Openerp开发进销存系统完毕总结

差不多用了2个星期的闲余事件，对于openerp v7.0进行了学习和应用开发。细节总结如下

安装Openoffice
在openoffice中安装openerp report designer插件(openerp 7.0中自带)


OpenErp学习


安装Openoffice
在openoffice中安装openerp report designer插件(openerp 7.0中自带)


1.保存openoffice文件在英文路径下。如果不保存,send to server的时候会没有反应


2. 主要类

基类：
osv openerp/osv/osv.py
在文件中 osv = Model
所以osv.osv和osv.Model其实是一样的
osv.Model定义在orm.py中

report_sxw openerp/report/report_sxw.py

日志：
logging python库自带
import logging
_logger = logging.getLogger(__name__)
_logger.error("IntegrityError", exc_info=True)

提示：
from osv.osv import except_osv
raise osv.except_osv('xinquanda_product', "_modify_quantity 0"%(record[0]['quantity']))

3.使用openerp report design + openoffice 3.4 + openerp 7.0
在send to server的时候会提示UnicodeDecodeError: 'ascii' codec can't decode byte
通过在addons\base_report_designer\base_report_designer.py添加如下三行代码解决
注意默认使用空格缩进。如果增加的代码使用tab缩进会产生unexpected indent错误
import sys


def upload_report(self, cr, uid, report_id, file_sxw, file_type, context=None):
'''
Untested function
'''
reload(sys)
sys.setdefaultencoding('utf8')

4.python 一个 *.py就是一个package
osv.osv就是osv.py文件内的osv对象

5.使用parent_id的时候，使用toolbar产生问题


6.selection里面使用中文内容，需要在前面增加u, 比如u'供货商'。否则插入的时候会判断出错


7.使用7.0 form如果没有sheet和group，会不显示filed string


8.使用openerp report designer自动生成rml会使用in作为object名。会导致在7.0下面无法解析。提示 cannot eval 'xxxx'之类的。修改名字解决问题


9.Win7的字体安装直接拖进去是不行的。文件名会变成xxx_1 xxx_2这样(用cmd查看)。所以需要使用cmd的xcopy命令进行放置。否则会安装了新字体，但是还是乱码。使用xcopy进去以后，虽然图形界面看不到该字体安装成功了。但是重启oe之后可以解决乱码问题。如果还不行尝试重启一下系统吧。


10.一个工程中存在相同的view_id导致了显示不出来同名menu


11.
View生成的时候调用的初始化函数
def view_init(self, cr, uid, fields_list, context=None):

使用菜单栏的导出功能，导出Field数据时调用
def export_data(self, cr, uid, ids, fields_to_export, context=None):

加载数据时调用，返回一个id list.代表需要加载的数据
def load(self, cr, uid, fields, data, context=None):
        """
        Attempts to load the data matrix, and returns a list of ids (or
        ``False`` if there was an error and no id could be generated) and a
        list of messages.


        The ids are those of the records created and saved (in database), in
        the same order they were extracted from the file. They can be passed
        directly to :meth:`~read`


    #
    # Overload this method if you need a window title which depends on the context
    #
    def view_header_get(self, cr, user, view_id=None, view_type='form', context=None):
        return False


// 获取名字，返回名字列表
def name_get(self, cr, user, ids, context=None):

// 根据参数进行名字查找.返回 (id, name)的tuple列表.相当于先用search进行搜索，然后再用name_get获取名字列表
def name_search(self, cr, user, name='', args=None, operator='ilike', context=None, limit=100):


// 仅仅使用name创建record
def name_create(self, cr, uid, name, context=None):

create
read
返回的是dict组成的list

write
unlink

def search(cr, user, args, offset=0, limit=None, order=None, context=None, count=False):

cr.execute
cr.fetchall

// 定义了
def func_search(self, cr, uid, obj, name field, args, context):

12. pgsql的备份与恢复
pg_dump.exe -f d:/backup/1234.backup -F t -h 127.0.0.1 -p 5432 -U openerp -b Erp
pg_restore.exe -F t -h 127.0.0.1 -p 5432 -U openerp -d tt d:/backup/1234.backup


13.
c:\>for /f "tokens=1-3 delims=- " %1 in ("%date%") do @echo %1%2%3
c:\>for /f "tokens=1-3 delims=.: " %1 in ("%time%") do @echo %1%2%3
http://www.jb51.net/article/30539.htm

