Linux 系统管理高级教程（九）

:

$ uptime
12:51:04 up 116 days, 7:09, 3 users, load average: 0.01, 0.07, 0.02
Listing 17-1.The uptime Command

$ free -h
               total        used        free      shared       buff/cache     available
Mem:           3.1G         59M         2.7G      13M          350M           2.8G
Swap:          1.5G         0B          1.5G
Listing 17-2.The free Command

$ top

$ ps aux |grep Z
USER    PID    %CPU %MEM   VSZ   RSS   TTY     STAT    START   TIME   COMMAND
ubuntu  7814   0.0  0.0    0     0     pts/0   Z+      11:52   0:00   [zombie] <defunct>

procs - ---------memory------------- ---swap-- ---io--- --system-- ------cpu-----
 r  b   swpd   free     buff  cache   si   so    bi    bo    in    cs     us sy id wa st
 0  0   422336 750352   8252 130736    0    0     0     0     27   56     0  0 100  0  0
 0  0   422332 750352   8252 130736    1    0     1     0     27   55     0  0 100  0  0

$ dd if=/dev/zero of=./largefile bs=1M count=1024

$ sudo yum install collectd collectd-mysql

$ sudo aptitude install collectd

global options

# plugin without options
LoadPlugin plugin_name
# loading a plugin and overriding options
<LoadPlugin plugin_name>
    ...plugin options...
</LoadPlugin>
# provide an option block to plugins without a LoadPlugin stanza (requires AutoLoadPlugin true)
<Plugin plugin_name>
    ... plugin options...
</Plugin>

#Hostname "localhost"
FQDNLookup true
#BaseDir "/var/lib/collectd"
#PluginDir "/usr/lib/collectd"
#TypesDB "/usr/share/collectd/types.db" "/etc/collectd/my_types.db"
#AutoLoadPlugin false
#CollectInternalStats false
#Interval 10
#MaxReadInterval 86400
#Timeout         2
#ReadThreads     5
#WriteThreads    5
#WriteQueueLimitHigh 1000000
#WriteQueueLimitLow   800000
Listing 17-3.collectd.conf Configuration Global Options

LoadPlugin syslog
<Plugin syslog>
    LogLevel info
</Plugin>

LoadPlugin cpu
LoadPlugin df
LoadPlugin disk
LoadPlugin interface
LoadPlugin load
LoadPlugin memory
LoadPlugin mysql
LoadPlugin swap
LoadPlugin rrdtool

<Plugin cpu>
    ReportByCpu true
    ReportByState true
    ValuesPercentage false
</Plugin>

<Plugin df>
    FSType rootfs
    FSType sysfs
    FSType proc
    FSType devtmpfs
    FSType devpts
    FSType tmpfs
    FSType fusectl
    FSType cgroup
    IgnoreSelected true
</Plugin>

<Plugin disk>
    Disk "/^(xv)?[hs]?d[a-z]\d?$/"
    IgnoreSelected false
    UseBSDName false
    UdevNameAttr "DEVNAME"
</Plugin>

/dev/sda2
/dev/hdb4
/dev/xvda3

<Plugin interface>
    Interface "localhost"
    IgnoreSelected true
</Plugin>

<Plugin load>
    ReportRelative true
</Plugin>

<Plugin memory>
    ValuesAbsolute true
    ValuesPercentage false
</Plugin>

<Plugin mysql>
    <Database no_db>
        Host "localhost"
        Port "3306"
        User “monitor"
        Password “monitorpasswd"
        ConnectTimeout 10
        InnodbStats true
    </Database>
</Plugin>

<Plugin rrdtool>
    DataDir "/var/lib/collectd/rrd"
    CacheTimeout 120
    CacheFlush 900
    WritesPerSecond 30
    CreateFilesAsync false
    RandomTimeout 0
</Plugin>

<Include "/etc/collectd/collectd.conf.d">
    Filter "*.conf"
</Include>

$ sudo systemctl start collectd
$ sudo systemctl status collectd
$ sudo systemctl enable collectd

-- Unit collectd.service has begun starting up.
Nov 15 21:55:26 backup collectd[8000]: plugin_load: plugin "syslog" successfully loaded.
Nov 15 21:55:26 backup collectd[8000]: plugin_load: plugin "cpu" successfully loaded.
Nov 15 21:55:26 backup collectd[8000]: plugin_load: plugin "interface" successfully loaded.
Nov 15 21:55:26 backup collectd[8000]: plugin_load: plugin "load" successfully loaded.
Nov 15 21:55:26 backup collectd[8000]: plugin_load: plugin "memory" successfully loaded.
Nov 15 21:55:26 backup collectd[8000]: plugin_load: plugin "mysql" successfully loaded.
Nov 15 21:55:26 backup collectd[8000]: plugin_load: plugin "rrdtool" successfully loaded.
Nov 15 21:55:26 backup collectd[8000]: Systemd detected, trying to signal readyness.
Nov 15 21:55:26 backup collectd[8000]: Initialization complete, entering read-loop.
Nov 15 21:55:26 backup systemd[1]: Started Collectd statistics daemon.
-- Subject: Unit collectd.service has finished start-up
-- Defined-By: systemd
-- Support: http://lists.freedesktop.org/mailman/listinfo/systemd-devel
--
-- Unit collectd.service has finished starting up.
--
-- The start-up result is done.
Nov 15 21:55:26 backup collectd[8000]: mysql plugin: Successfully connected to database <none> at server Localhost via UNIX socket with cipher <none> (server version: 5.5.50-MariaDB, protocol version: 10)

$ sudo yum install -y python-carbon

$ sudo yum install –y graphite-api

$ sudo aptitude install -y graphite-carbon

$ sudo aptitude install –y graphite-api

[cache]
STORAGE_DIR    = /var/lib/graphite/
LOCAL_DATA_DIR = /var/lib/graphite/whisper/
CONF_DIR       = /etc/carbon/
LOG_DIR        = /var/log/carbon/
PID_DIR        = /var/run/
ENABLE_LOGROTATION = False
USER = _graphite

ENABLE_UDP_LISTENER = False
UDP_RECEIVER_INTERFACE = 0.0.0.0
MAX_CACHE_SIZE = inf
MAX_UPDATES_PER_SECOND = 500
MAX_CREATES_PER_MINUTE = 50
CACHE_WRITE_STRATEGY = sorted
WHISPER_AUTOFLUSH = False
WHISPER_FALLOCATE_CREATE = True
USE_FLOW_CONTROL = True
LOG_LISTENER_CONNECTIONS = True
LOG_UPDATES = False
LOG_CACHE_HITS = False
LOG_CACHE_QUEUE_SORTS = True
USE_INSECURE_UNPICKLER = False
Listing 17-4.Default Carbon-Cache Settings

