FCOS 并没有使用RPN来回归边界框，而是采用逐像素的方法来回归边界框，只不过这部分的代码名称依然是RPN而以。下面打印了这部分的网络结构。
FCOSModule(
(head): FCOSHead(
(cls_tower): Sequential(
(0): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1))
(1): GroupNorm(32, 256, eps=1e-05, affine=True)
(2): ReLU()
(3): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1))
(4): GroupNorm(32, 256, eps=1e-05, affine=True)
(5): ReLU()
(6): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1))
(7): GroupNorm(32, 256, eps=1e-05, affine=True)
(8): ReLU()
(9): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1))
(10): GroupNorm(32, 256, eps=1e-05, affine=True)
(11): ReLU()
)
(bbox_tower): Sequential(
(0): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1))
(1): GroupNorm(32, 256, eps=1e-05, affine=True)
(2): ReLU()
(3): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1))
(4): GroupNorm(32, 256, eps=1e-05, affine=True)
(5): ReLU()
(6): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1))
(7): GroupNorm(32, 256, eps=1e-05, affine=True)
(8): ReLU()
(9): Conv2d(256, 256, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1))
(10): GroupNorm(32, 256, eps=1e-05, affine=True)
(11): ReLU()
)
(cls_logits): Conv2d(256, 80, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1))
(bbox_pred): Conv2d(256, 4, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1))
(centerness): Conv2d(256, 1, kernel_size=(3, 3), stride=(1, 1), padding=(1, 1))
(scales): ModuleList(
(0): Scale()
(1): Scale()
(2): Scale()
(3): Scale()
(4): Scale()
)
)
(box_selector_test): FCOSPostProcessor()
)1）FCOSHead 部分
i. cls_tower 和 bbox_tower
可以看到这两部分的网络结构是一样的，cls_tower用于分类分支，bbox_tower用于回归分支。因为分类和回归的任务性质不同，这两个部分不可以共享网络参数，所以每个都需要单独定义。它们两部分最终的输出size如下所示，cls_tower_list为cls_tower的输出，box_tower_list为bbox_tower的输出（这两部分是为了看一下这两网络的输出形式而在代码里新加的，源代码里没有）。包含5个输出（FPN的5个层），通道数都为256。
cls_tower_list = [] # list:5 {Tensor:(1,256,100,140),Tensor:(1,256,50,70),Tensor:(1,256,25,35),Tensor:(1,256,13,18),Tensor:(1,256,7,9)}
box_tower_list = [] # list:5 {Tensor:(1,256,100,140),Tensor:(1,256,50,70),Tensor:(1,256,25,35),Tensor:(1,256,13,18),Tensor:(1,256,7,9)}ii. cls_logits
接收来自cls_tower输出的特征，输出分类得分图，它的输出结果如下所示，一共5个输出，对应之前ResNet结合FPN的5个不同层，每个输出都有80个通道，每个通道表示一个类别。
logits = [] # list:5 {Tensor:(1,80,100,140),Tensor:(1,80,50,70),Tensor:(1,80,25,35),Tensor:(1,80,13,18),Tensor:(1,80,7,9)}iii. bbox_pred
接收来自bbox_tower输出的特征，输出回归的向量，如下所示，5个输出，每个有4个通道，表示对应于分类得分图位置的回归向量（l,t,r,b）
bbox_reg = [] # list:5 {Tensor:(1,4,100,140),Tensor:(1,4,50,70),Tensor:(1,4,25,35),Tensor:(1,4,13,18),Tensor:(1,4,7,9)}iv. centerness
接收来自bbox_tower输出的特征，FCOS论文中提出的中心质量分支，输出如下所示，每个只有1个通道，但会与对应的80个通道的得分图元素相乘（中心质量分支作用于分类得分图）。
centerness = [] # list:5 {Tensor:(1,1,100,140),Tensor:(1,1,50,70),Tensor:(1,1,25,35),Tensor:(1,1,13,18),Tensor:(1,1,7,9)}v. FCOSHead 类
至此，FCOSHead类的定义如下，它构建了上述的（i~iv）head网络，所谓的head，就是输出头，通过它得到网络每个部分（分类，回归和中心质量）的最后输出（网络的输出，不是最终的预测结果，最终的预测结果还需根据整个输出进行筛选确定），相当于把来自FPN的5层特征输入同一个head得到5层对应的输出。下面分析一些其中的细节：
class FCOSHead(torch.nn.Module):
def __init__(self, cfg, in_channels): # in_channels:256
"""
Arguments:
in_channels (int): number of channels of the input feature
"""
super(FCOSHead, self).__init__()
