非极大值抑制Python代码（Non-Maximum Suppression for Object Detection in Python）

非极大值抑制（NMS）：抑制不是极大值的元素，可以理解为局部最大搜索，这个局部代表一个邻域，邻域有两个参数可调节：一为邻域的维数，二为邻域的大小。行人检测后期，对检测出的窗口要执行非极大值抑制进行窗口的融合，从而过滤掉一些内部窗口等，达到窗口融合效果，从而使检测的准确率更高。
Histogram of Oriented Gradients for Objection Detection的原理可以被分解成6部分：

1. 正类图像取样
2. 负类图像取样
3. 训练一个线性SVM分类器
4. 执行hard-negative mining（不会翻）
5. 用hard-negative样本从新训练你的SVM分类器
6. 在你的测试集评估你的分类器，用非极大值抑制算法去忽视多余的、重叠的bounding boxes。
   这些步之后，你将的到一个很棒的物体检测器


NMS实现
一个向量化的实现：

#coding:utf-8
import numpy as np

def py_cpu_nms(dets, thresh):
    """Pure Python NMS baseline."""
    x1 = dets[:, 0]#第0列
    y1 = dets[:, 1]
    x2 = dets[:, 2]
    y2 = dets[:, 3]
    scores = dets[:, 4]

    areas = (x2 - x1 + 1) * (y2 - y1 + 1)
#从大到小排列，取index
    order = scores.argsort()[::-1]
#keep为最后保留的边框
    keep = []
    while order.size > 0:
#order[0]是当前分数最大的窗口，之前没有被过滤掉，肯定是要保留的
        i = order[0]
        keep.append(i)
#计算窗口i与其他所以窗口的交叠部分的面积
        xx1 = np.maximum(x1[i], x1[order[1:]])
        yy1 = np.maximum(y1[i], y1[order[1:]])
        xx2 = np.minimum(x2[i], x2[order[1:]])
        yy2 = np.minimum(y2[i], y2[order[1:]])

        w = np.maximum(0.0, xx2 - xx1 + 1)
        h = np.maximum(0.0, yy2 - yy1 + 1)
        inter = w * h
#交/并得到iou值
        ovr = inter / (areas[i] + areas[order[1:]] - inter)
#ind为所有与窗口i的iou值小于threshold值的窗口的index，其他窗口此次都被窗口i吸收
        inds = np.where(ovr <= thresh)[0]
#下一次计算前要把窗口i去除，所有i对应的在order里的位置是0，所以剩下的加1
        order = order[inds + 1]

    return keep

import numpy as np
def non_max_suppression_slow(boxes, overlapThresh):
    # if there are no boxes, return an empty list，图片中没有生成box，返回空列表
    if len(boxes) == 0:
        return []

    # initialize the list of picked indexes
    pick = []

    # grab the coordinates of the bounding boxes
    x1 = boxes[:,0]
    y1 = boxes[:,1]
    x2 = boxes[:,2]
    y2 = boxes[:,3]

    # compute the area of the bounding boxes and sort the bounding
    # boxes by the bottom-right y-coordinate of the bounding box
    area = (x2 - x1 + 1) * (y2 - y1 + 1)
    idxs = np.argsort(y2)

    # keep looping while some indexes still remain in the indexes
    # list
    while len(idxs) > 0:
        # grab the last index in the indexes list, add the index
        # value to the list of picked indexes, then initialize
        # the suppression list (i.e. indexes that will be deleted)
        # using the last index
        last = len(idxs) - 1
        i = idxs[last]
        pick.append(i)
        suppress = [last]

        # loop over all indexes in the indexes list
        for pos in xrange(0, last):
            # grab the current index
            j = idxs[pos]

            # find the largest (x, y) coordinates for the start of
            # the bounding box and the smallest (x, y) coordinates
            # for the end of the bounding box
            xx1 = max(x1[i], x1[j])
            yy1 = max(y1[i], y1[j])
            xx2 = min(x2[i], x2[j])
            yy2 = min(y2[i], y2[j])

            # compute the width and height of the bounding box
            w = max(0, xx2 - xx1 + 1)
            h = max(0, yy2 - yy1 + 1)

            # compute the ratio of overlap between the computed
            # bounding box and the bounding box in the area list
            overlap = float(w * h) / area[j]

            # if there is sufficient overlap, suppress the
            # current bounding box
            if overlap > overlapThresh:
                suppress.append(pos)

        # delete all indexes from the index list that are in the
        # suppression list
        idxs = np.delete(idxs, suppress)

    # return only the bounding boxes that were picked
    return boxes[pick]
