3 IEEE 802.3 summary of classification standards
1 Abstract:
Ethernet local area network operation is specified for selected speeds of operation from 1 Mb/s to 400 Gb/s using a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) allow use of selected Physical Layer devices (PHY) for operation over coaxial, twisted pair or fiber optic cables, or electrical backplanes. System considerations for multisegment shared access networks describe the use of Repeaters that are defined for operational speeds up to 1000 Mb/s. Local Area Network (LAN) operation is supported at all speeds. Other specified capabilities include: various PHY types for access networks, PHYs suitable for metropolitan area network applications, and the provision of power over selected twisted pair PHY types.
2 Scope:
This standard defines Ethernet local area, access and metropolitan area networks. Ethernet is specified at selected speeds of operation; and uses a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) provide an architectural and optional implementation interface to selected Physical Layer entities (PHY). The Physical Layer encodes frames for transmission and decodes received frames with the modulation specified for the speed of operation, transmission medium and supported link length. Other specified capabilities include: control and management protocols, and the provision of power over selected twisted pair PHY types.
3 IEEE 802.3 summary of classification standards
| Num | Versions | Full name | Date of Publication | Status | Abstract |
| 1 | 802.3cm-2020 | IEEE Standard for Ethernet -- Amendment 7:Physical Layer and Management Parameters for 400 Gb/s over Multimode Fiber | 30 March 2020 | active - Approved | This amendment to IEEE Std 802.3-2018 adds Clause 150. This amendment adds Physical Layer (PHY) specifications and management parameters for 400 Gb/s operation on four pairs (400GBASE-SR4.2) and eight pairs (400GBASE-SR8) of multimode fiber, over reaches of at least 100 m. Scope: Define Physical Layer specifications (PHY) and management parameters for the transfer of Ethernet format frames at 400 Gb/s over fewer than 16 pairs of multimode fiber physical media. |
| 2 | 802.3cq-2020 | IEEE Standard for Ethernet Amendment 6: Maintenance #13: Power over Ethernet over 2 pairs | 13 March 2020 | active - Approved | This amendment to IEEE Std 802.3-2018 makes technical and editorial corrections and refinements to Power over Ethernet over 2-pairs in Clause 33. Scope: This project will implement editorial and technical corrections, refinements, and clarifications to Clause 33, Power over Ethernet over 2 pairs, and related portions of the standard. No new features will be added by this project. |
| 3 | 802.3cg-2019 | IEEE Standard for Ethernet - Amendment 5:Physical Layer Specifications and Management Parameters for 10 Mb/s Operation and Associated Power Delivery over a Single Balanced Pair of Conductors | 5 Feb. 2020 | active - Approved | This amendment to IEEE Std 802.3-2018 specifies additions and appropriate modifications to add 10 Mb/s Physical Layer (PHY) specifications and management parameters for operation, and associated optional provision of power, over a single balanced pair of conductors. Scope: Specify additions to and appropriate modifications of IEEE Std 802.3 to add 10 Mb/s Physical Layer (PHY) specifications and management parameters for operation, and associated optional provision of power, on single balanced twisted-pair copper cabling. |
| 4 | 802.3cn-2019 | IEEE Standard for Ethernet - Amendment 4: Physical Layers and Management Parameters for 50Gb/s, 200Gb/s, and 400Gb/s Operation over Single-Mode Fiber | 20 Dec. 2019 | active - Approved | This amendment to IEEE Std 802.3-2018 adds Physical Layer (PHY) specifications and management parameters for 50 Gb/s, 200 Gb/s, and 400 Gb/s operation over single-mode fiber with reaches of at least 40 km. Scope: Define physical layer specifications and management parameters for the transfer of Ethernet format frames at 50 Gb/s, 200 Gb/s, and 400 Gb/s at reaches greater than 10 km over single-mode fiber. Make TDECQ (Transmitter and dispersion eye closure for PAM4) related changes to existing 200 Gb/s and 400 Gb/s physical medium dependent sublayers over single-mode fiber. |
| 5 | 802.3cd-2018 | IEEE Standard for Ethernet - Amendment 3: Media Access Control Parameters for 50 Gb/s and Physical Layers and Management Parameters for 50 Gb/s, 100 Gb/s, and 200 Gb/s Operation | 14 Feb. 2019 | active - Approved | Clause 131 through Clause 140 and Annex 135A through Annex 136D are added to IEEE Std 802.3-2018 by this amendment to specify IEEE 802.3 Media Access Control (MAC) parameters, Physical Layer specifications, and management parameters for the transfer of IEEE 802.3 format frames at 50 Gb/s, 100 Gb/s, and 200 Gb/s. (The PDF of this standard is available at no cost to you compliments of the IEEE GET program https://ieeexplore.ieee.org/browse/standards/get-program/page/series?id=68). Scope: Define Ethernet Media Access Control (MAC) parameters, Physical Layer specifications, and management parameters for the transfer of Ethernet format frames at 50 Gb/s over copper and optical media. Define additional Physical Layer specifications and management parameters at 100 Gb/s over copper and optical media. Define additional Physical Layer specifications and management parameters at 200 Gb/s over copper and multimode fiber physical media. |
| 6 | 802.3bt-2018 | IEEE Standard for Ethernet Amendment 2: Physical Layer and Management Parameters for Power over Ethernet over 4 pairs | 31 Jan. 2019 | active - Approved | The maximum Powered Device (PD) power available is increased by this amendment to IEEE Std 802.3-2018 by utilizing all four pairs in the specified structured wiring plant. This represents a substantial change to the capabilities of Ethernet with standardized power. The power classification information exchanged during negotiation is extended to allow meaningful power management capability. These enhancements solve the problem of higher power and more efficient standardized Power over Ethernet (PoE) delivery systems. (The PDF of this standard is available at no cost to you compliments of the IEEE GET program https://ieeexplore.ieee.org/browse/standards/get-program/page/series?id=68). Scope: The scope of this project is to augment the capabilities of the IEEE Std 802.3 standard with 4-pair power and associated power management information. The project will augment the methodology for the provision of power via balanced cabling to connected Data Terminal Equipment with 802.3 interfaces. Optional augmented power limit will be made available for certain structured cabling systems. Improvements introduced for 4-pair systems, excluding raising the power limit, are optionally enabled for 2-pair systems. Compatibility with existing equipment will be maintained. |
| 7 | 802.3cb-2018 | IEEE Standard for Ethernet - Amendment 1:Physical Layer Specifications and Management Parameters for 2.5 Gb/s and 5 Gb/s Operation over Backplane | 4 Jan. 2019 | active - Approved | Ethernet Media Access Control (MAC) parameters, Physical Layer specifications, and management objects for the serial transfer of Ethernet format frames at 2.5 Gb/s and 5 Gb/s over electrical backplanes are defined in this amendment to IEEE Std 802.3-2018. Scope: The scope of this project is to specify additions to and appropriate modifications of IEEE Std 802.3 to add 2.5 Gb/s and 5 Gb/s Physical Layer (PHY) specifications and management parameters for operation over backplanes consistent with current storage interconnect applications within a single rack |
| 8 | 802.3-2018 | IEEE Standard for Ethernet | 31 Aug. 2018 | active - Approved | Ethernet local area network operation is specified for selected speeds of operation from 1 Mb/s to 400 Gb/s using a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) allow use of selected Physical Layer devices (PHY) for operation over coaxial, twisted pair or fiber optic cables, or electrical backplanes. System considerations for multisegment shared access networks describe the use of Repeaters that are defined for operational speeds up to 1000 Mb/s. Local Area Network (LAN) operation is supported at all speeds. Other specified capabilities include: various PHY types for access networks, PHYs suitable for metropolitan area network applications, and the provision of power over selected twisted pair PHY types.(The PDF of this standard is ... Scope: This standard defines Ethernet local area, access and metropolitan area networks. Ethernet is specified at selected speeds of operation; and uses a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) provide an architectural and optional implementation interface to selected Physical Layer entities (PHY). The Physical Layer encodes frames for transmission and decodes received frames with the modulation specified for the speed of operation, transmission medium and supported link length. Other specified capabilities include: control and management protocols, and the provision of power over selected twisted pair PHY types. |
