六、PulseAudio
PulseAudio 是一个声音服务器，位于 ALSA 或 OSS 等设备驱动之上。它提供了比设备驱动程序更多的功能。PulseAudio 专为消费类音频而设计，可轻松在台式机、笔记本电脑和移动设备上使用声音。多个声音源都可以播放给 PulseAudio 服务器，服务器会将它们混合在一起播放。低延迟不是设计目标，因此不适合专业音频。
资源
以下是一些资源:
- PulseAudio 首页(
www.freedesktop.org/wiki/Software/PulseAudio) - 伦纳德的《脉冲音频和 Jack》(
http://0pointer.de/blog/projects/when-pa-and-when-not.html) - “专业音频很容易，消费音频很难”(
http://lac.linuxaudio.org/2010/recordings/day1_1400_Pro_Audio_is_Easy_Consumer_Audio_is_Hard.ogv)，Lennart Poettering 的 60 分钟演讲 - PulseAudio API 文档(
http://freedesktop.org/software/pulseaudio/doxygen/index.html)
开始、停止和暂停脉冲音频
如果你有一个当前的 Linux 系统，PulseAudio 可能正在运行。通过从命令行运行以下命令对此进行测试:
ps agx | grep pulse
如果您看到类似/usr/bin/pulseaudio --start --log-target=syslog的行，那么它已经在运行了。
如果它没有运行，而您已经安装了它，那么使用以下命令启动它:
pulseaudio --start
停止 PulseAudio 并不容易。卡拉·施罗德展示了如何在 www.linuxplanet.com/linuxplanet/tutorials/7130/2 。最基本的问题是，PulseAudio 被设置为在被杀死后重生。你必须通过编辑/etc/pulse/client.conf，将autospawn = yes改为autospawn = no，并将daemon-binary设置为/bin/true来关闭它。然后，您可以终止该进程，将其从启动文件中删除，等等。
如果您想暂时运行另一个声音系统(如 Jack ),您可能只想暂停 PulseAudio。你可以通过使用pasuspender来实现。这需要一个命令(在--之后)，并将暂停 PulseAudio 服务器对音频设备的访问，直到子命令完成。例如，下面的代码将运行 Jack 服务器，PulseAudio 将退出，直到它完成:
pasuspender -- jackd
用户空间工具
除了编程 API 之外，PulseAudio 还有一系列用户级工具。这些工具提供有关 PulseAudio 系统的信息，并允许各种控制。Gnome 项目也有一个 PulseAudio 感知的控制中心。本节考虑这些工具。
帕曼
这将显示有关 PulseAudio 服务器、其设备和客户端的信息。图 6-1 到 6-3 显示了它给出的信息类型。
图 6-3。
Pulse Audio Manager client information
图 6-2。
Pulse Audio Manager device information
图 6-1。
Pulse Audio Manager server information
铺路机
pavumeter是一个简单的仪表，用于显示默认设备的输入或输出电平。当pavumeter运行时，显示播放设备，如图 6-4 所示。
图 6-4。
Pulse Audio playback volume meter
如果由pavumeter --record运行，则显示记录设备，如图 6-5 所示。
图 6-5。
Pulse Audio record volume meter
pavucontrol
pavucontrol允许您控制不同连接的音频设备的输入和输出音量，如图 6-6 所示。
图 6-6。
Pulse Audio pavucontrol output devices
通过这些选项卡，pavucontrol是一个设备级混音器，能够控制各个设备的整体音量。
PulseAudio 的一个特殊优势是可以进行应用级混音。如果两个音频源写入同一个 PulseAudio 设备，音频将被混合到输出设备。pavucontrol可以使用 Playback 选项卡显示多个应用，显示当前正在混合的所有应用或所有流。每个流都可以单独控制其通道音量。
例如，廉价的 Karaoke 可以通过以下方式将麦克风的直通模块设置为扬声器:
pactl load-module module-loopback latency_msec=1
Karaoke 文件由诸如kmid到timidity的 Karaoke 播放器播放。这里有一个例子:
kmid nightsin.kar
当这两个运行时，可以使用pavucontrol控制相对音量，如图 6-7 。
图 6-7。
Pulse Audio pavucontrol multiple devices
Gnome 控制中心(声音)
命令gnome-control-center sound允许完全查看和控制连接的声音设备，包括选择默认输入和输出设备。看起来像图 6-8 。
图 6-8。
Gnome control center
parec/paplay/pacat
parec、paplay和pacatare是录制和回放声音文件的命令行工具。它们都是指向相同代码的符号链接，只是链接的名称不同。默认格式是 PCM s16。有许多选择，但它们并不总是如你所愿。例如，要以最小的延迟从默认录制设备播放到默认播放设备，请使用以下命令:
pacat -r --latency-msec=1 | pacat -p --latency-msec=1
这实际上有大约 50 毫秒的延迟。
pactl/pacmd
这两个命令基本上做同样的事情。pacmd是选项更多的互动版。例如，带有命令list-sinks的pacmd包括以下内容:
name: <alsa_output.pci-0000_00_1b.0.analog-stereo>
driver: <module-alsa-card.c>
flags: HARDWARE HW_MUTE_CTRL HW_VOLUME_CTRL DECIBEL_VOLUME LATENCY FLAT_VOLUME DYNAMIC_LATENCY
state: SUSPENDED
suspend cause: IDLE
priority: 9959
volume: 0: 93% 1: 93%
0: -1.88 dB 1: -1.88 dB
balance 0.00
base volume: 100%
0.00 dB
volume steps: 65537
muted: no
current latency: 0.00 ms
max request: 0 KiB
max rewind: 0 KiB
monitor source: 1
sample spec: s16le 2ch 44100Hz
channel map: front-left,front-right
Stereo
used by: 0
linked by: 0
configured latency: 0.00 ms; range is 16.00 .. 2000.00 ms
card: 1 <alsa_card.pci-0000_00_1b.0>
module: 5
properties:
alsa.resolution_bits = "16"
device.api = "alsa"
device.class = "sound"
alsa.class = "generic"
alsa.subclass = "generic-mix"
alsa.name = "STAC92xx Analog"
alsa.id = "STAC92xx Analog"
alsa.subdevice = "0"
alsa.subdevice_name = "subdevice #0"
alsa.device = "0"
alsa.card = "0"
alsa.card_name = "HDA Intel PCH"
alsa.long_card_name = "HDA Intel PCH at 0xe6e60000 irq 47"
alsa.driver_name = "snd_hda_intel"
device.bus_path = "pci-0000:00:1b.0"
sysfs.path = "/devices/pci0000:00/0000:00:1b.0/sound/card0"
device.bus = "pci"
device.vendor.id = "8086"
device.vendor.name = "Intel Corporation"
device.product.id = "1c20"
device.product.name = "6 Series/C200 Series Chipset Family High Definition Audio Controller"
device.form_factor = "internal"
device.string = "front:0"
device.buffering.buffer_size = "352800"
device.buffering.fragment_size = "176400"
device.access_mode = "mmap+timer"
device.profile.name = "analog-stereo"
device.profile.description = "Analog Stereo"
device.description = "Internal Audio Analog Stereo"
alsa.mixer_name = "IDT 92HD90BXX"
alsa.components = "HDA:111d76e7,10280494,00100102"
module-udev-detect.discovered = "1"
device.icon_name = "audio-card-pci"
ports:
analog-output: Analog Output (priority 9900)
analog-output-headphones: Analog Headphones (priority 9000)
active port: <analog-output>
设备名称
PulseAudio 使用自己的命名约定。使用 PulseAudio FAQ ( www.freedesktop.org/wiki/Software/PulseAudio/FAQ#How_do_I_record_stuff.3F )中的代码可以找到源设备(如麦克风)的名称。
pactl list | grep -A2 'Source #' | grep 'Name: .*\.monitor$' | cut -d" " -f2
在我的系统上，这会产生以下结果:
alsa_output.pci-0000_01_00.1.hdmi-stereo.monitor
alsa_output.pci-0000_00_1b.0.analog-stereo.monitor
alsa_input.pci-0000_00_1b.0.analog-stereo
类似地，输出设备如下:
pactl list | grep -A2 'Sink #' | grep 'Name: .*\.monitor$' | cut -d" " -f2
这给出了以下内容:
alsa_output.pci-0000_01_00.1.hdmi-stereo
alsa_output.pci-0000_00_1b.0.analog-stereo
环回模块
使用pactl，您可以加载模块module-loopback,如下所示:
pactl load-module module-loopback latency_msec=1
当加载模块时，声音在内部从输入设备传送到输出设备。延迟实际上为零。
如果你把这个模块装入，比如说，你的笔记本电脑，拔下扬声器，麦克风等等的时候要小心。内部扬声器和麦克风足够近，可以建立一个反馈回路。用以下命令卸载 N 号模块:
pactl unload-module N
(如果您忘记了模块号，只需运行pactl就会列出所有模块，这样您就可以识别环回模块。)
脉动音频和 ALSA
pacmd的输出显示 PulseAudio 使用 ALSA。关系更深:默认的 ALSA 设备是hw:0，但是 PulseAudio 覆盖了它。在/etc/asound.conf中有一个用来装载/etc/alsa/pulse-default.conf的钩子，它包含以下内容:
pcm.!default {
type pulse
hint {
description "Default"
}
}
这将使用 PulseAudio 模块替换默认设备。
打开默认的 ALSA 设备实际上会调用 PulseAudio，然后 pulse audio 会用它选择的设备回调 ALSA。
使用 PulseAudio 编程
PulseAudio 及其文档的来源是 PulseAudio 2.0 ( http://freedesktop.org/software/pulseaudio/doxygen/index.html )。使用 PulseAudio 编程有两种方式:简单 API 和异步 API。这两者都将在下面的章节中介绍。
简单 API
PulseAudio 有一个“简单”的 API 和一个复杂得多的异步 API。简单的 API 可能足以满足您的需求。
简单 API 有一小组函数，如下所示:
pa_simple * pa_simple_new (const char *server, const char *name, pa_stream_direction_t dir, const char *dev, const char *stream_name, const pa_sample_spec *ss, const pa_channel_map *map, const pa_buffer_attr *attr, int *error)
Create a new connection to the server.
void pa_simple_free (pa_simple *s)
Close and free the connection to the server.
int pa_simple_write (pa_simple *s, const void *data, size_t bytes, int *error)
Write some data to the server.
int pa_simple_drain (pa_simple *s, int *error)
Wait until all data already written is played by the daemon.
int pa_simple_read (pa_simple *s, void *data, size_t bytes, int *error)
Read some data from the server.
pa_usec_t pa_simple_get_latency (pa_simple *s, int *error)
Return the playback latency.
int pa_simple_flush (pa_simple *s, int *error)
Flush the playback buffer
.
播放文件
“从文件播放到默认输出设备”旁边显示的程序来自 PulseAudio 网站。基本结构如下:
- 创建新的播放流(
pa_simple_new)。 - 从文件中读取块(
read)… - …把它们写到流中(
pa_simple_write)。 - 通过冲洗水流结束(
pa_simple_drain)。
节目是pacat-simple.c。更奇怪的是，它做了一个dup2来将打开的文件描述符映射到stdin上，然后从stdin中读取。没必要这样。为什么不直接从原始文件描述符中读取呢？
/***
* This file is part of PulseAudio.
*
* PulseAudio is free software; you can redistribute it and/or modify
* it under the terms of the GNU Lesser General Public License as published
* by the Free Software Foundation; either version 2.1 of the License,
* or (at your option) any later version.
*
* PulseAudio is distributed in the hope that it will be useful, but
* WITHOUT ANY WARRANTY; without even the implied warranty of
* MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU
* General Public License for more details.
*
* You should have received a copy of the GNU Lesser General Public License
* along with PulseAudio; if not, write to the Free Software
* Foundation, Inc., 59 Temple Place, Suite 330, Boston, MA 02111-1307
* USA.
****/
#ifdef HAVE_CONFIG_H
#include <config.h>
#endif
#include <stdio.h>
#include <unistd.h>
#include <string.h>
#include <errno.h>
#include <fcntl.h>
#include <pulse/simple.h>
#include <pulse/error.h>
#define BUFSIZE 1024
int main(int argc, char*argv[]) {
// set to NULL for default output device
char *device = "alsa_output.pci-0000_00_1b.0.analog-stereo";
/* The Sample format to use */
static const pa_sample_spec ss = {
.format = PA_SAMPLE_S16LE,
.rate = 44100,
.channels = 2
};
pa_simple *s = NULL;
int ret = 1;
int error;
/* replace STDIN with the specified file if needed */
if (argc > 1) {
int fd;
if ((fd = open(argv[1], O_RDONLY)) < 0) {
fprintf(stderr, __FILE__": open() failed: %s\n", strerror(errno));
goto finish;
}
if (dup2(fd, STDIN_FILENO) < 0) {
fprintf(stderr, __FILE__": dup2() failed: %s\n", strerror(errno));
goto finish;
}
close(fd);
}
/* Create a new playback stream */
if (!(s = pa_simple_new(NULL, argv[0], PA_STREAM_PLAYBACK, device, "playback", &ss, NULL, NULL, &error))) {
fprintf(stderr, __FILE__": pa_simple_new() failed: %s\n", pa_strerror(error));
goto finish;
}
for (;;) {
uint8_t buf[BUFSIZE];
ssize_t r;
#if 1
pa_usec_t latency;
if ((latency = pa_simple_get_latency(s, &error)) == (pa_usec_t) -1) {
fprintf(stderr, __FILE__": pa_simple_get_latency() failed: %s\n", pa_strerror(error));
goto finish;
}
fprintf(stderr, "%0.0f usec \r", (float)latency);
#endif
/* Read some data ... */
if ((r = read(STDIN_FILENO, buf, sizeof(buf))) <= 0) {
if (r == 0) /* EOF */
break;
fprintf(stderr, __FILE__": read() failed: %s\n", strerror(errno));
goto finish;
}
/* ... and play it */
if (pa_simple_write(s, buf, (size_t) r, &error) < 0) {
fprintf(stderr, __FILE__": pa_simple_write() failed: %s\n", pa_strerror(error));
goto finish;
}
}
/* Make sure that every single sample was played */
if (pa_simple_drain(s, &error) < 0) {
fprintf(stderr, __FILE__": pa_simple_drain() failed: %s\n", pa_strerror(error));
goto finish;
}
ret = 0;
finish:
if (s)
pa_simple_free(s);
return ret;
}
记录到文件中
“从默认输入设备记录到文件”旁边显示的程序来自 PulseAudio 网站。叫parec-simple.c。基本结构如下:
- 创建新的录制流(
pa_simple_new)。 - 从流中读取块(
pa_simple_read)… - …将它们写入输出(
write)。 - 通过释放流来结束(
pa_simple_free)。
注意，您需要使用一个pa_sample_spec来告诉 PulseAudio 写入数据的格式。这里我选择了双通道、44100Hz 和 PCM 16 位小端格式。
/***
This file is part of PulseAudio.
