Pytorch基础代码实战系列之自定义Dataloader加载数据

深度学习框架Pytroch系列

注：大家觉得博客好的话，别忘了点赞收藏呀，本人每周都会更新关于人工智能和大数据相关的内容，内容多为原创，Python Java Scala SQL 代码，CV NLP 推荐系统等，Spark Flink Kafka Hbase Hive Flume等等~写的都是纯干货，各种顶会的论文解读，一起进步。
这个系列主要和大家分享深度学习框架Pytorch的各种api，从基础开始。
#博学谷IT学习技术支持#

---

---

前言

对于很多新同学来说Pytorch的api太多，太复杂，这个系列主要通过实战来说明各种api，帮助大家迅速入门。

如何自定义数据集：

• 1.数据和标签的目录结构先搞定(得知道到哪读数据)
• 2.写好读取数据和标签路径的函数(根据自己数据集情况来写)
• 3.完成单个数据与标签读取函数(给dataloader举一个例子)

咱们以花朵数据集为例：

• 原来数据集都是以文件夹为类别ID，现在咱们换一个套路，用txt文件指定数据路径与标签(实际情况基本都这样)
• 这回咱们的任务就是在txt文件中获取图像路径与标签，然后把他们交给dataloader
• 核心代码非常简单，按照对应格式传递需要的数据和标签就可以啦

---

一、预处理操作

需要数据的可以留言

import os
import matplotlib.pyplot as plt
%matplotlib inline
import numpy as np
import torch
from torch import nn
import torch.optim as optim
import torchvision
#pip install torchvision
from torchvision import transforms, models, datasets
#https://pytorch.org/docs/stable/torchvision/index.html
import imageio
import time
import warnings
import random
import sys
import copy
import json
from PIL import Image

# 1.读取txt文件中的路径和标签
def load_annotations(ann_file):
    data_infos = {}
    with open(ann_file) as f:
        samples = [x.strip().split(' ') for x in f.readlines()]
        for filename, gt_label in samples:
            data_infos[filename] = np.array(gt_label, dtype=np.int64)
    return data_infos

# 2.分别把数据和标签都存在list里
img_label = load_annotations('./flower_data/train.txt')
image_name = list(img_label.keys())
label = list(img_label.values())

# 3.图像数据路径得完整
data_dir = './flower_data/'
train_dir = data_dir + '/train_filelist'
valid_dir = data_dir + '/val_filelist'
image_path = [os.path.join(train_dir,img) for img in image_name]

二、Dataloader实现上述步骤

这里定义一个FlowerDataset类，把需要做的读取数据等预处理操作都放进来

from torch.utils.data import Dataset, DataLoader
class FlowerDataset(Dataset):
    def __init__(self, root_dir, ann_file, transform=None):
        self.ann_file = ann_file
        self.root_dir = root_dir
        self.img_label = self.load_annotations()
        self.img = [os.path.join(self.root_dir,img) for img in list(self.img_label.keys())]
        self.label = [label for label in list(self.img_label.values())]
        self.transform = transform

    def __len__(self):
        return len(self.img)

    def __getitem__(self, idx):
        image = Image.open(self.img[idx])
        label = self.label[idx]
        if self.transform:
            image = self.transform(image)
        label = torch.from_numpy(np.array(label))
        return image, label
    def load_annotations(self):
        data_infos = {}
        with open(self.ann_file) as f:
            samples = [x.strip().split(' ') for x in f.readlines()]
            for filename, gt_label in samples:
                data_infos[filename] = np.array(gt_label, dtype=np.int64)
        return data_infos

# 数据预处理(transform)
data_transforms = {
    'train':
        transforms.Compose([
        transforms.Resize(64),
        transforms.RandomRotation(45),#随机旋转，-45到45度之间随机选
        transforms.CenterCrop(64),#从中心开始裁剪
        transforms.RandomHorizontalFlip(p=0.5),#随机水平翻转 选择一个概率概率
        transforms.RandomVerticalFlip(p=0.5),#随机垂直翻转
        transforms.ColorJitter(brightness=0.2, contrast=0.1, saturation=0.1, hue=0.1),#参数1为亮度，参数2为对比度，参数3为饱和度，参数4为色相
        transforms.RandomGrayscale(p=0.025),#概率转换成灰度率，3通道就是R=G=B
        transforms.ToTensor(),
        transforms.Normalize([0.485, 0.456, 0.406], [0.229, 0.224, 0.225])#均值，标准差
    ]),
    'valid':
        transforms.Compose([
        transforms.Resize(64),
        transforms.CenterCrop(64),
        transforms.ToTensor(),
        transforms.Normalize([0.485, 0.456, 0.406], [0.229, 0.224, 0.225])
    ]),
}

train_dataset = FlowerDataset(root_dir=train_dir, ann_file = './flower_data/train.txt', transform=data_transforms['train'])
val_dataset = FlowerDataset(root_dir=valid_dir, ann_file = './flower_data/val.txt', transform=data_transforms['valid'])
train_loader = DataLoader(train_dataset, batch_size=64, shuffle=True)
val_loader = DataLoader(val_dataset, batch_size=64, shuffle=True)