| 9 | 802.3-2018 | IEEE Standard for Ethernet - Redline | 31 Aug. 2018 | active - Redline | Ethernet local area network operation is specified for selected speeds of operation from 1 Mb/s to 400 Gb/s using a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) allow use of selected Physical Layer devices (PHY) for operation over coaxial, twisted pair or fiber optic cables, or electrical backplanes. System considerations for multisegment shared access networks describe the use of Repeaters that are defined for operational speeds up to 1000 Mb/s. Local Area Network (LAN) operation is supported at all speeds. Other specified capabilities include: various PHY types for access networks, PHYs suitable for metropolitan area network applications, and the provision of power over selected twisted pair PHY types.(The PDF of this standard is ... Scope: This standard defines Ethernet local area, access and metropolitan area networks. Ethernet is specified at selected speeds of operation; and uses a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) provide an architectural and optional implementation interface to selected Physical Layer entities (PHY). The Physical Layer encodes frames for transmission and decodes received frames with the modulation specified for the speed of operation, transmission medium and supported link length. Other specified capabilities include: control and management protocols, and the provision of power over selected twisted pair PHY types. |
| 10 | 802.3br-2016 | IEEE Standard for Ethernet Amendment 5: Specification and Management Parameters for Interspersing Express Traffic | 14 Oct. 2016 | active - Approved | This amendment to IEEE Std 802.3-2015 specifies additions to and appropriate modifications to add support for interspersing express traffic over a single physical link. |
| 11 | 802.3bm-2015 | IEEE Standard for Ethernet - Amendment 3: Physical Layer Specifications and Management Parameters for 40 Gb/s and 100 Gb/s Operation over Fiber Optic Cables | 27 March 2015 | active - Approved | Physical Layer specifications and management parameters for 40 Gb/s operation over single-mode fiber (40GBASE-ER4) and for 100 Gb/s operation over multimode fiber (100GBASE-SR4) are added by this amendment. This amendment also specifies a four-lane variant of the 100 Gigabit Attachment Unit Interface (CAUI-4) and optional Energy Efficient Ethernet (EEE) for 40 Gb/s and 100 Gb/s operation over fiber optic cables. |
| 12 | 8802-3-2014 | ISO/IEC/IEEE International Standard for Ethernet | 1 April 2014 | active - Approved | Ethernet local area network operation is specified for selected speeds of operation from1 Mb/s to 100 Gb/s using a common media access control (MAC) specification and managementinformation base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD)MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation.Speed specific Media Independent Interfaces (MIIs) allow use of selected Physical Layer devices(PHY) for operation over coaxial, twisted-pair or fiber optic cables. System considerations formultisegment shared access networks describe the use of Repeaters that are defined for operational speeds up to 1000 Mb/s. Local Area Network (LAN) operation is supported at all speeds. Other specified capabilities include various PHY types for access networks, PHYs suitable for metropolitan area network applications, and the provision of power over selected twisted-pair PHY types. |
| 13 | 8802-3-2017/Amd 11-2019 | ISO/IEC/IEEE International Standard - Information technology - Telecommunications and information exchange between systems - Local and metropolitan area networks - Specific requirements - Part 3: Standard for Ethernet AMENDMENT 11: Physical layer and management parameters for serial 25 Gb/s Ethernet operation over single-mode fiber | 8 March 2019 | active - Approved | This amendment to IEEE Std 802.3-2015 adds Physical Layer (PHY) specifications and management parameters for 25 Gb/s operation over single-mode fiber at reaches of at least 10 km (25GBASE-LR) and 40 km (25GBASE-ER). |
| 14 | 8802-3-2017/Amd 10-2019 | ISO/IEC/IEEE International Standard - Information technology - Telecommunications and information exchange between systems - Local and metropolitan area networks - Specific requirements - Part 3: Standard for Ethernet AMENDMENT 10: Media access control parameters, physical layers, and management parameters for 200 Gb/s and 400 Gb/s operation | 28 Feb. 2019 | active - Approved | Clause 116 through Clause 124 and Annex 119A through Annex 120E are added by this amendment to IEEE Std 802.3-2015. This amendment includes IEEE 802.3 Media Access Control (MAC) parameters, Physical Layer specifications, and management parameters for the transfer of IEEE 802.3 format frames at 200 Gb/s and 400 Gb/s. |
| 15 | 8802-3-2017/Cor 1-2018 | Information technology -- Telecommunications and information exchange between systems -- Local and metropolitan area networks -- Specific requirements Part 3: Standard for Ethernet TECHNICAL CORRIGENDUM 1: Multi-lane timestamping | 18 Oct. 2018 | active - Approved | This corrigendum to IEEE Std 802.3-2015 clarifies which lane of the media dependent interface (MDI) of a multi-lane Physical Layer entity (PHY) is used as the timestamping reference point. |
| 16 | 8802-3:2017/Amd 8-2018 | ISO/IEC/IEEE International Standard - Information technology -- Telecommunications and information exchange between systems -- Local and metropolitan area networks -- Specific requirements -- Part 3: Standard for Ethernet AMENDMENT 8: Physical layer and management parameters for Power over Data Lines (PoDL) of single balanced twisted-pair Ethernet | 11 Dec. 2018 | active - Approved | Specifications and management parameters for the provision of power via a single twisted pair to connected Data Terminal Equipment (DTE) with IEEE 802.3 single balanced twisted-pair interfaces are added by this amendment to IEEE Std 802.3-2015. |
| 17 | 8802-3:2017/Amd 6-2018 | ISO/IEC/IEEE International Standard - Information technology - Telecommunications and information exchange between systems - Local and metropolitan area networks - Specific requirements - Part 3: Standard for Ethernet AMENDMENT 6: Physical layer specifications and management parameters for ethernet passive optical networks protocol over coax | 11 Dec. 2018 | active - Approved | Physical Layer specifications and management parameters for the operation of Ethernet Passive Optical Networks (EPON) Protocol over coaxial media is defined by this amendment to IEEE Std 802.3-2015. |
| 18 | 8802-3:2017/Amd 7-2017 | ISO/IEC/IEEE International Standard for Ethernet Amendment 7: Media Access Control Parameters, Physical Layers, and Management Parameters for 2.5 Gb/s and 5 Gb/s Operation, Types 2.5GBASE-T and 5GBASE-T | 16 March 2018 | active - Approved | Protocols, procedures, and managed objects to allow IEEE 802.11 media to provide internal connections within bridged networks, as well as access to bridged networks, are provided in this amendment. |
| 19 | 8802-3:2017/Amd 5-2017 | ISO/IEC/IEEE International Standard - Amendment 5: Specification and Management Parameters for Interspersing Express Traffic | 16 March 2018 | active - Approved | This amendment to IEEE Std 802.3-2015 specifies additions to and appropriate modifications to add support for interspersing express traffic over a single physical link. |
| 20 | 8802-3:2017/Amd 4-2017 | ISO/IEC/IEEE International Standard - Information technology -- Telecommunications and information exchange between systems -- Local and metropolitan area networks -- Specific requirements -- Part 3: Standard for Ethernet Amendment 4: Physical Layer Specifications and Management Parameters for 1 Gb/s Operation over a Single Twisted-Pair Copper Cable | 8 March 2018 | active - Approved | This amendment to IEEE Std 802.3-2015 adds point-to-point 1 Gb/s Physical Layer (PHY) specifications and management parameters for operation on a single twisted-pair copper cable in an automotive application. |