PulseAudio is free software; you can redistribute it and/or modify
it under the terms of the GNU Lesser General Public License as published
by the Free Software Foundation; either version 2.1 of the License,
or (at your option) any later version.
PulseAudio is distributed in the hope that it will be useful, but
WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU
General Public License for more details.
You should have received a copy of the GNU Lesser General Public License
along with PulseAudio; if not, write to the Free Software
Foundation, Inc., 59 Temple Place, Suite 330, Boston, MA 02111-1307
USA.
***/
#ifdef HAVE_CONFIG_H
#include <config.h>
#endif
#include <stdio.h>
#include <unistd.h>
#include <string.h>
#include <errno.h>
#include <pulse/simple.h>
#include <pulse/error.h>
#define BUFSIZE 1024
/* A simple routine calling UNIX write() in a loop */
static ssize_t loop_write(int fd, const void*data, size_t size) {
ssize_t ret = 0;
while (size > 0) {
ssize_t r;
if ((r = write(fd, data, size)) < 0)
return r;
if (r == 0)
break;
ret += r;
data = (const uint8_t*) data + r;
size -= (size_t) r;
}
return ret;
}
int main(int argc, char*argv[]) {
/* The sample type to use */
static const pa_sample_spec ss = {
.format = PA_SAMPLE_S16LE,
.rate = 44100,
.channels = 2
};
pa_simple *s = NULL;
int ret = 1;
int error;
/* Create the recording stream */
if (!(s = pa_simple_new(NULL, argv[0], PA_STREAM_RECORD, NULL, "record", &ss, NULL, NULL, &error))) {
fprintf(stderr, __FILE__": pa_simple_new() failed: %s\n", pa_strerror(error));
goto finish;
}
for (;;) {
uint8_t buf[BUFSIZE];
/* Record some data ... */
if (pa_simple_read(s, buf, sizeof(buf), &error) < 0) {
fprintf(stderr, __FILE__": pa_simple_read() failed: %s\n", pa_strerror(error));
goto finish;
}
/* And write it to STDOUT */
if (loop_write(STDOUT_FILENO, buf, sizeof(buf)) != sizeof(buf)) {
fprintf(stderr, __FILE__": write() failed: %s\n", strerror(errno));
goto finish;
}
}
ret = 0;
finish:
if (s)
pa_simple_free(s);
return ret;
}
此操作的输出是一个 PCM s16 文件。您可以使用sox(例如sox -c 2 -r 44100 tmp.s16 tmp.wav)将其转换为另一种格式，也可以将其作为原始数据导入 Audacity 并直接播放。
这些对于实时音频有多好？第一个程序可以显示等待时间(将#if 0改为#if 1)。这段代码也可以复制到第二段。结果并不好。
- 在我的笔记本电脑上录制有 11 毫秒的延迟。
- 回放有 130 毫秒的延迟。
从源到汇播放
您可以将这两个程序结合起来，使用录音和播放流从麦克风复制到扬声器。程序是pa-mic-2-speaker-simple.c，如下图所示:
#ifdef HAVE_CONFIG_H
#include <config.h>
#endif
#include <stdio.h>
#include <unistd.h>
#include <string.h>
#include <errno.h>
#include <fcntl.h>
#include <pulse/simple.h>
#include <pulse/error.h>
#define BUFSIZE 32
int main(int argc, char*argv[]) {
/* The Sample format to use */
static const pa_sample_spec ss = {
.format = PA_SAMPLE_S16LE,
.rate = 44100,
.channels = 2
};
pa_simple *s_in, *s_out = NULL;
int ret = 1;
int error;
/* Create a new playback stream */
if (!(s_out = pa_simple_new(NULL, argv[0], PA_STREAM_PLAYBACK, NULL, "playback", &ss, NULL, NULL, &error))) {
fprintf(stderr, __FILE__": pa_simple_new() failed: %s\n", pa_strerror(error));
goto finish;
}
if (!(s_in = pa_simple_new(NULL, argv[0], PA_STREAM_RECORD, NULL, "record", &ss, NULL, NULL, &error))) {
fprintf(stderr, __FILE__": pa_simple_new() failed: %s\n", pa_strerror(error));
goto finish;
}
for (;;) {
uint8_t buf[BUFSIZE];
ssize_t r;
#if 1
pa_usec_t latency;
if ((latency = pa_simple_get_latency(s_in, &error)) == (pa_usec_t) -1) {
fprintf(stderr, __FILE__": pa_simple_get_latency() failed: %s\n", pa_strerror(error));
goto finish;
}
fprintf(stderr, "In: %0.0f usec \r\n", (float)latency);
if ((latency = pa_simple_get_latency(s_out, &error)) == (pa_usec_t) -1) {
fprintf(stderr, __FILE__": pa_simple_get_latency() failed: %s\n", pa_strerror(error));
goto finish;
}
fprintf(stderr, "Out: %0.0f usec \r\n", (float)latency);
#endif
if (pa_simple_read(s_in, buf, sizeof(buf), &error) < 0) {
fprintf(stderr, __FILE__": read() failed: %s\n", strerror(errno));
goto finish;
}
/* ... and play it */
if (pa_simple_write(s_out, buf, sizeof(buf), &error) < 0) {
fprintf(stderr, __FILE__": pa_simple_write() failed: %s\n", pa_strerror(error));
goto finish;
}
}
/* Make sure that every single sample was played */
if (pa_simple_drain(s_out, &error) < 0) {
fprintf(stderr, __FILE__": pa_simple_drain() failed: %s\n", pa_strerror(error));
goto finish;
}
ret = 0;
finish:
if (s_in)
pa_simple_free(s_in);
if (s_out)
pa_simple_free(s_out);
return ret;
}
试着运行它，你会发现延迟是明显的，并且不令人满意。
异步 API
简单的 API 很简单。相比之下，异步 API 又大又复杂。使用这个 API 的例子也很少。
几乎所有与该 API 的交互都是异步的。对 PulseAudio 服务器发出一个调用，当响应就绪时，一个库调用一个回调函数，您将在发出库调用时将这个函数传递给它。这避免了用户代码阻塞或进行轮询调用的需要。
基本结构如下:
- 创建一个 PulseAudio 主循环(同步:
pa_mainloop_new)。 - 获取
mainloopAPI 对象，这是一个mainloop函数的表(同步:pa_mainloop_get_api)。 - 获取一个上下文对象与 PulseAudio 服务器对话(同步:
pa_context_new)。 - 建立与 PulseAudio 服务器的连接。这就是异步:
pa_context_connect。 - 从服务器注册上下文状态更改的回调:
pa_context_set_state_callback。 - 开始事件处理循环(
pa_mainloop_run)。 - 在上下文状态回调中，确定什么状态已经更改。例如，连接已经建立。
- 在这个回调中，设置、记录或回放流。
- 为这些流建立进一步的回调。
- 在流回调中，进行更多的处理，比如将记录流保存到文件中。
步骤 1-7 对于大多数应用来说都是常见的。将调用上下文状态回调来响应服务器中的更改。这些是状态变化，例如PA_CONTEXT_CONNECTIN、PA_CONTEXT_SETTING_NAME等等。与大多数应用相关的变化将是PA_CONTEXT_READY。这意味着应用可以在稳定状态下向服务器发出请求。
在第 8 步中，应用将设置自己的行为。这是通过为各种操作设置进一步的回调函数来实现的，比如列出设备或播放音频。
设备列表
函数pa_context_get_sink_info_list将设置一个回调函数，列出源设备，如下所示:
pa_context_get_sink_info_list(c, sinklist_cb, NULL)
其中c是上下文，sinklist_cb是应用的回调，NULL是传递给回调的用户数据。
回调的调用方式如下:
void sinklist_cb(pa_context *c, const pa_sink_info *i, int eol, void *userdata)
参数eol可以取三个值:负表示某种失败，零表示pa_sink_info的有效条目，正表示列表中不再有有效条目。
结构pa_sink_info定义如下:
struct {
const char * name;
uint32_t index;
const char * description;
pa_sample_spec sample_spec;
pa_channel_map channel_map;
uint32_t owner_module;
pa_cvolume volume;
int mute;
uint32_t monitor_source;
const char * monitor_source_name;
pa_usec_t latency;
const char * driver;
pa_sink_flags_t flags;
pa_proplist * proplist;
pa_usec_t configured_latency;
pa_volume_t base_volume;
pa_sink_state_t state;
uint32_t n_volume_steps;
uint32_t card;
uint32_t n_ports;
pa_sink_port_info ** ports;
pa_sink_port_info * active_port;
uint8_t n_formats;
pa_format_info ** formats;
} pa_sink_info
关于此结构的更多信息保存在 Doxygen " pa_sink_info结构参考"( http://freedesktop.org/software/pulseaudio/doxygen/structpa__sink__info.html )中。
供参考，主要字段是name和description。index是一些数据结构的不透明索引，在许多 PulseAudio 函数中使用。proplist是可能包含有趣信息的一般信息图。这可以通过遍历地图来检索。
输入设备也有类似的回调和数据结构。
A program to list input and output devices current when the application connects to the server is palist_devices.c:
/**
* palist_devices.c
* Jan Newmarch
*/
#include <stdio.h>
#include <string.h>
#include <pulse/pulseaudio.h>
#define _(x) x
// quit when this reaches 2
int no_more_sources_or_sinks = 0;
int ret;
pa_context *context;
void show_error(char *s) {
fprintf(stderr, "%s\n", s);
}
void print_properties(pa_proplist *props) {
void *state = NULL;
printf(" Properties are: \n");
while (1) {
char *key;
if ((key = pa_proplist_iterate(props, &state)) == NULL) {
return;
}
char *value = pa_proplist_gets(props, key);
printf(" key: %s, value: %s\n", key, value);
}
}
/**
* print information about a sink
*/
void sinklist_cb(pa_context *c, const pa_sink_info *i, int eol, void *userdata) {
// If eol is set to a positive number, you're at the end of the list
if (eol > 0) {
printf("**No more sinks\n");
no_more_sources_or_sinks++;
if (no_more_sources_or_sinks == 2)
exit(0);
return;
}
printf("Sink: name %s, description %s\n", i->name, i->description);
print_properties(i->proplist);
}
/**
* print information about a source
*/
void sourcelist_cb(pa_context *c, const pa_source_info *i, int eol, void *userdata) {
if (eol > 0) {
printf("**No more sources\n");
no_more_sources_or_sinks++;
if (no_more_sources_or_sinks == 2)
exit(0);
return;
}
printf("Source: name %s, description %s\n", i->name, i->description);
print_properties(i->proplist);
}
void context_state_cb(pa_context *c, void *userdata) {
switch (pa_context_get_state(c)) {
case PA_CONTEXT_UNCONNECTED:
case PA_CONTEXT_CONNECTING:
case PA_CONTEXT_AUTHORIZING:
case PA_CONTEXT_SETTING_NAME:
break;
case PA_CONTEXT_READY: {
pa_operation *o;
// set up a callback to tell us about source devices
if (!(o = pa_context_get_source_info_list(c,
sourcelist_cb,
NULL
))) {
show_error(_("pa_context_subscribe() failed"));
return;
}
pa_operation_unref(o);
// set up a callback to tell us about sink devices
if (!(o = pa_context_get_sink_info_list(c,
sinklist_cb,
NULL
))) {
show_error(_("pa_context_subscribe() failed"));
return;
}
pa_operation_unref(o);
break;
}
case PA_CONTEXT_FAILED:
case PA_CONTEXT_TERMINATED:
default:
return;
}
}
int main(int argc, char *argv[]) {
// Define our pulse audio loop and connection variables
pa_mainloop *pa_ml;
pa_mainloop_api *pa_mlapi;
// Create a mainloop API and connection to the default server
pa_ml = pa_mainloop_new();
pa_mlapi = pa_mainloop_get_api(pa_ml);
context = pa_context_new(pa_mlapi, "Device list");
// This function connects to the pulse server
pa_context_connect(context, NULL, 0, NULL);
// This function defines a callback so the server will tell us its state.
pa_context_set_state_callback(context, context_state_cb, NULL);
if (pa_mainloop_run(pa_ml, &ret) < 0) {
printf("pa_mainloop_run() failed.");
exit(1);
}
}
在我的笔记本电脑上，它给出了以下内容(省略):
Source: name alsa_output.pci-0000_01_00.1.hdmi-stereo.monitor, description Monitor of HDMI Audio stub Digital Stereo (HDMI)
Properties are:
key: device.description, value: Monitor of HDMI Audio stub Digital Stereo (HDMI)
key: device.class, value: monitor
key: alsa.card, value: 1
key: alsa.card_name, value: HDA NVidia
key: alsa.long_card_name, value: HDA NVidia at 0xe5080000 irq 17
key: alsa.driver_name, value: snd_hda_intel
key: device.bus_path, value: pci-0000:01:00.1
key: sysfs.path, value: /devices/pci0000:00/0000:00:01.0/0000:01:00.1/sound/card1
key: device.bus, value: pci
key: device.vendor.id, value: 10de
key: device.vendor.name, value: nVidia Corporation
key: device.product.id, value: 0e08
key: device.product.name, value: HDMI Audio stub
key: device.string, value: 1
key: module-udev-detect.discovered, value: 1
key: device.icon_name, value: audio-card-pci
Source: name alsa_output.pci-0000_00_1b.0.analog-stereo.monitor, description Monitor of Internal Audio Analog Stereo
Properties are:
...
Source: name alsa_input.pci-0000_00_1b.0.analog-stereo, description Internal Audio Analog Stereo
Properties are:
...
Source: name alsa_output.usb-Creative_Technology_Ltd_SB_X-Fi_Surround_5.1_Pro_000003d0-00-Pro.analog-stereo.monitor, description Monitor of SB X-Fi Surround 5.1 Pro Analog Stereo
Properties are:
...
Source: name alsa_input.usb-Creative_Technology_Ltd_SB_X-Fi_Surround_5.1_Pro_000003d0-00-Pro.analog-stereo, description SB X-Fi Surround 5.1 Pro Analog Stereo
Properties are:
...
