Android RecyclerView GridLayoutManager,Glide load Photo,classification by date tag, Kotlin

import android.content.Context
import android.graphics.Color
import android.graphics.drawable.Drawable
import android.os.Bundle
import android.provider.MediaStore
import android.text.TextUtils
import android.util.Log
import android.view.LayoutInflater
import android.view.View
import android.view.ViewGroup
import android.widget.ImageView
import android.widget.TextView
import androidx.appcompat.app.AppCompatActivity
import androidx.appcompat.widget.AppCompatImageView
import androidx.core.content.ContextCompat
import androidx.core.view.setPadding
import androidx.lifecycle.lifecycleScope
import androidx.recyclerview.widget.GridLayoutManager
import androidx.recyclerview.widget.LinearLayoutManager
import androidx.recyclerview.widget.RecyclerView
import androidx.recyclerview.widget.RecyclerView.RecyclerListener
import kotlinx.coroutines.Dispatchers
import kotlinx.coroutines.launch
import kotlinx.coroutines.withContext
import java.text.SimpleDateFormat

class MainActivity : AppCompatActivity() {
    companion object {
        const val TAG = "fly"

        const val SIZE = 500

        const val VIEW_TYPE = 0
        const val DATE_TYPE = 1

        const val SPAN_COUNT = 12
    }

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)

        val rv: RecyclerView = findViewById(R.id.rv)
        rv.setHasFixedSize(true)
        rv.setItemViewCacheSize(SPAN_COUNT * 10)
        rv.setRecyclerListener(object : RecyclerListener {
            override fun onViewRecycled(holder: RecyclerView.ViewHolder) {
                Log.d(TAG, "onViewRecycled ${holder.adapterPosition}")
                GlideApp.with(holder.itemView.context).clear((holder as MyVH).itemView)
            }
        })

        val layoutManager = GridLayoutManager(this, SPAN_COUNT)
        layoutManager.orientation = LinearLayoutManager.VERTICAL
        rv.layoutManager = layoutManager

        val adapter = MyAdapter(this)
        rv.adapter = adapter

        lifecycleScope.launch(Dispatchers.IO) {
            val items = readAllImage(this@MainActivity)

            items.sortByDescending {
                it.dateModified
            }

            val lists = items.distinctBy {
                it.dateString
            }

            lists.forEach { it_lists ->
                val idx = items.indexOfFirst {
                    it_lists.dateString == it.dateString
                }

                val data = MyData()
                data.type = DATE_TYPE
                data.dateString = it_lists.dateString
                items.add(idx, data) //不要直接加 it_Lists，这里面涉及到List的深拷贝/浅拷贝问题。
            }

            withContext(Dispatchers.Main) {
                adapter.dataChanged(items)
            }
        }

        layoutManager.spanSizeLookup = object : GridLayoutManager.SpanSizeLookup() {
            override fun getSpanSize(position: Int): Int {
                return if (adapter.getItemViewType(position) == DATE_TYPE) {
                    //group，标题
                    SPAN_COUNT
                } else {
                    //单个小格子
                    1
                }
            }
        }
    }

    class MyAdapter : RecyclerView.Adapter<MyVH> {
        private var mItems = arrayListOf<MyData>()
        private var mContext: Context? = null
        private var mPlaceholder: Drawable? = null
        private var mError: Drawable? = null

        constructor(ctx: Context) {
            mContext = ctx

            mPlaceholder = ContextCompat.getDrawable(mContext!!, android.R.drawable.ic_menu_gallery)
            mError = ContextCompat.getDrawable(mContext!!, android.R.drawable.stat_notify_error)
        }

        fun dataChanged(items: ArrayList<MyData>) {
            this.mItems = items
            notifyDataSetChanged()
        }

        override fun onCreateViewHolder(parent: ViewGroup, viewType: Int): MyVH {
            var v: View? = null
            if (viewType == VIEW_TYPE) {
                v = MyIV(mContext!!)
            } else {
                v = LayoutInflater.from(mContext!!).inflate(android.R.layout.simple_list_item_1, null)
                v.setBackgroundColor(Color.LTGRAY)
            }

            return MyVH(v!!)
        }

        override fun getItemCount(): Int {
            return mItems.size
        }

        override fun getItemViewType(position: Int): Int {
            return mItems[position].type
        }

        override fun onBindViewHolder(holder: MyVH, position: Int) {
            Log.d(TAG, "onBindViewHolder ${holder.adapterPosition}")
            val type = getItemViewType(position)
            if (type == VIEW_TYPE) {
                val path = mItems[holder.adapterPosition].path
                GlideApp.with(mContext!!)
                    .asBitmap()
                    .load(path)
                    .centerCrop()
                    .override(SIZE)
                    .error(mError)
                    .placeholder(mPlaceholder)
                    .into(holder.itemView as ImageView)
            } else if (type == DATE_TYPE) {
                holder.itemView.findViewById<TextView>(android.R.id.text1).text = "${mItems[position].dateString}"
            }
        }
    }

    class MyVH : RecyclerView.ViewHolder {
        constructor(itemView: View) : super(itemView) {