| 21 | 8802-3:2017/Amd 3-2017 | ISO/IEC/IEEE International Standard for Ethernet Amendment 3: Physical Layer and Management Parameters for 25 Gb/s and 40 Gb/s Operation, Types 25GBASE-T and 40GBASE-T | 8 March 2018 | active - Approved | This amendment to IEEE Std 802.3-2015 specifies new Physical Coding Sublayer (PCS) interfaces and new Physical Medium Attachment (PMA) sublayer interfaces for 25 Gb/s Ethernet and 40 Gb/s Ethernet. 25GBASE-T and 40GBASE-T specify LAN interconnects for up to 30 m of balanced twisted-pair structured cabling, for 25 Gb/s and 40 Gb/s, respectively. |
| 22 | 8802-3:2017/Amd 2-2017 | ISO/IEC/IEEE International Standard - Part 3: Standard for Ethernet - Amendment 2: Media Access Control Parameters, Physical Layers, and Management Parameters for 25 Gb/s Operation | 7 March 2018 | active - Approved | This amendment to IEEE Std 802.3-2015 adds Physical Layer (PHY) specifications and management parameters for 25 Gb/s operation over twinaxial copper cabling (25GBASE-CR and 25GBASE-CR-S), electrical backplanes (25GBASE-KR and 25GBASE-KR-S), and multimode fiber (25GBASE-SR). This amendment also specifies a 25 Gigabit Attachment Unit Interface (25GAUI) and optional Energy Efficient Ethernet (EEE). |
| 23 | 8802-3:2017/Amd 1-2017 | ISO/IEC/IEEE International Standard - Part 3: Standard for Ethernet - Amendment 1: Physical Layer Specifications and Management Parameters for 100 Mb/s Operation over a Single Balanced Twisted Pair Cable (100BASE-T1) | 7 March 2018 | active - Approved | This amendment to IEEE Std 802.3-2015 adds Physical Layer (PHY) specifications and management parameters for 25 Gb/s operation over twinaxial copper cabling (25GBASE-CR and 25GBASE-CR-S), electrical backplanes (25GBASE-KR and 25GBASE-KR-S), and multimode fiber (25GBASE-SR). This amendment also specifies a 25 Gigabit Attachment Unit Interface (25GAUI) and optional Energy Efficient Ethernet (EEE). |
| 24 | 802.3cc-2017 | IEEE Standard for Ethernet - Amendment 11: Physical Layer and Management Parameters for Serial 25 Gb/s Ethernet Operation Over Single-Mode Fiber | 15 Jan. 2018 | superseded | This amendment to IEEE Std 802.3-2015 adds Physical Layer (PHY) specifications and management parameters for 25 Gb/s operation over single-mode fiber at reaches of at least 10 km (25GBASE-LR) and 40 km (25GBASE-ER). Scope: The scope of this project is to add point-to-point single-mode fiber Physical Medium Dependent (PMD) options for serial 25 Gb/s operation at reaches greater than 100 m by specifying additions to, and appropriate modifications of, IEEE Std 802.3. |
| 25 | 802.3bs-2017 | IEEE Standard for Ethernet - Amendment 10: Media Access Control Parameters, Physical Layers, and Management Parameters for 200 Gb/s and 400 Gb/s Operation | 12 Dec. 2017 | superseded | Clause 116 through Clause 124 and Annex 119A through Annex 120E are added by this amendment to IEEE Std 802.3-2015. This amendment includes IEEE 802.3 Media Access Control (MAC) parameters, Physical Layer specifications, and management parameters for the transfer of IEEE 802.3 format frames at 200 Gb/s and 400 Gb/s. Scope: Define Ethernet Media Access Control (MAC) parameters, physical layer specifications, and management parameters for the transfer of Ethernet format frames at 200 Gb/s over single-mode fiber and 400 Gb/s over optical physical media |
| 26 | 802.3-2015/Cor 1-2017 | IEEE Standard for Ethernet - Corrigendum 1: Multi-lane Timestamping | 21 April 2017 | superseded | This corrigendum to IEEE Std 802.3-2015 clarifies which lane of the media dependent interface (MDI) of a multi-lane Physical Layer entity (PHY) is used as the timestamping reference point. Scope: Clarification of which lane of the media dependent interface (MDI) of a multilane Physical Layer entity (PHY) is used as the timestamping reference point. |
| 27 | 802.3bu-2016 | IEEE Standard for Ethernet--Amendment 8: Physical Layer and Management Parameters for Power over Data Lines (PoDL) of Single Balanced Twisted-Pair Ethernet | 7 Feb. 2017 | superseded | Specifications and management parameters for the provision of power via a single twisted pair to connected Data Terminal Equipment (DTE) with IEEE 802.3 single balanced twisted-pair interfaces are added by this amendment to IEEE Std 802.3-2015. Scope: Define methodology for the provision of power via a single twisted pair to connected Data Terminal Equipment (DTE) with IEEE 802.3 interfaces. |
| 28 | 802.3bn-2016 | IEEE Standard for Ethernet Amendment 6: Physical Layer Specifications and Management Parameters for Ethernet Passive Optical Networks Protocol over Coax | 7 Dec. 2016 | superseded | Physical Layer specifications and management parameters for the operation of Ethernet Passive Optical Networks (EPON) Protocol over coaxial media is defined by this amendment to IEEE Std 802.3-2015. Scope: The project is to amend IEEE Std 802.3 to add physical layer specifications and management parameters for symmetric and/or asymmetric operation of up to 10 Gb/s on point-to-multipoint Radio Frequency (RF) distribution plants comprising either amplified or passive coaxial media. It also extends the operation of Ethernet Passive Optical Networks (EPON) protocols, such as MultiPoint Control Protocol (MPCP) and Operation Administration and Management (OAM). |
| 29 | 802.3bz-2016 | IEEE Standard for Ethernet Amendment 7: Media Access Control Parameters, Physical Layers, and Management Parameters for 2.5 Gb/s and 5 Gb/s Operation, Types 2.5GBASE-T and 5GBASE-T | 18 Oct. 2016 | superseded | Ethernet Media Access Control (MAC) parameters, Physical Layer specifications, and management objects for the transfer of Ethernet format frames at 2.5 Gb/s and 5 Gb/s over balanced twisted-pair transmission media used in structured cabling are defined in this amendment to IEEE Std 802.3-2015. Scope: This amendment defines Ethernet Media Access Control (MAC) parameters, physical layer specifications, and management objects for the transfer of Ethernet format frames at 2.5 Gb/s and 5 Gb/s over balanced twisted pair transmission media used in structured cabling. |
| 30 | 802.3br-2016 | IEEE Standard for Ethernet Amendment 5: Specification and Management Parameters for Interspersing Express Traffic | 14 Oct. 2016 | superseded | This amendment to IEEE Std 802.3-2015 specifies additions to and appropriate modifications to add support for interspersing express traffic over a single physical link. Scope: The scope of this project is to specify additions to and appropriate modifications of IEEE Std 802.3 to add support for interspersing express traffic over a single physical link. |
| 31 | 802.3bp-2016 | IEEE Standard for Ethernet Amendment 4: Physical Layer Specifications and Management Parameters for 1 Gb/s Operation over a Single Twisted-Pair Copper Cable | 20 Sept. 2016 | superseded | This amendment to IEEE Std 802.3-2015 adds point-to-point 1 Gb/s Physical Layer (PHY) specifications and management parameters for operation on a single twisted-pair copper cable in an automotive application. Scope: The scope of this project is to specify additions to and appropriate modifications of IEEE Std 802.3 to add a point-to-point 1 Gb/s Physical Layer (PHY) specifications and management parameters for operation over a single twisted pair copper cable. |
| 32 | 802.3bq-2016 | IEEE Standard for Ethernet Amendment 3: Physical Layer and Management Parameters for 25 Gb/s and 40 Gb/s Operation, Types 25GBASE-T and 40GBASE-T | 8 Sept. 2016 | superseded | This amendment to IEEE Std 802.3-2015 specifies new Physical Coding Sublayer (PCS) interfaces and new Physical Medium Attachment (PMA) sublayer interfaces for 25 Gb/s Ethernet and 40 Gb/s Ethernet. 25GBASE-T and 40GBASE-T specify LAN interconnects for up to 30 m of balanced twisted-pair structured cabling, for 25 Gb/s and 40 Gb/s, respectively. Scope: Specify Physical Layers (PHYs) for operation at 25 Gb/s and 40 Gb/s on balanced twisted-pair copper cabling, using existing Media Access Control, and with extensions to the appropriate physical layer management parameters. |
| 33 | 802.3by-2016 | EEE Standard for Ethernet -- Amendment 2: Media Access Control Parameters, Physical Layers, and Management Parameters for 25 Gb/s Operation Amendment 2: Media Access Control Parameters, Physical Layers, and Management Parameters for 25 Gb/s Operation | 29 July 2016 | superseded | This amendment to IEEE Std 802.3-2015 adds Physical Layer (PHY) specifications and management parameters for 25 Gb/s operation over twinaxial copper cabling (25GBASE-CR and 25GBASE-CR-S), electrical backplanes (25GBASE-KR and 25GBASE-KR-S), and multimode fiber (25GBASE-SR). This amendment also specifies a 25 Gigabit Attachment Unit Interface (25GAUI) and optional Energy Efficient Ethernet (EEE). Scope: This amendment defines Ethernet Media Access Control (MAC) parameters, physical layer specifications, and management parameters for the transfer of Ethernet format frames at 25 Gb/s for server to switch interconnections. |