14.
report name一样导致了report对应的model调用错误

15.
select 'cp' || right(cast(pow(10, 10) as varchar) || id, 10) as sn, customer_id as name, '付款' as operation, pay_value as value, date, note from xinquanda_customer_payment
union
select 'co' || right(cast(pow(10, 10) as varchar) || id, 10) as sn, customer_id as name, '退货' as operation, price_totle as value, date , '' as note from xinquanda_product_customer_out
union
select 'ci' || right(cast(pow(10, 10) as varchar) || id, 10) as sn, customer_id as name, '供货' as operation, price_totle as value, date , '' as note from xinquanda_product_customer_in;


16.有关于view视图的创建与显示
1.在.py的对象创建里面定义_auto = False
2.所有_column都需要有readonly=True的属性
3._sql设定视图创建sql语句或者在__init__(self, cr)函数里面创建具体视图

如果调用视图的action使用了tree type进行显示，可能会在报错

2013-06-19 01:36:24,151 2392 [1;31m[1;49mERROR[0m Erp openerp.osv.orm: read xinquanda.funds.supplier:None
None
2013-06-19 01:36:24,154 2392 [1;31m[1;49mERROR[0m Erp openerp.osv.osv: Uncaught exception
Traceback (most recent call last):
 File "D:\programs\GreenOpenERP-7.0-20130428-232407\openerp\osv\osv.py", line 131, in wrapper
return f(self, dbname, *args, **kwargs)
 File "D:\programs\GreenOpenERP-7.0-20130428-232407\openerp\osv\osv.py", line 197, in execute
res = self.execute_cr(cr, uid, obj, method, *args, **kw)
 File "D:\programs\GreenOpenERP-7.0-20130428-232407\openerp\osv\osv.py", line 185, in execute_cr
return getattr(object, method)(cr, uid, *args, **kw)
 File "D:\programs\GreenOpenERP-7.0-20130428-232407\openerp\osv\orm.py", line 3606, in read
select = map(lambda x: isinstance(x, dict) and x['id'] or x, select)
TypeError: argument 2 to map() must support iteration
2013-06-19 01:36:24,180 2392 [1;31m[1;49mERROR[0m Erp openerp.netsvc: argument 2 to map() must support iteration
Traceback (most recent call last):
 File "D:\programs\GreenOpenERP-7.0-20130428-232407\openerp\netsvc.py", line 296, in dispatch_rpc
result = ExportService.getService(service_name).dispatch(method, params)
 File "D:\programs\GreenOpenERP-7.0-20130428-232407\openerp\service\web_services.py", line 626, in dispatch
res = fn(db, uid, *params)
 File "D:\programs\GreenOpenERP-7.0-20130428-232407\openerp\osv\osv.py", line 188, in execute_kw
return self.execute(db, uid, obj, method, *args, **kw or {})
 File "D:\programs\GreenOpenERP-7.0-20130428-232407\openerp\osv\osv.py", line 131, in wrapper
return f(self, dbname, *args, **kwargs)
 File "D:\programs\GreenOpenERP-7.0-20130428-232407\openerp\osv\osv.py", line 197, in execute
res = self.execute_cr(cr, uid, obj, method, *args, **kw)
 File "D:\programs\GreenOpenERP-7.0-20130428-232407\openerp\osv\osv.py", line 185, in execute_cr
return getattr(object, method)(cr, uid, *args, **kw)
 File "D:\programs\GreenOpenERP-7.0-20130428-232407\openerp\osv\orm.py", line 3606, in read
select = map(lambda x: isinstance(x, dict) and x['id'] or x, select)
TypeError: argument 2 to map() must support iteration


17. 直接在view form的field里面写select属性，貌似不能直接实现查询功能。需要添加search view来自定义搜索
a. 生成 search_view定义

        <record id="xinquanda_product_customer_in_search" model="ir.ui.view">
            <field name="name">xinquanda.product.customer.in.search</field>
            <field name="model">xinquanda.product.customer.in</field>
            <field name="arch" type="xml">
<search string="进货">
<field name="name" filter_domain="[('name','ilike',self),]"/>
<field name="customer_id" filter_domain="[('customer_id','ilike',self),]"/>
</search>
            </field>
        </record>
b. 在action里面指定需要的 search_view_id