三、验证Dataloader

image, label = next(iter(train_loader))
sample = image[0].squeeze()
sample = sample.permute((1, 2, 0)).numpy()
sample *= [0.229, 0.224, 0.225]
sample += [0.485, 0.456, 0.406]
plt.imshow(sample)
plt.show()
print('Label is: {}'.format(label[0].numpy()))

四、模型训练

模型训练过程和之前讲的一样

dataloaders = {'train':train_loader,'valid':val_loader}
model_name = 'resnet'  #可选的比较多 ['resnet', 'alexnet', 'vgg', 'squeezenet', 'densenet', 'inception']
#是否用人家训练好的特征来做
feature_extract = True

# 是否用GPU训练
train_on_gpu = torch.cuda.is_available()

if not train_on_gpu:
    print('CUDA is not available.  Training on CPU ...')
else:
    print('CUDA is available!  Training on GPU ...')

device = torch.device("cuda:0" if torch.cuda.is_available() else "cpu")
model_ft = models.resnet18()
num_ftrs = model_ft.fc.in_features
model_ft.fc = nn.Sequential(nn.Linear(num_ftrs, 102))
input_size = 64
# 优化器设置
optimizer_ft = optim.Adam(model_ft.parameters(), lr=1e-3)
scheduler = optim.lr_scheduler.StepLR(optimizer_ft, step_size=7, gamma=0.1)#学习率每7个epoch衰减成原来的1/10
criterion = nn.CrossEntropyLoss()
def train_model(model, dataloaders, criterion, optimizer, num_epochs=25, is_inception=False, filename='best.pth'):
    since = time.time()
    best_acc = 0
    model.to(device)

    val_acc_history = []
    train_acc_history = []
    train_losses = []
    valid_losses = []
    LRs = [optimizer.param_groups[0]['lr']]

    best_model_wts = copy.deepcopy(model.state_dict())

    for epoch in range(num_epochs):
        print('Epoch {}/{}'.format(epoch, num_epochs - 1))
        print('-' * 10)

        # 训练和验证
        for phase in ['train', 'valid']:
            if phase == 'train':
                model.train()  # 训练
            else:
                model.eval()   # 验证

            running_loss = 0.0
            running_corrects = 0

            # 把数据都取个遍
            for inputs, labels in dataloaders[phase]:
                inputs = inputs.to(device)
                labels = labels.to(device)

                # 清零
                optimizer.zero_grad()
                # 只有训练的时候计算和更新梯度
                with torch.set_grad_enabled(phase == 'train'):
                    outputs = model(inputs)
                    loss = criterion(outputs, labels)
                    _, preds = torch.max(outputs, 1)
                    #print(loss)

                    # 训练阶段更新权重
                    if phase == 'train':
                        loss.backward()
                        optimizer.step()

                # 计算损失
                running_loss += loss.item() * inputs.size(0)
                running_corrects += torch.sum(preds == labels.data)

            epoch_loss = running_loss / len(dataloaders[phase].dataset)
            epoch_acc = running_corrects.double() / len(dataloaders[phase].dataset)


            time_elapsed = time.time() - since
            print('Time elapsed {:.0f}m {:.0f}s'.format(time_elapsed // 60, time_elapsed % 60))
            print('{} Loss: {:.4f} Acc: {:.4f}'.format(phase, epoch_loss, epoch_acc))


            # 得到最好那次的模型
            if phase == 'valid' and epoch_acc > best_acc:
                best_acc = epoch_acc
                best_model_wts = copy.deepcopy(model.state_dict())
                state = {
                  'state_dict': model.state_dict(),#字典里key就是各层的名字，值就是训练好的权重
                  'best_acc': best_acc,
                  'optimizer' : optimizer.state_dict(),#优化器的状态信息
                }
                torch.save(state, filename)
            if phase == 'valid':
                val_acc_history.append(epoch_acc)
                valid_losses.append(epoch_loss)
                scheduler.step(epoch_loss)#学习率衰减
            if phase == 'train':
                train_acc_history.append(epoch_acc)
                train_losses.append(epoch_loss)

        print('Optimizer learning rate : {:.7f}'.format(optimizer.param_groups[0]['lr']))
        LRs.append(optimizer.param_groups[0]['lr'])
        print()

    time_elapsed = time.time() - since
    print('Training complete in {:.0f}m {:.0f}s'.format(time_elapsed // 60, time_elapsed % 60))
    print('Best val Acc: {:4f}'.format(best_acc))

    # 训练完后用最好的一次当做模型最终的结果,等着一会测试
    model.load_state_dict(best_model_wts)
    return model, val_acc_history, train_acc_history, valid_losses, train_losses, LRs

model_ft, val_acc_history, train_acc_history, valid_losses, train_losses, LRs  = train_model(model_ft, dataloaders, criterion, optimizer_ft, num_epochs=20, filename='best.pth')

---

总结

今天第任务非常简单，是属于一个入门级的代码，适合新手，后面会一步一步加入新的内容。加深难度的。