| 34 | 802.3bw-2015 | IEEE Standard for Ethernet Amendment 1: Physical Layer Specifications and Management Parameters for 100 Mb/s Operation over a Single Balanced Twisted Pair Cable (100BASE-T1) | 7 March 2016 | superseded | The 100BASE-T1 Physical Layer (PHY) specifications and management parameters for point-to-point full duplex 100 Mb/s operation over single twisted pair balanced cabling is defined in this amendment. This specification provides fully functional and electrical specifications for the type 100BASE-T1 PHY. This specification also specifies the baseband medium used with 100BASE-T1. Scope: The scope of this project is to specify additions to and appropriate modifications of IEEE Std 802.3 Standard for Ethernet to add a point-to-point full duplex 100 Mb/s Physical Layer (PHY) specifications and management parameters for operation over single twisted pair balanced cabling. |
| 35 | 802.3-2015 | IEEE Standard for Ethernet | 4 March 2016 | superseded | Ethernet local area network operation is specified for selected speeds of operation from 1 Mb/s to 100 Gb/s using a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) allow use of selected Physical Layer devices (PHY) for operation over coaxial, twisted pair or fiber optic cables, or electrical backplanes. System considerations for multisegment shared access networks describe the use of Repeaterswhich are defined for operational speeds up to 1000 Mb/s. Local Area Network (LAN) operation is supported at all speeds. Other specified capabilities include: various PHY types for access networks, PHYs suitable for metropolitan area network applications, and the provision of power over selected twisted pair PHY types. Scope: This standard defines Ethernet local area, access and metropolitan area networks. Ethernet is specified at selected speeds of operation; and uses a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) provide an architectural and optional implementation interface to selected Physical Layer entities (PHY). The Physical Layer encodes frames for transmission and decodes received frames with the modulation specified for the speed of operation, transmission medium and supported link length. Other specified capabilities include: control and management protocols, and the provision of power over selected twisted pair PHY types. |
| 36 | 802.3bm-2015 | IEEE Standard for Ethernet - Amendment 3: Physical Layer Specifications and Management Parameters for 40 Gb/s and 100 Gb/s Operation over Fiber Optic Cables | 27 March 2015 | superseded | Physical Layer specifications and management parameters for 40 Gb/s operation over single-mode fiber (40GBASE-ER4) and for 100 Gb/s operation over multimode fiber (100GBASE-SR4) are added by this amendment. This amendment also specifies a four-lane variant of the 100 Gigabit Attachment Unit Interface (CAUI-4) and optional Energy Efficient Ethernet (EEE) for 40 Gb/s and 100 Gb/s operation over fiber optic cables. |
| 37 | 802.3bj-2014 | IEEE Standard for Ethernet Amendment 2: Physical Layer Specifications and Management Parameters for 100 Gb/s Operation Over Backplanes and Copper Cables | 3 Sept. 2014 | superseded | 100 Gb/s Physical Layer (PHY) specifications and management parameters for operation on electrical backplanes and twinaxial copper cables are added by this amendment to IEEE Std 802.3-2012. This amendment also specifies optional Energy Efficient Ethernet (EEE) for 40 Gb/s and 100 Gb/s operation over electrical backplanes and copper cables. |
| 38 | 802.3bk-2013 | IEEE Standard for Ethernet - Amendment 1: Physical Layer Specifications and Management Parameters for Extended Ethernet Passive Optical Networks | 30 Aug. 2013 | superseded | This amendment to IEEE Std 802.3 defines the physical layer specifications and management parameters for EPON operation on point-to-multipoint passive optical networks supporting extended power budget classes of PX30, PX40, PRX40, and PR40 PMDs. Scope: This amendment to IEEE Std 802.3 defines the physical layer specifications and management parameters for EPON operation on point-to-multipoint passive optical networks supporting extended power budget classes of PX30, PX40, PRX40, and PR40 PMDs. |
| 39 | 802.3-2012 | IEEE Standard for Ethernet | 28 Dec. 2012 | superseded | Ethernet local area network operation is specified for selected speeds of operation from 1 Mb/s to 100 Gb/s using a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) allow use of selected Physical Layer devices (PHY) for operation over coaxial, twisted-pair or fiber optic cables. System considerations for multisegment shared access networks describe the use of Repeaters that are defined for operational speeds up to 1000 Mb/s. Local Area Network (LAN) operation is supported at all speeds. Other specified capabilities include various PHY types for access networks, PHYs suitable for metropolitan area network applications, and the provision of power over selected twisted-pair PHY types. Scope: This standard defines Ethernet local area, access and metropolitan area networks. Ethernet is specified at selected speeds of operation; and uses a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) provide an architectural and optional implementation interface to selected Physical Layer entities (PHY). The Physical Layer encodes frames for transmission and decodes received frames with the modulation specified for the speed of operation, transmission medium and supported link length. Other specified capabilities include: control and management protocols, and the provision of power over selected twisted pair PHY types. |
| 40 | 802.3bd-2011 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Specific requirements-- Part 3: CSMA/CD Access Method and Physical Layer Specifications - Amendment 8: MAC Control Frame for Priority-based Flow Control | 10 Aug. 2011 | superseded | MAC Control Frame to support IEEE 802.1Q Priority-based Flow Control is defined in this amendment. Scope: MAC Control Frame to support IEEE 802.1Q Priority-based Flow Control is defined in this amendment. |
| 41 | 802.3bf-2011 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Part 3: CSMA/CD Access Method and Physical Layer Specifications Amendment 7: Media Access Control (MAC) Service Interface and Management Parameters to Support Time Synchronization Protocols | 15 July 2011 | superseded | This amendment to IEEE Std 802.3 defines the Time Synchronization Service Interface (TSSI) to indicate when the Start Frame Delimiter (SFD) crosses the generic Medium Independent Interface (xMII), together with management objects indicating transmit and receive data delay between the Medium Dependent Interface (MDI) and xMII for the given Physical Layer devices (PHY). Both features are required to support time synchronization protocols, e.g., IEEE Std 802.1AS or IEEE Std 1588-2008. Scope: This amendment to IEEE Std 802.3 defines the Time Synchronization Service Interface (TSSI) to indicate when the Start Frame Delimiter (SFD) crosses the generic Medium Independent Interface (xMII), together with management objects indicating transmit and receivedata delay between the Medium Dependent Interface (MDI) and xMII for the given Physical Layer devices (PHY). Both features are required to support time synchronization protocols, e.g., IEEE Std 802.1AS™ or IEEE Std 1588™-2008 |
| 42 | 802.3bg-2011 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Specific requirements-- Part 3: CSMA/CD Access Method and Physical Layer Specifications Amendment 6: Physical Layer and Management Parameters for Serial 40 Gb/s Ethernet Operation Over Single Mode Fiber | 31 March 2011 | superseded | This amendment to IEEE Std 802.3-2008 specifies a new Physical Medium Dependent (PMD) sublayer, 40GBASE-FR, for serial 40 Gb/s operation over up to 2 km of single-mode fiber. Keywords: 40 Gb/s Ethernet, 40GBASE-FR, IEEE 802.3bg, Optical Transport Network, OTN, Physical Medium Dependent sublayer, PMD sublayer, single-mode fiber, SMF. Scope: The scope of this project is to add a single-mode fiber Physical Medium Dependent (PMD) option for serial 40 Gb/s operation by specifying additions to, and appropriate modifications of, IEEE Std 802.3-2008 as amended by the IEEE P802.3ba project (and any other approved amendment or corrigendum). Purpose: This project will define a 40 Gb/s serial PMD that supports a link distance of at least 2km over single-mode fiber that is optically compatible with existing carrier 40Gb/s client interfaces (OTU3/STM-256/OC-768/40G Packet over SONET (POS)), which will enable interconnection between equipment in carrier networks or as uplink interconnections from enterprises, data centers, or other network operators into carrier networks. |