# TODO: Implement the sigmoid version first.
num_classes = cfg.MODEL.FCOS.NUM_CLASSES - 1 # 80
self.fpn_strides = cfg.MODEL.FCOS.FPN_STRIDES # [8,16,32,64,128]
self.norm_reg_targets = cfg.MODEL.FCOS.NORM_REG_TARGETS # True
self.centerness_on_reg = cfg.MODEL.FCOS.CENTERNESS_ON_REG # True
self.use_dcn_in_tower = cfg.MODEL.FCOS.USE_DCN_IN_TOWER # False
cls_tower = []
bbox_tower = []
for i in range(cfg.MODEL.FCOS.NUM_CONVS): # 4
if self.use_dcn_in_tower and \
i == cfg.MODEL.FCOS.NUM_CONVS - 1:
conv_func = DFConv2d
else:
conv_func = nn.Conv2d
cls_tower.append(
conv_func(
in_channels,
in_channels,
kernel_size=3,
stride=1,
padding=1,
bias=True
)
)
cls_tower.append(nn.GroupNorm(32, in_channels))
cls_tower.append(nn.ReLU())
bbox_tower.append(
conv_func(
in_channels,
in_channels,
kernel_size=3,
stride=1,
padding=1,
bias=True
)
)
bbox_tower.append(nn.GroupNorm(32, in_channels))
bbox_tower.append(nn.ReLU())
self.add_module('cls_tower', nn.Sequential(*cls_tower))
self.add_module('bbox_tower', nn.Sequential(*bbox_tower))
self.cls_logits = nn.Conv2d(
in_channels, num_classes, kernel_size=3, stride=1,
padding=1
)
self.bbox_pred = nn.Conv2d(
in_channels, 4, kernel_size=3, stride=1,
padding=1
)
self.centerness = nn.Conv2d(
in_channels, 1, kernel_size=3, stride=1,
padding=1
)
# initialization
for modules in [self.cls_tower, self.bbox_tower,
self.cls_logits, self.bbox_pred,
self.centerness]:
for l in modules.modules():
if isinstance(l, nn.Conv2d):
torch.nn.init.normal_(l.weight, std=0.01)
torch.nn.init.constant_(l.bias, 0)
# initialize the bias for focal loss
prior_prob = cfg.MODEL.FCOS.PRIOR_PROB # 0.01
bias_value = -math.log((1 - prior_prob) / prior_prob) # -4.59511985013459
torch.nn.init.constant_(self.cls_logits.bias, bias_value)
self.scales = nn.ModuleList([Scale(init_value=1.0) for _ in range(5)])
def forward(self, x): # form FPN, tuple:5
logits = [] # list:5 {Tensor:(1,80,100,140),Tensor:(1,80,50,70),Tensor:(1,80,25,35),Tensor:(1,80,13,18),Tensor:(1,80,7,9)}
bbox_reg = [] # list:5 {Tensor:(1,4,100,140),Tensor:(1,4,50,70),Tensor:(1,4,25,35),Tensor:(1,4,13,18),Tensor:(1,4,7,9)}
centerness = [] # list:5 {Tensor:(1,1,100,140),Tensor:(1,1,50,70),Tensor:(1,1,25,35),Tensor:(1,1,13,18),Tensor:(1,1,7,9)}
# cls_tower_list = [] # list:5 {Tensor:(1,256,100,140),Tensor:(1,256,50,70),Tensor:(1,256,25,35),Tensor:(1,256,13,18),Tensor:(1,256,7,9)}
# box_tower_list = [] # list:5 {Tensor:(1,256,100,140),Tensor:(1,256,50,70),Tensor:(1,256,25,35),Tensor:(1,256,13,18),Tensor:(1,256,7,9)}
for l, feature in enumerate(x):
cls_tower = self.cls_tower(feature)
box_tower = self.bbox_tower(feature)
# cls_tower_list.append(cls_tower)
# box_tower_list.append(box_tower)
logits.append(self.cls_logits(cls_tower))
if self.centerness_on_reg:
centerness.append(self.centerness(box_tower))
else:
centerness.append(self.centerness(cls_tower))
bbox_pred = self.scales[l](self.bbox_pred(box_tower))
if self.norm_reg_targets:
bbox_pred = F.relu(bbox_pred)
if self.training:
bbox_reg.append(bbox_pred)
else:
bbox_reg.append(bbox_pred * self.fpn_strides[l])
else:
bbox_reg.append(torch.exp(bbox_pred))
return logits, bbox_reg, centerness## ------ self.scales = nn.ModuleList([Scale(init_value=1.0) for _ in range(5)])
定义如下，和而且从上面的代码可以看到边界框的回归用到了它，
bbox_pred = self.scales[l](self.bbox_pred(box_tower))
这是因为Head接收FPN 5层不同尺寸的特征（五层特征共享head），其回归范围不同，所以需要用缩放因子scale对回归结果进行缩放。
class Scale(nn.Module):
def __init__(self, init_value=1.0):
super(Scale, self).__init__()
self.scale = nn.Parameter(torch.FloatTensor([init_value])) # scale , size is 1
def forward(self, input):
return input * self.scale打印了以下5个scale 的值，如下所示
number l is 0
self.scale is Parameter containing:
tensor([0.9034], device='cuda:0', requires_grad=True)
=============================================
number l is 1
self.scale is Parameter containing:
tensor([0.9520], device='cuda:0', requires_grad=True)
=============================================
number l is 2
self.scale is Parameter containing:
tensor([0.9570], device='cuda:0', requires_grad=True)
=============================================
number l is 3
self.scale is Parameter containing:
tensor([0.9397], device='cuda:0', requires_grad=True)
=============================================
number l is 4
self.scale is Parameter containing:
tensor([0.8791], device='cuda:0', requires_grad=True)## ------- nn.ModuleList
nn.ModuleList,它是一个存储不同module，并自动将每个module的parameters添加到网络之中的容器。nn.ModuleList并没有定义一个网络，它只是将不同的模块储存在一起，这些模块之间并没有什么先后顺序可言，参考pytorch小记：nn.ModuleList和nn.Sequential的用法以及区别
2） FCOSModule 部分
FCOSModule部分就是用来得到网络最终预测的结果，它包含上面的FCOSHead，并且经过一些后处理得到最终预测的边界框和以及类别。（当然在训练阶段时会有损失函数，不过demo过程不涉及，这部分在接下来的Train过程会涉及到）
整体代码如下
class FCOSModule(torch.nn.Module):
"""
Module for FCOS computation. Takes feature maps from the backbone and
FCOS outputs and losses. Only Test on FPN now.
