RLHF中reward model的奖励值有哪些计算方法？Loss如何计算？

reward 模型的训练涉及到几个问题：

奖励值如何输出？（注意不是reward model loss）
reward model的常见loss有哪些？
针对不同的奖励值的输出方法、不同的loss计算，相应的reward model训练数据样式是怎么样的？
可以使用的模型结构有哪些？

decoder-only模型

如常见的GPT-1/2/3，Llama，Qwen，gemma等模型可以作为reward model的基座模型。

使用decoder-only模型有多种输出奖励值的方式：

point wise

获取输入序列的最后一个token的hidden state，然后接一个线性层映射到2分类（accept和reject），然后使用交叉熵损失计算loss。
获取输入序列的最后一个token的hidden state，然后接一个线性层映射到一个标量值，然后使用MES等计算loss。要求训练数据的标签是一个标量值（打分值）。

存在的问题：不同标注人员的打分标准很难保持一致，如标注员A：0.8 VS 0.7，标注员B：0.6 VS 0.5
https://rlhflow.github.io/posts/2024-05-29-multi-objective-reward-modeling/
- reward model的训练是通过构建多个aspect的回归loss

pair wise

获取输入序列的最后一个token的hidden state，然后接一个线性层映射到一个标量值，将accept和reject的奖励差值作为loss进行优化，有两种具体实现方式：

OpenAI的实现方式：

class LogSigLoss(nn.Module):
    """
    Pairwise Loss for Reward Model
    Details: https://arxiv.org/abs/2203.02155
    """

    def forward(self, chosen_reward: torch.Tensor, reject_reward: torch.Tensor) -> torch.Tensor:
        return -torch.nn.functional.logsigmoid(chosen_reward - reject_reward).mean()

Anthropic的实现方式

class LogExpLoss(nn.Module):
    """
    Pairwise Loss for Reward Model
    Details: https://arxiv.org/abs/2204.05862
    """

    def forward(self, chosen_reward: torch.Tensor, reject_reward: torch.Tensor) -> torch.Tensor:
        loss = torch.log(1 + torch.exp(reject_reward - chosen_reward)).mean()
        return loss

token-level pairwise reward loss的具体实现方法

本质是accept response和reject response的token-wise的reward的差值的sigmoid（尽可能的去掉pad token loss，并且去掉prompt token loss）

具体的实现方式参考：url

def compute_loss(
    self, model: "PreTrainedModel", inputs: Dict[str, torch.Tensor], return_outputs: bool = False
) -> Union[torch.Tensor, Tuple[torch.Tensor, List[torch.Tensor]]]:
    r"""
    Computes pairwise loss. The first n examples are chosen and the last n examples are rejected.
    Subclass and override to inject custom behavior.
    Note that the first element will be removed from the output tuple.
    See: https://github.com/huggingface/transformers/blob/v4.39.1/src/transformers/trainer.py#L3777
    """
    # Compute rewards
    _, _, values = model(**inputs, output_hidden_states=True, return_dict=True)
    unwrapped_model: "PreTrainedModel" = self.accelerator.unwrap_model(self.model)
    if getattr(unwrapped_model.config, "model_type", None) == "chatglm":
        values = torch.transpose(values, 0, 1)
    # Split the inputs and rewards into two parts, chosen and rejected
    batch_size = inputs["input_ids"].size(0) // 2
    chosen_input_ids, rejected_input_ids = inputs["input_ids"][:batch_size], inputs["input_ids"][batch_size:]
    chosen_rewards, rejected_rewards = values[:batch_size], values[batch_size:]
    chosen_scores, rejected_scores = [], []
    # Compute pairwise loss. Only backprop on the different tokens before padding
    # Inspired by: https://github.com/CarperAI/trlx/blob/main/examples/summarize_rlhf/reward_model/reward_model.py
    loss = 0
    for i in range(batch_size):
        chosen_length = (chosen_input_ids[i] != self.tokenizer.pad_token_id).nonzero()[-1] + 1
        rejected_length = (rejected_input_ids[i] != self.tokenizer.pad_token_id).nonzero()[-1] + 1
        check_divergence = (chosen_input_ids[i] != rejected_input_ids[i]).nonzero()
        if len(check_divergence) == 0:
            end_index = chosen_length
            div_index = end_index - 1
        else:
            end_index = max(chosen_length, rejected_length)
            div_index = check_divergence[0]
        assert div_index > 0
        chosen_trunc_rewards = chosen_rewards[i, div_index:end_index]
        rejected_trunc_rewards = rejected_rewards[i, div_index:end_index]
        if return_outputs:  # use the score on the last token except pad token for inference
            chosen_scores.append(chosen_rewards[i, chosen_length - 1])
            rejected_scores.append(rejected_rewards[i, rejected_length - 1])
        loss += -torch.nn.functional.logsigmoid(chosen_trunc_rewards - rejected_trunc_rewards).mean()
    loss = loss / batch_size
    if return_outputs:
        chosen_scores, rejected_scores = torch.stack(chosen_scores), torch.stack(rejected_scores)
        return loss, [loss, chosen_scores, rejected_scores]
    return loss
