grad cam的直接使用【实测成功】

仅作为记录，大佬请跳过。

完全参考大佬github：传送门

所有代码

import os
os.environ["CUDA_VISIBLE_DEVICES"] = '2/'
import cv2
import numpy as np
import torch
import torch.nn as nn
from PIL import Image
from torchvision import transforms
from torchvision import models
import matplotlib.pyplot as plt


class ActivationsAndGradients:
    """ Class for extracting activations and
    registering gradients from targeted intermediate layers """

    def __init__(self, model, target_layers, reshape_transform):
        self.model = model
        self.gradients = []
        self.activations = []
        self.reshape_transform = reshape_transform
        self.handles = []
        for target_layer in target_layers:
            self.handles.append(
                target_layer.register_forward_hook(
                    self.save_activation))
            # Backward compatibility with older pytorch versions:
            if hasattr(target_layer, 'register_full_backward_hook'):
                self.handles.append(
                    target_layer.register_full_backward_hook(
                        self.save_gradient))
            else:
                self.handles.append(
                    target_layer.register_backward_hook(
                        self.save_gradient))

    def save_activation(self, module, input, output):
        activation = output
        if self.reshape_transform is not None:
            activation = self.reshape_transform(activation)
        self.activations.append(activation.cpu().detach())

    def save_gradient(self, module, grad_input, grad_output):
        # Gradients are computed in reverse order
        grad = grad_output[0]
        if self.reshape_transform is not None:
            grad = self.reshape_transform(grad)
        self.gradients = [grad.cpu().detach()] + self.gradients

    def __call__(self, x):
        self.gradients = []
        self.activations = []
        return self.model(x)

    def release(self):
        for handle in self.handles:
            handle.remove()


class GradCAM:
    def __init__(self, model, target_layers, reshape_transform=None):
        self.model = model.eval()
        self.target_layers = target_layers
        self.reshape_transform = reshape_transform
        self.activations_and_grads = ActivationsAndGradients(
            self.model, target_layers, reshape_transform)

    """ Get a vector of weights for every channel in the target layer.
        Methods that return weights channels,
        will typically need to only implement this function. """

    @staticmethod
    def get_cam_weights(grads):
        return np.mean(grads, axis=(2, 3), keepdims=True)

    @staticmethod
    def get_loss(output, target_category):
        loss = 0
        for i in range(len(target_category)):
            loss = loss + output[i, target_category[i]]
        return loss

    def get_cam_image(self, activations, grads):
        weights = self.get_cam_weights(grads)
        weighted_activations = weights * activations
        cam = weighted_activations.sum(axis=1)

        return cam

    @staticmethod
    def get_target_width_height(input_tensor):
        width, height = input_tensor.size(-1), input_tensor.size(-2)
        return width, height

    def compute_cam_per_layer(self, input_tensor):
        activations_list = [a.cpu().data.numpy()
                            for a in self.activations_and_grads.activations]
        grads_list = [g.cpu().data.numpy()
                      for g in self.activations_and_grads.gradients]
        target_size = self.get_target_width_height(input_tensor)

        cam_per_target_layer = []
        # Loop over the saliency image from every layer

        for layer_activations, layer_grads in zip(activations_list, grads_list):
            cam = self.get_cam_image(layer_activations, layer_grads)
            cam[cam < 0] = 0  # works like mute the min-max scale in the function of scale_cam_image
            scaled = self.scale_cam_image(cam, target_size)
            cam_per_target_layer.append(scaled[:, None, :])

        return cam_per_target_layer

    def aggregate_multi_layers(self, cam_per_target_layer):
        cam_per_target_layer = np.concatenate(cam_per_target_layer, axis=1)
        cam_per_target_layer = np.maximum(cam_per_target_layer, 0)
        result = np.mean(cam_per_target_layer, axis=1)
        return self.scale_cam_image(result)

    @staticmethod
    def scale_cam_image(cam, target_size=None):
        result = []
        for img in cam:
            img = img - np.min(img)
            img = img / (1e-7 + np.max(img))
            if target_size is not None:
                img = cv2.resize(img, target_size)
            result.append(img)
        result = np.float32(result)

        return result

    def __call__(self, input_tensor, target_category=None):

