ICC2与INNOVUS命令对照表

ICC2与INNOVUS命令对照表

Target	ICC2	INNOVUS
设置多CPU	set_host_options -max_cores16	setMultiCpuUsage -localCpu 16
获得物体的属性	get_attribute	get_property dbGet或get_db
报告物体的属性	report_attr -application -class $class $object	report_property
获得Net的routing rule	get_attr [get_netsxxx] routing_rule	get_db net:$net_name .route_rule.name
获得Instance的ref name	get_attr [get_cells $inst_name] ref_name	get_db inst:$inst_name .base_cell.name get_property [get_cells $inst_name] ref_name
定义proc的属性和参数	define_proc_attributes	define_proc_arguments
获取选中的物体名称	get_selection	dbGet selected get_db selected
取消选中的所有物体	change_selection -remove	deselectAll
选中物体	change_selection [get_xxx]	select_obj selectInst|selectNet
移动选中的物体	editMove -dx $x -dy $y	move_objects -delta "$x $y" [get_selection]
删除指定的PG Stripe/Ring/…	ICC2:remoe_routes -ring/-stripe	editDelete-shape
创建Placement blockage	create_placement_blockage	createPlaceBlockage
创建Routing Blockage	create_routing_blockage	createRouteBlk
报告timing	report_timing -delay_type max/min	report_timing -late/early
报告指定path group的 Timing	report_timing -groups	report_timing -path_group
报告Timing的时候展开 Clock path	report_timing-path_type full_clock_expanded	report_timing -path_type full_clock
报告PBA mode的timing ,mode选择Path或者 exhaustive	report_timing-pba_mode path|exhaustive	report_timing -retime_mode exhaustive/path -retime path_slew_propagation
报告Timing path的一些 属性	get_attr [get_timing_paths xxx] attr_name	get_property [report_timing -collection] attr_name get_db [report_timing -collection] .XXX
设置Path margin/slack adjustment	set_path_margin	set_path_adjust
GUI里面添加注释/标注等	gui_add_annotation	add_gui_shape
删除GUI里面添加的注释/ 标注	gui_remove_all_annotations	delete_gui_object
取消所有高亮	gui_change_highlight -remove  -all_colors	dehighlight -all
对shape进行几何运算	compute_polygons	dbShape
创建Floorplan	initialize_floorplan	floorPlan
添加Tap cell	ICC2:create_tap_cells	addWellTap
添加End Cap	ICC2:create_boundary_cells	addEndCap
布局/Place	place_opt	place_opt_design
对Cell进行legalize	legalize_placement	refinePlace
检查布局是否legal	checkPlace	checkPlace
Magnet place	place_connected	place_connected
CTS	clock_opt	ccopt_design
Route	route_auto	routeDesign -globalDetail
添加Filler	ICC2:create_stdcell_fillers	addFiller
ECO route	route_eco	ecoRoute
保存设计	save_block save_lib	saveDesign
禁止Register被MBFF merge	set_multibit_options -exclude [get_cells xxx]	dbSet [dbGetInstByName  <flip name> ].dontMergeMultibit 1 set_db [get_dbinst: .dont_merge_multibit1
使能ICG Clone/Split	set_app_options -name place_opt.flow.optimize_icgs  -value true 或者split_clock_gates	set_ccopt_property clone_clock_gates true/false set_db cts_clone_clock_gates true/false
对一些Net设置Skip绕线	set_attribute -objects [get_nets $net_name] -name physical_status -value locked	setAttribute-net$net_name -skip_routingtrue
只绕一些指定的nets	ICC2: route_group -nets $collection_of_critical_nets route_group -from_file $file_name	selectNet xxx setNanoRouteMode -quiet -routeSelectedNetOnly 1 routeDesign -globalDetail
检查天线效应	ICC2: check_routes -antenna true #default就是true	verifyProcessAntenna
检查DRC	ICC2: check_routes	set_verify_drc_mode verify_drc
检查LVS	ICC2: check_Ivs	verifyConnectivity