LINE_RECEIVER_INTERFACE = 0.0.0.0
PICKLE_RECEIVER_INTERFACE = 0.0.0.0
CACHE_QUERY_INTERFACE = 0.0.0.0
LINE_RECEIVER_PORT = 2003
PICKLE_RECEIVER_PORT = 2004
CACHE_QUERY_PORT = 7002

[cache:1]
LINE_RECEIVER_PORT = 2103
PICKLE_RECEIVER_PORT = 2104

[carbon]
pattern = ^carbon\.
retentions = 60s:90d

[default_1min_for_1day]
pattern = .*
retentions = 60s:1d

carbon.agents.host1.cache.queries

[database_metrics]
pattern = ^collectd_(db|backup)_*
retentions = 15s:7d,1m:90d,15m:180d

[cache]
STORAGE_DIR    = /var/lib/graphite/
LOCAL_DATA_DIR = /var/lib/graphite/whisper/
CONF_DIR       = /etc/carbon/
LOG_DIR        = /var/log/carbon/
PID_DIR        = /var/run/
ENABLE_LOGROTATION = False
USER = carbon
LOG_LISTENER_CONNECTIONS = True
USE_INSECURE_UNPICKLER = False
USE_FLOW_CONTROL = True
CACHE_WRITE_STRATEGY = sorted

[relay]
LINE_RECEIVER_INTERFACE = 0.0.0.0
PICKLE_RECEIVER_INTERFACE = 0.0.0.0
LINE_RECEIVER_PORT = 2013
PICKLE_RECEIVER_PORT = 2014
DESTINATIONS = monitor.example.com:2004
LOG_LISTENER_CONNECTIONS = True
RELAY_METHOD = rules
MAX_DATAPOINTS_PER_MESSAGE = 500
MAX_QUEUE_SIZE = 10000
QUEUE_LOW_WATERMARK_PCT = 0.8
USE_FLOW_CONTROL = True

[default]
default = true
destinations = monitor.example.com:2004

[backup_example]
pattern = ^collectd_backup_example_com\.*
destination = 192.168.0.250:2004
continue = true

$ sudo systemctl start carbon-relay

$ sudo systemctl start carbon-relay@default

LoadPlugin write_graphite

<Plugin write_graphite>
  <Node "monitor">
    Host "relay.example.com"
    Port "2013"
    Protocol "tcp"
    ReconnectInterval 0
    LogSendErrors true
    Prefix "collectd_"
    StoreRates true
    AlwaysAppendDS false
    EscapeCharacter "_"
  </Node>
</Plugin>

$ sudo getsebool collectd_tcp_network_connect
collectd_tcp_network_connect --> off
$ sudo setsebool collectd_tcp_network_connect on

Nov 22 23:19:06 backup collectd[5999]: plugin_load: plugin "write_graphite" successfully loaded.

22/11/2016 12:29:56 :: MetricLineReceiver connection with 192.168.0.30:38309 established

20/11/2016 10:19:03 :: MetricPickleReceiver connection with 192.168.0.251:52146 established

21/11/2016 11:35:48 :: new metric collectd_backup_example_com.cpu-0.cpu-user matched schema default_1min_for_1day

$ sudo pip3 install gunicorn

$ ln –s /usr/local/bin/gunicorn /usr/bin/gunicorn

[Unit]
Description=graphite-api socket

[Socket]
ListenStream=/run/graphite-api.sock
ListenStream=127.0.0.1:8881

[Install]
WantedBy=sockets.target

[Unit]
Description=Graphite-API service
Requires=graphite-api.socket

[Service]
ExecStart=/usr/bin/gunicorn -b 127.0.0.1:8881 -w2 graphite_api.app:app
Restart=on-failure
ExecReload=/bin/kill -s HUP $MAINPID
ExecStop=/bin/kill -s TERM $MAINPID
PrivateTmp=true

[Install]
WantedBy=multi-user.target

$ sudo systemctl start graphite-api.service

upstream graphite {
    server 127.0.0.1:8881 fail_timeout=0;
}

server {
    server_name monitor;
    listen 80;
    root /var/www;

    location / {
        try_files $uri @graphite;
    }

    location @graphite {
        proxy_pass http://graphite;
    }
}

$ sudo ln –s /etc/nginx/sites-available/graphite.conf /etc/nginx/sites-enabled/graphite.conf
$ sudo systemctl start nginx

$ sudo systemctl start nginx

$ curl -H 'Host: monitor' http://127.0.0.1:80/metrics/find?query=*
[{"text": "carbon", "expandable": 1, "allowChildren": 1, "id": "carbon", "leaf": 0}, {"text": "relay", "expandable": 1, "allowChildren": 1, "id": "relay", "leaf": 0}]

$ sudo bash -c 'echo "deb https://packagecloud.io/grafana/stable/debian/ jessie main" > /etc/apt/sources.list.d/grafana.list'
$ curl https://packagecloud.io/gpg.key | sudo apt-key add -
$ sudo aptitude update
$ sudo aptitude install –y grafana

$ sudo systemctl start grafana-server

$ ulimit -u 1
$ ls
bash: fork: Resource temporarily unavailable

$ sysctl –a
abi.vsyscall32 = 1
crypto.fips_enabled = 0
debug.exception-trace = 1
debug.kprobes-optimization = 1
dev.hpet.max-user-freq = 64
dev.mac_hid.mouse_button2_keycode = 97
...
vm.percpu_pagelist_fraction = 0
vm.stat_interval = 1
vm.swappiness = 30
vm.user_reserve_kbytes = 29608
vm.vfs_cache_pressure = 100
vm.zone_reclaim_mode = 0

$ sudo sysctl vm.swappiness
vm.swappiness = 30

$ cat /proc/sys/vm/swappiness
30

$ sudo sysctl -w vm.swappiness=20

$ sudo sysctl -w dev.raid.speed_limit_min=20000

UUID=f87a71b8-a323-4e8e-acc9-efb0758a0642 / ext4 defaults,
   errors=remount-ro,relatime 0 1