**No more sources
Sink: name alsa_output.pci-0000_01_00.1.hdmi-stereo, description HDMI Audio stub Digital Stereo (HDMI)
Properties are:
key: alsa.resolution_bits, value: 16
key: device.api, value: alsa
key: device.class, value: sound
key: alsa.class, value: generic
key: alsa.subclass, value: generic-mix
key: alsa.name, value: HDMI 0
key: alsa.id, value: HDMI 0
key: alsa.subdevice, value: 0
key: alsa.subdevice_name, value: subdevice #0
key: alsa.device, value: 3
key: alsa.card, value: 1
key: alsa.card_name, value: HDA NVidia
key: alsa.long_card_name, value: HDA NVidia at 0xe5080000 irq 17
key: alsa.driver_name, value: snd_hda_intel
key: device.bus_path, value: pci-0000:01:00.1
key: sysfs.path, value: /devices/pci0000:00/0000:00:01.0/0000:01:00.1/sound/card1
key: device.bus, value: pci
key: device.vendor.id, value: 10de
key: device.vendor.name, value: nVidia Corporation
key: device.product.id, value: 0e08
key: device.product.name, value: HDMI Audio stub
key: device.string, value: hdmi:1
key: device.buffering.buffer_size, value: 352768
key: device.buffering.fragment_size, value: 176384
key: device.access_mode, value: mmap+timer
key: device.profile.name, value: hdmi-stereo
key: device.profile.description, value: Digital Stereo (HDMI)
key: device.description, value: HDMI Audio stub Digital Stereo (HDMI)
key: alsa.mixer_name, value: Nvidia GPU 1c HDMI/DP
key: alsa.components, value: HDA:10de001c,10281494,00100100
key: module-udev-detect.discovered, value: 1
key: device.icon_name, value: audio-card-pci
Sink: name alsa_output.pci-0000_00_1b.0.analog-stereo, description Internal Audio Analog Stereo
Properties are:
...
Sink: name alsa_output.usb-Creative_Technology_Ltd_SB_X-Fi_Surround_5.1_Pro_000003d0-00-Pro.analog-stereo, description SB X-Fi Surround 5.1 Pro Analog Stereo
Properties are:
...
**No more sinks
一个具有相同效果的替代程序是由 Igor Brezac 和 Eric Connell 编写的 PulseAudio:一个获取设备列表的异步示例( www.ypass.net/blog/2009/10/pulseaudio-an-async-example-to-get-device-lists )。它不像前一个那样遵循复杂的路线，因为它只向服务器查询它的设备。然而，它使用自己的状态机来跟踪它在回调过程中的位置！
监测正在发生的变化:新的源和汇
前面的程序列出了在建立与服务器的连接时向 PulseAudio 注册的源设备和接收设备。但是，当连接新设备或断开现有设备时，PulseAudio 会在上下文中注册一个更改，这也可以通过回调来监控。
这样做的关键是用pa_context_subscribe订阅上下文变化。这需要一个上下文、订阅事件的掩码和用户数据。掩码的可能值在 http://freedesktop.org/software/pulseaudio/doxygen/def_8h.html#ad4e7f11f879e8c77ae5289145ecf6947 处描述，包括汇点变化的PA_SUBSCRIPTION_MASK_SINK和汇点输入事件的PA_SUBSCRIPTION_MASK_SINK_INPUT。
设置回调函数来监控这些变化有点奇怪。函数pa_context_subscribe接受一个类型为pa_context_success_cb的回调函数，但是它不包含关于回调原因的信息。与其这样，还不如先给pa_context_set_subscribe_callback打电话。这需要一个类型为pa_context_subscribe_cb_t的回调函数，它确实传递了这样的信息。然后在pa_context_subscribe用NULL回拨！
在pa_context_subscribe_cb_t订阅回调中，可以检查回调的原因并调用适当的代码。如果发现一个新的接收器订阅，那么可以用pa_context_get_sink_info_by_index找到关于接收器的信息，这需要另一个回调！在追踪所有这些回调之后，您最终可以获得新设备的信息。
注意pa_context_get_sink_info_list使用的回调函数和pa_context_get_sink_info_by_index使用的回调函数是一样的。无论接收器设备是单个设备还是设备列表中的一个设备，每个接收器设备都会调用一次回调。
A program to list devices on connection and also to list changes as devices are connected or disconnected is palist_devices_ongoing.c:
/**
* palist_clients.c
* Jan Newmarch
*/
/***
This file is based on pacat.c and pavuctl.c, part of PulseAudio.
pacat.c:
Copyright 2004-2006 Lennart Poettering
Copyright 2006 Pierre Ossman <ossman@cendio.se> for Cendio AB
PulseAudio is free software; you can redistribute it and/or modify
it under the terms of the GNU Lesser
General Public License as published
by the Free Software Foundation; either version 2.1 of the License,
or (at your option) any later version.
PulseAudio is distributed in the hope that it will be useful, but
WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU
General Public License for more details.
You should have received a copy of the GNU Lesser General Public License
along with PulseAudio; if not, write to the Free Software
Foundation, Inc., 59 Temple Place, Suite 330, Boston, MA 02111-1307
USA.
***/
#include <stdio.h>
#include <string.h>
#include <pulse/pulseaudio.h>
#define _(x) x
int ret;
pa_context *context;
void show_error(char *s) {
fprintf(stderr, "%s\n", s);
}
void print_properties(pa_proplist *props) {
void *state = NULL;
printf(" Properties are: \n");
while (1) {
char *key;
if ((key = pa_proplist_iterate(props, &state)) == NULL) {
return;
}
char *value = pa_proplist_gets(props, key);
printf(" key: %s, value: %s\n", key, value);
}
}
/**
* print information about a sink
*/
void sink_cb(pa_context *c, const pa_sink_info *i, int eol, void *userdata) {
// If eol is set to a positive number, you're at the end of the list
if (eol > 0) {
return;
}
printf("Sink: name %s, description %s\n", i->name, i->description);
// print_properties(i->proplist);
}
/**
* print information about a source
*/
void source_cb(pa_context *c, const pa_source_info *i, int eol, void *userdata) {
if (eol > 0) {
return;
}
printf("Source: name %s, description %s\n", i->name, i->description);
// print_properties(i->proplist);
}
void subscribe_cb(pa_context *c, pa_subscription_event_type_t t, uint32_t index, void *userdata) {
switch (t & PA_SUBSCRIPTION_EVENT_FACILITY_MASK) {
case PA_SUBSCRIPTION_EVENT_SINK:
if ((t & PA_SUBSCRIPTION_EVENT_TYPE_MASK) == PA_SUBSCRIPTION_EVENT_REMOVE)
printf("Removing sink index %d\n", index);
else {
pa_operation *o;
if (!(o = pa_context_get_sink_info_by_index(c, index, sink_cb, NULL))) {
show_error(_("pa_context_get_sink_info_by_index() failed"));
return;
}
pa_operation_unref(o);
}
break;
case PA_SUBSCRIPTION_EVENT_SOURCE:
if ((t & PA_SUBSCRIPTION_EVENT_TYPE_MASK) == PA_SUBSCRIPTION_EVENT_REMOVE)
printf("Removing source index %d\n", index);
else {
pa_operation *o;
if (!(o = pa_context_get_source_info_by_index(c, index, source_cb, NULL))) {
show_error(_("pa_context_get_source_info_by_index() failed"));
return;
}
pa_operation_unref(o);
}
break;
}
}
void context_state_cb(pa_context *c, void *userdata) {
switch (pa_context_get_state(c)) {
case PA_CONTEXT_UNCONNECTED:
case PA_CONTEXT_CONNECTING:
case PA_CONTEXT_AUTHORIZING:
case PA_CONTEXT_SETTING_NAME:
break;
case PA_CONTEXT_READY: {
pa_operation *o;
if (!(o = pa_context_get_source_info_list(c,
source_cb,
NULL
))) {
show_error(_("pa_context_subscribe() failed"));
return;
}
pa_operation_unref(o);
if (!(o = pa_context_get_sink_info_list(c,
sink_cb,
NULL
))) {
show_error(_("pa_context_subscribe() failed"));
return;
}
pa_operation_unref(o);
pa_context_set_subscribe_callback(c, subscribe_cb, NULL);
if (!(o = pa_context_subscribe(c, (pa_subscription_mask_t)
(PA_SUBSCRIPTION_MASK_SINK|
PA_SUBSCRIPTION_MASK_SOURCE), NULL, NULL))) {
show_error(_("pa_context_subscribe() failed"));
return;
}
pa_operation_unref(o);
break;
}
case PA_CONTEXT_FAILED:
case PA_CONTEXT_TERMINATED:
default:
return;
}
}
int main(int argc, char *argv[]) {
// Define our pulse audio loop and connection variables
pa_mainloop *pa_ml;
pa_mainloop_api *pa_mlapi;
pa_operation *pa_op;
pa_time_event *time_event;
// Create a mainloop API and connection to the default server
pa_ml = pa_mainloop_new();
pa_mlapi = pa_mainloop_get_api(pa_ml);
context = pa_context_new(pa_mlapi, "Device list");
// This function connects to the pulse server
pa_context_connect(context, NULL, 0, NULL);
// This function defines a callback so the server will tell us its state.
pa_context_set_state_callback(context, context_state_cb, NULL);
if (pa_mainloop_run(pa_ml, &ret) < 0) {
printf("pa_mainloop_run() failed.");
exit(1);
}
}
记录一条小溪
如果你从 FreeDesktop.org(www.freedesktop.org/wiki/Software/PulseAudio/Download)下载 PulseAudio 的源码，你会在utils目录中找到一个名为pacat.c的程序。这个程序使用了一些私有 API，不会使用公共库进行编译。它还拥有你期望从制作程序中得到的所有功能。我已经把它去掉了复杂性，这样你就可以找到进入这个 API 的方法。文件是parec.c。
/**
* parec.c
* Jan Newmarch
*/
/***
This file is based on pacat.c, part of PulseAudio.
pacat.c:
Copyright 2004-2006 Lennart Poettering
Copyright 2006 Pierre Ossman <ossman@cendio.se> for Cendio AB
PulseAudio is free software; you can redistribute it and/or modify
it under the terms of the GNU Lesser General Public License as published
by the Free Software Foundation; either version 2.1 of the License,
or (at your option) any later version.
PulseAudio is distributed in the hope that it will be useful, but
WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU
General Public License for more details.
You should have received a copy of the GNU Lesser General Public License
along with PulseAudio; if not, write to the Free Software
Foundation, Inc., 59 Temple Place, Suite 330, Boston, MA 02111-1307
USA.
***/
#include <stdio.h>
#include <string.h>
#include <pulse/pulseaudio.h>
#define CLEAR_LINE "\n"
#define _(x) x
// From pulsecore/macro.h
#define pa_memzero(x,l) (memset((x), 0, (l)))
#define pa_zero(x) (pa_memzero(&(x), sizeof(x)))
int fdout;
char *fname = "tmp.s16";
int verbose = 1;
int ret;
pa_context *context;
static pa_sample_spec sample_spec = {
.format = PA_SAMPLE_S16LE,
.rate = 44100,
.channels = 2
};
static pa_stream *stream = NULL;
/* This is my builtin card. Use paman to find yours
or set it to NULL to get the default device
*/
static char *device = "alsa_input.pci-0000_00_1b.0.analog-stereo";
static pa_stream_flags_t flags = 0;
void stream_state_callback(pa_stream *s, void *userdata) {
assert(s);
switch (pa_stream_get_state(s)) {
case PA_STREAM_CREATING:
// The stream has been created, so
// let's open a file to record to
printf("Creating stream\n");
fdout = creat(fname, 0711);
break;
case PA_STREAM_TERMINATED:
close(fdout);
break;
case PA_STREAM_READY:
// Just for info: no functionality in this branch
if (verbose) {
const pa_buffer_attr *a;
char cmt[PA_CHANNEL_MAP_SNPRINT_MAX], sst[PA_SAMPLE_SPEC_SNPRINT_MAX];
printf("Stream successfully created.");
if (!(a = pa_stream_get_buffer_attr(s)))
printf("pa_stream_get_buffer_attr() failed: %s", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
else {
printf("Buffer metrics: maxlength=%u, fragsize=%u", a->maxlength, a->fragsize);
}
printf("Connected to device %s (%u, %ssuspended).",
pa_stream_get_device_name(s),
pa_stream_get_device_index(s),
pa_stream_is_suspended(s) ? "" : "not ");
}
break;
case PA_STREAM_FAILED:
default:
printf("Stream error: %s", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
exit(1);
}
}
/*********** Stream callbacks **************/
/* This is called whenever new data is available */
static void stream_read_callback(pa_stream *s, size_t length, void *userdata) {
assert(s);
assert(length > 0);
// Copy the data from the server out to a file
fprintf(stderr, "Can read %d\n", length);
while (pa_stream_readable_size(s) > 0) {
const void *data;
size_t length;
// peek actually creates and fills the data vbl
if (pa_stream_peek(s, &data, &length) < 0) {
fprintf(stderr, "Read failed\n");
exit(1);
return;
}
fprintf(stderr, "Writing %d\n", length);
write(fdout, data, length);
// swallow the data peeked at before
pa_stream_drop(s);
}
}
// This callback gets called when our context changes state. We really only
// care about when it's ready or if it has failed
void state_cb(pa_context *c, void *userdata) {
pa_context_state_t state;
int *pa_ready = userdata;
printf("State changed\n");
state = pa_context_get_state(c);
switch (state) {
// There are just here for reference
case PA_CONTEXT_UNCONNECTED:
case PA_CONTEXT_CONNECTING:
case PA_CONTEXT_AUTHORIZING:
case PA_CONTEXT_SETTING_NAME:
default:
break;
case PA_CONTEXT_FAILED:
case PA_CONTEXT_TERMINATED:
*pa_ready = 2;
break;
case PA_CONTEXT_READY: {
pa_buffer_attr buffer_attr;
if (verbose)
printf("Connection established.%s\n", CLEAR_LINE);
if (!(stream = pa_stream_new(c, "JanCapture", &sample_spec, NULL))) {
printf("pa_stream_new() failed: %s", pa_strerror(pa_context_errno(c)));
exit(1);
}
// Watch for changes in the stream state to create the output file
pa_stream_set_state_callback(stream, stream_state_callback, NULL);
// Watch for changes in the stream's read state to write to the output file
pa_stream_set_read_callback(stream, stream_read_callback, NULL);
// Set properties of the record buffer
pa_zero(buffer_attr);
buffer_attr.maxlength = (uint32_t) -1;
buffer_attr.prebuf = (uint32_t) -1;
buffer_attr.fragsize = buffer_attr.tlength = (uint32_t) -1;
buffer_attr.minreq = (uint32_t) -1;
// and start recording
if (pa_stream_connect_record(stream, device, &buffer_attr, flags) < 0) {
printf("pa_stream_connect_record() failed: %s", pa_strerror(pa_context_errno(c)));
exit(1);
}
}
break;
}
}
int main(int argc, char *argv[]) {
// Define our pulse audio loop and connection variables
pa_mainloop *pa_ml;
pa_mainloop_api *pa_mlapi;
pa_operation *pa_op;
pa_time_event *time_event;
// Create a mainloop API and connection to the default server
pa_ml = pa_mainloop_new();
pa_mlapi = pa_mainloop_get_api(pa_ml);
context = pa_context_new(pa_mlapi, "test");
// This function connects to the pulse server
pa_context_connect(context, NULL, 0, NULL);
// This function defines a callback so the server will tell us its state.
pa_context_set_state_callback(context, state_cb, NULL);
if (pa_mainloop_run(pa_ml, &ret) < 0) {
printf("pa_mainloop_run() failed.");
exit(1);
}
}
播放文件
记录输入流是通过调用pa_stream_peek在流读取回调中完成的。类似地，播放输出流是通过调用pa_stream_write的流写回调来完成的。
在下面的程序中，回调是在上下文状态更改回调的PA_CONTEXT_READY分支中设置的。向流写回调传递消费流准备接收的字节数，因此从文件中读取该字节数并将它们写入流。
在文件结尾必须小心。PulseAudio 的输出缓冲区中可能有未播放的素材。这需要在程序退出前排空。这是通过函数pa_stream_drain完成的。在文件结束时，首先将流写回调设置为null，这样输出流就不会一直调用更多的输入，然后清空流。完成后将调用流排出完成回调，因此程序可以退出(或做其他事情)。
在这个程序中，我包含了比以前更多的回调函数，以展示可以监控的特性范围。
节目是pacat2.c。
/**
* pacat2.c
* Jan Newmarch
*/
/***
This file is based on pacat.c, part of PulseAudio.
pacat.c:
Copyright 2004-2006 Lennart Poettering
Copyright 2006 Pierre Ossman <ossman@cendio.se> for Cendio AB
PulseAudio is free software; you can redistribute it and/or modify
it under the terms of the GNU Lesser General Public License as published
by the Free Software Foundation; either version 2.1 of the License,
or (at your option) any later version.
