LFSR线性反馈移位寄存器Verilog实现

用Verilog实现如下图所示的线性反馈移位寄存器：

The reset should resetthe LFSR to 1

直接写逻辑门的代码

这种写法比较笨拙。

这里寄存器只有5 bits，数量不算多，因此，这种写法还可以接受，如果寄存器的位数更大呢，比如64bit，甚至128bit，那这种写法就显得非常繁琐了。

module top_module(
    input clk,
    input reset,    // Active-high synchronous reset to 5'h1
    output [4:0] q
);

    always@(posedge clk) begin
        if(reset)
            q <= 5'h1;
        else begin
            q[4] <= 1'b0 ^ q[0];
            q[3] <= q[4];
            q[2] <= q[3] ^ q[0];
            q[1] <= q[2];
            q[0] <= q[1];
        end
    end
endmodule

更优的写法

下述这种写法写起来更为简单，尤其是当移位寄存器的位数非常多的时候，优势更为明显。因为LFSR即使位数很多，但是，有反馈的位数并不会太多，下述代码中组合逻辑always模块的代码量仅仅取决于有反馈的位数。

module top_module(
    input clk,
    input reset,
    output reg [4:0] q);

    reg [4:0] q_next;        // q_next is not a register

    // Convenience: Create a combinational block of logic that computes
    // what the next value should be.
    // Combinational always block: Use blocking assignments.
    always @(*) begin
        q_next = q[4:1];    // Shift all the bits. This is incorrect for q_next[4] and q_next[2]
                            //向右移一位，高位自动填充0，因此，只写了q[4:1]
        q_next[4] = q[0];   // Give q_next[4] and q_next[2] their correct assignments
                            //0与x异或，得到的结果是x本身
        q_next[2] = q[3] ^ q[0];
    end


    // This is just a set of DFFs. I chose to compute the connections between the
    // DFFs above in its own combinational always block, but you can combine them if you wish.
    // You'll get the same circuit either way.
    // Edge-triggered always block: Use non-blocking assignments.
    always @(posedge clk) begin
        if (reset)
            q <= 5'h1;
        else
            q <= q_next;
    end

endmodule