"""
def __init__(self, cfg, in_channels):
super(FCOSModule, self).__init__()
head = FCOSHead(cfg, in_channels)
box_selector_test = make_fcos_postprocessor(cfg)
loss_evaluator = make_fcos_loss_evaluator(cfg)
self.head = head
self.box_selector_test = box_selector_test
self.loss_evaluator = loss_evaluator
self.fpn_strides = cfg.MODEL.FCOS.FPN_STRIDES # [8,16,32,64,128]
def forward(self, images, features, targets=None):
"""
Arguments:
images (ImageList): images for which we want to compute the predictions
features (list[Tensor]): features computed from the images that are
used for computing the predictions. Each tensor in the list
correspond to different feature levels
targets (list[BoxList): ground-truth boxes present in the image (optional)
Returns:
boxes (list[BoxList]): the predicted boxes from the RPN, one BoxList per
image.
losses (dict[Tensor]): the losses for the model during training. During
testing, it is an empty dict.
"""
box_cls, box_regression, centerness = self.head(features)
locations = self.compute_locations(features)
if self.training: # only use on training
return self._forward_train(
locations, box_cls,
box_regression,
centerness, targets
)
else: # demo
return self._forward_test(
locations, box_cls, box_regression,
centerness, images.image_sizes
)
def _forward_train(self, locations, box_cls, box_regression, centerness, targets):
loss_box_cls, loss_box_reg, loss_centerness = self.loss_evaluator(
locations, box_cls, box_regression, centerness, targets
)
losses = {
"loss_cls": loss_box_cls,
"loss_reg": loss_box_reg,
"loss_centerness": loss_centerness
}
return None, losses
def _forward_test(self, locations, box_cls, box_regression, centerness, image_sizes):
boxes = self.box_selector_test(
locations, box_cls, box_regression,
centerness, image_sizes
)
return boxes, {}
def compute_locations(self, features): # 传入的是backbone的特征
locations = [] # 网格坐标点， FPN每层特征各个位置 -----> 原图像的位置
for level, feature in enumerate(features): # 获取FPN输出的每层特征
h, w = feature.size()[-2:] # FPN每层特征的尺寸
locations_per_level = self.compute_locations_per_level(
h, w, self.fpn_strides[level],
feature.device
) # FPN每层特征中 各个位置 对应原图像的位置 生成的网格坐标点
locations.append(locations_per_level)
return locations
def compute_locations_per_level(self, h, w, stride, device):
shifts_x = torch.arange(
0, w * stride, step=stride,
dtype=torch.float32, device=device
) # 乘以步长映射回原图像大小，特征点对应于原图像是一块区域，所以以步长为间隔
shifts_y = torch.arange(
0, h * stride, step=stride,
dtype=torch.float32, device=device
)
shift_y, shift_x = torch.meshgrid(shifts_y, shifts_x)
shift_x = shift_x.reshape(-1)
shift_y = shift_y.reshape(-1)
locations = torch.stack((shift_x, shift_y), dim=1) + stride // 2 # 加步长整除2是因为特征点对应原图一块区域的中心，所以从stride//2坐标开始
return locations首先，它的输入如下所示（代码在generalized_rcnn.py 的forward部分），包括原图像的Tensor，骨干网络（ResNet和FPN）的输出特征，以及ground_truth（demo过程没有，Train过程有）
images = to_image_list(images)
features = self.backbone(images.tensors)
proposals, proposal_losses = self.rpn(images, features, targets)接下来按前向传播的顺序细节描述以下
i. box_cls, box_regression, centerness = self.head(features)
第1)部分描述的FCOSHead的输出
ii. location = self.compute_locations(features)
返回FPN不同层特征各个位置对应于原图像的位置。因为FCOSHead输出的各个层级的特征尺寸大小与其接收的 来自FPN输出的各个层级的特征尺寸大小一样，并没有改变，改变的只有通道数，即FCOSHead并没有改变输入特征尺寸的大小，而是只改变了输入通道数，所以这个location就是分类得分图（logits）各个位置 反射回 原图像对应的各个位置。
iii. boxes= self.box_selector_test(locations, box_cls, box_regression,centerness, image_sizes )
后处理过程，代码定义如下，主要是FCOSPostProcessor这个类，对整个网络的输出进行筛选确定最终结果。接下来细节描述一下需要注意的地方
class FCOSPostProcessor(torch.nn.Module):
"""
Performs post-processing on the outputs of the RetinaNet boxes.
This is only used in the testing.