PulseAudio is distributed in the hope that it will be useful, but
WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU
General Public License for more details.
You should have received a copy of the GNU Lesser General Public License
along with PulseAudio; if not, write to the Free Software
Foundation, Inc., 59 Temple Place, Suite 330, Boston, MA 02111-1307
USA.
***/
#include <stdio.h>
#include <string.h>
#include <pulse/pulseaudio.h>
#include <sys/stat.h>
#include <sys/types.h>
#include <fcntl.h>
#include <errno.h>
#include <unistd.h>
// ???
#define CLEAR_LINE "\n"
// From pulsecore/macro.h JN
#define pa_memzero(x,l) (memset((x), 0, (l)))
#define pa_zero(x) (pa_memzero(&(x), sizeof(x)))
int verbose = 1;
int ret;
static pa_volume_t volume = PA_VOLUME_NORM;
static int volume_is_set = 0;
static int fdin;
static pa_sample_spec sample_spec = {
.format = PA_SAMPLE_S16LE,
.rate = 44100,
.channels = 2
};
static pa_stream *stream = NULL;
static pa_channel_map channel_map;
static pa_proplist *proplist = NULL;
// Define our pulse audio loop and connection variables
static pa_mainloop *mainloop;
static pa_mainloop_api *mainloop_api;
static pa_operation *pa_op;
static pa_context *context = NULL;
static void *buffer = NULL;
static size_t buffer_length = 0, buffer_index = 0;
static pa_io_event* stdio_event = NULL;
// Get device name from e.g. paman
//static char *device = "alsa_output.pci-0000_00_1b.0.analog-stereo";
// Use default device
static char *device = NULL;
static pa_stream_flags_t flags = 0;
static size_t latency = 0, process_time = 0;
static int32_t latency_msec = 1, process_time_msec = 0;
static int raw = 1;
/* Connection draining complete */
static void context_drain_complete(pa_context*c, void *userdata) {
pa_context_disconnect(c);
}
static void stream_drain_complete(pa_stream*s, int success, void *userdata) {
pa_operation *o = NULL;
if (!success) {
printf("Failed to drain stream: %s", pa_strerror(pa_context_errno(context)));
exit(1);
}
if (verbose)
printf("Playback stream drained.");
pa_stream_disconnect(stream);
pa_stream_unref(stream);
stream = NULL;
if (!(o = pa_context_drain(context, context_drain_complete, NULL)))
pa_context_disconnect(context);
else {
pa_operation_unref(o);
if (verbose)
printf("Draining connection to server.");
}
}
/* Start draining */
static void start_drain(void) {
printf("Draining\n");
if (stream) {
pa_operation *o;
pa_stream_set_write_callback(stream, NULL, NULL);
if (!(o = pa_stream_drain(stream, stream_drain_complete, NULL))) {
//printf("pa_stream_drain(): %s", pa_strerror(pa_context_errno(context)));
exit(1);
return;
}
pa_operation_unref(o);
} else
exit(0);
}
/* Write some data to the stream */
static void do_stream_write(size_t length) {
size_t l;
assert(length);
printf("do stream write: Writing %d to stream\n", length);
if (!buffer || !buffer_length) {
buffer = pa_xmalloc(length);
buffer_length = length;
buffer_index = 0;
//printf(" return without writing\n");
//return;
}
while (buffer_length > 0) {
l = read(fdin, buffer + buffer_index, buffer_length);
if (l <= 0) {
start_drain();
return;
}
if (pa_stream_write(stream, (uint8_t*) buffer + buffer_index, l, NULL, 0, PA_SEEK_RELATIVE) < 0) {
printf("pa_stream_write() failed: %s", pa_strerror(pa_context_errno(context)));
exit(1);
return;
}
buffer_length -= l;
buffer_index += l;
if (!buffer_length) {
pa_xfree(buffer);
buffer = NULL;
buffer_index = buffer_length = 0;
}
}
}
void stream_state_callback(pa_stream *s, void *userdata) {
assert(s);
switch (pa_stream_get_state(s)) {
case PA_STREAM_CREATING:
break;
case PA_STREAM_TERMINATED:
break;
case PA_STREAM_READY:
if (verbose) {
const pa_buffer_attr *a;
char cmt[PA_CHANNEL_MAP_SNPRINT_MAX], sst[PA_SAMPLE_SPEC_SNPRINT_MAX];
printf("Stream successfully created.\n");
if (!(a = pa_stream_get_buffer_attr(s)))
printf("pa_stream_get_buffer_attr() failed: %s\n", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
else {
printf("Buffer metrics: maxlength=%u, fragsize=%u\n", a->maxlength, a->fragsize);
}
/*
printf("Using sample spec '%s', channel map '%s'.",
pa_sample_spec_snprint(sst, sizeof(sst), pa_stream_get_sample_spec(s)),
pa_channel_map_snprint(cmt, sizeof(cmt), pa_stream_get_channel_map(s)));
*/
printf("Connected to device %s (%u, %ssuspended).\n",
pa_stream_get_device_name(s),
pa_stream_get_device_index(s),
pa_stream_is_suspended(s) ? "" : "not ");
}
break;
case PA_STREAM_FAILED:
default:
printf("Stream error: %s", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
exit(1); //quit(1);
}
}
/*********** Stream callbacks **************/
static void stream_success(pa_stream *s, int succes, void *userdata) {
printf("Succeded\n");
}
static void stream_suspended_callback(pa_stream *s, void *userdata) {
assert(s);
if (verbose) {
if (pa_stream_is_suspended(s))
fprintf(stderr, "Stream device suspended.%s \n", CLEAR_LINE);
else
fprintf(stderr, "Stream device resumed.%s \n", CLEAR_LINE);
}
}
static void stream_underflow_callback(pa_stream *s, void *userdata) {
assert(s);
if (verbose)
fprintf(stderr, "Stream underrun.%s \n", CLEAR_LINE);
}
static void stream_overflow_callback(pa_stream *s, void *userdata) {
assert(s);
if (verbose)
fprintf(stderr, "Stream overrun.%s \n", CLEAR_LINE);
}
static void stream_started_callback(pa_stream *s, void *userdata) {
assert(s);
if (verbose)
fprintf(stderr, "Stream started.%s \n", CLEAR_LINE);
}
static void stream_moved_callback(pa_stream *s, void *userdata) {
assert(s);
if (verbose)
fprintf(stderr, "Stream moved to device %s (%u, %ssuspended).%s \n", pa_stream_get_device_name(s), pa_stream_get_device_index(s), pa_stream_is_suspended(s) ? "" : "not ", CLEAR_LINE);
}
static void stream_buffer_attr_callback(pa_stream *s, void *userdata) {
assert(s);
if (verbose)
fprintf(stderr, "Stream buffer attributes changed.%s \n", CLEAR_LINE);
}
static void stream_event_callback(pa_stream *s, const char *name, pa_proplist *pl, void *userdata) {
char *t;
assert(s);
assert(name);
assert(pl);
t = pa_proplist_to_string_sep(pl, ", ");
fprintf(stderr, "Got event '%s', properties '%s'\n", name, t);
pa_xfree(t);
}
/* This is called whenever new data may be written to the stream */
static void stream_write_callback(pa_stream *s, size_t length, void *userdata) {
//assert(s);
//assert(length > 0);
printf("Stream write callback: Ready to write %d bytes\n", length);
printf(" do stream write from stream write callback\n");
do_stream_write(length);
}
// This callback gets called when our context changes state. We really only
// care about when it's ready or if it has failed
void state_cb(pa_context *c, void *userdata) {
pa_context_state_t state;
int *pa_ready = userdata;
printf("State changed\n");
state = pa_context_get_state(c);
switch (state) {
// There are just here for reference
case PA_CONTEXT_UNCONNECTED:
case PA_CONTEXT_CONNECTING:
case PA_CONTEXT_AUTHORIZING:
case PA_CONTEXT_SETTING_NAME:
default:
break;
case PA_CONTEXT_FAILED:
case PA_CONTEXT_TERMINATED:
*pa_ready = 2;
break;
case PA_CONTEXT_READY: {
pa_buffer_attr buffer_attr;
if (verbose)
printf("Connection established.%s\n", CLEAR_LINE);
if (!(stream = pa_stream_new(c, "JanPlayback", &sample_spec, NULL))) {
printf("pa_stream_new() failed: %s", pa_strerror(pa_context_errno(c)));
exit(1); // goto fail;
}
pa_stream_set_state_callback(stream, stream_state_callback, NULL);
pa_stream_set_write_callback(stream, stream_write_callback, NULL);
//pa_stream_set_read_callback(stream, stream_read_callback, NULL);
pa_stream_set_suspended_callback(stream, stream_suspended_callback, NULL);
pa_stream_set_moved_callback(stream, stream_moved_callback, NULL);
pa_stream_set_underflow_callback(stream, stream_underflow_callback, NULL);
pa_stream_set_overflow_callback(stream, stream_overflow_callback, NULL);
pa_stream_set_started_callback(stream, stream_started_callback, NULL);
pa_stream_set_event_callback(stream, stream_event_callback, NULL);
pa_stream_set_buffer_attr_callback(stream, stream_buffer_attr_callback, NULL);
pa_zero(buffer_attr);
buffer_attr.maxlength = (uint32_t) -1;
buffer_attr.prebuf = (uint32_t) -1;
pa_cvolume cv;
if (pa_stream_connect_playback(stream, NULL, &buffer_attr, flags,
NULL,
NULL) < 0) {
printf("pa_stream_connect_playback() failed: %s", pa_strerror(pa_context_errno(c)));
exit(1); //goto fail;
} else {
printf("Set playback callback\n");
}
pa_stream_trigger(stream, stream_success, NULL);
}
break;
}
}
int main(int argc, char *argv[]) {
struct stat st;
off_t size;
ssize_t nread;
// We'll need these state variables to keep track of our requests
int state = 0;
int pa_ready = 0;
if (argc != 2) {
fprintf(stderr, "Usage: %s file\n", argv[0]);
exit(1);
}
// slurp the whole file into buffer
if ((fdin = open(argv[1], O_RDONLY)) == -1) {
perror("open");
exit(1);
}
// Create a mainloop API and connection to the default server
mainloop = pa_mainloop_new();
mainloop_api = pa_mainloop_get_api(mainloop);
context = pa_context_new(mainloop_api, "test");
// This function connects to the pulse server
pa_context_connect(context, NULL, 0, NULL);
printf("Connecting\n");
// This function defines a callback so the server will tell us it's state.
// Our callback will wait for the state to be ready. The callback will
// modify the variable to 1 so we know when we have a connection and it's
// ready.
// If there's an error, the callback will set pa_ready to 2
pa_context_set_state_callback(context, state_cb, &pa_ready);
if (pa_mainloop_run(mainloop, &ret) < 0) {
printf("pa_mainloop_run() failed.");
exit(1); // goto quit
}
}
当延迟设置为默认值时，每次回调可以写入的字节数是 65，470 字节。这给出了 65，470 / 44，100 秒的最小延迟，即大约 1500 毫秒。当延迟和处理时间都设置为 1 毫秒时，缓冲区大小约为 1440 字节，延迟为 32 毫秒。
使用 I/O 回调播放文件
将文件写入输出流很简单:从文件读入缓冲区，并通过写入流来保持清空缓冲区。从文件中读取很简单:使用标准的 Unix read函数。您请求读取一些字节，而read函数返回实际读取的字节数。这在上一节中已经讨论过了。
PulseAudio 发行版中的程序使用更复杂的系统。它使用 I/O 就绪回调将一些处理传递给 I/O 回调。这利用了两个功能。
pa_stream_writable_size告知可以向流中写入多少字节。- 向流中写入一定数量的字节。
逻辑如下:通过从文件中读取来填充缓冲区，同时从缓冲区向流中写入尽可能多的字节，直到达到缓冲区大小的限制或流可以接受的字节数，以较小者为准。
在 PulseAudio 中，这是使用回调函数异步完成的。两个相关的功能如下:
-
函数
pa_stream_set_write_callback()注册了一个回调函数，只要流准备好被写入，这个回调函数就会被调用。注册回调如下所示:pa_stream_set_write_callback(stream, stream_write_callback, NULL)向回调传递要写入的流(
s)和可以写入的字节数(length)。void stream_write_callback(pa_stream *s, size_t length, void *userdata) -
从文件中读取的回调由保存在
mainloop_api表中的一个函数注册。注册函数是io_new，并被传递一个文件和回调函数的 Unix 文件描述符。注册回调看起来像这样:mainloop_api->io_new(mainloop_api, fdin, PA_IO_EVENT_INPUT, stdin_callback, NULL))回调被传递文件描述符(
fd)来读取。void stdin_callback(pa_mainloop_api *mainloop_api, pa_io_event *stdio_event, int fd, pa_io_event_flags_t f, void *userdata)注意 PulseAudio 代码从源文件的描述符到
STDIN_FILENO做了一个dup2，它匹配函数的名称。我看不出这有什么意义，反正他们的代码用的是fd。
这些回调应该在什么时候注册？流写回调可以在流创建后的任何时候注册，这是由pa_stream_new完成的。对于stdin回调，我只能通过在流准备好之后注册它来让它正常工作，也就是说，在流状态回调函数的PA_STREAM_READY分支中。
那么，在所有这些之后，程序的逻辑是什么？
- 在
stdin回调中:- 如果缓冲区里有东西，就返回。再加就没有意义了。
- 如果缓冲区是空的，那么查询流，看看有多少可以写入其中。
- 如果流没有更多内容，那么只需将一些内容读入缓冲区并返回。
- 如果流可以被写入，那么从文件中读入缓冲区并将其写入流。
- 在流写回调中:
- 如果缓冲区不为空，将其内容写入流。
从文件中播放的程序目前看起来像pacat.c。
/***
This file is based on pacat.c, part of PulseAudio
.
pacat.c:
Copyright 2004-2006 Lennart Poettering
Copyright 2006 Pierre Ossman <ossman@cendio.se> for Cendio AB
PulseAudio is free software; you can redistribute it and/or modify
it under the terms of the GNU Lesser General Public License as published
by the Free Software Foundation; either version 2.1 of the License,
or (at your option) any later version.