$ sudo mount -o remount,relatime /

$sudo tune2fs -l /dev/md0 | grep features
Filesystem features: has_journal ext_attr resize_inode dir_index filetype needs_recovery extent 64bit flex_bg
    sparse_super large_file huge_file uninit_bg dir_nlink extra_isize

sudo tune2fs -O dir_index /dev/md0

sudo tune2fs -O ^dir_index /dev/md0

$ cat /sys/block/sda/queue/scheduler
noop deadline [cfq]

$ sudo bash -c  'echo deadline > /sys/block/sda/queue/scheduler'
$ cat /sys/block/sda/queue/scheduler
noop [deadline] cfq

$ vi /etc/default/grub
GRUB_CMDLINE_LINUX="console=tty0 ... rhgb quiet elevator=deadline"

$ sudo grub2-mkconfig -o /boot/grub2//grub.cfg

$ cat /sys/block/sda/queue/scheduler
noop [deadline] cfq

$ sudo grub2-mkconfig -o /boot/grub/grub2.cfg

$ sudo journalctl
-- Logs begin at Fri 2016-11-25 22:16:00 AEDT, end at Mon 2016-11-28 21:07:54 AEDT. --
Nov 25 22:16:00 au-mel-centos-1 systemd-journal[89]: Runtime journal is using 8.0M...current limit 92.0M).
Nov 25 22:16:00 au-mel-centos-1 systemd-journal[89]: Runtime journal is using 8.0M...current limit 92.0M).
Nov 25 22:16:00 au-mel-centos-1 kernel: Initializing cgroup subsys cpuset
Nov 25 22:16:00 au-mel-centos-1 kernel: Initializing cgroup subsys cpu
Nov 25 22:16:00 au-mel-centos-1 kernel: Initializing cgroup subsys cpuacct
Nov 25 22:16:00 au-mel-centos-1 kernel: Linux version 3.10.0-327.4.5.el7.x86_64 ...CentOS 4.8.3-9) (GCC)...
Nov 25 22:16:00 au-mel-centos-1 kernel: Command line: BOOT_IMAGE=/vmlinuz-3.10.0-327.4.5.el7.x86_64...
Nov 25 22:16:00 au-mel-centos-1 kernel: e820: BIOS-provided physical RAM map:
Listing 18-1.The journalctl Command

$ sudo journalctl –n 10
-- Logs begin at Fri 2016-11-25 22:16:00 AEDT, end at Mon 2016-11-28 21:24:54 AEDT. --
Nov 28 21:01:01 backup run-parts(/etc/cron.hourly)[9627]: starting 0yum-hourly.cron
...
Nov 28 21:24:54 backup sudo[9647]:   bsingh : TTY=pts/0 ; PWD=/home/bsingh ; USER=root ; COMMAND=/bin/journalctl -n 10

$ sudo journalctl -n 1 -o verbose
-- Logs begin at Fri 2016-11-25 22:16:00 AEDT, end at Mon 2016-11-28 21:29:46 AEDT. --
Mon 2016-11-28 21:29:46.407435 AEDT [s=1798dd89d9ff412b8edcc9e7b5cb8484;i=1c0b;b=11ffa7916baa42a89cbbc756af6d26bc;m=2486cb476a;t=54259f362b5ab;x=68026ef74697a39]
    _BOOT_ID=11ffa7916baa42a89cbbc756af6d26bc
    _MACHINE_ID=e3c7fd86ed8b4ef69e569a93e30db6ab
    PRIORITY=5
    _CAP_EFFECTIVE=1fffffffff
    _HOSTNAME=backup
    _TRANSPORT=rsyslog
    SYSLOG_FACILITY=10
    _AUDIT_LOGINUID=1000
    _SYSTEMD_OWNER_UID=1000
    _SYSTEMD_SLICE=user-1000.slice
    SYSLOG_IDENTIFIER=sudo
    _COMM=sudo
    _EXE=/usr/bin/sudo
    _SELINUX_CONTEXT=unconfined_u:unconfined_r:unconfined_t:s0-s0:c0.c1023
    _AUDIT_SESSION=40
    _SYSTEMD_CGROUP=/user.slice/user-1000.slice/session-40.scope
    _SYSTEMD_SESSION=40
    _SYSTEMD_UNIT=session-40.scope
    _UID=1005
    _GID=1006
    MESSAGE=  bsingh : TTY=pts/0 ; PWD=/home/bsingh ; USER=root ; COMMAND=/bin/journalctl -n 1 -o verbose
    _PID=9653
    _CMDLINE=sudo journalctl -n 1 -o verbose
    _SOURCE_REALTIME_TIMESTAMP=1480328986407435
Listing 18-2.Journal Metadata

$ sudo journalctl –k
-- Logs begin at Fri 2016-11-25 22:16:00 AEDT, end at Mon 2016-11-28 22:06:08 AEDT. --
Nov 25 22:16:00 au-mel-centos-1 kernel: Initializing cgroup subsys cpuset
Nov 25 22:16:00 au-mel-centos-1 kernel: Initializing cgroup subsys cpu
...
Nov 28 21:01:01 backup kernel: SELinux: initialized (dev tmpfs, type tmpfs), uses transition SIDs
Nov 28 22:01:01 backup kernel: SELinux: initialized (dev tmpfs, type tmpfs), uses transition SIDs

$ sudo journalctl -p err -k
-- Logs begin at Fri 2016-11-25 22:16:00 AEDT, end at Mon 2016-11-28 22:10:14 AEDT. --
Nov 25 22:16:13 backup kernel: CIFS VFS: Send error in SessSetup = -127
Nov 25 22:16:13 backup kernel: CIFS VFS: cifs_mount failed w/return code = -127
Nov 25 22:17:13 backup kernel: CIFS VFS: Send error in SessSetup = -13

$ sudo journalctl –p info –b

$ sudo journalctl -p info --since "2016-11-28 22:44:00" --until "2016-11-28 22:54:00"

$ sudo journalctl --utc

$ sudo journalctl –F _COMM
unix_chkpwd
request-key
freshclam-sleep
run-parts
pickup
usermod
...

$ sudo journalctl _COMM=usermod -b
-- Logs begin at Fri 2016-11-25 22:16:00 AEDT, end at Mon 2016-11-28 23:09:04 AEDT. --
Nov 25 22:48:41 backup usermod[4844]: add 'jsmith' to group 'sales'
Nov 25 22:48:41 backup usermod[4844]: add 'jsmith' to shadow group 'sales'

$ sudo journalctl -f -u httpd.service
-- Logs begin at Fri 2016-11-25 22:16:00 AEDT. --
Nov 28 23:27:11 backup systemd[1]: Starting The Apache HTTP Server...
Nov 28 23:27:11 backup systemd[1]: Started The Apache HTTP Server.

