这款万用表的内阻有多大呢？

卓晴
已于 2022-10-31 10:40:47 修改
阅读量1.3k
点赞数 1
分类专栏：教学-交流-科普科学-技术-探究文章标签：电路实验万用表内阻
于 2022-10-30 13:04:41 首次发布
本文链接：https://blog.csdn.net/zhuoqingjoking97298/article/details/127593299
版权
科学-技术-探究同时被 2 个专栏收录
2559 篇文章
订阅专栏
教学-交流-科普
1438 篇文章
订阅专栏
万用表内阻
01 万用表内阻

一、背景介绍

今天看到一个有趣的短片，博主小哥把玩两个金属圆板，非常清晰的展示了电容的工作原理。但其中一个实验，涉及到使用万用表测量金属板电压，对于有经验的人来说，对于他的实验结果会感到非常奇怪。
-7-
二、万用表内阻

首先，从视频中来看这两个圆盘之间的电容大约为0.18nF 充电之后，两个圆盘相互离开，可以看到电压在升高。这实际上没有考虑到测量电压万用表的内阻。通常情况下，万用表的内阻为10M欧姆，对于0.1nF电容，应该在10ms就释放完了。可以这个短片中却显示电压在升高！这太奇怪了。
-9-
※ 总结 ※

本文记录了一个短频中使用万用表测量两个平行铁片电压的实验。显然这个实验没有考虑到万用表的内阻。实在不清楚影片中万用表内阻该是多少了。
-3-