        <record id="action_xinquanda_product_customer_in_form" model="ir.actions.act_window">
            <field name="name">客户供货</field>
            <field name="type">ir.actions.act_window</field>
            <field name="res_model">xinquanda.product.customer.in</field>
            <field name="view_type">form</field>
            <field name="view_mode">tree,form</field>
            <field name="view_id" ref="xinquanda_product_customer_in_tree"/>
<field name="search_view_id" ref="xinquanda_product_customer_in_search"/>
        </record>


18. domain里面operator的集合
operator must be a string with a valid comparison operator from this list: =, !=, >, >=, <, <=, like, ilike, in, not in, child_of, parent_left, parent_right The semantics of most of these operators are obvious. The child_of operator will look for records who are children or grand-children of a given record, according to the semantics of this model (i.e following the relationship field named by self._parent_name, by default parent_id.

[('name', 'like', 'Behave')] =>
name LIKE '%Behave%'


[('name', 'ilike', 'Behave%')] =>
name LIKE '%Behave%%'


[('name', '=like', 'Behave')] =>
name LIKE 'Behave' (no sense to use it like this)


[('name', '=ilike', 'Behave%')] =>
name LIKE 'Behave%' (with =ilike, we can control more finely the criteria)


19. domain不能直接使用<, >等符号作为domain的operator。 这个不是openerp的问题，而是xml标准的问题
>           开始标记  &gt;


<           结束标记  &lt;


"            引号        &quot;


'             撇号       &apos;


&          "&"符      &amp;

20. 有name_get函数的列如果要实现查找，需要对应实现name_search函数
def name_get(self, cr, uid, ids, context=None):
if isinstance(ids, (list, tuple)) and not len(ids):
return []
if isinstance(ids, (long, int)):
ids = [ids]
reads = self.read(cr, uid, ids, ['name','parent_id'], context=context)
res = []


for record in reads:
name = record['name']
if record['parent_id'] and record['parent_id'][1] != u'所有货物':
name = record['parent_id'][1]+'/'+name
res.append((record['id'], name))
return res


def name_search(self, cr, user, name='', args=None, operator='ilike', context=None, limit=100):
_logger = logging.getLogger(__name__)
_logger.error("name_search name=%s args=%s operator=%s context=%s"%(name, args, operator, context), exc_info=True)

if name == '':
result = super(xinquanda_product_category, self).name_search(cr, user, name, args, operator, context, limit)
_logger.error("1 name_search result=%s"%(result), exc_info=True)
return result
#去除父类名
nameIndex = name.rfind('/')
if nameIndex != -1:
name = name[nameIndex+1:]

_logger.error("2 name_search name=%s"%(name), exc_info=True)

result = super(xinquanda_product_category, self).name_search(cr, user, name, args, operator, context, limit)
_logger.error("2 name_search result=%s"%(result), exc_info=True)
return result

21. 统计功能的另一种实现
直接修改search和read函数。而非通过数据库试图实现。
class xinquanda_statistics_product_period(osv.osv):

_name = 'xinquanda.statistics.product.period'
_description = u'货物销售时间段统计'
_auto = False

_search_context = {}

def search(self, cr, uid, args, offset=0, limit=None, order=None, context=None, count=False):
_logger = logging.getLogger(__name__)
_logger.error("search args:%s, offset=%s limit=%s context:%s order=%s"%(
args,
offset,
limit,
context,
order), exc_info=True)

_search_context = {}
date_start = '2010-01-01'
date_end = '2100-12-31'

for arg in args:
if arg[0] == 'date_start':
self._search_context['date_start'] = arg[2]
if arg[0] == 'date_end':
self._search_context['date_end'] = arg[2]
if arg[0] == 'product_id':
self._search_context['id']


whereSql = ' where true'
if self._search_context.get('date_start'):
date_start = self._search_context.get('date_start')
whereSql = whereSql + " and i.date >= '%s'"%(date_start)

if self._search_context.get('date_end'):
date_end = self._search_context.get('date_end')
whereSql = whereSql + (" and i.date <= '%s'"%(date_end))


groupSql = ' group by product_id'
orderSql = ''
offsetSql = ''
limitSql = ''

if order:
orderSql = 'order by %s'%(order)

if offset > 0:
offsetSql = ' offset %d'%offset
if limit:
limitSql = ' limit %d'%limit

selectSql = """select product_id as id, product_id, '%s' as date_start, '%s' as date_end, sum(l.quantity) as quantity_totle, sum(l.quantity * l.price_sale) as price_totle, sum(l.quantity * (l.price_sale - p.price_buy)) as profits from xinquanda_product_customer_in_list as l join xinquanda_product as p on l.product_id = p.id join xinquanda_product_customer_in as i on l.in_id = i.id %s %s %s %s %s"""%(date_start, date_end, whereSql, groupSql, orderSql, offsetSql, limitSql)