$ sudo mkdir /var/log/journal
$ sudo systemctl restart systemd-journald

$ sudo journalctl --verify-key 4f5f8f-9eb38b-eff95a-bc0bc8/191914-35a4e900
PASS: /var/log/journal/e3c7fd86ed8b4ef69e569a93e30db6ab/system.journal
PASS: /var/log/journal/e3c7fd86ed8b4ef69e569a93e30db6ab/user-1005.journal

$ sudo vi /etc/systemd/journal-remote.conf
[Remote]
ServerKeyFile=/etc/pki/tls/private/backup.example.com.key
ServerCertificateFile=/etc/pki/tls/certs/backup.example.com.cert
TrustedCertificateFile=/etc/pki/tls/certs/cacert.pem

$ sudo mkdir –p /var/log/journal/remote && sudo chown systemd-journal-remote /var/log/journal/remote

$ sudo firewall-cmd --permanent --zone public --add-port=19532/tcp
$ sudo firewall-cmd --reload

$ sudo systemctl enable systemd-journal-remote
$ sudo systemctl start systemd-journal-remote
$ sudo systemctl status systemd-journal-remote

$ sudo vi /etc/systemd/journal-upload.conf
[Upload]
URL=https://backup.example.com:19532
ServerKeyFile=/etc/pki/tls/private/gateway.example.com.key
ServerCertificateFile=/etc/pki/tls/certs/gateway.example.com.cert
TrustedCertificateFile=/etc/pki/tls/certs/cacert.pem

$ sudo chown systemd-journal-upload /var/lib/systemd/journal-upload
$ sudo usermod –aG systemd-journal systemd-journal-upload

$ sudo systemctl enable systemd-journal-upload
$ sudo systemctl start systemd-journal-upload

[jsmith@backup ∼]$ sudo ls -l /var/log/journal/remote/
total 16388
-rw-r-----. 1 systemd-journal-remote systemd-journal 8388608 Nov 29 22:58 remote-
gateway@3a016bda55334bcd88d8a6fa52b1dc61-0000000000000001-0005426ea713ed3c.journal

Nov 30 00:54:25 backup systemd: Stopping System Logging Service...
Nov 30 00:54:25 backup systemd: Starting System Logging Service...
Nov 30 00:54:28 backup systemd: Started System Logging Service.

#################
#### MODULES ####
#################

module(load="imuxsock") # provides support for local system logging
module(load="imklog")   # provides kernel logging support
#module(load="immark")  # provides --MARK-- message capability

# provides UDP syslog reception
#module(load="imudp")
#input(type="imudp" port="514")

# provides TCP syslog reception
#module(load="imtcp")
#input(type="imtcp" port="514")

# Enable non-kernel facility klog messages
$KLogPermitNonKernelFacility on

###########################
#### GLOBAL DIRECTIVES ####
###########################

#
# Use traditional timestamp format.
# To enable high precision timestamps

, comment out the following line.
#
$ActionFileDefaultTemplate RSYSLOG_TraditionalFileFormat

# Filter duplicated messages
$RepeatedMsgReduction on

#
# Set the default permissions for all log files.
#
$FileOwner syslog
$FileGroup adm
$FileCreateMode 0640
$DirCreateMode 0755
$Umask 0022
$PrivDropToUser syslog
$PrivDropToGroup syslog

#
# Where to place spool and state files
#
$WorkDirectory /var/spool/rsyslog

#
# Include all config files in /etc/rsyslog.d/
#
$IncludeConfig /etc/rsyslog.d/*.conf

#
# First some standard log files.  Log by facility.
#
auth,authpriv.*            /var/log/auth.log
*.*;auth,authpriv.none        -/var/log/syslog
#cron.*                /var/log/cron.log
#daemon.*            -/var/log/daemon.log
kern.*                -/var/log/kern.log
#lpr.*                -/var/log/lpr.log
mail.*                -/var/log/mail.log
#user.*                -/var/log/user.log

#
# Logging for the mail system.  Split it up so that
# it is easy to write scripts to parse these files.
#
#mail.info            -/var/log/mail.info
#mail.warn            -/var/log/mail.warn
mail.err            /var/log/mail.err

#
# Logging for INN news system.
#
news.crit            /var/log/news/news.crit
news.err            /var/log/news/news.err
news.notice            -/var/log/news/news.notice

#
# Some "catch-all" log files.
#
#*.=debug;\
#    auth,authpriv.none;\
#    news.none;mail.none    -/var/log/debug
#*.=info;*.=notice;*.=warn;\
#    auth,authpriv.none;\
#    cron,daemon.none;\
#    mail,news.none        -/var/log/messages

#
# Emergencies are sent to everybody logged in.
#
*.emerg                                :omusrmsg:*

#
# I like to have messages displayed on the console, but only on a virtual
# console I usually leave idle.
#
#daemon,mail.*;\
#    news.=crit;news.=err;news.=notice;\
#    *.=debug;*.=info;\
#    *.=notice;*.=warn    /dev/tty8

# The named pipe /dev/xconsole is for the `xconsole' utility.  To use it,
# you must invoke `xconsole' with the `-file' option:
#
#    $ xconsole -file /dev/xconsole [...]
#
# NOTE: adjust the list below, or you'll go crazy if you have a reasonably
#      busy site..
#
daemon.*;mail.*;\
    news.err;\
    *.=debug;*.=info;\
    *.=notice;*.=warn    |/dev/xconsole

mail.*        -/var/log/mail.log
Listing 18-3.rsyslog.conf Syntax

*.emerg                                :omusrmsg:*
Listing 18-4.rsyslog.conf * Wildcard Selector

kern.none                      /var/log/messages
Listing 18-5.rsyslog.conf none Wildcard Selector

cron.err          /var/log/cron
auth.!=emerg    /dev/lpr1
news.=notice     |/tmp/pipe
auth-priv         root,jsmith
Listing 18-6.File, Device, and Named Pipe Actions

mail     @backup.example.com
Listing 18-7.Logging to a Remote System

*.*     @backup.example.com

$ sudo firewall-cmd --permanent --zone public --add-port=514/udp

*.*    :omrelp:backup.example.com:2514

auth,auth-priv.crit              /var/log/auth
Listing 18-8.Multiple Facilities

auth;auth-priv.debug;auth-priv.!=emerg        /var/log/auth
Listing 18-9.Multiple Priorities

auth                               /var/log/auth
auth.crit                         jsmith
auth.emerg                    /dev/console
Listing 18-10.Logging to Multiple Places

mail.*    action(type="omfile" sync="no" file="/var/log/maillog”)
                   action(type="omfwd" Target="monitor.example.com" Port="10514" Protocol="tcp")