PulseAudio is distributed in the hope that it will be useful, but
WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU
General Public License for more details.
You should have received a copy of the GNU Lesser General Public License
along with PulseAudio; if not, write to the Free Software
Foundation, Inc., 59 Temple Place, Suite 330, Boston, MA 02111-1307
USA.
***/
#include <stdio.h>
#include <string.h>
#include <pulse/pulseaudio.h>
#include <sys/stat.h>
#include <sys/types.h>
#include <fcntl.h>
#include <errno.h>
#include <unistd.h>
#define CLEAR_LINE "\n"
// From pulsecore/macro.h JN
#define pa_memzero(x,l) (memset((x), 0, (l)))
#define pa_zero(x) (pa_memzero(&(x), sizeof(x)))
int verbose = 1;
int ret;
static pa_volume_t volume = PA_VOLUME_NORM;
static int volume_is_set = 0;
static int fdin;
.
static pa_sample_spec sample_spec = {
.format = PA_SAMPLE_S16LE,
.rate = 44100,
.channels = 2
};
static pa_stream *stream = NULL;
static pa_channel_map channel_map;
static pa_proplist *proplist = NULL;
// Define our pulse audio loop and connection variables
static pa_mainloop *mainloop;
static pa_mainloop_api *mainloop_api;
static pa_operation *pa_op;
static pa_context *context = NULL;
static void *buffer = NULL;
static size_t buffer_length = 0, buffer_index = 0;
static pa_io_event* stdio_event = NULL;
static char *device = "alsa_output.pci-0000_00_1b.0.analog-stereo";
static pa_stream_flags_t flags = 0;
static size_t latency = 0, process_time = 0;
static int32_t latency_msec = 0, process_time_msec = 0;
static int raw = 1;
/* Write some data to the stream */
static void do_stream_write(size_t length) {
size_t l;
assert(length);
printf("do stream write: Writing %d to stream\n", length);
if (!buffer || !buffer_length) {
printf(" return without writing\n");
return;
.
}
l = length;
if (l > buffer_length)
l = buffer_length;
printf(" writing %d\n", l);
if (pa_stream_write(stream, (uint8_t*) buffer + buffer_index, l, NULL, 0, PA_SEEK_RELATIVE) < 0) {
printf("pa_stream_write() failed: %s", pa_strerror(pa_context_errno(context)));
exit(1);
return;
}
buffer_length -= l;
buffer_index += l;
if (!buffer_length) {
pa_xfree(buffer);
buffer = NULL;
buffer_index = buffer_length = 0;
}
}
/* Connection draining complete */
static void context_drain_complete(pa_context*c, void *userdata) {
pa_context_disconnect(c);
}
static void stream_drain_complete(pa_stream*s, int success, void *userdata) {
pa_operation *o = NULL;
if (!success) {
printf("Failed to drain stream: %s", pa_strerror(pa_context_errno(context)));
exit(1);
}
if (verbose)
printf("Playback stream drained.");
pa_stream_disconnect(stream);
pa_stream_unref(stream);
stream = NULL;
if (!(o = pa_context_drain(context, context_drain_complete, NULL)))
pa_context_disconnect(context);
.
else {
pa_operation_unref(o);
if (verbose)
printf("Draining connection to server.");
}
}
/* Start draining */
static void start_drain(void) {
printf("Draining\n");
if (stream) {
pa_operation *o;
pa_stream_set_write_callback(stream, NULL, NULL);
if (!(o = pa_stream_drain(stream, stream_drain_complete, NULL))) {
//printf("pa_stream_drain(): %s", pa_strerror(pa_context_errno(context)));
exit(1);
return;
}
pa_operation_unref(o);
} else
exit(0);
}
/* New data on STDIN **/
static void stdin_callback(pa_mainloop_api *mainloop_api, pa_io_event *stdio_event, int fd, pa_io_event_flags_t f, void *userdata) {
size_t l, w = 0;
ssize_t r;
printf("In stdin callback\n");
//pa_assert(a == mainloop_api);
// pa_assert(e);
// pa_assert(stdio_event == e);
if (buffer) {
mainloop_api->io_enable(stdio_event, PA_IO_EVENT_NULL);
printf(" Buffer isn't null\n");
.
return;
}
if (!stream || pa_stream_get_state(stream) != PA_STREAM_READY || !(l = w = pa_stream_writable_size(stream)))
l = 4096;
buffer = pa_xmalloc(l);
if ((r = read(fd, buffer, l)) <= 0) {
if (r == 0) {
if (verbose)
printf("Got EOF.\n");
start_drain();
} else {
printf("read() failed: %s\n", strerror(errno));
exit(1);
}
mainloop_api->io_free(stdio_event);
stdio_event = NULL;
return;
}
printf(" Read %d\n", r);
buffer_length = (uint32_t) r;
buffer_index = 0;
if (w) {
printf(" do stream write from stdin callback\n");
do_stream_write(w);
}
}
void stream_state_callback(pa_stream *s, void *userdata) {
assert(s);
switch (pa_stream_get_state(s)) {
case PA_STREAM_CREATING:
.
break;
case PA_STREAM_TERMINATED:
break;
case PA_STREAM_READY:
if (verbose) {
const pa_buffer_attr *a;
char cmt[PA_CHANNEL_MAP_SNPRINT_MAX], sst[PA_SAMPLE_SPEC_SNPRINT_MAX];
printf("Stream successfully created.\n");
if (!(a = pa_stream_get_buffer_attr(s)))
printf("pa_stream_get_buffer_attr() failed: %s\n", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
else {
printf("Buffer metrics: maxlength=%u, fragsize=%u\n", a->maxlength, a->fragsize);
}
/*
printf("Using sample spec '%s', channel map '%s'.",
pa_sample_spec_snprint(sst, sizeof(sst), pa_stream_get_sample_spec(s)),
pa_channel_map_snprint(cmt, sizeof(cmt), pa_stream_get_channel_map(s)));
.
*/
printf("Connected to device %s (%u, %ssuspended).\n",
pa_stream_get_device_name(s),
pa_stream_get_device_index(s),
pa_stream_is_suspended(s) ? "" : "not ");
}
// TRY HERE???
if (!(stdio_event = mainloop_api->io_new(mainloop_api,
fdin, // STDIN_FILENO,
PA_IO_EVENT_INPUT,
stdin_callback, NULL))) {
printf("io_new() failed.");
exit(1);
}
break;
case PA_STREAM_FAILED:
default:
printf("Stream error: %s", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
exit(1); //quit(1);
}
}
/*********** Stream callbacks **************/
static void stream_read_callback(pa_stream *s, size_t length, void *userdata) {
printf("Raedy to read\n");
}
static void stream_success(pa_stream *s, int succes, void *userdata) {
printf("Succeded\n")
.;
}
static void stream_suspended_callback(pa_stream *s, void *userdata) {
assert(s);
if (verbose) {
if (pa_stream_is_suspended(s))
fprintf(stderr, "Stream device suspended.%s \n", CLEAR_LINE);
else
fprintf(stderr, "Stream device resumed.%s \n", CLEAR_LINE);
}
}
static void stream_underflow_callback(pa_stream *s, void *userdata) {
assert(s);
if (verbose)
fprintf(stderr, "Stream underrun.%s \n", CLEAR_LINE);
}
static void stream_overflow_callback(pa_stream *s, void *userdata) {
assert(s);
if (verbose)
fprintf(stderr, "Stream overrun.%s \n", CLEAR_LINE);
}
static void stream_started_callback(pa_stream *s, void *userdata) {
assert(s);
if (verbose)
fprintf(stderr, "Stream started.%s \n", CLEAR_LINE);
}
static void stream_moved_callback(pa_stream *s, void *userdata) {
assert(s);
.
if (verbose)
fprintf(stderr, "Stream moved to device %s (%u, %ssuspended).%s \n", pa_stream_get_device_name(s), pa_stream_get_device_index(s), pa_stream_is_suspended(s) ? "" : "not ", CLEAR_LINE);
}
static void stream_buffer_attr_callback(pa_stream *s, void *userdata) {
assert(s);
if (verbose)
fprintf(stderr, "Stream buffer attributes changed.%s \n", CLEAR_LINE);
}
static void stream_event_callback(pa_stream *s, const char *name, pa_proplist *pl, void *userdata) {
char *t;
assert(s);
assert(name);
assert(pl);
t = pa_proplist_to_string_sep(pl, ", ");
fprintf(stderr, "Got event '%s', properties '%s'\n", name, t);
pa_xfree(t);
}
/* This is called whenever new data may be written to the stream */
static void stream_write_callback(pa_stream *s, size_t length, void *userdata) {
//assert(s);
.
//assert(length > 0);
printf("Stream write callback: Ready to write %d bytes\n", length);
if (raw) {
// assert(!sndfile);
if (stdio_event)
mainloop_api->io_enable(stdio_event, PA_IO_EVENT_INPUT);
if (!buffer)
return;
printf(" do stream write from stream write callback\n");
do_stream_write(length);
}
}
// This callback gets called when our context changes state. We really only
// care about when it's ready or if it has failed
void state_cb(pa_context *c, void *userdata) {
pa_context_state_t state;
int *pa_ready = userdata;
printf("State changed\n");
state = pa_context_get_state(c);
switch (state) {
// There are just here for reference
case PA_CONTEXT_UNCONNECTED:
case PA_CONTEXT_CONNECTING:
case PA_CONTEXT_AUTHORIZING:
case PA_CONTEXT_SETTING_NAME:
default:
break;
case PA_CONTEXT_FAILED:
case PA_CONTEXT_TERMINATED:
*pa_ready = 2;
break;
case PA_CONTEXT_READY: {
pa_buffer_attr buffer_attr;
if (verbose)
printf("Connection established.%s\n", CLEAR_LINE);
if (!(stream = pa_stream_new(c, "JanPlayback", &sample_spec, NULL))) {
printf("pa_stream_new() failed: %s", pa_strerror(pa_context_errno(c)));
exit(1); // goto fail;
.
}
pa_stream_set_state_callback(stream, stream_state_callback, NULL);
pa_stream_set_write_callback(stream, stream_write_callback, NULL);
pa_stream_set_read_callback(stream, stream_read_callback, NULL);
pa_stream_set_suspended_callback(stream, stream_suspended_callback, NULL);
pa_stream_set_moved_callback(stream, stream_moved_callback, NULL);
pa_stream_set_underflow_callback(stream, stream_underflow_callback, NULL);
pa_stream_set_overflow_callback(stream, stream_overflow_callback, NULL);
pa_stream_set_started_callback(stream, stream_started_callback, NULL);
pa_stream_set_event_callback(stream, stream_event_callback, NULL);
pa_stream_set_buffer_attr_callback(stream, stream_buffer_attr_callback, NULL);
pa_zero(buffer_attr);
buffer_attr.maxlength = (uint32_t) -1;
buffer_attr.prebuf = (uint32_t) -1;
buffer_attr.fragsize = buffer_attr.tlength = (uint32_t) -1;
buffer_attr.minreq = (uint32_t) -1;
pa_cvolume cv;
if (pa_stream_connect_playback(stream, NULL, &buffer_attr, flags,
NULL,
NULL) < 0) {
printf("pa_stream_connect_playback() failed: %s", pa_strerror(pa_context_errno(c)));
.
exit(1); //goto fail;
} else {
printf("Set playback callback\n");
}
pa_stream_trigger(stream, stream_success, NULL);
}
break;
}
}
int main(int argc, char *argv[]) {
struct stat st;
off_t size;
ssize_t nread;
// We'll need these state variables to keep track of our requests
int state = 0;
int pa_ready = 0;
if (argc != 2) {
fprintf(stderr, "Usage: %s file\n", argv[0]);
exit(1);
}
// slurp the whole file into buffer
if ((fdin = open(argv[1], O_RDONLY)) == -1) {
perror("open");
exit(1);
}
// Create a mainloop API and connection to the default server
mainloop = pa_mainloop_new();
mainloop_api = pa_mainloop_get_api(mainloop);
context = pa_context_new(mainloop_api, "test");
// This function connects to the pulse server
pa_context_connect(context, NULL, 0, NULL);
printf("Connecting\n");
// This function defines a callback so the server will tell us it's state.
// Our callback will wait for the state to be ready. The callback will
// modify the variable to 1 so we know when we have a connection and it's
// ready.