"""
def __init__(
self,
pre_nms_thresh,
pre_nms_top_n,
nms_thresh,
fpn_post_nms_top_n,
min_size,
num_classes,
bbox_aug_enabled=False
):
"""
Arguments:
pre_nms_thresh (float)
pre_nms_top_n (int)
nms_thresh (float)
fpn_post_nms_top_n (int)
min_size (int)
num_classes (int)
box_coder (BoxCoder)
"""
super(FCOSPostProcessor, self).__init__()
self.pre_nms_thresh = pre_nms_thresh # 0.05
self.pre_nms_top_n = pre_nms_top_n # 1000
self.nms_thresh = nms_thresh # 0.6
self.fpn_post_nms_top_n = fpn_post_nms_top_n # 100
self.min_size = min_size # 0
self.num_classes = num_classes # 81
self.bbox_aug_enabled = bbox_aug_enabled
def forward_for_single_feature_map(
self, locations, box_cls,
box_regression, centerness,
image_sizes):
"""
Arguments:
anchors: list[BoxList]
box_cls: tensor of size N, A * C, H, W
box_regression: tensor of size N, A * 4, H, W
"""
N, C, H, W = box_cls.shape # 推理阶段N=1，训练阶段N=Batchsize
# put in the same format as locations
box_cls = box_cls.view(N, C, H, W).permute(0, 2, 3, 1) # shape : (N,H,W,C)
box_cls = box_cls.reshape(N, -1, C).sigmoid() # shape (N, H*W,C)，sigmoid函数将输出值变为0到1之间
box_regression = box_regression.view(N, 4, H, W).permute(0, 2, 3, 1) # shape (N,H,W,4)
box_regression = box_regression.reshape(N, -1, 4) # (N,H*W,4)
centerness = centerness.view(N, 1, H, W).permute(0, 2, 3, 1) # （N，H，W，1）
centerness = centerness.reshape(N, -1).sigmoid() # (N,H*W)
candidate_inds = box_cls > self.pre_nms_thresh # bool型 0或1，论文中所述的大于0.05为正样本，其余为背景负样本
pre_nms_top_n = candidate_inds.contiguous().view(N, -1).sum(1) # ||这里加了个.contiguous()，要不会报错。||sum(1)为对行求和，看一共有多少个正样本 ，为一个数值Tensor
pre_nms_top_n = pre_nms_top_n.clamp(max=self.pre_nms_top_n) # pre_nms_top_n的值是否大于1000，大于1000取1000，小于保留原有不变。保留最多1000个正样本
# multiply the classification scores with centerness scores
box_cls = box_cls * centerness[:, :, None] # 分类得分图与中心质量分数相乘
results = []
for i in range(N): # N=Batchsize，demo时N=1
per_box_cls = box_cls[i]
per_candidate_inds = candidate_inds[i]
per_box_cls = per_box_cls[per_candidate_inds] # 拿出得分图中正样本的点
per_candidate_nonzeros = per_candidate_inds.nonzero() # 得到正样本在得分图中的信息。得分图已经resize成（H*W,C），第一维相当于位置，第二维相当于类别。
per_box_loc = per_candidate_nonzeros[:, 0] # 位置信息 举例Tensor(294,)
per_class = per_candidate_nonzeros[:, 1] + 1 # 类别信息，加1是因为背景也算了1类，为第0类。 举例Tensor(294,)
per_box_regression = box_regression[i] # （H*W，4）
per_box_regression = per_box_regression[per_box_loc] # 每个正样本点对应的回归向量 举例Tensor(294,4)
per_locations = locations[per_box_loc] # 每个正样本点对应于原图像上的点，举例 Tensor:(294,2)
per_pre_nms_top_n = pre_nms_top_n[i] # 举例 294
if per_candidate_inds.sum().item() > per_pre_nms_top_n.item(): # 正样本数是否大于1000个
per_box_cls, top_k_indices = \
per_box_cls.topk(per_pre_nms_top_n, sorted=False) # 选取前per_pre_nms_top_n个，不进行大小排序。返回一个元组 (values,indices)对应per_box_cls, top_k_indices
per_class = per_class[top_k_indices] # per_class保留的是所有正样本的类别信息，现在只取前1000个
per_box_regression = per_box_regression[top_k_indices] # 回归向量，只取对应的前1000个
per_locations = per_locations[top_k_indices] # 正样本点对应的原图像的点，只取前1000个
detections = torch.stack([
per_locations[:, 0] - per_box_regression[:, 0],
per_locations[:, 1] - per_box_regression[:, 1],
per_locations[:, 0] + per_box_regression[:, 2],
per_locations[:, 1] + per_box_regression[:, 3],
], dim=1) # 预测的bbox的 x1,y1,x2,y2, 左上角顶点与右下角顶点 举例 Tesnor(294,4)
h, w = image_sizes[i]
boxlist = BoxList(detections, (int(w), int(h)), mode="xyxy")
boxlist.add_field("labels", per_class) # 类属性extra_fields字典里添加 "labels"：per_class
boxlist.add_field("scores", torch.sqrt(per_box_cls)) # 同上，添加位置得分，这里将per_box_cls开根号了，
boxlist = boxlist.clip_to_image(remove_empty=False) # 将超出原图像的边界框进行平滑调整
boxlist = remove_small_boxes(boxlist, self.min_size) # 将w和h为负数的去掉，此时的bbox还是 xyxy 形式的
results.append(boxlist)
return results
def forward(self, locations, box_cls, box_regression, centerness, image_sizes):
"""
Arguments:
anchors: list[list[BoxList]]
box_cls: list[tensor]
box_regression: list[tensor]
image_sizes: list[(h, w)]
Returns:
boxlists (list[BoxList]): the post-processed anchors, after
applying box decoding and NMS
"""
sampled_boxes = [] # list:5,对应5层的不同特征，每一个都是BoxList类对象
for _, (l, o, b, c) in enumerate(zip(locations, box_cls, box_regression, centerness)):
sampled_boxes.append(
self.forward_for_single_feature_map(
l, o, b, c, image_sizes
)
)
boxlists = list(zip(*sampled_boxes)) # list：1，里面是5个元组
boxlists = [cat_boxlist(boxlist) for boxlist in boxlists]
if not self.bbox_aug_enabled: # True demo时
boxlists = self.select_over_all_levels(boxlists)