$ sudo yum install –y rsyslog-relp rsyslog-gnutls
$ sudo aptitude install –y rsyslog-relp rsyslog-gnutls

$ sudo setfacl -m u:syslog:rx /etc/ssl/private
$ sudo setfacl -m u:syslog:r /etc/ssl/private/nfs.example.com.key

$ sudo vi /etc/rsyslog.d/relp.conf
# make gtls driver the default
$DefaultNetstreamDriver gtls

# certificate files
$DefaultNetstreamDriverCAFile /etc/pki/tls/certs/cacert.pem
$DefaultNetstreamDriverCertFile /etc/pki/tls/certs/gateway.example.com.cert
$DefaultNetstreamDriverKeyFile /etc/pki/tls/private/gateway.example.com.key

$ActionSendStreamDriverAuthMode x509/name
$ActionSendStreamDriverPermittedPeer backup.example.com
$ActionSendStreamDriverMode 1
*.* @@backup.example.com:6514

$ sudo systemctl restart rsyslog

$ sudo vi /etc/rsyslog.d/relp.conf
$ModLoad imtcp

$DefaultNetstreamDriver gtls

$DefaultNetstreamDriverCAFile /etc/pki/tls/certs/cacert.pem
$DefaultNetstreamDriverCertFile /etc/pki/tls/certs/backup.example.com.cert
$DefaultNetstreamDriverKeyFile /etc/pki/tls/private/backup.example.com.key

$InputTCPServerStreamDriverAuthMode x509/name
$InputTCPServerStreamDriverPermittedPeer *.example.com
$InputTCPServerStreamDriverMode 1
$InputTCPServerRun 6514

$ sudo firewall-cmd --permanent --zone public --add-port=6514/tcp
$ sudo firewall-cmd --reload

$ sudo systemctl restart rsyslog

Dec  1 12:01:17 gateway chronyd[608]: Selected source 27.124.125.250
Dec  1 12:01:19 gateway chronyd[608]: Selected source 27.124.125.250
Dec  1 12:01:21 backup systemd: Starting user-0.slice.
Dec  1 12:01:01 backup systemd: Started Session 143 of user root.
Dec  1 12:05:51 gateway chronyd[608]: Selected source 202.127.210.37
Dec  1 12:08:22 dc1 systemd[1]: Started CUPS Scheduler.

$ sudo systemctl start rsyslog
$ sudo systemctl stop rsyslog
$ sudo systemctl status rsyslog

$ logger -p mail.info "This is a test message for facility mail and priority info"

#!/bin/bash

for f in
{auth,authpriv,cron,daemon,kern,lpr,mail,mark,news,rsyslog,user,uucp,local0,local1,
local2,local3,local4,local5,local6,local7}

   do
    for p in {debug,info,notice,warning,err,crit,alert,emerg}
   do
     logger -p $f.$p "Test rsyslog messages from facility $f with priority $p"
   done
   done
exit 0

Listing 18-11.Log Testing bash Script

$ tail -f /tmp/logfile | logger -p daemon.info

weekly
rotate 4
create
dateext
include /etc/logrotate.d
/var/log/wtmp {
    monthly
    create 0664 root utmp
    minsize 1M
    rotate 1
}
/var/log/btmp {
    missingok
    monthly
    create 0600 root utmp
    rotate 1
}
Listing 18-12.logrotate.conf

/var/log/messages /var/log/secure /var/log/maillog /var/log/spooler
/var/log/boot.log /var/log/cron
{
daily
rotate 7
sharedscripts
postrotate
     /bin/kill -HUP 'cat /var/run/rsyslogd.pid 2> /dev/null' 2> /dev/null || true
endscript
}
Listing 18-13.CentOS rsyslog logrotate File

$ sudo logrotate /etc/logrotate2.conf

$ sudo yum install -y https://artifacts.elastic.co/downloads/beats/filebeat/filebeat-5.0.2-x86_64.rpm

filebeat.prospectors:
- input_type: log
  paths:
    - /var/log/messages
    - /var/log/*.log
    - /var/log/audit/audit.log
tags: ["security", "network"]
fields:
  env: production
output.logstash:
  hosts: ["monitor.example.com:5044"]
  ssl.certificate_authorities: ["/etc/pki/tls/certs/cacert.pem"]
  ssl.certificate: "/etc/pki/tls/certs/gateway.example.com.cert"
  ssl.key: "/etc/pki/tls/private/gateway.example.com.key"
Listing 18-14.Filebeat.yml

---
key: value
- lista
- listb
keya:
  - valuea
  - valueb

- input_type: log
  paths:
    - /var/log/*.log
- input_type: log
  paths:
    - /var/log/apache/httpd-*.log
  document_type: apache

$ sudo systemctl enable filebeat
$ sudo systemctl start filebeat

wget -qO - https://artifacts.elastic.co/GPG-KEY-elasticsearch | sudo apt-key add -
sudo aptitude install –y apt-transport-https
echo "deb https://artifacts.elastic.co/packages/5.x/apt stable main" | sudo tee -a /etc/apt/sources.list.d/elastic-5.x.list
sudo aptitude update

$ sudo aptitude install –y logstash

$ sudo vi /etc/logstash/conf.d/general.conf
input {
  beats {
    port => 5044
    ssl  => true
    ssl_certificate => “/etc/ssl/certs/monitor.example.com.cert”
    ssl_key => “/etc/ssl/private/monitor.example.com.key”
    ssl_certificate_authorities [ “/etc/ssl/certs/cacert.pem” ]
    ssl_verify_mode => force_peer
  }
}
output {
  stdout { codec => rubydebug }
}

Input {
  ...
}
filter {
  ...
}
output {
  ...
}

$ sudo -u logstash /usr/share/logstash/bin/logstash -f /etc/logstash/conf.d/general.conf
WARNING: Could not find logstash.yml which is typically located in $LS_HOME/config or /etc/logstash. You can specify the path using --path.settings. Continuing using the defaults
Could not find log4j2 configuration at path /usr/share/logstash/config/log4j2.properties. Using default config which logs to console
04:20:40.036 [[main]-pipeline-manager] INFO  logstash.inputs.beats - Beats inputs: Starting input listener {:address=>"0.0.0.0:5044"}
04:20:40.072 [[main]-pipeline-manager] INFO  logstash.pipeline - Starting pipeline {"id"=>"main", "pipeline.workers"=>2, "pipeline.batch.size"=>125, "pipeline.batch.delay"=>5, "pipeline.max_inflight"=>250}
04:20:40.075 [[main]-pipeline-manager] INFO  logstash.pipeline - Pipeline main started
04:20:40.087 [[main]<beats] INFO  org.logstash.beats.Server - Starting server on port: 5044
04:20:40.134 [Api Webserver] INFO  logstash.agent - Successfully started Logstash API endpoint {:port=>9600}