| 43 | 802.3az-2010 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Specific requirements-- Part 3: CSMA/CD Access Method and Physical Layer Specifications Amendment 5: Media Access Control Parameters, Physical Layers, and Management Parameters for Energy-Efficient Ethernet | 27 Oct. 2010 | superseded | This amendment to IEEE Std 802.3-2008 specifies changes to several existing physical layers to enable energy-efficient operation of Ethernet. Changes to 10BASE-T include a reduction in transmit voltage requirements. Changes to 100BASE-TX, 1000BASE-T, 10GBASE-T, 1000BASE-KX, 10GBASE-KX4 and 10GBASE-KR include the definition of a Low Power Idle (LPI) mode and mechanisms to communicate and manage the entry and exit into and out of LPI and the operation of this mode. New Link Layer Discovery Protocol (LLDP) TLVs are defined for negotiating system level energy-efficiency parameters. Scope: Clause 14 defines the functional, electrical, and mechanical characteristics of the type 10BASE-T MAU and one specific medium for use with that MAU. This clause also specifies the functional, electrical, and mechanical characteristics of the energy-efficient version of 10BASE-T, the type 10BASE-Te MAU, and one specific medium for use with that MAU. The relationship of this clause to the entire ISO/IEC 8802-3IEEE 802.3 LAN International Standard is shown in Figure 14–1. The purpose of the MAU is to provide a simple, inexpensive, and flexible means of attaching devices to the medium. NOTE—Support for both 10BASE-T and 10BASE-Te signal levels in a single device is not required. This MAU and medium specification is aimed primarily at office applications where twisted-pair cable is often installed. Installation and reconfiguration simplicity is allowed by the type of cable and connectors used. The 10BASE-T specification builds upon Clause 1 through Clause 7 and Clause 9 of this standard. |
| 44 | 802.3ba-2010 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Specific requirements-- Part 3: CSMA/CD Access Method and Physical Layer Specifications Amendment 4: Media Access Control Parameters, Physical Layers, and Management Parameters for 40 Gb/s and 100 Gb/s Operation | 22 June 2010 | superseded | This amendment to IEEE Std 802.3-2008 includes changes to IEEE Std 802.3-2008 and adds Clause 80 through Clause 88, Annex 83A through Annex 83C, Annex 85A, and Annex 86A. This amendment includes IEEE 802.3 Media Access Control (MAC) parameters, Physical Layer specifications, and management parameters for the transfer of IEEE 802.3 format frames at 40 Gb/s and 100 Gb/s. Scope: This amendment to IEEE Std 802.3-2008 includes changes to IEEE Std 802.3-2008 and adds Clause 80 through Clause 88, Annex 83A through Annex 83C, Annex 85A, and Annex 86A. This amendment includes IEEE 802.3 Media Access Control (MAC) parameters, Physical Layer specifications, and management parameters for the transfer of IEEE 802.3 format frames at 40 Gb/s and 100 Gb/s. |
| 45 | 802.3-2008/Cor 1-2009 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Specific requirements-- Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications Corrigendum 1: Timing Considerations for PAUSE Operation | 1 Feb. 2010 | superseded | The correction to the PAUSE reaction timing delay for the 10GBASE-T port type is addressed in this corrigendum to IEEE Std 802.3-2008. Scope: The scope is to correct the PAUSE reaction delay value so that it is sufficient for all IEEE Std 802.3 'Physical Layer entity (PHY) types. Purpose: The PAUSE reaction delay value specified is not sufficient for all PHYs. |
| 46 | 802.3at-2009 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Specific requirements-- Part 3: CSMA/CD Access Method and Physical Layer Specifications Amendment 3: Data Terminal Equipment (DTE) Power via the Media Dependent Interface (MDI) Enhancements | 30 Oct. 2009 | superseded | This amendment includes changes to IEEE Std 802.3-2008 to augment the capabilities of IEEE Std 802.3 with higher power levels and improved power management information. Scope: A protocol and a set of managed objects that can be used for discovering the physical topology from adjacent stations in IEEE 802 LANs are defined in this standard. |
| 47 | 802.3av-2009 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Specific requirements-- Part 3: CSMA/CD Access Method and Physical Layer Specifications Amendment 1: Physical Layer Specifications and Management Parameters for 10 Gb/s Passive Optical Networks | 30 Oct. 2009 | superseded | This amendment to IEEE Std 802.3-2008 extends Ethernet Passive Optical Networks (EPONs) operation to 10 Gb/s providing both symmetric, 10 Gb/s downstream and upstream, and asymmetric, 10 Gb/s downstream and 1 Gb/s upstream, data rates. It specifies the 10 Gb/s EPON Reconciliation Sublayer, 10GBASE-PR symmetric and 10/1GBASE-PRX Physical Coding Sublayers (PCSs) and Physical Media Attachments (PMAs), and Physical Medium Dependent sublayers (PMDs) that support both symmetric and asymmetric data rates while maintaining complete backward compatibility with already deployed 1 Gb/s EPON equipment. The EPON operation is defined for distances of at least 10 km and at least 20 km, and for split ratios of 1:16 and 1:32. An additional MAC control opcode is also defined to provide organization specific extension operation. Scope: This amendment to IEEE Std 802.3-2008 extends Ethernet Passive Optical Networks (EPONs) operation to 10 Gb/s providing both symmetric, 10 Gb/s downstream and upstream, and asymmetric, 10 Gb/s downstream and 1 Gb/s upstream, data rates. It specifies the 10 Gb/s EPON Reconciliation Sublayer, 10GBASE-PR symmetric and 10/1GBASE-PRX Physical Coding Sublayers (PCSs) and Physical Media Attachments (PMAs), and Physical Medium Dependent sublayers (PMDs) that support both symmetric and asymmetric data rates while maintaining complete backward compatibility with already deployed 1 Gb/s EPON equipment. The EPON operation is defined for distances of at least 10 km and at least 20 km, and for split ratios of 1:16 and 1:32. An additional MAC Control opcode is also defined to provide organization specific extension operation |
| 48 | 802.3bc-2009 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Specific requirements-- Part 3: CSMA/CD Access Method and Physical Layer Specifications Amendment 2: Ethernet Organizationally Specific Type, Length, Value (TLVs) | 28 Sept. 2009 | superseded | This amendment to IEEE Std 802.3-2008 transfers the IEEE 802.3 Organizationally Specific TLVs, specified in IEEE Std 802.1ABtrade-2009, Station and Media Access Control Connectivity Discovery, to IEEE Std 802.3. Scope: This amendment to IEEE Std 802.3-2008 transfers the IEEE 802.3 Organizationally Specific TLVs, specified in IEEE Std 802.1AB(TM)-2009, Station and Media Access Control Connectivity Discovery, to IEEE Std 802.3. |
| 49 | 802.3-2008 | IEEE Standard for Information technology--Telecommunications and information exchange between systems--Local and metropolitan area networks--Specific requirements Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications | 26 Dec. 2008 | superseded | Ethernet local area network operation is specified for selected speeds of operation from 1 Mb/s to 10 Gb/s using a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) allow use of selected Physical Layer devices (PHY) for operation over coaxial, twisted pair or fiber optic cables. System considerations for multisegment shared access networks describe the use of Repeaters which are defined for operational speeds up to 1000 Mb/s. Local Area Network (LAN) operation is supported at all speeds. Scope: This standard defines Ethernet local area, access and metropolitan area networks. Ethernet is specified at selected speeds of operation; and uses a common media access control (MAC) specification and management information base (MIB). The Carrier Sense Multiple Access with Collision Detection (CSMA/CD)MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) provide an architectural and optional implementation interface to selected Physical Layer entities (PHY). The Physical Layer encodes frames for transmission and decodes received frames with the modulation specified for the speed of operation, transmission medium and supported link length. Other specified capabilities include: control and management protocols, and the provision of power over selected twisted pair PHY types. |