return boxlists
# TODO very similar to filter_results from PostProcessor
# but filter_results is per image
# TODO Yang: solve this issue in the future. No good solution
# right now.
def select_over_all_levels(self, boxlists):
num_images = len(boxlists)
results = [] # 举例 BoxList：100
for i in range(num_images):
# multiclass nms
result = boxlist_ml_nms(boxlists[i], self.nms_thresh) # NMS非极大值抑制后的结果，为BoxList类实例 举例 BoxList：111
number_of_detections = len(result) # NMS抑制后剩余的边界框数目， 举例int： 111
# Limit to max_per_image detections **over all classes**
if number_of_detections > self.fpn_post_nms_top_n > 0: # 如果大于100个
cls_scores = result.get_field("scores") # 分类得分
image_thresh, _ = torch.kthvalue(
cls_scores.cpu(),
number_of_detections - self.fpn_post_nms_top_n + 1
) # 取到数 number_of_detections - self.fpn_post_nms_top_n + 1最小值， 举例 取到数第 12个最小值，返回该数值和其索引坐标
keep = cls_scores >= image_thresh.item() # bool型 0/1 大于 image_thresh的为1，其余为0， 举例 Tensor：（111， ）
keep = torch.nonzero(keep).squeeze(1) # 拿出keep中元素为1的索引，举例 Tensor：（100， ）
result = result[keep] # result为 BoxList类实例，举例 BoxList：100
results.append(result)
return results
def make_fcos_postprocessor(config):
pre_nms_thresh = config.MODEL.FCOS.INFERENCE_TH # 0.05
pre_nms_top_n = config.MODEL.FCOS.PRE_NMS_TOP_N # 1000
nms_thresh = config.MODEL.FCOS.NMS_TH # 0.6
fpn_post_nms_top_n = config.TEST.DETECTIONS_PER_IMG # 100
bbox_aug_enabled = config.TEST.BBOX_AUG.ENABLED # False
box_selector = FCOSPostProcessor(
pre_nms_thresh=pre_nms_thresh,
pre_nms_top_n=pre_nms_top_n,
nms_thresh=nms_thresh,
fpn_post_nms_top_n=fpn_post_nms_top_n,
min_size=0,
num_classes=config.MODEL.FCOS.NUM_CLASSES,
bbox_aug_enabled=bbox_aug_enabled
)
return box_selector(i)
candidate_inds = box_cls > self.pre_nms_thresh
pre_nms_top_n = candidate_inds.contiguous().view(N, -1).sum(1)
pre_nms_top_n = pre_nms_top_n.clamp(max=self.pre_nms_top_n)这里首先根据
self.pre_nms_thresh = pre_nms_thresh # 0.05
阈值来筛选正负样本，根据论文中所述，大于0.05的为正样本，其余的为负样本。然后看看一共有多少个正样本，sum(1)函数参考[python] 关于sum函数:sum(-1)、sum(1)、sum(0)以及keepdims=True的说明，最后利用clamp函数（参考pytorch:torch.clamp()）保留最多1000个正样本。
(ii). box_cls = box_cls * centerness[:, :, None]
这个[:,:,None]的操作就是为原来的数组添加一维，参考切片[:, None, None]的含义。 将分类分支与中心质量分支相乘，对应论文中来惩罚距离目标中心较远的点产生的低质量边界框。
（iii）
per_box_cls = per_box_cls[per_candidate_inds]
per_candidate_nonzeros = per_candidate_inds.nonzero()
per_box_loc = per_candidate_nonzeros[:, 0]
per_class = per_candidate_nonzeros[:, 1] + 1 这里首先拿出分类输出中正样本的点，per_candidate_inds是bool型，数组[bool]就会拿出对应bool=1 位置处的数值得到一行数组。如下图举例所示。
然后再配合nonzero函数（参考python nonzero()函数的用法）得到这些正样本的点在分类输出中的位置。注意现在分类输出的shape是（H*W,C），第一维表示的是位置信息（二维坐标被拉成一维了），第二维是类别信息。所以接下来就是分开把这两个信息拿出来了，per_candidate_nonzeros[:, 1] + 1 操作是因为背景也算了一类（在predictor.py 中
CATEGORIES = [
"__background",
"person",
"bicycle",
"car",
"motorcycle",
"airplane",
"bus",
第一类别就是背景）。
（iv） per_box_cls, top_k_indices = \
per_box_cls.topk(per_pre_nms_top_n, sorted=False)
这里之前先判断了一下正样本数是否大于1000个，大于1000个则利用 torch.topk函数（参考pytorch -- topk()）来按顺序选取前1000个样本，不按大小排序。
（v）detections = torch.stack([
per_locations[:, 0] - per_box_regression[:, 0],
per_locations[:, 1] - per_box_regression[:, 1],
per_locations[:, 0] + per_box_regression[:, 2],
per_locations[:, 1] + per_box_regression[:, 3],
], dim=1)
通过论文回归向量的设置反向来求得预测的边界框，原回归向量的设置如下所示
（l,t,r,b）为网络输出的回归向量，(x,y)为location中对应的分类输出的坐标；把上式中的x0,y0,x1,y1 单独移到一边即可。
（vi）boxlist = BoxList(detections, (int(w), int(h)), mode="xyxy")
boxlist.add_field("labels", per_class)
boxlist.add_field("scores", torch.sqrt(per_box_cls))
boxlist = boxlist.clip_to_image(remove_empty=False)
boxlist = remove_small_boxes(boxlist, self.min_size)
至此这里引出了 BoxList这个类，代码如下所示。除了利用下面这个类中的属性self.extra_fields = {} （对应于boxlist.add_field函数）来添加字典，以及boxlist.clip_to_image用来平滑调整超出图像的边界框以外，还用了remove_small_boxes函数。
def remove_small_boxes(boxlist, min_size):
"""
Only keep boxes with both sides >= min_size
Arguments:
boxlist (Boxlist)
min_size (int)
"""
# TODO maybe add an API for querying the ws / hs
xywh_boxes = boxlist.convert("xywh").bbox # 传入的mode为xywh，这里后面跟了个box是因为这个函数返回的是一个类实例BoxList。返回的是边界框的xywh形式，举例 Tensor：（294，4）
_, _, ws, hs = xywh_boxes.unbind(dim=1) # 分开赋值
keep = (
(ws >= min_size) & (hs >= min_size)
).nonzero().squeeze(1) # 把w或h小于0的结果排除掉，举例 Tensor：（294，）
return boxlist[keep]
这里利用的语句包括：self.bbox.split(1, dim=-1) （参考torch.split()），bbox = torch.cat( (xmin, ymin, xmax - xmin + TO_REMOVE, ymax - ymin + TO_REMOVE), dim=-1 ) （参考PyTorch的torch.cat）， _, _, ws, hs = xywh_boxes.unbind(dim=1) （参考PyTorch 函数解释：torch.narrow()、torch.unbind()）。
class BoxList(object):
"""
This class represents a set of bounding boxes.