// If there's an error, the callback will set pa_ready to 2
pa_context_set_state_callback(context, state_cb, &pa_ready);
.
if (pa_mainloop_run(mainloop, &ret) < 0) {
printf("pa_mainloop_run() failed.");
exit(1); // goto quit
}
}
控制延迟
在 www.freedesktop.org/wiki/Software/PulseAudio/Documentation/Developer/Clients/LactencyControl 中描述了管理延迟。
在您的代码中，当调用pa_stream_connect_playback() resp 时，您必须执行以下操作。pa_stream_connect_record():
- 在 flags 参数中传递
PA_STREAM_ADJUST_LATENCY。只有设置了该标志，PA才会重新配置低级设备的缓冲区大小，并将其调整到您指定的延迟。 - 在
buffer_attr参数中传递一个pa_buffer_attr结构。在该结构的字段中，确保将每个字段初始化为(uint32_t) -1)，除了tlength(用于回放)resp。fragsize(录音用)。将它们初始化为您想要达到的延迟。使用pa_usec_to_bytes(&ss, ...)将延时从时间单位转换为字节。
额外的代码如下:
// Set properties of the record buffer
pa_zero(buffer_attr);
buffer_attr.maxlength = (uint32_t) -1;
buffer_attr.prebuf = (uint32_t) -1;
if (latency_msec > 0) {
buffer_attr.fragsize = buffer_attr.tlength = pa_usec_to_bytes(latency_msec * PA_USEC_PER_MSEC, &sample_spec);
flags |= PA_STREAM_ADJUST_LATENCY;
} else if (latency > 0) {
buffer_attr.fragsize = buffer_attr.tlength = (uint32_t) latency;
flags |= PA_STREAM_ADJUST_LATENCY;
} else
buffer_attr.fragsize = buffer_attr.tlength = (uint32_t) -1;
if (process_time_msec > 0) {
buffer_attr.minreq = pa_usec_to_bytes(process_time_msec * PA_USEC_PER_MSEC, &sample_spec);
} else if (process_time > 0)
buffer_attr.minreq = (uint32_t) process_time;
else
buffer_attr.minreq = (uint32_t) -1;
PulseAudio 还具有估计设备延迟的机制。它使用来自计时事件的信息。必须声明计时器事件回调，如下所示:
pa_context_rttime_new(context, pa_rtclock_now() + TIME_EVENT_USEC, time_event_callback, NULL))
计时器事件回调是“单次”回调。它安装一个流更新计时器回调，并设置另一个计时器回调。
void time_event_callback(pa_mainloop_api *m,
pa_time_event *e, const struct timeval *t,
void *userdata) {
if (stream && pa_stream_get_state(stream) == PA_STREAM_READY) {
pa_operation *o;
if (!(o = pa_stream_update_timing_info(stream, stream_update_timing_callback, NULL)))
1; //pa_log(_("pa_stream_update_timing_info() failed: %s"), pa_strerror(pa_context_errno(context)));
else
pa_operation_unref(o);
}
pa_context_rttime_restart(context, e, pa_rtclock_now() + TIME_EVENT_USEC);
然后，流更新定时器回调可以估计等待时间。
void stream_update_timing_callback(pa_stream *s, int success, void *userdata) {
pa_usec_t l, usec;
int negative = 0;
// pa_assert(s);
fprintf(stderr, "Update timing\n");
if (!success ||
pa_stream_get_time(s, &usec) < 0 ||
pa_stream_get_latency(s, &l, &negative) < 0) {
fprintf(stderr, "Failed to get latency\n");
return;
}
fprintf(stderr, _("Time: %0.3f sec; Latency: %0.0f usec."),
(float) usec / 1000000,
(float) l * (negative?-1.0f:1.0f));
fprintf(stderr, " \r");
}
通过将fragsize和tlength设置为-1，将延迟留给 PulseAudio，我得到如下结果:
Time: 0.850 sec; Latency: 850365 usec.
Time: 0.900 sec; Latency: 900446 usec.
Time: 0.951 sec; Latency: 950548 usec.
Time: 1.001 sec; Latency: 1000940 usec.
Time: 1.051 sec; Latency: 50801 usec.
Time: 1.101 sec; Latency: 100934 usec.
Time: 1.151 sec; Latency: 151007 usec.
Time: 1.201 sec; Latency: 201019 usec.
Time: 1.251 sec; Latency: 251150 usec.
Time: 1.301 sec; Latency: 301160 usec.
Time: 1.351 sec; Latency: 351218 usec.
Time: 1.401 sec; Latency: 401329 usec.
Time: 1.451 sec; Latency: 451400 usec.
Time: 1.501 sec; Latency: 501465 usec.
Time: 1.551 sec; Latency: 551587 usec.
Time: 1.602 sec; Latency: 601594 usec
.
将它们设置为 1 毫秒，我得到了以下结果:
Time: 1.599 sec; Latency: 939 usec.
Time: 1.649 sec; Latency: 1105 usec.
Time: 1.699 sec; Latency: -158 usec.
Time: 1.750 sec; Latency: 1020 usec.
Time: 1.800 sec; Latency: 397 usec.
Time: 1.850 sec; Latency: -52 usec.
Time: 1.900 sec; Latency: 1827 usec.
Time: 1.950 sec; Latency: 529 usec.
Time: 2.000 sec; Latency: -90 usec.
Time: 2.050 sec; Latency: 997 usec.
Time: 2.100 sec; Latency: 436 usec.
Time: 2.150 sec; Latency: 866 usec.
Time: 2.200 sec; Latency: 406 usec.
Time: 2.251 sec; Latency: 1461 usec.
Time: 2.301 sec; Latency: 107 usec.
Time: 2.351 sec; Latency: 1257 usec.
完成这一切的程序是parec-latency.c。
/* parec-latency.c */
#include <stdio.h>
#include <string.h>
#include <pulse/pulseaudio.h>
#define CLEAR_LINE "\n"
#define _(x) x
#define TIME_EVENT_USEC 50000
// From pulsecore/macro.h
#define pa_memzero(x,l) (memset((x), 0, (l)))
#define pa_zero(x) (pa_memzero(&(x), sizeof(x)))
int fdout;
char *fname = "tmp.pcm";
int verbose = 1;
int ret;
pa_context *context;
static pa_sample_spec sample_spec = {
.format = PA_SAMPLE_S16LE,
.rate = 44100,
.channels = 2
};
static pa_stream *stream = NULL;
/* This is my builtin card. Use paman to find yours
or set it to NULL to get the default device
*/
static char *device = "alsa_input.pci-0000_00_1b.0.analog-stereo";
static pa_stream_flags_t flags = 0;
static size_t latency = 0, process_time = 0;
static int32_t latency_msec = 0, process_time_msec = 0;
void stream_state_callback(pa_stream *s, void *userdata) {
assert(s);
switch (pa_stream_get_state(s)) {
case PA_STREAM_CREATING:
// The stream has been created, so
// let's open a file to record to
printf("Creating stream\n");
fdout = creat(fname, 0711);
break;
case PA_STREAM_TERMINATED:
close(fdout);
break;
case PA_STREAM_READY:
// Just for info: no functionality in this branch
if (verbose) {
const pa_buffer_attr *a;
char cmt[PA_CHANNEL_MAP_SNPRINT_MAX], sst[PA_SAMPLE_SPEC_SNPRINT_MAX];
printf("Stream successfully created.");
if (!(a = pa_stream_get_buffer_attr(s)))
printf("pa_stream_get_buffer_attr() failed: %s", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
else {
printf("Buffer metrics: maxlength=%u, fragsize=%u", a->maxlength, a->fragsize);
}
printf("Connected to device %s (%u, %ssuspended).",
pa_stream_get_device_name(s),
pa_stream_get_device_index(s),
pa_stream_is_suspended(s) ? "" : "not ");
}
break;
case PA_STREAM_FAILED:
default:
printf("Stream error: %s", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
exit(1);
}
}
/* Show the current latency */
static void stream_update_timing_callback(pa_stream *s, int success, void *userdata) {
pa_usec_t l, usec;
int negative = 0;
// pa_assert(s);
fprintf(stderr, "Update timing\n");
if (!success ||
pa_stream_get_time(s, &usec) < 0 ||
pa_stream_get_latency(s, &l, &negative) < 0) {
// pa_log(_("Failed to get latency"));
//pa_log(_("Failed to get latency: %s"), pa_strerror(pa_context_errno(context)));
// quit(1);
return;
}
fprintf(stderr, _("Time: %0.3f sec; Latency: %0.0f usec.\n"),
(float) usec / 1000000,
(float) l * (negative?-1.0f:1.0f));
//fprintf(stderr, " \r");
}
static void time_event_callback(pa_mainloop_api *m,
pa_time_event *e, const struct timeval *t,
void *userdata) {
if (stream && pa_stream_get_state(stream) == PA_STREAM_READY) {
pa_operation *o;
if (!(o = pa_stream_update_timing_info(stream, stream_update_timing_callback, NULL)))
1; //pa_log(_("pa_stream_update_timing_info() failed: %s"), pa_strerror(pa_context_errno(context)));
else
pa_operation_unref(o);
}
pa_context_rttime_restart(context, e, pa_rtclock_now() + TIME_EVENT_USEC);
}
void get_latency(pa_stream *s) {
pa_usec_t latency;
int neg;
pa_timing_info *timing_info;
timing_info = pa_stream_get_timing_info(s);
if (pa_stream_get_latency(s, &latency, &neg) != 0) {
fprintf(stderr, __FILE__": pa_stream_get_latency() failed\n");
return;
}
fprintf(stderr, "%0.0f usec \r", (float)latency);
}
/*********** Stream callbacks **************/
/* This is called whenever new data is available */
static void stream_read_callback(pa_stream *s, size_t length, void *userdata) {
assert(s);
assert(length > 0);
// Copy the data from the server out to a file
//fprintf(stderr, "Can read %d\n", length);
while (pa_stream_readable_size(s) > 0) {
const void *data;
size_t length;
//get_latency(s);
// peek actually creates and fills the data vbl
if (pa_stream_peek(s, &data, &length) < 0) {
fprintf(stderr, "Read failed\n");
exit(1);
return;
}
fprintf(stderr, "Writing %d\n", length);
write(fdout, data, length);
// swallow the data peeked at before
pa_stream_drop(s);
}
}
// This callback gets called when our context changes state. We really only
// care about when it's ready or if it has failed
void state_cb(pa_context *c, void *userdata) {
pa_context_state_t state;
int *pa_ready = userdata;
printf("State changed\n");
state = pa_context_get_state(c);
switch (state) {
// There are just here for reference
case PA_CONTEXT_UNCONNECTED:
case PA_CONTEXT_CONNECTING:
case PA_CONTEXT_AUTHORIZING:
case PA_CONTEXT_SETTING_NAME:
default:
break;
case PA_CONTEXT_FAILED:
case PA_CONTEXT_TERMINATED:
*pa_ready = 2;
break;
case PA_CONTEXT_READY: {
pa_buffer_attr buffer_attr;
if (verbose)
printf("Connection established.%s\n", CLEAR_LINE);
if (!(stream = pa_stream_new(c, "JanCapture", &sample_spec, NULL))) {
printf("pa_stream_new() failed: %s", pa_strerror(pa_context_errno(c)));
exit(1);
}
// Watch for changes in the stream state to create the output file
pa_stream_set_state_callback(stream, stream_state_callback, NULL);
// Watch for changes in the stream's read state to write to the output file
pa_stream_set_read_callback(stream, stream_read_callback, NULL);
// timing info
pa_stream_update_timing_info(stream, stream_update_timing_callback, NULL);
// Set properties of the record buffer
pa_zero(buffer_attr);
buffer_attr.maxlength = (uint32_t) -1;
buffer_attr.prebuf = (uint32_t) -1;
if (latency_msec > 0) {
buffer_attr.fragsize = buffer_attr.tlength = pa_usec_to_bytes(latency_msec * PA_USEC_PER_MSEC, &sample_spec);
flags |= PA_STREAM_ADJUST_LATENCY;
} else if (latency > 0) {
buffer_attr.fragsize = buffer_attr.tlength = (uint32_t) latency;
flags |= PA_STREAM_ADJUST_LATENCY;
} else
buffer_attr.fragsize = buffer_attr.tlength = (uint32_t) -1;
if (process_time_msec > 0) {
buffer_attr.minreq = pa_usec_to_bytes(process_time_msec * PA_USEC_PER_MSEC, &sample_spec);
} else if (process_time > 0)
buffer_attr.minreq = (uint32_t) process_time;
else
buffer_attr.minreq = (uint32_t) -1;
flags |= PA_STREAM_INTERPOLATE_TIMING;
get_latency(stream);
// and start recording
if (pa_stream_connect_record(stream, device, &buffer_attr, flags) < 0) {
printf("pa_stream_connect_record() failed: %s", pa_strerror(pa_context_errno(c)));
exit(1);
}
}
break;
}
}
int main(int argc, char *argv[]) {
// Define our pulse audio loop and connection variables
pa_mainloop *pa_ml;
pa_mainloop_api *pa_mlapi;
pa_operation *pa_op;
pa_time_event *time_event;
// Create a mainloop API and connection to the default server
pa_ml = pa_mainloop_new();
pa_mlapi = pa_mainloop_get_api(pa_ml);
context = pa_context_new(pa_mlapi, "test");
// This function connects to the pulse server
pa_context_connect(context, NULL, 0, NULL);
// This function defines a callback so the server will tell us its state.