| 50 | 802.3-2005/Cor 2-2007 | IEEE Standard for Information Technology - Telecommunications and Information Exchange Between Systems - Local and Metropolitan Area Networks - Specific Requirements Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications - Corrigendum 2: IEEE Std 802.3an-2006 10GBASE-T Correction | 17 Aug. 2007 | superseded | Corrigendum to IEEE Std 802.3-2005. This corrigendum will correct Equation 55-55. It has been incorporated into the second printing of IEEE Std 802.3an-2006. Scope: This corrigendum will correct Equation 55-55 Purpose: Somehow during the draft development, a Log10 term in the equation was missed. No one in the ballot group commented on it. The change does not qualify as an errata and therefore is being done as a corrigendum. |
| 51 | 802.3ap-2007 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Specific requirements-- Part 3: CSMA/CD Access Method and Physical Layer Specifications - Amendment: Ethernet Operation Over Electrical Backplanes | 22 May 2007 | superseded | This amendment to IEEE Std 802.3-2005 includes the new Clause 69 through Clause 74. Clause 69 provides an overview of Ethernet operation over electrical backplanes. Clause 70 through Clause 72 define three new PMDs developed for operation over electrical backplanes. 1000 BASE-KX specifies 1 Gb/s serial operation, 10 GBASE-KX4 specifies 10 Gb/s 4-lane operation, and 10 GBASE-KR specifies 10 Gb/s serial operation. Clause 73 specifies an Auto-Negotiation function for use over electrical backplanes. Finally, Clause 74 specifies an optional forward error correction (FEC) sublayer for 10 GBASE-R PHYs for improved link performance. Scope: The scope of this project is to specify additions to and appropriate modifications of IEEE Std 802.3 to specify operation at 1000 Mb/s and 10 Gb/s across an electrical backplane leveraging the existing MAC. Purpose: The purpose of this project is to provide standards based Ethernet interconnection of server and telecommunication blades over a modular platform backplane. Industry trends for LAN, SAN and other applications are migrating to backplane interconnects, and this project will optimize Ethernet operation for backplanes. |
| 52 | 802.3as-2006 | IEEE Standard for Information technology-- Telecommunications and information exchange between systems-- Local and metropolitan area networks-- Specific requirements Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications | 13 Nov. 2006 | superseded | This amendment to IEEE Std 802.3-2005 extends the IEEE 802.3 basic frame format with the addition of an envelope frame to accommodate additional prefixes and suffixes required by higher layer encapsulation protocols such as those defined by IEEE 802.1 (e.g., Provider Bridges, MAC Security), ITU-T or IETF (e.g., MPLS). Scope: Specify the IEEE 802.3 frame format when optional envelope information is present while preserving the original MAC service data unit. Also, specify related adjustments to IEEE 802.3 Media Access Control (MAC) parameters and management attribute definitions. Purpose: The purpose of this project is to extend the size of the IEEE 802.3 frame format to accommodate IEEE 802.1ad Provider Bridging, IEEE 802.1AE MACSec and other applications requiring envelope information. |
| 53 | 802.3aq-2006 | IEEE Standard for Information technology--Telecommunications and information exchange between systems--Local and metropolitan area networks--Specific requirements Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications | 16 Oct. 2006 | superseded | Amendment to IEEE Std 802.3-2005 This amendment to IEEE Std 802.3-2005 specifies a new PMD, 10GBASE-LRM, for serial, 10 Gb/s operation over up to 220 m of 62.5 µm and 50 µm multimode fiber, including installed, FDDI grade multimode fiber Scope: The scope of this project is to specify additions to and appropriate modifications of IEEE Std 802.3-2002 as amended to add a Physical Layer (PHY) for operation at 10 Gb/s on standards based structured fiber cabling, using the existing MAC and with extensions to the appropriate physical layer management parameters of IEEE Std 802.3. Purpose: This project will define a lower-cost, 10Gb/s serial PHY that supports a link distance of at least 220m over installed FDDI-grade multimode fiber. The specification should enable migration to smaller form factor pluggable modules. |
| 54 | 802.3an-2006 | Standard for Information Technology - Telecommunications and Information Exchange Between Systems – LAN/MAN - Specific Requirements Part 3: CSMA/CD Access Method and Physical Layer Specifications - Amendment: Physical Layer and Management Parameters for 10 Gb/s Operation, Type 10GBASE-T | 1 Sept. 2006 | superseded | This amendment to IEEE Std 802.3-2005 specifies a new Physical Coding Sublayer interface and a new Physical Medium Attachment sublayer interface for 10 Gb/s Ethernet. 10GBASE-T specifies a LAN interconnect for up to 100 m of balanced twisted-pair structured cabling systems. Scope: The scope of this project is to specify a Physical Layer (PHY) for operation at 10 Gb/s on standards based structured copper cabling, using the existing Media Access Controller, and with extensions to the appropriate physical layer management parameters, of IEEE Std 802.3. Purpose: The purpose of this project is to provide a lower-cost, twisted pair copper cabling option for 10Gb/s interconnection of equipment up to 100 m. |
| 55 | 802.3-2005/Cor 1-2006 | IEEE Standard for Information Technology - Telecommunications and Information Exchange Between Systems - Local and Metropolitan Area Networks - Specific Requirements Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications - Corrigendum 1 | 26 June 2006 | superseded | This corrigendum clarifies and corrects isolation text including harmonization for both powered and unpowered Medium Dependent Interfaces Scope: This corrigendum clarifies and corrects isolation text for twisted pair Ethernet physical interfaces, including harmonization for both powered and unpowered Medium Dependent interfaces. Purpose: The current text is technically not implementable for powered interfaces, and implementers must now make common sense deviations from the specifications of 802.3 to build power sourcing equipment. |
| 56 | 802.3-2005 | IEEE Standard for Information Technology - Telecommunications and Information Exchange Between Systems - Local and Metropolitan Area Networks - Specific Requirements Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications | 9 Dec. 2005 | superseded | Ethernet local area network operation is specified for selected speeds of operation from 1 Mb/s to 10 Gb/s using a common media access control (MAC) specification, management information base (MIB), and capability for Link Aggregation of multiple physical links into a single logical link. The Carrier Sense Multiple Access with Collision Detection (CSMA/CD) MAC protocol specifies shared medium (half duplex) operation, as well as full duplex operation. Speed specific Media Independent Interfaces (MIIs) allow use of selected physical layer (PHY) interfaces for operation over coxial, twisted pair or fiber optic cables. System considerations for multisegment shared access networks describe the use of Repeaters which are defined for operational speeds up to 1000 Mb/s. Local Area Network (LAN) operation is supported at all speeds. Other specified capabilities include: various PHY types for access networks, PHYs suitable for metropolitan area network applications, and the provision of power over selected twisted pair PHY types. (Supersedes 802.3-2002 + 802.3ae-2002 + 802.3af-2003 + 802.3ah-2004 + 802.3aj-2003 + 802.3ak-2004). An interpretation is available at http://standards.ieee.org/findstds/interps/802.3-2005_interp.html Scope: This project is a revision of IEEE Std 802.3-2002 integrating approved amendments and corrigenda plus corrections and clarifications submitted as maintenance changes through the IEEE 802.3 maintenance process. This project will not add any significant new functionality. Purpose: This project is expected to merge at least four amendments into the base standard. It also adds maintenance changes submitted through the IEEE 802.3 maintenance process (www.ieee802.org/3/maint) to fix errors and ambiguities in the published standard. This will provide a single base document for ongoing work and satisfy IEEE-SA SB requirements. |
