chebnet介绍与实现

原理

论文：“Convolutional Neural Networks on Graphs with Fast Localized Spectral Filtering”
卷积公式：

参数说明：

$\hat{L}$ 表示缩放和标准化的拉普拉斯矩阵：$\frac{2L}{{\lambda }_{max}}-I$
${\lambda }_{max}$是L分解出的最大特征值, $I$是单位矩阵。
思想：其实仔细观察$Z^{(k)}$,可以发现当K=1时，chebnet的卷积公式就退化成了GCN：

也就是说GCN是K=1的chebnet，是一种chebbnet的一种简化。而chebnet,来自于拉普拉斯的切比雪夫多项式形式，有兴趣可以自行了解，学过高数的都知道，对一个函数进行级数分解，往往只需要前面1~3项就可以很精确了，因此实际使用中，我们的K也不会很大，基本就是2-3的样子。

说明

对于PyG类：torch_geometric.nn.chebConv
只实现核心功能。
我的输入为：我的输入：data={“graph”:adj[N,N],“flow_x”:features[B,N,D,H]} B和H 可以是1

代码

class ChebConv1(nn.Module):
    """
    The ChebNet convolution operation.

    :param in_c: int, number of input channels.
    :param out_c: int, number of output channels.
    :param K: int, the order of Chebyshev Polynomial.
    """
    def __init__(self, in_c, out_c, K, bias=True, normalize=True):
        super(ChebConv, self).__init__()
        self.normalize = normalize

        self.weight = nn.Parameter(torch.Tensor(K + 1, 1, in_c, out_c))  # [K+1, 1, in_c, out_c]
        init.xavier_normal_(self.weight)

        if bias:
            self.bias = nn.Parameter(torch.Tensor(1, 1, out_c))
            init.zeros_(self.bias)
        else:
            self.register_parameter("bias", None)

        self.K = K + 1

    def forward(self, inputs, graph):
        """
        :param inputs: the input data, [B, N, C]
        :param graph: the graph structure, [N, N]
        :return: convolution result, [B, N, D]
        """
        L = ChebConv1.get_laplacian(graph, self.normalize)  # [N, N]
        mul_L = self.cheb_polynomial(L).unsqueeze(1)   # [K, 1, N, N]

        result = torch.matmul(mul_L, inputs)  # [K, B, N, C]
        result = torch.matmul(result, self.weight)  # [K, B, N, D]
        result = torch.sum(result, dim=0) + self.bias  # [B, N, D]

        return result
	# 将Z一次性计算出来，存到列表中备用
    def cheb_polynomial(self, laplacian):
        """
        Compute the Chebyshev Polynomial, according to the graph laplacian.

        :param laplacian: the graph laplacian, [N, N].
        :return: the multi order Chebyshev laplacian, [K, N, N].
        """
        N = laplacian.size(0)  # [N, N]
        multi_order_laplacian = torch.zeros([self.K, N, N], device=laplacian.device, dtype=torch.float)  # [K, N, N]
        multi_order_laplacian[0] = torch.eye(N, device=laplacian.device, dtype=torch.float)

        if self.K == 1:
            return multi_order_laplacian
        else:
            multi_order_laplacian[1] = laplacian
            if self.K == 2:
                return multi_order_laplacian
            else:
                for k in range(2, self.K):
                    multi_order_laplacian[k] = 2 * torch.mm(laplacian, multi_order_laplacian[k-1]) - \
                                               multi_order_laplacian[k-2]

        return multi_order_laplacian

    @staticmethod
    def get_laplacian(graph, normalize):
        """
        return the laplacian of the graph.

        :param graph: the graph structure without self loop, [N, N].
        :param normalize: whether to used the normalized laplacian.
        :return: graph laplacian.
        """
        if normalize:
            D = torch.diag(torch.sum(graph, dim=-1) ** (-1 / 2))
            L = torch.eye(graph.size(0), device=graph.device, dtype=graph.dtype) - torch.mm(torch.mm(D, graph), D)
        else:
            D = torch.diag(torch.sum(graph, dim=-1))
            L = D - graph
        return L
class ChebNet1(nn.Module):
    def __init__(self, in_c, hid_c, out_c, K):
        """
        :param in_c: int, number of input channels.
        :param hid_c: int, number of hidden channels.
        :param out_c: int, number of output channels.
        :param K:
        """
        super(ChebNet1, self).__init__()
        self.conv1 = ChebConv1(in_c=in_c, out_c=hid_c, K=K)
        self.conv2 = ChebConv1(in_c=hid_c, out_c=out_c, K=K)
        self.act = nn.ReLU()

    def forward(self, data, device):
        graph_data = data["graph"].to(device)[0]  # [N, N]
        flow_x = data["flow_x"].to(device)  # [B, N, H, D]

        B, N = flow_x.size(0), flow_x.size(1)

        flow_x = flow_x.view(B, N, -1)  # [B, N, H*D]

        output_1 = self.act(self.conv1(flow_x, graph_data))
        output_2 = self.act(self.conv2(output_1, graph_data))

        return output_2.unsqueeze(2)

总结

chebNet 比GCN稍微复杂一些，主要是Z值得计算比较麻烦一些。