pa_context_set_state_callback(context, state_cb, NULL);
if (!(time_event = pa_context_rttime_new(context, pa_rtclock_now() + TIME_EVENT_USEC, time_event_callback, NULL))) {
//pa_log(_("pa_context_rttime_new() failed."));
//goto quit;
}
if (pa_mainloop_run(pa_ml, &ret) < 0) {
printf("pa_mainloop_run() failed.");
exit(1);
}
}
向扬声器播放麦克风
结合你目前所拥有的，你得到pa-mic-2-speaker.c。
/*
* Copy from microphone to speaker
* pa-mic-2-speaker.c
*/
#include <stdio.h>
#include <string.h>
#include <pulse/pulseaudio.h>
#define CLEAR_LINE "\n"
#define BUFF_LEN 4096
// From pulsecore/macro.h
#define pa_memzero(x,l) (memset((x), 0, (l)))
#define pa_zero(x) (pa_memzero(&(x), sizeof(x)))
static void *buffer = NULL;
static size_t buffer_length = 0, buffer_index = 0;
int verbose = 1;
int ret;
static pa_sample_spec sample_spec = {
.format = PA_SAMPLE_S16LE,
.rate = 44100,
.channels = 2
};
static pa_stream *istream = NULL,
*ostream = NULL;
// This is my builtin card. Use paman to find yours
//static char *device = "alsa_input.pci-0000_00_1b.0.analog-stereo";
static char *idevice = NULL;
static char *odevice = NULL;
static pa_stream_flags_t flags = 0;
static size_t latency = 0, process_time = 0;
static int32_t latency_msec = 1, process_time_msec = 0;
void stream_state_callback(pa_stream *s, void *userdata) {
assert(s);
switch (pa_stream_get_state(s)) {
case PA_STREAM_CREATING:
// The stream has been created, so
// let's open a file to record to
printf("Creating stream\n");
// fdout = creat(fname, 0711);
buffer = pa_xmalloc(BUFF_LEN);
buffer_length = BUFF_LEN;
buffer_index = 0;
break;
case PA_STREAM_TERMINATED:
// close(fdout);
break;
case PA_STREAM_READY:
// Just for info: no functionality in this branch
if (verbose) {
const pa_buffer_attr *a;
char cmt[PA_CHANNEL_MAP_SNPRINT_MAX], sst[PA_SAMPLE_SPEC_SNPRINT_MAX];
printf("Stream successfully created.");
if (!(a = pa_stream_get_buffer_attr(s)))
printf("pa_stream_get_buffer_attr() failed: %s", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
else {
printf("Buffer metrics: maxlength=%u, fragsize=%u", a->maxlength, a->fragsize);
}
printf("Connected to device %s (%u, %ssuspended).",
pa_stream_get_device_name(s),
pa_stream_get_device_index(s),
pa_stream_is_suspended(s) ? "" : "not ");
}
break;
case PA_STREAM_FAILED:
default:
printf("Stream error: %s", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
exit(1);
}
}
/*********** Stream callbacks **************/
/* This is called whenever new data is available */
static void stream_read_callback(pa_stream *s, size_t length, void *userdata) {
assert(s);
assert(length > 0);
// Copy the data from the server out to a file
fprintf(stderr, "Can read %d\n", length);
while (pa_stream_readable_size(s) > 0) {
const void *data;
size_t length, lout;
// peek actually creates and fills the data vbl
if (pa_stream_peek(s, &data, &length) < 0) {
fprintf(stderr, "Read failed\n");
exit(1);
return;
}
fprintf(stderr, "read %d\n", length);
lout = pa_stream_writable_size(ostream);
fprintf(stderr, "Writable: %d\n", lout);
if (lout == 0) {
fprintf(stderr, "can't write, zero writable\n");
return;
}
if (lout < length) {
fprintf(stderr, "Truncating read\n");
length = lout;
}
if (pa_stream_write(ostream, (uint8_t*) data, length, NULL, 0, PA_SEEK_RELATIVE) < 0) {
fprintf(stderr, "pa_stream_write() failed\n");
exit(1);
return;
}
// STICK OUR CODE HERE TO WRITE OUT
//fprintf(stderr, "Writing %d\n", length);
//write(fdout, data, length);
// swallow the data peeked at before
pa_stream_drop(s);
}
}
/* This is called whenever new data may be written to the stream */
// We don't actually write anything this time
static void stream_write_callback(pa_stream *s, size_t length, void *userdata) {
//assert(s);
//assert(length > 0);
printf("Stream write callback: Ready to write %d bytes\n", length);
}
// This callback gets called when our context changes state. We really only
// care about when it's ready or if it has failed
void state_cb(pa_context *c, void *userdata) {
pa_context_state_t state;
int *pa_ready = userdata;
printf("State changed\n");
state = pa_context_get_state(c);
switch (state) {
// There are just here for reference
case PA_CONTEXT_UNCONNECTED:
case PA_CONTEXT_CONNECTING:
case PA_CONTEXT_AUTHORIZING:
case PA_CONTEXT_SETTING_NAME:
default:
break;
case PA_CONTEXT_FAILED:
case PA_CONTEXT_TERMINATED:
*pa_ready = 2;
break;
case PA_CONTEXT_READY: {
pa_buffer_attr buffer_attr;
if (verbose)
printf("Connection established.%s\n", CLEAR_LINE);
if (!(istream = pa_stream_new(c, "JanCapture", &sample_spec, NULL))) {
printf("pa_stream_new() failed: %s", pa_strerror(pa_context_errno(c)));
exit(1);
}
if (!(ostream = pa_stream_new(c, "JanPlayback", &sample_spec, NULL))) {
printf("pa_stream_new() failed: %s", pa_strerror(pa_context_errno(c)));
exit(1);
}
// Watch for changes in the stream state to create the output file
pa_stream_set_state_callback(istream, stream_state_callback, NULL);
// Watch for changes in the stream's read state to write to the output file
pa_stream_set_read_callback(istream, stream_read_callback, NULL);
pa_stream_set_write_callback(ostream, stream_write_callback, NULL);
// Set properties of the record buffer
pa_zero(buffer_attr);
buffer_attr.maxlength = (uint32_t) -1;
buffer_attr.prebuf = (uint32_t) -1;
if (latency_msec > 0) {
buffer_attr.fragsize = buffer_attr.tlength = pa_usec_to_bytes(latency_msec * PA_USEC_PER_MSEC, &sample_spec);
flags |= PA_STREAM_ADJUST_LATENCY;
} else if (latency > 0) {
buffer_attr.fragsize = buffer_attr.tlength = (uint32_t) latency;
flags |= PA_STREAM_ADJUST_LATENCY;
} else
buffer_attr.fragsize = buffer_attr.tlength = (uint32_t) -1;
if (process_time_msec > 0) {
buffer_attr.minreq = pa_usec_to_bytes(process_time_msec * PA_USEC_PER_MSEC, &sample_spec);
} else if (process_time > 0)
buffer_attr.minreq = (uint32_t) process_time;
else
buffer_attr.minreq = (uint32_t) -1;
// and start recording
if (pa_stream_connect_record(istream, idevice, &buffer_attr, flags) < 0) {
printf("pa_stream_connect_record() failed: %s", pa_strerror(pa_context_errno(c)));
exit(1);
}
if (pa_stream_connect_playback(ostream, odevice, &buffer_attr, flags,
NULL,
NULL) < 0) {
printf("pa_stream_connect_playback() failed: %s", pa_strerror(pa_context_errno(c)));
exit(1); //goto fail;
} else {
printf("Set playback callback\n");
}
}
break;
}
}
int main(int argc, char *argv[]) {
// Define our pulse audio loop and connection variables
pa_mainloop *pa_ml;
pa_mainloop_api *pa_mlapi;
pa_operation *pa_op;
pa_context *pa_ctx;
// Create a mainloop API and connection to the default server
pa_ml = pa_mainloop_new();
pa_mlapi = pa_mainloop_get_api(pa_ml);
pa_ctx = pa_context_new(pa_mlapi, "test");
// This function connects to the pulse server
pa_context_connect(pa_ctx, NULL, 0, NULL);
// This function defines a callback so the server will tell us its state.
pa_context_set_state_callback(pa_ctx, state_cb, NULL);
if (pa_mainloop_run(pa_ml, &ret) < 0) {
printf("pa_mainloop_run() failed.");
exit(1);
}
}
当延迟设置为 1 毫秒时，实际延迟大约为 16 毫秒到 28 毫秒。我无法察觉。
设置设备的音量
每个设备都可以通过 PulseAudio 控制其输入或输出音量。被调用的主要接收器是pa_context_set_sink_volume_by_name和pa_context_set_sink_volume_by_index，对源的调用类似。
这些调用利用了一个叫做pa_cvolume的结构。可以使用如下调用来操作此结构:
pa_cvolume_initpa_cvolume_setpa_cvolume_mute
在下面的程序中，您通过从stdin中读取整数值并使用这些值来设置特定设备上的音量。这种循环最好在 PulseAudio 框架的单独线程中进行。我没有在这里介绍应用线程，而是使用了另一组 PulseAudio 调用，为 PulseAudio 主循环设置了一个单独的线程。这些呼叫如下:
pa_threaded_mainloop而不是pa_mainlooppa_threaded_mainloop_get_api而不是pa_mainloop_get_apipa_threaded_mainloop_start而不是pa_mainloop_start
线程调用允许您在自己的线程中启动 PulseAudio，并让当前线程读取音量值。这给出了相对简单的程序pavolume.c。
/**
* pavolume.c
* Jan Newmarch
*/
#include <stdio.h>
#include <string.h>
#include <pulse/pulseaudio.h>
#define _(x) x
char *device = "alsa_output.pci-0000_00_1b.0.analog-stereo";
int ret;
pa_context *context;
void show_error(char *s) {
fprintf(stderr, "%s\n", s);
}
void volume_cb(pa_context *c, int success, void *userdata) {
if (success)
printf("Volume set\n");
else
printf("Volume not set\n");
}
void context_state_cb(pa_context *c, void *userdata) {
switch (pa_context_get_state(c)) {
case PA_CONTEXT_UNCONNECTED:
case PA_CONTEXT_CONNECTING:
case PA_CONTEXT_AUTHORIZING:
case PA_CONTEXT_SETTING_NAME:
break;
case PA_CONTEXT_READY: {
pa_operation *o;
break;
}
case PA_CONTEXT_FAILED:
case PA_CONTEXT_TERMINATED:
default:
return;
}
}
int main(int argc, char *argv[]) {
long volume = 0;
char buf[128];
struct pa_cvolume v;
// Define our pulse audio loop and connection variables
pa_threaded_mainloop *pa_ml;
pa_mainloop_api *pa_mlapi;
// Create a mainloop API and connection to the default server
//pa_ml = pa_mainloop_new();
pa_ml = pa_threaded_mainloop_new();
pa_mlapi = pa_threaded_mainloop_get_api(pa_ml);
context = pa_context_new(pa_mlapi, "Voulme control");
// This function connects to the pulse server
pa_context_connect(context, NULL, 0, NULL);
// This function defines a callback so the server will tell us its state.
pa_context_set_state_callback(context, context_state_cb, NULL);
pa_threaded_mainloop_start(pa_ml);
printf("Enter volume for device %s\n");
pa_cvolume_init(&v);
while (1) {
puts("Enter an integer 0-65536\n");
fgets(buf, 128, stdin);
volume = atoi(buf);
pa_cvolume_set(&v, 2, volume);
pa_context_set_sink_volume_by_name(context,
device,
&v,
volume_cb,
NULL
);
}
}
列出客户
PulseAudio 是一个服务器，它在底层与设备对话，在顶层与客户端对话。客户是音频的生产者和消费者。PulseAudio 的作用之一是将来自不同源客户端的信号混合到共享输出设备。为此，PulseAudio 跟踪客户端的注册，并通过适当的回调将这些注册提供给其他客户端。
程序palist_clients.c类似于程序palist_devices.c。主要区别在于，当上下文将状态更改为PA_CONTEXT_READY时，应用订阅PA_SUBSCRIPTION_MASK_CLIENT而不是(PA_SUBSCRIPTION_MASK_SINK|PA_SUBSCRIPTION_MASK_SOURCE)，订阅回调请求pa_context_get_client_info而不是pa_context_get_source_info。
程序palist_clients.c如下:
/**
* palist_clients.c
* Jan Newmarch
*/
#include <stdio.h>
#include <string.h>
#include <pulse/pulseaudio.h>
#define CLEAR_LINE "\n"
#define _(x) x
// From pulsecore/macro.h
//#define pa_memzero(x,l) (memset((x), 0, (l)))
//#define pa_zero(x) (pa_memzero(&(x), sizeof(x)))
int ret;
pa_context *context;
void show_error(char *s) {
/* stub */
}
void print_properties(pa_proplist *props) {
void *state = NULL;
printf(" Properties are: \n");
while (1) {
char *key;
if ((key = pa_proplist_iterate(props, &state)) == NULL) {
return;
}
char *value = pa_proplist_gets(props, key);
printf(" key %s, value %s\n", key, value);
}
}
void add_client_cb(pa_context *context, const pa_client_info *i, int eol, void *userdata) {
if (eol < 0) {
if (pa_context_errno(context) == PA_ERR_NOENTITY)
return;
show_error(_("Client callback failure"));
return;
}
if (eol > 0) {
return;
}
printf("Found a new client index %d name %s eol %d\n", i->index, i->name, eol);
print_properties(i->proplist);
}
void remove_client_cb(pa_context *context, const pa_client_info *i, int eol, void *userdata) {
if (eol < 0) {
if (pa_context_errno(context) == PA_ERR_NOENTITY)
return;
show_error(_("Client callback failure"));
return;
}
if (eol > 0) {
return;
}
printf("Removing a client index %d name %s\n", i->index, i->name);
print_properties(i->proplist);
}
void subscribe_cb(pa_context *c, pa_subscription_event_type_t t, uint32_t index, void *userdata) {
switch (t & PA_SUBSCRIPTION_EVENT_FACILITY_MASK) {
case PA_SUBSCRIPTION_EVENT_CLIENT:
if ((t & PA_SUBSCRIPTION_EVENT_TYPE_MASK) == PA_SUBSCRIPTION_EVENT_REMOVE) {
printf("Remove event at index %d\n", index);
pa_operation *o;
if (!(o = pa_context_get_client_info(c, index, remove_client_cb, NULL))) {
show_error(_("pa_context_get_client_info() failed"));
return;
}
pa_operation_unref(o);
} else {
pa_operation *o;
if (!(o = pa_context_get_client_info(c, index, add_client_cb, NULL))) {
show_error(_("pa_context_get_client_info() failed"));
return;
}
pa_operation_unref(o);
}
break;
}
}
void context_state_cb(pa_context *c, void *userdata) {
switch (pa_context_get_state(c)) {
case PA_CONTEXT_UNCONNECTED:
case PA_CONTEXT_CONNECTING:
case PA_CONTEXT_AUTHORIZING:
case PA_CONTEXT_SETTING_NAME:
break;
case PA_CONTEXT_READY: {
pa_operation *o;
pa_context_set_subscribe_callback(c, subscribe_cb, NULL);
if (!(o = pa_context_subscribe(c, (pa_subscription_mask_t)
(PA_SUBSCRIPTION_MASK_CLIENT), NULL, NULL))) {
show_error(_("pa_context_subscribe() failed"));
return;
}
pa_operation_unref(o);
if (!(o = pa_context_get_client_info_list(context,
add_client_cb,
NULL
) )) {
show_error(_("pa_context_subscribe() failed"));
return;
}
pa_operation_unref(o);
break;
}
case PA_CONTEXT_FAILED:
return;
case PA_CONTEXT_TERMINATED:
default:
return;
}
}
void stream_state_callback(pa_stream *s, void *userdata) {
assert(s);
switch (pa_stream_get_state(s)) {
case PA_STREAM_CREATING:
break;
case PA_STREAM_TERMINATED:
break;
case PA_STREAM_READY:
break;
case PA_STREAM_FAILED:
default:
printf("Stream error: %s", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
exit(1);
}
}
int main(int argc, char *argv[]) {
// Define our pulse audio loop and connection variables
pa_mainloop *pa_ml;
pa_mainloop_api *pa_mlapi;
pa_operation *pa_op;
pa_time_event *time_event;
// Create a mainloop API and connection to the default server
pa_ml = pa_mainloop_new();
pa_mlapi = pa_mainloop_get_api(pa_ml);
context = pa_context_new(pa_mlapi, "test");
// This function connects to the pulse server
pa_context_connect(context, NULL, 0, NULL);
// This function defines a callback so the server will tell us its state.
//pa_context_set_state_callback(context, state_cb, NULL);
pa_context_set_state_callback(context, context_state_cb, NULL);
if (pa_mainloop_run(pa_ml, &ret) < 0) {
printf("pa_mainloop_run() failed.");
exit(1);
}
}
我的系统上的输出如下(省略):
Found a new client index 0 name ConsoleKit Session /org/freedesktop/ConsoleKit/Session2 eol 0
Properties are:
key application.name, value ConsoleKit Session /org/freedesktop/ConsoleKit/Session2
key console-kit.session, value /org/freedesktop/ConsoleKit/Session2
Found a new client index 4 name XSMP Session on gnome-session as 1057eba7239ba1ec3d136359809598590100000018790044 eol 0
Properties are:
key application.name, value XSMP Session on gnome-session as 1057eba7239ba1ec3d136359809598590100000018790044
key xsmp.vendor, value gnome-session
key xsmp.client.id, value 1057eba7239ba1ec3d136359809598590100000018790044
Found a new client index 5 name GNOME Volume Control Media Keys eol 0
Properties are:
...