| 57 | 802.3ah-2004 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Part 3: CSMA/CD Access Method and Physical Layer Specifications Amendment: Media Access Control Parameters, Physical Layers, and Management Parameters for Subscriber Access Networks | 7 Sept. 2004 | superseded | This amendment to IEEE Std 802.3-2002 as amended by IEEE Std 802.3ae-2002, IEEE Std 802.3af-2003, IEEE Std 802.3aj-2003, and IEEE Std 802.3ak-2004 combines a minimal set of extensions to the IEEE 802.3 Media Access Control (MAC) and MAC Control sublayers with a family of Physical (PHY) Layers. These Physical Layers include optical fiber and voice grade copper cable Physical Medium Dependent sublayers (PMDs) for point-to-point connections in subscriber access networks. This amendment also introduces the concept of Ethernet Passive Optical Networks (EPONs), in which a point to multi-point (P2MP) network topology is implemented with passive optical splitters, along with optical fiber PMDs that support this topology. In addition, a mechanism for network Operations, Administration and Maintenance (OAM) is included to facilitate network operation and troubleshooting. To support these innovations, options for unidirectional transmission of frames are provided for 100BASE-X, 1000BASE-X, 10GBASE-R, 10GBASE-W, and 10GBASE-X. Scope: Define 802.3 Media Access Control (MAC) parameters and minimal augmentation of the MAC operation, physical layer specifications, and management parameters for the transfer of 802.3 format frames in subscriber access networks at operating speeds within the scope of the current IEEE Std 802.3 and approved new projects. Purpose: To expand the application of Ethernet to include subscriber access networks in order to provide a significant increase in performance while minimizing equipment, operation, and maintenance costs. |
| 58 | 802.3ak-2004 | IEEE Standard for Information technology-- Local and metropolitan area networks-- Part 3: CSMA/CD Access Method and Physical Layer Specifications Amendment: Physical Layer and Management Parameters for 10 Gb/s Operation, Type 10GBASE-CX4 | 1 March 2004 | superseded | This amendment to IEEE Std 802.3-2002 as amended by IEEE Std 802.3ae-2002, IEEE Std 802.3af-2003 and IEEE Std 802.3aj-2003 specifies a new physical layer medium dependent sublayer interface for 10Gb/s Ethernet. 10GBASE-CX4 specifies an equipment interconnect based on the 10 Gigabit Attachment Unit Interface (XAUI) for up to 15m of balanced shielded cabling. Scope: The scope of this project is to specify additions to and appropriate modifications of IEEE Std 802.3 as amended by IEEE Std 802.3ae-2002 (and any other approved amendment or corrigendum) to add a copper Physical Medium Dependent (PMD) option for 10 Gb/s operation, building upon the existing 10GBASE-X Physical Coding Sublayer (PCS) and 10 Gigabit Attachment Unit Interface (XAUI) specifications. Purpose: The purpose of this project is to provide a lower-cost option for interconnection of closely located equipment (within ~15m of cable), typically within a stack or between equipment racks within a room. |
| 59 | 802.3aj-2003 | Standard for Information Technology - Telecommunications and Information Exchange Between Systems - Local and Metropolitan Area Networks - Specific Requirements - Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications - Maintenance 7 | 26 Sept. 2003 | superseded | Superseded by IEEE Std 802.3-2005 IEEE Std 802.3, which addresses the CSMA/CD access method and physical layer specifications will be enhanced through necessary amendments and corrigenda. Scope: IEEE Std 802.3, which addresses the CSMA/CD access method and physical layer specifications will be enhanced through necessary amendments and corrigenda. Purpose: IEEE Std 802.3 will be kept current and reflective of current implementation and application requirements, in accordance with the IEEE 802.3 Working Group maintenance process, defined at http://ieee802.org/3/. |
| 60 | 802.3af-2003 | IEEEE Standard for Information Technology - Telecommunications and Information Exchange Between Systems - Local and Metropolitan Area Networks - Specific Requirements - Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications - Data Terminal Equipment (DTE) Power Via Media Dependent Interface (MDI) | 17 Jun 2003 | superseded | Support for optionally powering a 10BASE-T,100BASE-TX or 1000BASE-T DTE device via the Power Interface (PI)using physical layers defined in Clauses 14,25,and 40.The Power Sourcing Equipment (PSE)is located at an endpoint or midspan,separate from and between the MDIs,and provides power to the Powered Device (PD)over the Link Section.The PSE detection protocol distinguishes a compatible PD from non-compatible devices and precludes the application of power and possible damage to non-compatible devices.The PSE monitors the Maintain Power Signature (MPS)and removes power when it is no longer requested or required.Optional management function requirements are specified. Scope: Define methodology for the provision of power via balanced cabling to connected Data Terminal Equipment with 802.3 interfaces. The amount of power will be limited by cabling physics and regulatory considerations. Compatibility with existing equipment will be considered. Purpose: To provide power for a new class of devices with 802.3 interfaces enabled by progress in silicon technology. These devices are characterized by low power requirements and LAN connectivity. |
| 61 | 802.3ae-2002 | IEEE Standard for Information technology - Local and metropolitan area networks - Part 3: CSMA/CD Access Method and Physical Layer Specifications - Media Access Control (MAC) Parameters, Physical Layer, and Management Parameters for 10 Gb/s Operation | 26 Aug. 2002 | superseded | Support to extend the IEEE 802.3 protocol and MAC specification to an operating speedof 10 Gb/s. Several Physical Coding Sublayers known as 10GBASE-X, 10GBASE-R, and10GBASE-W are specified, as well as significant additional supporting material for a 10 GigabitMedia Independent Interface (XGMII), a 10 Gigabit Attachment Unit Interface (XAUI), a 10 GigabitSixteen-Bit Interface (XSBI) and management. (An Interpretation for this standard is available at http://standards.ieee.org/findstds/interps/802.3ae-2002_interp.pdf) Scope: Define 802.3 Media Access Control (MAC) parameters and minimal augmentation of its operation, physical layer characteristics and management parameters for transfer of LLC and Ethernet format frames at 10 Gb/s using full duplex operation as defined in the 802.3 standard. In addition to the traditional LAN space, add parameters and mechanisms that enable deployment of Ethernet over the Wide Area Network operating at a data rate compatible with OC-192c and SDH VC-4-64c payload rate. Purpose: The purpose of this project is to extend the 802.3 protocol to an operating speed of 10 Gb/s and to expand the Ethernet application space to include Wide Area Network links in order to provide a significant increase in bandwidth while maintaining maximum compatibility with the installed base of 802.3 interfaces, previous investment in research and development, and principles of network operation and management. |
| 62 | 802.3-2002 | IEEE Standard for Information technology-Telecommunications and information exchange between systems-Local and metropolitan area networks-Specific requirements Part 3: Carrier sense multiple access with collision detection (CSMA/CD) access method and physical layer specifications | 8 March 2002 | superseded | " The media access control characteristics for the Carrier Sense Multiple Access with Collision De-tection (CSMA/CD) access method for shared medium local area networks are described. The control charac-teristics for full duplex dedicated channel use are also described. Specifications are provided for MAU types1BASE5 at 1 Mb/s; Attachment Unit Interface (AUI) and MAU types 10BASE5, 10BASE2, FOIRL (fiber opticinter-repeater link), 10BROAD36, 10BASE-T, 10BASE-FL, 10BASE-FB, and 10BASE-FP at 10 Mb/s; MediaIndependent Interface (MII) and PHY types 100BASE-T4, 100BASE-TX, 100BASE-FX, and 100BASE-T2 at100 Mb/s; and the Gigabit MII (GMII) and 1000BASE-X PHY types, 1000BASE-SX, 1000BASE-LX, and1000BASE-CX, which operate at 1000 Mb/s (Gigabit Ethernet) as well as PHY type 1000BASE-T. Repeaterspecifications are provided at each speed. Full duplex specifications are provided at the Physical Layer for10BASE-T, 10BASE-FL, 100BASE-TX, 100BASE-FX, 100BASE-T2, and Gigabit Ethernet. System consider-ations for multisegment networks at each speed and management information base (MIB) specifications andadditions to support Virtual Bridged Local Area Networks (VLANs) as specified in IEEE P802.1Q (R) are also pro-vided. Also specified is an optional Link Aggregation sublayer which multiple physical links to be aggregatedtogethere to form a single logical link. " Scope: Maintenance changes and current 802.3 Standard Purpose: Define parameters for Carrier Sense Multiple Access with Collision Detection (CSMA/CD) access method and physical layer specifications. Add accumulated maintenance changes and provide general review of current 802.3 Standard (1998 Edition and 802.3ab, 802.3ac 802.3ad) |