The bounding boxes are represented as a Nx4 Tensor.
In order to uniquely determine the bounding boxes with respect
to an image, we also store the corresponding image dimensions.
They can contain extra information that is specific to each bounding box, such as
labels.
"""
def __init__(self, bbox, image_size, mode="xyxy"):
device = bbox.device if isinstance(bbox, torch.Tensor) else torch.device("cpu")
bbox = torch.as_tensor(bbox, dtype=torch.float32, device=device)
if bbox.ndimension() != 2:
raise ValueError(
"bbox should have 2 dimensions, got {}".format(bbox.ndimension())
)
if bbox.size(-1) != 4:
raise ValueError(
"last dimension of bbox should have a "
"size of 4, got {}".format(bbox.size(-1))
)
if mode not in ("xyxy", "xywh"):
raise ValueError("mode should be 'xyxy' or 'xywh'")
self.bbox = bbox
self.size = image_size # (image_width, image_height)
self.mode = mode
self.extra_fields = {}
def add_field(self, field, field_data):
self.extra_fields[field] = field_data
def get_field(self, field):
return self.extra_fields[field]
def has_field(self, field):
return field in self.extra_fields
def fields(self):
return list(self.extra_fields.keys())
def _copy_extra_fields(self, bbox):
for k, v in bbox.extra_fields.items():
self.extra_fields[k] = v
def convert(self, mode):
if mode not in ("xyxy", "xywh"):
raise ValueError("mode should be 'xyxy' or 'xywh'")
if mode == self.mode:
return self
# we only have two modes, so don't need to check
# self.mode
xmin, ymin, xmax, ymax = self._split_into_xyxy() # 举例 Tensor:(294,1),Tensor:(294,1),Tensor:(294,1),Tensor:(294,1)
if mode == "xyxy":
bbox = torch.cat((xmin, ymin, xmax, ymax), dim=-1)
bbox = BoxList(bbox, self.size, mode=mode)
else:
TO_REMOVE = 1
bbox = torch.cat(
(xmin, ymin, xmax - xmin + TO_REMOVE, ymax - ymin + TO_REMOVE), dim=-1
) # 转成xywh形式。 举例 Tensor:(294,4)
bbox = BoxList(bbox, self.size, mode=mode)
bbox._copy_extra_fields(self)
return bbox
def _split_into_xyxy(self):
if self.mode == "xyxy": # True
xmin, ymin, xmax, ymax = self.bbox.split(1, dim=-1)
return xmin, ymin, xmax, ymax
elif self.mode == "xywh":
TO_REMOVE = 1
xmin, ymin, w, h = self.bbox.split(1, dim=-1) # 把bbox中的tensor切成小块，然后赋值给对应的变量。相当于列表或者元组对应元素赋值
return (
xmin,
ymin,
xmin + (w - TO_REMOVE).clamp(min=0),
ymin + (h - TO_REMOVE).clamp(min=0),
) # 返回 xywh形式
else:
raise RuntimeError("Should not be here")
def resize(self, size, *args, **kwargs):
"""
Returns a resized copy of this bounding box
:param size: The requested size in pixels, as a 2-tuple:
(width, height).
"""
ratios = tuple(float(s) / float(s_orig) for s, s_orig in zip(size, self.size))
if ratios[0] == ratios[1]:
ratio = ratios[0]
scaled_box = self.bbox * ratio
bbox = BoxList(scaled_box, size, mode=self.mode)
# bbox._copy_extra_fields(self)
for k, v in self.extra_fields.items():
if not isinstance(v, torch.Tensor):
v = v.resize(size, *args, **kwargs)
bbox.add_field(k, v)
return bbox
ratio_width, ratio_height = ratios
xmin, ymin, xmax, ymax = self._split_into_xyxy()
scaled_xmin = xmin * ratio_width
scaled_xmax = xmax * ratio_width
scaled_ymin = ymin * ratio_height
scaled_ymax = ymax * ratio_height
scaled_box = torch.cat(
(scaled_xmin, scaled_ymin, scaled_xmax, scaled_ymax), dim=-1
)
bbox = BoxList(scaled_box, size, mode="xyxy")
# bbox._copy_extra_fields(self)
for k, v in self.extra_fields.items():
if not isinstance(v, torch.Tensor):
v = v.resize(size, *args, **kwargs)
bbox.add_field(k, v)
return bbox.convert(self.mode)
def transpose(self, method):
"""
Transpose bounding box (flip or rotate in 90 degree steps)
:param method: One of :py:attr:`PIL.Image.FLIP_LEFT_RIGHT`,
:py:attr:`PIL.Image.FLIP_TOP_BOTTOM`, :py:attr:`PIL.Image.ROTATE_90`,
:py:attr:`PIL.Image.ROTATE_180`, :py:attr:`PIL.Image.ROTATE_270`,
:py:attr:`PIL.Image.TRANSPOSE` or :py:attr:`PIL.Image.TRANSVERSE`.