        # 正向传播得到网络输出logits(未经过softmax)
        output = self.activations_and_grads(input_tensor)
        if isinstance(target_category, int):
            target_category = [target_category] * input_tensor.size(0)

        if target_category is None:
            target_category = np.argmax(output.cpu().data.numpy(), axis=-1)
            print(f"category id: {target_category}")
        else:
            assert (len(target_category) == input_tensor.size(0))

        self.model.zero_grad()
        loss = self.get_loss(output, target_category)
        loss.backward(retain_graph=True)

        # In most of the saliency attribution papers, the saliency is
        # computed with a single target layer.
        # Commonly it is the last convolutional layer.
        # Here we support passing a list with multiple target layers.
        # It will compute the saliency image for every image,
        # and then aggregate them (with a default mean aggregation).
        # This gives you more flexibility in case you just want to
        # use all conv layers for example, all Batchnorm layers,
        # or something else.
        cam_per_layer = self.compute_cam_per_layer(input_tensor)
        return self.aggregate_multi_layers(cam_per_layer)

    def __del__(self):
        self.activations_and_grads.release()

    def __enter__(self):
        return self

    def __exit__(self, exc_type, exc_value, exc_tb):
        self.activations_and_grads.release()
        if isinstance(exc_value, IndexError):
            # Handle IndexError here...
            print(
                f"An exception occurred in CAM with block: {exc_type}. Message: {exc_value}")
            return True


def show_cam_on_image(img: np.ndarray,
                      mask: np.ndarray,
                      use_rgb: bool = False,
                      colormap: int = cv2.COLORMAP_JET) -> np.ndarray:
    """ This function overlays the cam mask on the image as an heatmap.
    By default the heatmap is in BGR format.
    :param img: The base image in RGB or BGR format.
    :param mask: The cam mask.
    :param use_rgb: Whether to use an RGB or BGR heatmap, this should be set to True if 'img' is in RGB format.
    :param colormap: The OpenCV colormap to be used.
    :returns: The default image with the cam overlay.
    """

    heatmap = cv2.applyColorMap(np.uint8(255 * mask), colormap)
    if use_rgb:
        heatmap = cv2.cvtColor(heatmap, cv2.COLOR_BGR2RGB)
    heatmap = np.float32(heatmap) / 255

    if np.max(img) > 1:
        raise Exception(
            "The input image should np.float32 in the range [0, 1]")

    cam = heatmap + img
    cam = cam / np.max(cam)
    return np.uint8(255 * cam)


def image_proprecess(img_path):
    img = Image.open(img_path)
    data_transforms = transforms.Compose([
        transforms.Resize((384, 384), interpolation=3),
        transforms.ToTensor(),
        transforms.Normalize([0.485, 0.456, 0.406], [0.229, 0.224, 0.225])
        ])
    data = data_transforms(img)
    data = torch.unsqueeze(data,0)
    img_resize = img.resize((384,384))
    return img_resize,data

def Init_Setting():
    model = models.mobilenet_v3_large(pretrained=True)
    #model.load_state_dict(torch.load('model.pth'))
    model = model.cuda().eval()
    return model


if __name__ == "__main__":
    imgs_path = "/dataset/gramcamtool/img/image.png"
    model = Init_Setting()
    target_layers = [model.features[-1]]
    img, data = image_proprecess(imgs_path)

    cam = GradCAM(model=model, target_layers=target_layers)
    target_category = None

    data = data.cuda()
    grayscale_cam = cam(input_tensor=data, target_category=target_category)
    grayscale_cam = grayscale_cam[0, :]
    visualization = show_cam_on_image(np.array(img) / 255.,
                                      grayscale_cam,
                                      use_rgb=True)
    plt.imshow(visualization)
    plt.xticks()
    plt.yticks()
    plt.axis('off')
    plt.savefig("/dataset/gramcamtool/img/gradcam_image.jpg")

数据

该.py路径的img文件夹中，放入image.png。
博主选择的图像来源：传送门。

运行即可

展示
