正文

for cur in cont:

   if cv2.contourArea(cur) < 10000:

       continue

   var_motion = 1

   (cur_x, cur_y,cur_w, cur_h) = cv2.boundingRect(cur)



   # To create a rectangle of green color around the moving object

   cv2.rectangle(cur_frame, (cur_x, cur_y), (cur_x + cur_w, cur_y + cur_h), (0, 255, 0), 3)

from the frame adding the motion status

motionTrackList.append(var_motion)

motionTrackList = motionTrackList[-2:]

Adding the Start time of the motion

if motionTrackList[-1] == 1 and motionTrackList[-2] == 0:

   motionTime.append(datetime.now())

Adding the End time of the motion

if motionTrackList[-1] == 0 and motionTrackList[-2] == 1:

   motionTime.append(datetime.now())

In the gray scale displaying the captured image

cv2.imshow("The image captured in the Gray Frame is shown below: ", gray_frame)

To display the difference between inital static frame and the current frame

cv2.imshow("Difference between the inital static frame and the current frame: ", differ_frame)

To display on the frame screen the black and white images from the video

cv2.imshow("Threshold Frame created from the PC or Laptop Webcam is: ", thresh_frame)

Through the colour frame displaying the contour of the object

cv2.imshow(“From the PC or Laptop webcam, this is one example of the Colour Frame:”, cur_frame)

Creating a key to wait

wait_key = cv2.waitKey(1)

With the help of the ‘m’ key ending the whole process of our system

if wait_key == ord(‘m’):

   # adding the motion variable value to motiontime list when something is moving on the screen

   if var_motion == 1:

       motionTime.append(datetime.now())

   break


#### 完成代码


关闭循环后，我们会将 dataFrame 和 motionTime 列表中的数据添加到 CSV 文件中，最后关闭视频。

At last we are adding the time of motion or var_motion inside the data frame

for a in range(0, len(motionTime), 2):

dataFrame = dataFrame.append({“Initial” : time[a], “Final” : motionTime[a + 1]}, ignore_index = True)

To record all the movements, creating a CSV file

dataFrame.to_csv(“EachMovement.csv”)

Releasing the video

video.release()

Now, Closing or destroying all the open windows with the help of openCV

cv2.destroyAllWindows()


### **流程总结**


我们已经创建了代码；现在让我们再次简要讨论该过程。


首先，我们使用设备的网络摄像头拍摄视频，然后将输入视频的初始帧作为参考，并不时检查下一帧。如果找到与第一个不同的帧，则存在运动。这将在绿色矩形中标记。


### **组合代码**


我们已经在不同的部分看到了代码。现在，让我们结合起来：

Importing the Pandas libraries

import pandas as panda

Importing the OpenCV libraries

import cv2

Importing the time module

import time

Importing the datetime function of the datetime module

from datetime import datetime

Assigning our initial state in the form of variable initialState as None for initial frames

initialState = None

List of all the tracks when there is any detected of motion in the frames

motionTrackList= [ None, None ]

A new list ‘time’ for storing the time when movement detected

motionTime = []

Initialising DataFrame variable ‘dataFrame’ using pandas libraries panda with Initial and Final column

dataFrame = panda.DataFrame(columns = [“Initial”, “Final”])

starting the webCam to capture the video using cv2 module

video = cv2.VideoCapture(0)

using infinite loop to capture the frames from the video

while True:

Reading each image or frame from the video using read function

check, cur_frame = video.read()

Defining ‘motion’ variable equal to zero as initial frame

var_motion = 0

From colour images creating a gray frame

gray_image = cv2.cvtColor(cur_frame, cv2.COLOR_BGR2GRAY)

To find the changes creating a GaussianBlur from the gray scale image

gray_frame = cv2.GaussianBlur(gray_image, (21, 21), 0)

For the first iteration checking the condition

we will assign grayFrame to initalState if is none

if initialState is None:

   initialState = gray_frame

   continue

Calculation of difference between static or initial and gray frame we created

differ_frame = cv2.absdiff(initialState, gray_frame)

the change between static or initial background and current gray frame are highlighted

thresh_frame = cv2.threshold(differ_frame, 30, 255, cv2.THRESH_BINARY)[1]

thresh_frame = cv2.dilate(thresh_frame, None, iterations = 2)

For the moving object in the frame finding the coutours

cont,_ = cv2.findContours(thresh_frame.copy(),

                  cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE)