Found a new client index 7 name GNOME Volume Control Applet eol 0
Properties are:
...
Found a new client index 53 name Metacity eol 0
Properties are:
...
Found a new client index 54 name Firefox eol 0
Properties are:
...
Found a new client index 248 name PulseAudio Volume Control eol 0
Properties are:
...
Found a new client index 341 name test eol 0
Properties are:
...
列出客户端源和接收器
客户可以充当信息源；像 MPlayer 和 VLC 这样的程序就是这么做的，它们向 PulseAudio 发送流。其他客户端可以充当接收器。客户端本身由前面的程序监控。为了监控他们的活动，您将pa_subscribe_callback上的屏蔽设置为(PA_SUBSCRIPTION_MASK_CLIENT | PA_SUBSCRIPTION_MASK_SINK_INPUT | PA_SUBSCRIPTION_MASK_SOURCE_OUTPUT)。在订阅回调中，调用PA_SUBSCRIPTION_EVENT_SINK_INPUT分支中的pa_context_get_sink_input_info,对源输出进行同样的操作。
向接收器输入回调传递结构pa_sink_input_info。这包含熟悉的name和index字段，但也有一个名为client的整数字段。这将接收器输入链接回负责接收器的客户端的索引。在下面的程序中，您还列出了所有客户端，以便可以直观地跟踪这些链接。编程上，PulseAudio 让你自己保留很多信息(比如什么客户端有什么索引)；这里忽略这个。
列出客户机并监视其输入和输出流变化的程序是pamonitor_clients.c。
/**
* pamonitor_clients.c
* Jan Newmarch
*/
#include <stdio.h>
#include <string.h>
#include <pulse/pulseaudio.h>
#define CLEAR_LINE "\n"
#define _(x) x
// From pulsecore/macro.h
#define pa_memzero(x,l) (memset((x), 0, (l)))
#define pa_zero(x) (pa_memzero(&(x), sizeof(x)))
int ret;
pa_context *context;
void show_error(char *s) {
/* stub */
}
void add_client_cb(pa_context *context, const pa_client_info *i, int eol, void *userdata)
{
if (eol < 0) {
if (pa_context_errno(context) == PA_ERR_NOENTITY)
return;
show_error(_("Client callback failure"));
return;
}
if (eol > 0) {
return;
}
printf("Found a new client index %d name %s eol %d\n", i->index, i->name, eol);
}
void remove_client_cb(pa_context *context, const pa_client_info *i, int eol, void *userdata) {
if (eol < 0) {
if (pa_context_errno(context) == PA_ERR_NOENTITY)
return;
show_error(_("Client callback failure"));
return;
}
if (eol > 0) {
return;
}
printf("Removing a client index %d name %s\n", i->index, i->name);
}
void sink_input_cb(pa_context *c, const pa_sink_input_info *i, int eol, void *userdata) {
if (eol < 0) {
if (pa_context_errno(context) == PA_ERR_NOENTITY)
return;
show_error(_("Sink input callback failure"));
return;
}
if (eol > 0) {
return;
}
printf("Sink input found index %d name %s for client %d\n", i->index, i->name, i->client);
}
void source_output_cb(pa_context *c, const pa_source_output_info *i, int eol, void *userdata) {
if (eol < 0) {
if (pa_context_errno(context) == PA_ERR_NOENTITY)
return;
show_error(_("Source output callback failure"));
return;
}
if (eol > 0) {
return;
}
printf("Source output found index %d name %s for client %d\n", i->index, i->name, i->client);
}
void subscribe_cb(pa_context *c, pa_subscription_event_type_t t, uint32_t index, void *userdata) {
switch (t & PA_SUBSCRIPTION_EVENT_FACILITY_MASK) {
case PA_SUBSCRIPTION_EVENT_CLIENT:
if ((t & PA_SUBSCRIPTION_EVENT_TYPE_MASK) == PA_SUBSCRIPTION_EVENT_REMOVE) {
printf("Remove event at index %d\n", index);
pa_operation *o;
if (!(o = pa_context_get_client_info(c, index, remove_client_cb, NULL))) {
show_error(_("pa_context_get_client_info() failed"));
return;
}
pa_operation_unref(o);
} else {
pa_operation *o;
if (!(o = pa_context_get_client_info(c, index, add_client_cb, NULL))) {
show_error(_("pa_context_get_client_info() failed"));
return;
}
pa_operation_unref(o);
}
break;
case PA_SUBSCRIPTION_EVENT_SINK_INPUT:
if ((t & PA_SUBSCRIPTION_EVENT_TYPE_MASK) == PA_SUBSCRIPTION_EVENT_REMOVE)
printf("Removing sink input %d\n", index);
else {
pa_operation *o;
if (!(o = pa_context_get_sink_input_info(context, index, sink_input_cb, NULL))) {
show_error(_("pa_context_get_sink_input_info() failed"));
return;
}
pa_operation_unref(o);
}
break;
case PA_SUBSCRIPTION_EVENT_SOURCE_OUTPUT:
if ((t & PA_SUBSCRIPTION_EVENT_TYPE_MASK) == PA_SUBSCRIPTION_EVENT_REMOVE)
printf("Removing source output %d\n", index);
else {
pa_operation *o;
if (!(o = pa_context_get_source_output_info(context, index, source_output_cb, NULL))) {
show_error(_("pa_context_get_sink_input_info() failed"));
return;
}
pa_operation_unref(o);
}
break;
}
}
void context_state_cb(pa_context *c, void *userdata) {
switch (pa_context_get_state(c)) {
case PA_CONTEXT_UNCONNECTED:
case PA_CONTEXT_CONNECTING:
case PA_CONTEXT_AUTHORIZING:
case PA_CONTEXT_SETTING_NAME:
break;
case PA_CONTEXT_READY: {
pa_operation *o;
pa_context_set_subscribe_callback(c, subscribe_cb, NULL);
if (!(o = pa_context_subscribe(c, (pa_subscription_mask_t)
(PA_SUBSCRIPTION_MASK_CLIENT |
PA_SUBSCRIPTION_MASK_SINK_INPUT |
PA_SUBSCRIPTION_MASK_SOURCE_OUTPUT), NULL, NULL))) {
show_error(_("pa_context_subscribe() failed"));
return;
}
pa_operation_unref(o);
if (!(o = pa_context_get_client_info_list(context,
add_client_cb,
NULL
) )) {
show_error(_("pa_context_subscribe() failed"));
return;
}
pa_operation_unref(o);
break;
}
case PA_CONTEXT_FAILED:
return;
case PA_CONTEXT_TERMINATED:
default:
// Gtk::Main::quit();
return;
}
}
void stream_state_callback(pa_stream *s, void *userdata) {
assert(s);
switch (pa_stream_get_state(s)) {
case PA_STREAM_CREATING:
break;
case PA_STREAM_TERMINATED:
break;
case PA_STREAM_READY:
break;
case PA_STREAM_FAILED:
default:
printf("Stream error: %s", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
exit(1);
}
}
int main(int argc, char *argv[]) {
// Define our pulse audio loop and connection variables
pa_mainloop *pa_ml;
pa_mainloop_api *pa_mlapi;
pa_operation *pa_op;
pa_time_event *time_event;
// Create a mainloop API and connection to the default server
pa_ml = pa_mainloop_new();
pa_mlapi = pa_mainloop_get_api(pa_ml);
context = pa_context_new(pa_mlapi, "test");
// This function connects to the pulse server
pa_context_connect(context, NULL, 0, NULL);
// This function defines a callback so the server will tell us its state.
//pa_context_set_state_callback(context, state_cb, NULL);
pa_context_set_state_callback(context, context_state_cb, NULL);
if (pa_mainloop_run(pa_ml, &ret) < 0) {
printf("pa_mainloop_run() failed.");
exit(1);
}
}
我的系统上的输出如下:
Found a new client index 0 name ConsoleKit Session /org/freedesktop/ConsoleKit/Session2 eol 0
Found a new client index 4 name XSMP Session on gnome-session as 1057eba7239ba1ec3d136359809598590100000018790044 eol 0
Found a new client index 5 name GNOME Volume Control Media Keys eol 0
Found a new client index 7 name GNOME Volume Control Applet eol 0
Found a new client index 53 name Metacity eol 0
Found a new client index 54 name Firefox eol 0
Found a new client index 248 name PulseAudio Volume Control eol 0
Found a new client index 342 name test eol 0
控制接收客户端的音量
PulseAudio 的一个显著特点是，它不仅可以将流混合到一个设备中，还可以控制每个流的音量。这是对每个设备的音量控制的补充。在pavucontrol中，你可以在播放选项卡上看到这一点，在这里可以调整播放客户端的音量。
从程序上来说，这是通过调用带有参数的pa_context_set_sink_input_volume来完成的，这些参数是接收输入和音量的索引。在下面的程序中，我按照在pavolume_client.c程序中所做的那样，将 PulseAudio 设置为在单独的线程中运行，并在主线程中输入音量值。一个细微的区别是，你必须等待客户端启动接收输入，这是通过休眠来完成的，直到接收输入回调将一个非零值赋给sink_index变量。粗糙，是的。在像pavucontrol这样的程序中，GUI 无论如何都是在单独的线程中运行的，你不需要求助于这样简单的技巧。
节目是pavolume_sink.c。例如，如果你使用 MPlayer 播放一个文件，那么它的音量可以通过这个程序来调整。
/**
* pavolume_sink.c
* Jan Newmarch
*/
#include <stdio.h>
#include <string.h>
#include <pulse/pulseaudio.h>
#define CLEAR_LINE "\n"
#define _(x) x
int ret;
// sink we will control volume on when it is non-zero
int sink_index = 0;
int sink_num_channels;
pa_context *context;
void show_error(char *s) {
/* stub */
}
void sink_input_cb(pa_context *c, const pa_sink_input_info *i, int eol, void *userdata) {
if (eol < 0) {
if (pa_context_errno(context) == PA_ERR_NOENTITY)
return;
show_error(_("Sink input callback failure"));
return;
}
if (eol > 0) {
return;
}
printf("Sink input found index %d name %s for client %d\n", i->index, i->name, i->client);
sink_num_channels = i->channel_map.channels;
sink_index = i->index;
}
void volume_cb(pa_context *c, int success, void *userdata) {
if (success)
printf("Volume set\n");
else
printf("Volume not set\n");
}
void subscribe_cb(pa_context *c, pa_subscription_event_type_t t, uint32_t index, void *userdata) {
switch (t & PA_SUBSCRIPTION_EVENT_FACILITY_MASK) {
case PA_SUBSCRIPTION_EVENT_SINK_INPUT:
if ((t & PA_SUBSCRIPTION_EVENT_TYPE_MASK) == PA_SUBSCRIPTION_EVENT_REMOVE)
printf("Removing sink input %d\n", index);
else {
pa_operation *o;
if (!(o = pa_context_get_sink_input_info(context, index, sink_input_cb, NULL))) {
show_error(_("pa_context_get_sink_input_info() failed"));
return;
}
pa_operation_unref(o);
}
break;
}
}
void context_state_cb(pa_context *c, void *userdata) {
switch (pa_context_get_state(c)) {
case PA_CONTEXT_UNCONNECTED:
case PA_CONTEXT_CONNECTING:
case PA_CONTEXT_AUTHORIZING:
case PA_CONTEXT_SETTING_NAME:
break;
case PA_CONTEXT_READY: {
pa_operation *o;
pa_context_set_subscribe_callback(c, subscribe_cb, NULL);
if (!(o = pa_context_subscribe(c, (pa_subscription_mask_t)
(PA_SUBSCRIPTION_MASK_SINK_INPUT), NULL, NULL))) {
show_error(_("pa_context_subscribe() failed"));
return;
}
break;
}
case PA_CONTEXT_FAILED:
return;
case PA_CONTEXT_TERMINATED:
default:
// Gtk::Main::quit();
return;
}
}
void stream_state_callback(pa_stream *s, void *userdata) {
assert(s);
switch (pa_stream_get_state(s)) {
case PA_STREAM_CREATING:
break;
case PA_STREAM_TERMINATED:
break;
case PA_STREAM_READY:
break;
case PA_STREAM_FAILED:
default:
printf("Stream error: %s", pa_strerror(pa_context_errno(pa_stream_get_context(s))));
exit(1);
}
}
int main(int argc, char *argv[]) {
// Define our pulse audio loop and connection variables
pa_threaded_mainloop *pa_ml;
pa_mainloop_api *pa_mlapi;
pa_operation *pa_op;
pa_time_event *time_event;
long volume = 0;
char buf[128];
struct pa_cvolume v;
// Create a mainloop API and connection to the default server
pa_ml = pa_threaded_mainloop_new();
pa_mlapi = pa_threaded_mainloop_get_api(pa_ml);
context = pa_context_new(pa_mlapi, "test");
// This function connects to the pulse server
pa_context_connect(context, NULL, 0, NULL);
// This function defines a callback so the server will tell us its state.
//pa_context_set_state_callback(context, state_cb, NULL);
pa_context_set_state_callback(context, context_state_cb, NULL);
pa_threaded_mainloop_start(pa_ml);
/* wait till there is a sink */
while (sink_index == 0) {
sleep(1);
}
printf("Enter volume for sink %d\n", sink_index);
pa_cvolume_init(&v);
while (1) {
puts("Enter an integer 0-65536");
fgets(buf, 128, stdin);
volume = atoi(buf);
pa_cvolume_set(&v, sink_num_channels, volume);
pa_context_set_sink_input_volume(context,
sink_index,
&v,
volume_cb,
NULL
);
}
}
结论
本章介绍了 PulseAudio。这是目前消费者 Linux 的标准声音系统。有许多实用程序可用于探索 PulseAudio。有两种 API:简单 API 和异步 API。本章介绍了如何使用这些 API 来演奏和录音。还研究了脉搏音频的其他方面。
延迟不是目标，也不是为实时音频设计的。但是，您可以要求延迟较小，如果 PulseAudio 可以做到这一点，它将为您提供合理的性能。但是，PulseAudio 不保证延迟，因此如果最大延迟很关键，那么 PulseAudio 可能不合适。
PulseAudio 目前构建在 ALSA 之上，通常通过使自己成为默认的 ALSA 插件来进行交互。
扫一扫
305
被折叠的 条评论
为什么被折叠?
到【灌水乐园】发言
