ESP32S2 VOIP Development board语音全功能开发板

CPU:ESP32S2 支持外置NOR/PSRAM
WIFI:1路原生
ETH:1路
4G模块:A7600
音频:ES8388双路输入输出
ADCKEY:1路
ADCBAT:1路
专用:RFID接口
LCD接口:支持TFT/黑白屏，IIC触摸
扩展:I2C输出扩展16路IO支持矩阵键盘
支持锂电池接口:需说明
应用:ETHtoWIFI转发，4GtoWIFI转发，VOIP SIP语音电话，DTU开发，RFID门禁，工业控制,大学生电子竞赛等众多应用场合。

本开发板是集众多模块为一体，可以支持乐鑫提供很多免费驱动，建议安装V4.4以上版本。电路经过验证稳定可靠。
CPU:ESP32S2
Support external NOR/PSRAM

WIFI: 1 way native

ETH: 1 way

4G module: A7600

Audio: ES8388 dual input and output

ADCKEY: 1 way

ADCBAT: 1 way

Dedicated: RFID interface

LCD interface: support TFT/black and white screen, IIC touch

Extension: I2C output expansion 16 channel IO support matrix keyboard

Support lithium battery interface: to be explained

Applications: ETHtoWIFI forwarding, 4GtoWIFI forwarding, VOIP voice phone, DTU development, RFID access control, industrial control and many other applications.

This development board is a combination of many modules, which can support Lexin to provide many free drivers. It is recommended to install V4.4 or above. The circuit is proved to be stable and reliable.
Looking forward to communicating with you

期待大家交流：Email：zhouxinjie1@163.com