        }
    }

    class MyIV : AppCompatImageView {
        constructor(ctx: Context) : super(ctx) {
            setPadding(1)
        }

        override fun onMeasure(widthMeasureSpec: Int, heightMeasureSpec: Int) {
            super.onMeasure(widthMeasureSpec, heightMeasureSpec)
            val w = MeasureSpec.getSize(widthMeasureSpec)
            val h = MeasureSpec.getSize(heightMeasureSpec)
            val size = Math.max(w, h) //取w,h的最大值。
            setMeasuredDimension(size, size) //使得ImageView为正方形。
        }
    }

    class MyData {
        var type = VIEW_TYPE

        var dateModified: Long? = 0L
        var dateString: String? = null
        var path: String? = null
        var index: Int? = null

        override fun toString(): String {
            return "MyData(type=$type, dateModified=$dateModified, dateString=$dateString, path=$path, index=$index)"
        }
    }

    private fun readAllImage(context: Context): ArrayList<MyData> {
        val photos = ArrayList<MyData>()

        //读取所有图片
        val cursor = context.contentResolver.query(
            MediaStore.Images.Media.EXTERNAL_CONTENT_URI, null, null, null, null
        )

        var index = 0
        val sdf = SimpleDateFormat("yyyy-MM-dd")
        while (cursor!!.moveToNext()) {
            //路径 uri
            val path = cursor.getString(cursor.getColumnIndexOrThrow(MediaStore.Images.Media.DATA))
            if (TextUtils.isEmpty(path)) {
                continue
            }

            val dateModified = cursor.getString(cursor.getColumnIndexOrThrow(MediaStore.Images.Media.DATE_MODIFIED))

            //图片名称
            //val name = cursor.getString(cursor.getColumnIndexOrThrow(MediaStore.Images.Media.DISPLAY_NAME))
            //图片大小
            //val size = cursor.getLong(cursor.getColumnIndexOrThrow(MediaStore.Images.Media.SIZE))

            val dateStr = sdf.format(dateModified?.toLong()!! * 1000)

            val data = MyData()
            data.type = VIEW_TYPE
            data.path = path
            data.dateModified = dateModified.toLong()
            data.dateString = dateStr
            data.index = index++

            photos.add(data)
        }
        cursor.close()

        return photos
    }
}

import android.content.Context
import android.util.Log
import com.bumptech.glide.GlideBuilder
import com.bumptech.glide.annotation.GlideModule
import com.bumptech.glide.load.engine.cache.InternalCacheDiskCacheFactory
import com.bumptech.glide.load.engine.cache.MemorySizeCalculator
import com.bumptech.glide.load.engine.executor.GlideExecutor
import com.bumptech.glide.module.AppGlideModule


@GlideModule
class MyGlideModule : AppGlideModule() {

    override fun applyOptions(context: Context, builder: GlideBuilder) {
        super.applyOptions(context, builder)
        builder.setLogLevel(Log.DEBUG)

        val memoryCacheScreens = 200F
        val maxSizeMultiplier = 0.8F

        val calculator = MemorySizeCalculator.Builder(context)
            .setMemoryCacheScreens(memoryCacheScreens)
            .setBitmapPoolScreens(memoryCacheScreens)
            .setMaxSizeMultiplier(maxSizeMultiplier)
            .setLowMemoryMaxSizeMultiplier(maxSizeMultiplier * 0.8F)
            .setArrayPoolSize((1024 * 1024 * memoryCacheScreens).toInt())
            .build()
        builder.setMemorySizeCalculator(calculator)

        val diskCacheSize = 1024 * 1024 * 2000L
        builder.setDiskCache(InternalCacheDiskCacheFactory(context, diskCacheSize))

        val mSourceBuilder = GlideExecutor.newSourceBuilder()
            .setUncaughtThrowableStrategy(GlideExecutor.UncaughtThrowableStrategy.LOG)
            .setThreadCount(2)
            //.setThreadTimeoutMillis(1000) //线程读写超时时间。
            .setName("fly-Source")
            .build()

        val mDiskCacheBuilder = GlideExecutor.newDiskCacheBuilder()
            .setThreadCount(1)
            //.setThreadTimeoutMillis(1000) //线程读写超时时间。
            .setName("fly-DiskCache")
            .build()

        val mAnimationBuilder = GlideExecutor.newAnimationBuilder()
            .setThreadCount(1)
            //.setThreadTimeoutMillis(1000) //线程读写超时时间。
            .setName("fly-Animation")
            .build()

        builder.setSourceExecutor(mSourceBuilder)
        builder.setDiskCacheExecutor(mDiskCacheBuilder)
        builder.setAnimationExecutor(mAnimationBuilder)
    }

    override fun isManifestParsingEnabled(): Boolean {
        return false
    }
}