"""
if method not in (FLIP_LEFT_RIGHT, FLIP_TOP_BOTTOM):
raise NotImplementedError(
"Only FLIP_LEFT_RIGHT and FLIP_TOP_BOTTOM implemented"
)
image_width, image_height = self.size
xmin, ymin, xmax, ymax = self._split_into_xyxy()
if method == FLIP_LEFT_RIGHT:
TO_REMOVE = 1
transposed_xmin = image_width - xmax - TO_REMOVE
transposed_xmax = image_width - xmin - TO_REMOVE
transposed_ymin = ymin
transposed_ymax = ymax
elif method == FLIP_TOP_BOTTOM:
transposed_xmin = xmin
transposed_xmax = xmax
transposed_ymin = image_height - ymax
transposed_ymax = image_height - ymin
transposed_boxes = torch.cat(
(transposed_xmin, transposed_ymin, transposed_xmax, transposed_ymax), dim=-1
)
bbox = BoxList(transposed_boxes, self.size, mode="xyxy")
# bbox._copy_extra_fields(self)
for k, v in self.extra_fields.items():
if not isinstance(v, torch.Tensor):
v = v.transpose(method)
bbox.add_field(k, v)
return bbox.convert(self.mode)
def crop(self, box):
"""
Cropss a rectangular region from this bounding box. The box is a
4-tuple defining the left, upper, right, and lower pixel
coordinate.
"""
xmin, ymin, xmax, ymax = self._split_into_xyxy()
w, h = box[2] - box[0], box[3] - box[1]
cropped_xmin = (xmin - box[0]).clamp(min=0, max=w)
cropped_ymin = (ymin - box[1]).clamp(min=0, max=h)
cropped_xmax = (xmax - box[0]).clamp(min=0, max=w)
cropped_ymax = (ymax - box[1]).clamp(min=0, max=h)
# TODO should I filter empty boxes here?
if False:
is_empty = (cropped_xmin == cropped_xmax) | (cropped_ymin == cropped_ymax)
cropped_box = torch.cat(
(cropped_xmin, cropped_ymin, cropped_xmax, cropped_ymax), dim=-1
)
bbox = BoxList(cropped_box, (w, h), mode="xyxy")
# bbox._copy_extra_fields(self)
for k, v in self.extra_fields.items():
if not isinstance(v, torch.Tensor):
v = v.crop(box)
bbox.add_field(k, v)
return bbox.convert(self.mode)
# Tensor-like methods
def to(self, device):
bbox = BoxList(self.bbox.to(device), self.size, self.mode)
for k, v in self.extra_fields.items():
if hasattr(v, "to"):
v = v.to(device)
bbox.add_field(k, v)
return bbox
def __getitem__(self, item):
bbox = BoxList(self.bbox[item], self.size, self.mode)
for k, v in self.extra_fields.items():
bbox.add_field(k, v[item])
return bbox
def __len__(self):
return self.bbox.shape[0]
def clip_to_image(self, remove_empty=True):
TO_REMOVE = 1
self.bbox[:, 0].clamp_(min=0, max=self.size[0] - TO_REMOVE)
self.bbox[:, 1].clamp_(min=0, max=self.size[1] - TO_REMOVE)
self.bbox[:, 2].clamp_(min=0, max=self.size[0] - TO_REMOVE)
self.bbox[:, 3].clamp_(min=0, max=self.size[1] - TO_REMOVE)
if remove_empty:
box = self.bbox
keep = (box[:, 3] > box[:, 1]) & (box[:, 2] > box[:, 0])
return self[keep]
return self
def area(self):
box = self.bbox
if self.mode == "xyxy":
TO_REMOVE = 1
area = (box[:, 2] - box[:, 0] + TO_REMOVE) * (box[:, 3] - box[:, 1] + TO_REMOVE)
elif self.mode == "xywh":
area = box[:, 2] * box[:, 3]
else:
raise RuntimeError("Should not be here")
return area
def copy_with_fields(self, fields, skip_missing=False):
bbox = BoxList(self.bbox, self.size, self.mode)
if not isinstance(fields, (list, tuple)):
fields = [fields]
for field in fields:
if self.has_field(field):
bbox.add_field(field, self.get_field(field))
elif not skip_missing:
raise KeyError("Field '{}' not found in {}".format(field, self))
return bbox
def __repr__(self):
s = self.__class__.__name__ + "("
s += "num_boxes={}, ".format(len(self))
s += "image_width={}, ".format(self.size[0])
s += "image_height={}, ".format(self.size[1])
s += "mode={})".format(self.mode)
return s（vii）接下来回到FCOSPostProcessor类里的forward函数里，再经过所有层（5层）的单个处理过程之后，结果都保存在了sampled_boxes当中，其为list=5的列表，里面是5个BoxList类。然后
boxlists = [cat_boxlist(boxlist) for boxlist in boxlists] 引出下面函数。
def cat_boxlist(bboxes):
"""
Concatenates a list of BoxList (having the same image size) into a
