人脸检测论文：BlazeFace: Sub-millisecond Neural Face Detection on Mobile GPUs 及其Pytorch实现

论文链接：https://arxiv.org/pdf/1907.05047v1.pdf
PyTorch：https://github.com/shanglianlm0525/BlazeFace

1 概述

BlazeFace算法是作者在MobileNet-SSD目标检测框架下，改进了网络结构、anchor机制、替换NMS后处理，使算法在人脸检测任务中保持高精度的同时，在移动GPU推理量身定制的轻量级网络。

2 模型架构与设计

2-1 增大感受野

在深度可分离卷积（depthwise separable convolution）中，depthwise convolution部分（$s^{2}c{k}^2$）与 pointwise convolution 部分（$s^{2}cd$）计算量比值为（$k^2：d$），可见depthwise separable convolution计算量主要由$d$决定。使用5*5卷积核代替3*3卷积核，不会带来太大开销，但是可以增大感受野（receptive field）。基于此作者设计了下面两种结构：

2-2 改进的anchor 机制

SSD 使用 1×1, 2×2, 4×4, 8×8, 和 16×16 的五层特征图来回归目标，为了GPU计算更友好，因此作者使用6个8×8的特征图来替换原来分别为2个2×2, 4×4, 8×8的特征图。

2-3 使用tie resolution策略替换NMS

由于2-2中使用的anchor机制使用较高的（8×8, 和 16×16）分辨率，所以视频检测人脸中，检测出的人脸会明显抖动。作者提出一种blending策略替换原来的NMS，即将边界框的回归参数估计为重叠预测之间的加权平均值。

3 Backbone网络结构

4 实验结果

与MobileNetV2-SSD性能比较

速度很快呀

PyTorch实现：

import torch
import torch.nn as nn

class BlazeBlock(nn.Module):
    def __init__(self, in_channels,out_channels,mid_channels=None,stride=1):
        super(BlazeBlock, self).__init__()
        mid_channels = mid_channels or in_channels
        assert stride in [1, 2]
        if stride>1:
            self.use_pool = True
        else:
            self.use_pool = False

        self.branch1 = nn.Sequential(
            nn.Conv2d(in_channels=in_channels,out_channels=mid_channels,kernel_size=5,stride=stride,padding=2,groups=in_channels),
            nn.BatchNorm2d(mid_channels),
            nn.Conv2d(in_channels=mid_channels,out_channels=out_channels,kernel_size=1,stride=1),
            nn.BatchNorm2d(out_channels),
        )

        if self.use_pool:
            self.shortcut = nn.Sequential(
                nn.MaxPool2d(kernel_size=stride, stride=stride),
                nn.Conv2d(in_channels=in_channels, out_channels=out_channels, kernel_size=1, stride=1),
                nn.BatchNorm2d(out_channels),
            )

        self.relu = nn.ReLU(inplace=True)

    def forward(self, x):
        branch1 = self.branch1(x)
        out = (branch1+self.shortcut(x)) if self.use_pool else (branch1+x)
        return self.relu(out)

class DoubleBlazeBlock(nn.Module):
    def __init__(self,in_channels,out_channels,mid_channels=None,stride=1):
        super(DoubleBlazeBlock, self).__init__()
        mid_channels = mid_channels or in_channels
        assert stride in [1, 2]
        if stride > 1:
            self.use_pool = True
        else:
            self.use_pool = False

        self.branch1 = nn.Sequential(
            nn.Conv2d(in_channels=in_channels, out_channels=in_channels, kernel_size=5, stride=stride,padding=2,groups=in_channels),
            nn.BatchNorm2d(in_channels),
            nn.Conv2d(in_channels=in_channels, out_channels=mid_channels, kernel_size=1, stride=1),
            nn.BatchNorm2d(mid_channels),
            nn.ReLU(inplace=True),
            nn.Conv2d(in_channels=mid_channels, out_channels=mid_channels, kernel_size=5, stride=1,padding=2),
            nn.BatchNorm2d(mid_channels),
            nn.Conv2d(in_channels=mid_channels, out_channels=out_channels, kernel_size=1, stride=1),
            nn.BatchNorm2d(out_channels),
        )

        if self.use_pool:
            self.shortcut = nn.Sequential(
                nn.MaxPool2d(kernel_size=stride, stride=stride),
                nn.Conv2d(in_channels=in_channels, out_channels=out_channels, kernel_size=1, stride=1),
                nn.BatchNorm2d(out_channels),
            )

        self.relu = nn.ReLU(inplace=True)

    def forward(self, x):
        branch1 = self.branch1(x)
        out = (branch1 + self.shortcut(x)) if self.use_pool else (branch1 + x)
        return self.relu(out)


class BlazeFace(nn.Module):
    def __init__(self):
        super(BlazeFace, self).__init__()

        self.firstconv = nn.Sequential(
            nn.Conv2d(in_channels=3, out_channels=24, kernel_size=3, stride=2, padding=1),
            nn.BatchNorm2d(24),
            nn.ReLU(inplace=True),
        )

        self.blazeBlock = nn.Sequential(
            BlazeBlock(in_channels=24, out_channels=24),
            BlazeBlock(in_channels=24, out_channels=24),
            BlazeBlock(in_channels=24, out_channels=48, stride=2),
            BlazeBlock(in_channels=48, out_channels=48),
            BlazeBlock(in_channels=48, out_channels=48),
        )

        self.doubleBlazeBlock = nn.Sequential(
            DoubleBlazeBlock(in_channels=48, out_channels=96, mid_channels=24, stride=2),
            DoubleBlazeBlock(in_channels=96, out_channels=96, mid_channels=24),
            DoubleBlazeBlock(in_channels=96, out_channels=96, mid_channels=24),
            DoubleBlazeBlock(in_channels=96, out_channels=96, mid_channels=24, stride=2),
            DoubleBlazeBlock(in_channels=96, out_channels=96, mid_channels=24),
            DoubleBlazeBlock(in_channels=96, out_channels=96, mid_channels=24),
        )
        self.initialize()

    def initialize(self):
        for m in self.modules():
            if isinstance(m, nn.Conv2d):
                nn.init.kaiming_normal_(m.weight)
                nn.init.constant_(m.bias, 0)
            elif isinstance(m, nn.BatchNorm2d):
                nn.init.constant_(m.weight, 1)
                nn.init.constant_(m.bias, 0)

    def forward(self, x):
        x = self.firstconv(x)
        x = self.blazeBlock(x)
        x = self.doubleBlazeBlock(x)
        return x

if __name__=='__main__':
    model = BlazeFace()
    print(model)

    input = torch.randn(1, 3, 128, 128)
    out = model(input)
    print(out.shape)
