;
TreeNode<T> *firstChild;
TreeNode<T> *nextSibling;
};
template <typename T>
class Tree{
typedef TreeNode<T> node_type;
public:
Tree() = default;
Tree(T ref) :refval(ref), root(NULL)
{}
public:
void init_tree(const char* str);
void preorder_traverse()const;
int Size()const;
int Height()const;
node_type* Root()const;
node_type* Find(const T&)const;
node_type* Parent(node_type *)const;
bool is_empty()const;
protected:
void init_tree(node_type *&, const char *&);
void preorder_traverse(node_type *)const;
int Size(node_type *)const;
int Height(node_type *)const;
node_type* Find(node_type *, const T&)const;
node_type* Parent(node_type *, node_type *)const;
private:
node_type *root;
T refval;
};
//public interface
template <typename T>
void Tree<T>::init_tree(const char* str)
{
init_tree(root, str);
}
template <typename T>
void Tree<T>::preorder_traverse()const
{
preorder_traverse(root);
}
template <typename T>
int Tree<T>::Size()const
{
return Size(root);
}
template <typename T>
int Tree<T>::Height()const
{
return Height(root);
}
template <typename T>
TreeNode<T>* Tree<T>::Root()const
{
return root;
}
template <typename T>
TreeNode<T>* Tree<T>::Find(const T& val)const
{
return Find(root, val);
}
template <typename T>
TreeNode<T>* Tree<T>::Parent(node_type *cur)const
{
return Parent(root, cur);
}
template <typename T>
bool Tree<T>::is_empty()const
{
return root == NULL;
}
//protected interface
template <typename T>
void Tree<T>::init_tree(node_type *&t, const char *&str)
{
if(*str == refval){
t = NULL;
return ;
}
else{
t = new node_type(*str);
init_tree(t->firstChild, ++str);
init_tree(t->nextSibling, ++str);
}
}
template <typename T>
void Tree<T>::preorder_traverse(node_type *t)const
{
if(t == NULL)
return ;
cout << t->m_data << " ";
preorder_traverse(t->firstChild);
preorder_traverse(t->nextSibling);
}
template <typename T>
int Tree<T>::Size(node_type *t)const
{
if(t == NULL)
return 0;
else
return 1 + Size(t->firstChild) + Size(t->nextSibling);
}
template <typename T>
int Tree<T>::Height(node_type *t)const
{
if(t == NULL)
return 0;
if(t->firstChild == NULL)
return 1;
int m_current;
int max = 0;
auto tmp = t->firstChild;
while(tmp != NULL){
m_current = Height(tmp);
if(m_current > max)
max = m_current;
tmp = tmp->nextSibling;
}
return max + 1;
}
template <typename T>
TreeNode<T>* Tree<T>::Find(node_type *t, const T& val)const
{
if(t == NULL)
return NULL;
if(t->m_data == val)
return t;
auto tmp = Find(t->firstChild, val);
if(tmp == NULL)
tmp = Find(t->nextSibling, val);
return tmp;
}
template <typename T>
TreeNode<T>* Tree<T>::Parent(node_type *t, node_type *cur)const
{
if(t == NULL || cur == NULL || t == cur)
return NULL;
if(t->firstChild == cur)
return t;
auto p = t->firstChild;
while(p != NULL && p != cur){
auto tmp = Parent(p, cur);
if(tmp != NULL)
return tmp;
p = p->nextSibling;
}
if(p != NULL && p == cur)
return t;
else
return NULL;
}
#endif