$ sudo systemctl start filebeat && tail –f /var/log/filebeat/filebeat

{
    "@timestamp" => 2016-12-04T06:33:33.868Z,
    "offset" => 11979,
    "@version" => "1",
    "input_type" => "log",
    "beat" => {
        "hostname" => "gateway.example.com",
            "name" => "gateway.example.com",
         "version" => "5.0.2"
     },
     "host" => "gateway.example.com",
     "source" => "/var/log/messages",
      "message" => "Dec  4 06:33:24 gateway jsmith: tesing this is a test",
      "fields" => {
           "env" => "production"
       },
       "type" => "log",
       "tags" => [
          [0] "security",
          [1] "network",
          [2] "beats_input_codec_plain_applied"
       ]
}
Listing 18-15.Beat from Gateway Server Logs

         "host" => "gateway.example.com",
         "source" => "/var/log/audit/audit.log",
         "message" => "type=SERVICE_STOP msg=audit(1480834167.796:997): pid=1 uid=0 auid=4294967295 ses=4294967295 subj=system_u:system_r:init_t:s0 msg='unit=NetworkManager-dispatcher comm=\"systemd\" exe=\"/usr/lib/systemd/systemd\" hostname=? addr=? terminal=? res=success'",
         "type" => "log",

filebeat.prospectors:
- input_type: log
  paths:
    - /var/log/messages
    - /var/log/*.log
- input_type: log
  paths:
    - /var/log/audit/audit.log
  document_type: auditd

    "host" => "gateway.example.com",
    "source" => "/var/log/audit/audit.log",
    "message" => "type=SERVICE_STOP msg=...terminal=? res=success'",
    "fields" => {
        "env" => "production"
    },
    "type" => "auditd",

type=SERVICE_STOP msg=audit(1480844911.323:1080): pid=1 uid=0 auid=4294967295 ses=4294967295 subj=system_u:system_r:init_t:s0 msg='unit=openvpn@gateway comm="systemd" exe="/usr/lib/systemd/systemd" hostname=? addr=? terminal=? res=success'

filter {
  if [type] == "auditd" {
    # audit.log get matched and worked on here
  }
}

filter {
  if [type] =∼ "auditd" {
    kv { }
  }
}

{
    "msg" => [
        [0] "audit(1480844911.323:1080):",
        [1] "unit=openvpn@gateway comm=\"systemd\" exe=\"/usr/lib/systemd/systemd\" hostname=? addr=? terminal=? res=success"
    ],
    "uid" => "0",
    "ses" => "4294967295",
    "auid" => "4294967295",
    "pid" => "1",
    "source" => "/var/log/audit/audit.log",
    "message" => "type=SERVICE_STOP msg=audit(1480844911.323:1080): pid=1 uid=0 auid=4294967295 ses=4294967295 subj=system_u:system_r:init_t:s0 msg='unit=openvpn@gateway comm=\"systemd\" exe=\"/usr/lib/systemd/systemd\" hostname=? addr=? terminal=? res=success'",
    "type" => "SERVICE_STOP",
    "subj" => "system_u:system_r:init_t:s0"
    "tags" => [
        [0] "security",
        [1] "network",
        [2] "beats_input_codec_plain_applied"
    ],
    "offset" => 5738705,
    "input_type" => "log",
    "@timestamp" => 2016-12-04T09:48:31.650Z,
    "@version" => "1",
    "beat" => {
        "hostname" => "gateway.example.com",
        "name" => "gateway.example.com",
        "version" => "5.0.2"
    },
    "host" => "gateway.example.com",
    "fields" => {
        "env" => "production"
    },
}

filter {
  if [type] =∼ "auditd" {
    kv { }
    mutate {
      rename => {
        "type"        => "audit_type"
        "auid"        => "audit_uid"
        "fsuid"       => "audit_fs_uid"
        "suid"        => "audit_set_uid"
        “subj”        => “audit_subject”
        "ses"         => "session_id"
        “hostname => “audit_hostname”
      }
    }
  }
}

{
...
    "audit_uid"       => "4294967295",
    "audit_subject" => "system_u:system_r:init_t:s0",
    "audit_type"     => "SERVICE_STOP"
    "session_id"     => "4294967295",
...
}

%{SYNTAX:SEMANTIC}

    grok {
      match => { "msg" => "audit\(%{NUMBER:audit_epoch}:%{NUMBER:audit_counter}\):" }
    }

{
...
    "offset" => 5745528,
    "audit_epoch" => "1480846476.689",
   "audit_counter" => "1106",
...
}

$ sudo aptitude install –y elasticsearch

cluster.name: monitor
node.name: monitor-node-1

$ sudo systemctl start elasticsearch

$ curl http://localhost:9200
{
  "name" : "7mf_JBi",
  "cluster_name" : "elasticsearch",
  "cluster_uuid" : "69nMGfoYRYiwatKO6Nj1BA",
  "version" : {
    "number" : "5.0.2",
    "build_hash" : "f6b4951",
    "build_date" : "2016-11-24T10:07:18.101Z",
    "build_snapshot" : false,
    "lucene_version" : "6.2.1"
  },
  "tagline" : "You Know, for Search"
}

curl -H "Content-Type: application/json" "http://localhost:9200/logstash-*/_search" -d '{
   "query": {
     "match": {
       "event_type": "SERVICE_STOP"
     }
   },
   "sort": [ "_doc" ]
 }'

{
  "took":2,
  "timed_out":false,
  "_shards": {
     "total":5,
     "successful":5,
     "failed":0
   },
  "hits":  {
    "total":74,
    "max_score":null,
    "hits":[...the events...]
  }
}

$ sudo aptitude install –y kibana

server.port: 5601
server.host: "192.168.0.250"
elasticsearch.url: "http://localhost:9200"

$ sudo systemctl start kibana

$ sudo yum install nagios nagios-plugins nagios-plugins-ssh nagios-plugins-smtp nagios-plugins-bacula
nagios-plugins-disk nagios-plugins-fping nagios-plugins-http nagios-plugins-ldap nagios-plugins-mysql