single BoxList
Arguments:
bboxes (list[BoxList])
"""
assert isinstance(bboxes, (list, tuple))
assert all(isinstance(bbox, BoxList) for bbox in bboxes)
size = bboxes[0].size # BoxList里的size属性，为图像的size，举例 （1120，800）
assert all(bbox.size == size for bbox in bboxes)
mode = bboxes[0].mode # BoxList里的mode属性 xyxy
assert all(bbox.mode == mode for bbox in bboxes)
fields = set(bboxes[0].fields()) # BoxList类里面的fields函数，返回的是 set:2,['labels','scores']
assert all(set(bbox.fields()) == fields for bbox in bboxes)
cat_boxes = BoxList(_cat([bbox.bbox for bbox in bboxes], dim=0), size, mode) # BoxList实例类 将5层预测的所有bbox放在一起， 举例 {BoxList:737},属性bbox={Tensor:(737,4)}
for field in fields: # 'labels','scores'
data = _cat([bbox.get_field(field) for bbox in bboxes], dim=0)
cat_boxes.add_field(field, data)
return cat_boxes这里的fields = set(bboxes[0].fields())利用了set函数，它可以删除重复数据（参考python的set()函数），.fileds()函数来自BoxList类内，定义如下：
def fields(self):
return list(self.extra_fields.keys())
返回该类内属性extra_fields中的健，即 "labels","scores"。然后
cat_boxes = BoxList(_cat([bbox.bbox for bbox in bboxes], dim=0), size, mode)
用到了_cat函数，其定义如下，
def _cat(tensors, dim=0):
"""
Efficient version of torch.cat that avoids a copy if there is only a single element in a list
"""
assert isinstance(tensors, (list, tuple))
if len(tensors) == 1:
return tensors[0]
return torch.cat(tensors, dim)
torch.cat函数（参考PyTorch的torch.cat）将来自5层的预测输出结果bbox连接在一起，这一步的主要作用是把预测结果的回归向量放到了一起。而且这里还重新定义了一个新的BoxList实例类cat_boxes，然后通过下面的代码 在cat_boxes实例属性 extra_fields 字典中写入对应的并放到一起的 {'label': Tensor:(737, ) , 'socer':Tensor:(737, ) } （<----举例）。
for field in fields: # 'labels','scores'
data = _cat([bbox.get_field(field) for bbox in bboxes], dim=0)
cat_boxes.add_field(field, data)
接下来会执行下面这步操作
if not self.bbox_aug_enabled: # True demo时
boxlists = self.select_over_all_levels(boxlists)
跳到 select_over_all_levels(self, boxlists):函数里，result = boxlist_ml_nms(boxlists[i], self.nms_thresh)引出boxlist_ml_nms函数，如下所示，这个_box_ml_nms在源代码里并没有直接的NMS非极大值抑制函数，而是用的接口（底层的C语言）编译的开源NMS。然后
image_thresh, _ = torch.kthvalue(
cls_scores.cpu(),
number_of_detections - self.fpn_post_nms_top_n + 1
)
中利用torch.kthvalue函数（参考Pytorch学习之torch----比较操作(Comparison Ops)）来删除超过100个以外数量的最小值。至此后处理过程FCOSPostProcessor类运行完毕，返回最终的result---一个BoxList的类实例。
def boxlist_ml_nms(boxlist, nms_thresh, max_proposals=-1,
score_field="scores", label_field="labels"): # nms_thresh=0.6
"""
Performs non-maximum suppression on a boxlist, with scores specified
in a boxlist field via score_field.
Arguments:
boxlist(BoxList)
nms_thresh (float)
max_proposals (int): if > 0, then only the top max_proposals are kept
after non-maximum suppression
score_field (str)
"""
if nms_thresh <= 0:
return boxlist
mode = boxlist.mode # 'xyxy'
boxlist = boxlist.convert("xyxy") # 转成xyxy形式，这个直接返回的,没有改变什么，原boxlist.mode='xyxy'
boxes = boxlist.bbox # 回归向量 举例 Tensor:(737,4)
scores = boxlist.get_field(score_field) # 分类得分 举例 Tensor:(737, )
labels = boxlist.get_field(label_field) # 分类得分对应的标签 举例 Tensor(737, )
keep = _box_ml_nms(boxes, scores, labels.float(), nms_thresh) # 运用非极大值抑制，网上查资料说的是用Cpython编译出开源的NMS，并没有在原代码中直接编写NMS
if max_proposals > 0:
keep = keep[: max_proposals]
boxlist = boxlist[keep]
return boxlist.convert(mode)然后继续接回到第2）部分的iii，这里
def _forward_test(self, locations, box_cls, box_regression, centerness, image_sizes):
boxes = self.box_selector_test(
locations, box_cls, box_regression,
centerness, image_sizes
)
return boxes, {}
这里返回的是处理后的 一个 BoxList类实例，这也是FCOSHead类的返回值（forward函数里的）
else: # demo
return self._forward_test(
locations, box_cls, box_regression,
centerness, images.image_sizes
)
后面的{}是因为 在 generalized_rcnn.py中调用FCOSHead的语句如下所示：
proposals, proposal_losses = self.rpn(images, features, targets)
这是demo过程，所以不需要返回损失函数。至此，代码rpn（并没有i用到anchor，这是anchor free 的）这部分结束了。
1148
被折叠的 条评论
为什么被折叠?
到【灌水乐园】发言
