四种为 echarts 条形图柱子设置不同颜色的方法,总有一款适合你

直接在 data 中设置

可以在 series 的 data 数组中,为每个数据项指定一个对象,该对象除了包含 value 外,还可以包含一个 itemStyle 属性来指定颜色。比较常用,例如:

series: [
  {
    type: 'bar',
    data: [
      { value: 100, itemStyle: { color: 'red' } },
      { value: 200, itemStyle: { color: 'blue' } },
       { value: 300, itemStyle: { color: 'green' } },
    ],
  }
]

效果图:
在这里插入图片描述

使用回调函数映射颜色

利用 itemStyle.color 属性的回调函数功能,根据数据项的索引或值来动态设置颜色。个人来说非常推荐这种写法,因为我们通常拿到的是后端的一组数据,代码简洁性和可复用性很高,例如:

series: [
  {
    type: 'bar',
    data: [100, 200, 300, 400],
    itemStyle: {
      color: function (params) {
        // 根据params的
        const colorsMap = [
            '#ff0000',
            '#00ff00',
            '#0000ff',
            '#ffff00']
        return colorsMap[params.dataIndex];
      }
    }
  }
]

效果图:
在这里插入图片描述

使用回调函数映射渐变色

官方文档

如果需要每个柱子有渐变色,可以在 itemStyle 中使用 color 属性设置渐变颜色,并且通过回调函数确保每个柱子的渐变色不同。例如:

series: [
      {
        type: "bar",
        data: [100, 200, 300],
        itemStyle: {
          color: function (params) {
            // 动态生成渐变色或者根据条件返回预设的渐变色
            const gradientColors = [
              {
                // 线性渐变,前四个参数分别是 x0, y0, x2, y2, 范围从 0 - 1,
                // 相当于在图形包围盒中的百分比
                x: 0,
                y: 0,
                x2: 0,
                y2: 1,
                type: "linear",
                colorStops: [
                  { offset: 0, color: "red" },
                  { offset: 1, color: "blue" }
                ]
              },
              {
                x: 1,
                y: 0,
                x2: 0,
                y2: 0,
                type: "linear",
                colorStops: [
                  { offset: 0, color: "red" },
                  { offset: 1, color: "blue" }
                ]
              },
              // 径向渐变,前三个参数分别是圆心 x, y 和半径,取值同线性渐变
              {
                type: "radial",
                x: 0.5,
                y: 0.5,
                r: 1,
                colorStops: [
                  {
                    offset: 0,
                    color: "red" // 0% 处的颜色
                  },
                  {
                    offset: 1,
                    color: "blue" // 100% 处的颜色
                  }
                ]
              }
            ];

            return gradientColors[params.dataIndex];
          }
        }
      }
    ]

效果图:

在这里插入图片描述

随机颜色

这种一般是用在动态展示不同关键词的时候,比如说关键词云图(echarts-wordcloud),首先是定义一个生成随机颜色的函数

const randomRGB = () => {
  const r = Math.floor(Math.random() * 255);
  const g = Math.floor(Math.random() * 255);
  const b = Math.floor(Math.random() * 255);
  return `rgb(${r},${g},${b})`;
};

使用的时候直接在 color 调用即可

// 例如
textStyle: {
  color: randomRGB;
}

//完整的series配置
series: [
  {
    type: "wordCloud",
    sizeRange: [8, 46],
    rotationRange: [0, 0],
    gridSize: 0,
    layoutAnimation: true,
    textStyle: {
      color: randomColor
    },
    emphasis: {
      testStyle: {
        fontWeight: "bold",
        color: "#ffffff"
      }
    },
    data: props.data.datas
  }
];

效果图:

在这里插入图片描述

总结

综上所述,主要通过直接赋值、回调函数静态映射和回调函数动态生成(包括渐变色)这几种方式来设置不同柱子的不同颜色。具体采用哪种方法取决于需求的复杂度和个性化程度,我相信总有一款适合你。

最后,推荐一个前端实用的网站CSS 可视化,好多实用工具,就配色而言推荐一个他的配色方案
不同颜色。具体采用哪种方法取决于需求的复杂度和个性化程度,我相信总有一款适合你。