$ sudo apt-get install nagios3 nagios-plugins

$ sudo useradd nagios  && \
sudo groupadd nagcmd && \
sudo usermod -aG nagcmd www-data && \
sudo usermod –aG nagcmd nagios

$ wget https://assets.nagios.com/downloads/nagioscore/releases/nagios-4.2.3.tar.gz && \
tar zxf nagios-4.2.3.tar.gz && \
cd nagios-4.2.3/

$ ./configure --with-httpd-conf=/etc/apache2/conf-available \
  --with-nagios-user=nagios \
  --with-nagios-group=nagcmd \
  --sysconfdir=/etc/nagios

$ sudo make all
$ sudo bash -c 'make install
make install-init
make install-config
make install-commandmode
make install-webconf'

$ wget https://nagios-plugins.org/download/nagios-plugins-2.1.4.tar.gz && \
tar zxf nagios-plugins-2.1.4.tar.gz && \
cd nagios-plugins-2.1.4/ && \
./configure --with-nagios-user=nagios --with-nagios-group=nagcmd && \
make && sudo make install

$ sudo vi /etc/systemd/system/nagios.service
[Unit]
Documentation=man:systemd-sysv-generator(8)
SourcePath=/etc/init.d/nagios
Description=LSB: nagios host/service/network monitoring and management system
Before=multi-user.target
Before=multi-user.target
Before=multi-user.target
Before=graphical.target
Before=shutdown.target
After=local-fs.target
After=remote-fs.target
After=systemd-journald-dev-log.socket
After=nss-lookup.target
After=network-online.target
After=time-sync.target
Wants=network-online.target
Conflicts=shutdown.target

[Service]
Type=forking
Restart=no
TimeoutSec=5min
IgnoreSIGPIPE=no
KillMode=process
GuessMainPID=no
RemainAfterExit=yes
ExecStart=/etc/init.d/nagios start
ExecStop=/etc/init.d/nagios stop
ExecReload=/etc/init.d/nagios reload

$ sudo systemctl start nagios

$ sudo nagios -v /etc/nagios/nagios.cfg

$ sudo nagios3 -v /etc/nagios3/nagios.cfg

$ sudo /usr/local/nagios/bin/nagios -v /etc/nagios/nagios.cfg

log_file=/var/log/nagios/nagios.log

# Definitions for monitoring the local (Linux) host
cfg_file=/etc/nagios/objects/localhost.cfg

cfg_file=/etc/nagios/objects/commands.cfg
cfg_file=/etc/nagios/objects/contacts.cfg
cfg_file=/etc/nagios/objects/timeperiods.cfg
cfg_file=/etc/nagios/objects/templates.cfg
...

cfg_dir=/etc/nagios/conf.d

define host {
        use                   linux-server    ; Name of host template to use
                                                       ; This host definition will inherit all variables that are defined
                                                       ; in (or inherited by) the linux-server host template definition.
        host_name       localhost
        alias                 localhost
        address            127.0.0.1
        }
Listing 18-16.A Host Object

define host {
        name                           linux-server
        use                              generic-host
        check_period               24x7
        check_interval             5
        retry_interval               1
        max_check_attempts  10
        check_command         check-host-alive
        notification_period       workhours
        notification_interval     120
        notification_options     d,u,r
        contact_groups           admins
        register                       0
        }
Listing 18-17.A Host Object Template

dns-servers <- critical-servers <- linux-servers <- generic-host

define timeperiod{
          timeperiod_name       24x7
          alias                 24 Hours A Day, 7 Days A Week
          Sunday                00:00-24:00
          monday                00:00-24:00
          tuesday               00:00-24:00
          wednesday             00:00-24:00
          Thursday              00:00-24:00
          friday                00:00-24:00
          saturday              00:00-24:00
          }

Sunday    00:00-02:00,17:00-19:00

define command{
          command_name    check-host-alive
          command_line    $USER1$/check_ping -H $HOSTADDRESS$ -w 3000.0,80% -c 5000.0,100% -p 1
          }

$USER1$/check_ping -H $HOSTADDRESS$ -w 3000.0,80% -c 5000.0,100% -p 1

$USER1$=/usr/lib64/nagios/plugins

define timeperiod{
          timeperiod_name      workhours
          alias                "Normal" Working Hours
          monday               09:00-17:00
          tuesday              09:00-17:00
          wednesday            09:00-17:00
          thursday             09:00-17:00
          Friday               09:00-17:00
          }

define contactgroup{
          contactgroup_name       admins
          alias                   Nagios Administrators
          members                 nagios-admin
          }

define contact{
         contact_name                             nagios-admin
         alias                                            Nagios Admin
         service_notification_period         24x7
         host_notification_period            24x7
         service_notification_options       w,u,c,r
         host_notification_options            d,r
         service_notification_commands  notify-by-email
         host_notification_commands       host-notify-by-email
         email                                           nagios-admin@localhost
         }

define command{
          command_name      host-notify-by-email
           command_line    /usr/bin/printf "%b" "***** Nagios *****\n\nNotification Type: $NOTIFICATIONTYPE$\nHost: $HOSTNAME$\nState: $HOSTSTATE$\nAddress: $HOSTADDRESS$\nInfo: $HOSTOUTPUT$\n\nDate/Time: $LONGDATETIME$\n" | /usr/bin/mail -s "** $NOTIFICATIONTYPE$ Host Alert: $HOSTNAME$ is $HOSTSTATE$ **" $CONTACTEMAIL$
   }

***** Nagios *****

Notification Type: PROBLEM
Host: gateway.example.com
State: DOWN

Address: 192.168.0.254
Info: PING CRITICAL - Packet loss = 100%

Date/Time: Fri Feb 13 00:30:28 EST 2009

define host{
          name                                   generic-host
          notifications_enabled              1
          event_handler_enabled         1
          flap_detection_enabled           1
          failure_prediction_enabled    1
          process_perf_data                  1
          retain_status_information        1
          retain_nonstatus_information  1
          notification_period                   24x7
          register                              0
          }
Listing 18-18.The generic-host Template

define host{
          use                      linux-server
          host_name          gateway.example.com
          alias                    gateway.example.com
          address               192.168.0.254
          }

define service{
          use                                local-service
          host_name                    localhost
          service_description       Root Partition
          check_command           check_local_disk!20%!10%!/
          }
Listing 18-19.A Service Definition