_logger.error("search selectSql=%s"%(
selectSql), exc_info=True)

cr.execute(selectSql)
records = cr.fetchall()

result = []
for record in records:
result.append(record[0])

return result

def read(self, cr, user, ids, fields=None, context=None, load='_classic_read'):
_logger = logging.getLogger(__name__)
_logger.error("read ids:%s, fields:%s context:%s load=%s self._search_context=%s"%(
ids,
fields,
context,
load,
self._search_context), exc_info=True)

date_start = '2010-01-01'
date_end = '2100-12-31'

whereSql = ' where true'
if self._search_context.get('date_start'):
date_start = self._search_context.get('date_start')
whereSql = whereSql + " and i.date >= '%s'"%(date_start)

if self._search_context.get('date_end'):
date_end = self._search_context.get('date_end')
whereSql = whereSql + (" and i.date <= '%s'"%(date_end))

if isinstance(ids, (int, long)):
ids = (ids,)
if isinstance(ids, tuple):
ids = list(ids,)


if len(ids) > 0:
temp = '%s'%(ids)
temp = temp.replace('[', '(', 1)
temp = temp.replace(']', ')', 1)
whereSql = whereSql + ' and product_id in ' + temp

groupSql = ' group by product_id;'


selectSql = """select product_id as id, product_id, '%s' as date_start, '%s' as date_end, sum(l.quantity) as quantity_totle, sum(l.quantity * l.price_sale) as price_totle, sum(l.quantity * (l.price_sale - p.price_buy)) as profits from xinquanda_product_customer_in_list as l join xinquanda_product as p on l.product_id = p.id join xinquanda_product_customer_in as i on l.in_id = i.id %s %s"""%(date_start, date_end, whereSql, groupSql)

_logger.error("read selectSql=%s"%(
selectSql), exc_info=True)

cr.execute(selectSql)
result = cr.fetchall()


#把result转化为record要求的dict格式
colum_field = ['id', 'product_id', 'date_start', 'date_end', 'quantity_totle', 'price_totle', 'profits']
read_result = []
for record in result:
read_record = {}
index = 0
while index < len(colum_field):
read_record[colum_field[index]] = record[index]
index = index + 1
read_result.append(read_record)


#清空search
self._search_context = {}

return read_result

_columns = {
'product_id' : fields.many2one('xinquanda.product', '货物', readonly=True, select=True),
'date_start': fields.date('起始日期', readonly=True, required=True),
'date_end': fields.date('结束日期', readonly=True, required=True),
'quantity_totle' : fields.integer('销售总量', readonly=True, select=True),
'price_totle' : fields.float('销售总额', readonly=True),
'profits' : fields.float('利润', readonly=True),
 }

xinquanda_statistics_product_period()#对象定义结束


22. 权限分配可以开启技术菜单。通过配置组的权限来实现

23. 设置表格默认列数。在action的xml里面增加<field name="limit">lines number</field>



24.设置表格默认顺序。在py定义里面增加 _order = 'field name [desc]'

25.对于field.selection类型的定义， 期设定的((key, value),...)选择，key和value都必须是string.
如果不是string, 可能导致最后在界面上无法正确的解析显示出来

26.在search domain想要搜索非空即可，则domain的写法是('field name', 'not in', False))。如果搜索空字段，则是('field name', 'in', False))。具体可以参考osv/expression def __leaf_to_sql(self, eleaf):

27.在report的定义文件里面。比如是我的report_all_view.xml里面。通过设置report的属性可以实现是否打印公司页眉页脚。

<report auto="True" header="False" id="report_cash_statistics_day_flow" model="k.cash.statistics.day.flow" name="日收支清单" rml="ExpressManagement/report/report_cash_statistics_day_flow.rml" string="日收支清单"/>