!20%!10%!/

define command{
          command_name    check_local_disk
          command_line       $USER1$/check_disk -w $ARG1$ -c $ARG2$ -p $ARG3$
          }

command_line    $USER1$/check_disk -w 20% -c 10% -p /

define service{
          use                            local-service
          host_name                localhost
          service_description   Var Partition
          check_command       check_local_disk!20%!10%!/var
          }

define service{
        name                                     local-service
        use                                        generic-service
        max_check_attempts            4
        normal_check_interval         5
        retry_check_interval              1
        register                                  0
        }

define service{
          use                               local-service   ; Name of service template to use
          host_name                    gateway.example.com
          service_description       Check SMTP
          check_command           check_smtp!25
          }
Listing 18-20.A Network-Based Service Definition

define command{
         command_name    check_smtp
         command_line    $USER1$/check_smtp -H $HOSTADDRESS$ -p $ARG1$
         }

[1481325559] SERVICE ALERT: gateway.example.com;Check SMTP;CRITICAL;HARD;4;
CRITICAL - Socket timeout after 10 seconds

# sudo -u nagios ssh-keygen -t rsa -b 4096
Generating public/private rsa key pair.
Enter file in which to save the key (/var/spool/nagios/.ssh/id_rsa):
Created directory '/var/spool/nagios/.ssh'.
Enter passphrase (empty for no passphrase):
Enter same passphrase again:
Your identification has been saved in /var/spool/nagios/.ssh/id_rsa.
Your public key has been saved in /var/spool/nagios/.ssh/id_rsa.pub.
The key fingerprint is:
df:fc:d6:d2:50:66:65:51:79:d1:f8:56:a1:78:a4:df nagios@nagios.example.com

gateway$ sudo useradd nagios

gateway$ sudo mkdir /home/nagios/.ssh
gateway$ sudo chmod 0700 /home/nagios/.ssh

nagios$ scp .ssh/id_rsa.pub jsmith@gateway.example.com:/tmp/authorized_keys
nagios$ ssh jsmith@gateway.example.com
gateway$ sudo mv /tmp/authorized_keys /home/nagios/.ssh/authorized_keys && \
sudo chown nagios /home/nagios/.ssh/authorized_keys && \
sudo chmod 0644 /home/nagios/.ssh/authorized_keys

nagios# sudo –u nagios –E ssh nagios@gateway
The authenticity of host 'gateway (192.168.0.254)' can't be established.
ECDSA key fingerprint is 2d:94:d5:bd:3e:40:93:fe:d4:9b:eb:6f:93:4d:f3:a1.
Are you sure you want to continue connecting (yes/no)? yes
Warning: Permanently added 'gateway,192.168.0.254' (ECDSA) to the list of known hosts.

gateway$ sudo yum install nagios-plugins nagios-plugins-load

gateway$ sudo apt-get install nagios-plugins

$ sudo vi /etc/nagios/objects/commands.cfg
# ssh_check_commands
define command{
         command_name       check_load_ssh
         command_line       $USER1$/check_by_ssh -H $HOSTADDRESS$ -l nagios
-C "/usr/lib64/nagios/plugins/check_load -w $ARG1$ -c $ARG2$"
        }

define host{
        name            basic-ssh-checks
        use               linux-server
        hostgroups   linux-group
        register        0
        }

define host{
        host_name       gateway
        alias                 gateway.example.com
        use                  basic-ssh-checks
        }

define service{
         use                              local-service
         hostgroup_name         linux-group
         service_description     Current Load
         check_command         check_load_ssh!5.0,4.0,3.0!10.0,6.0,4.0
        }

define hostgroup{
        hostgroup_name  linux-group
        }

Listing 18-21.linux-servers-base.cfg

define service{
         use                              local-service
         hostgroup_name         linux-group
         service_description     Current Load
         check_command         check_load_ssh!5.0,4.0,3.0!10.0,6.0,4.0
        }

use_syslog=0

debug_level=0

#          -1 = Everything
#          0 = Nothing
#          1 = Functions
#          2 = Configuration
#          4 = Process information
#          8 = Scheduled events
#          16 = Host/service checks
#          32 = Notifications
#          64 = Event broker
#          128 = External commands
#          256 = Commands
#          512 = Scheduled downtime
#          1024 = Comments
#          2048 = Macros

AuthName "Nagios Access"
AuthType Basic
AuthUserFile /etc/nagios/passwd
<IfModule mod_authz_core.c>
      # Apache 2.4
     <RequireAll>
        Require all granted
        Require valid-user
    </RequireAll>
</IfModule>

AuthName "Nagios Access"
AuthType Basic
AuthUserFile /etc/nagios/htpasswd.users
Require valid-user

$ sudo htpasswd -c /etc/nagios/passwd jsmith
New password:
Re-type new password:
Adding password for user jsmith
Listing 18-22.Using the htpasswd Command

use_authentication=1

authorized_for_all_services=jsmith,nagiosadmin

authorized_for_all_services=*

Linux 系统管理高级教程（九）

十七、性能监控和优化

基本健康检查

CPU 使用情况

内存使用

磁盘空间

日志

高级工具

CPU 和内存使用

交换空间使用

磁盘存取

dstat 更深入

持续性能监控

已收集

集合配置

开始和停止收集 d

石墨

石墨装置

配置碳缓存

配置碳继电器

正在更新 Collectd 配置

检查日志

配置 Graphite-API

设置 Gunicorn

设置 Nginx

格拉凡娜

安装 Grafana

添加存储后端

性能优化

资源限制

为所有用户设置限制

sysctl 和 proc 文件系统

存储设备

文件系统调整

输入输出调度程序

摘要

十八、日志记录和监控

记录

-报纸

Journalctl Filters

使用 fss 保护日志

日志-远程

rsyslogd(rsyslogd)

配置 rsyslog

工具

优先

行动

组合多个选择器

配置 RELP

配置 RELP 客户端

配置 RELP 服务器

启动和停止 rsyslog

使用记录器测试日志记录

日志管理和轮换

测井分析和对比

介绍 Beats 和 Logstash

安装和配置 Beats

安装和配置 Logstash

日志隐藏过滤器

日志存储的弹性搜索

弹性搜索安装和配置

Kibana 安装和配置

进一步的信息

监控

Nagios-Core 简介

安装 Nagios

在 CentOS 上安装 Nagios

在 Ubuntu 上安装 Nagios

启动 Nagios

Nagios 配置

nagios.cfg 文件

主机配置

主机模板

时间段

命令

通知期

联系人和联系人组

定义我们的主机

服务配置

简单的远程监控