| 63 | 802.3-2000 | IEEE Standard for Information Technology - LAN/MAN - Specific Requirements -Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications | 16 Oct. 2000 | superseded | Incoporating IEEE Std 802.3, 1998 Edition, IEEE Std 802.3ac-1998, IEEE Std 802.3ab-1999, and IEEE Std 802.3ad-2000. Superseded by 802.3-2002 (802.3ag). The media access control characteristics for the Carrier Sense Multiple Access with Collision Detection (CSMA/CD) access method for shared medium local area networks are described. The control characteristics for full duplex dedicated channel use are also described. Specifications are provided for MAU types 1BASE5 at 1 Mb/s; Attachment Unit Interface (AUI) and MAU types 10BASE5, 10BASE2, FOIRL (fiber optic inter-repeater link), 10BROAD36, 10BASE-T, 10BASE-FL, 10BASE-FB, and 10BASE-FP at 10 Mb/s; Media Independent Interface (MII) and PHY types 100BASE-T4, 100BASE-TX, 100BASE-FX, and 100BASE-T2 at 100 Mb/s; and the Gigabit MII (GMII) and 1000BASE-X PHY types, 1000BASE-SX, 1000BASE-LX, and 1000BASE-CX, which operate at 1000 Mb/s (Gigabit Ethernet) as well as PHY type 1000BASE-T. Repeater specifications are provided at each speed. Full duplex specifications are provided at the Physical Layer for 10BASE-T, 10BASE-FL, 100BASE-TX, 100BASE-FX, 100BASE-T2, and Gigabit Ethernet. System considerations for multi-segment networks at each speed and management information base (MIB) specifications and additions to support Virtual Bridged Local Area Networks (VLANs) as specified in IEEE P802.1Q are also provided. Also specified is an optional Link Aggregation sublayer which multiple physical links to be aggregated together to form a single logical link. |
| 64 | 802.3ad-2000 | IEEE Standard for Information Technology - Local and Metropolitan Area Networks - Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications-Aggregation of Multiple Link Segments | 28 June 2000 | superseded | Incorporated in IEEE Std 802.3, 2000 Edition. Superseded by 802.3-2002. An optional Link Aggregation sublayer for use with CSMA/CD MACs is defined. Link Aggregation allows one or more links to be aggregated together to form a Link Aggregation Group, such that a MAC Client can treat the Link Aggregation Group as if it were a single link. To this end, it specifies the establishment of DTE to DTE logical links, consisting of N parallel instances of full duplex point-to-point links operating at the same data rate. Scope: Specify a DTE to Dte logical link which consists of n parallel instances of an 802.3 point-to-point link segment. The logical link will support existing 802.3 MAC Clients. Define the necessary management objects and protocols to support link aggregation, including identification, addition and deletion of link segments to and from the logical link. Purpose: To increase link availability and bandwidth between DETs by specifying the necessary mechanisms for parallel link segment aggregation. |
| 65 | 802.3ab-1999 | IEEE Standard for Information Technology - Telecommunications and information exchange between systems - Local and Metropolitan Area Networks - Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications - Physical Layer Parameters and Specifications for 1000 Mb/s Operation over 4 pair of Category 5 Balanced Copper Cabling, Type 1000BASE-T | 26 July 1999 | superseded | Superseded by IEEE Std 802.3-2002. This IEEE Standards product is part of the 802 Family on LAN/MAN. Abstract: Type 1000BASE-T PCS, type 1000BASE-T PMA sublayer, and type 1000BASE-T Medium Dependent Interface (MDI) are defined. This supplement provides fully functional, electrical and mechanical specifications for the type 1000BASE-T PCS, PMA, and MDI. This supplement also specifies the baseband medium used with 1000BASE-T. Scope: Define physical layer characteristics and specifications for 1000 Mb/s operation on 4 pair of 100 ohm Category 5 balanced copper cabling as defined by EIA/TIA-568-A, Annex E or its equivalent as built from material specified by ISO/IEC 11801:1995. Purpose: The purpose of this project is to extend the 802.3 protocol to provide 1000 Mb/s operation over installed Category 5 generic facilities balanced copper cabling. |
| 66 | 802.3ac-1998 | IEEE Standard for Information technology - Telecommunications and information exchange between systems - Local and metropolitan area networks - Specific requirements Part 3: Carrier sense multiple access with collision detection (CSMA/CD) frame extensions for Virtual Bridged Local Area Networks (VLAN) tagging on 802.3 networks | 6 Nov. 1998 | superseded | Changes and additions to IEEE standard 802.3, 1998 edition, to support virtual bridged local area networks (VLANs) as specified in IEEE P802.1Q. draft standard for local and metropolitan area networks: virtual bridged local area networks, are provided. Incoporating IEEE Std 802.3, 1998 Edition, IEEE Std 802.3ac-1998, IEEE Std 802.3ab-1999, and IEEE Std 802.3ad-2000. Scope: Specifications of 802.3 frame when carrying Virtual Bridged Local Area network (VLAN) tag information. Necessary adjustments to 802.3 Media Access Control (MAC) parameters e.g. maxFrameSize to accommodate Virtual Bridged Local Area Network tagged framesual Bridged Local Area Network (VLAN) tag information. Necessary adjustments to IEEE Std 802.3 clause 30 management attribute definitions to accommodate Virtual Bridged Local Area Network tagged frames. Purpose: To adjust the 802.3 frame format to align IEEE Std 802.3 with IEEE 802.1Q. |
| 67 | 802.3-1998 | IEEE Standards for Information technology—Telecommunications and information exchange between systems—Local and metropolitan area networks-Specific requirements-Part 3: Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications | 28 Sept. 1998 | superseded | The media access control characteristics for the Carrier Sense Multiple Access with Collision Detection (CSMA/CD) access method for shared medium local area networks are described. The control characteristics for full duplex dedicated channel use are also described. Specifications are provided for MAU types 1BASE5 at 1 Mb/s; Attachment Unit Interface (AUI) and MAU types 10BASE5, 10BASE2, FOIRL (fiber optic inter-repeater link), 10BROAD36, 10BASE-T, 10BASE-FL, 10BASE-FB, and 10BASE-FP at 10 Mb/s; Media Independent Interface (MII) and PHY types 100BASE-T4, 100BASE-TX, 100BASE-FX, and 100BASE-T2 at 100 Mb/s; and the Gigabit MII (GMII) and 1000BASE-X PHY types, ... Scope: This is a comprehensive International Standard for Local Area Networks (LANs) employing CSMA/CD as the access method. This International Standard is intended to encompass several media types and techniques for signal rates from 1 Mb/s to 1000 Mb/s. This edition of the standard provides the necessary specifications for the following families of systems: a 1 Mb/s baseband system, 10 Mb/s baseband and broadband systems, a 100 Mb/s baseband system, and a 1000 Mb/s baseband system. Purpose: This standard provides for two distinct modes of operation: half duplex and full duplex. A given IEEE 802.3 instantiation operates in either half or full duplex mode at any one time. The term "CSMA/CD MAC" is used throughout this standard synonymously with "802.3 MAC," and may represent an instance of either a half duplex or full duplex mode data terminal equipment (DTE), even though full duplex mode DTEs do not implement the CSMA/CD algorithms traditionally used to arbitrate access to shared-media LANs. |
| 68 | 802.3r-1996 | IEEE Standard Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications - Type 10BASE5 Medium Attachment Unit (MAU) Protocol Implementation Conformance Statement (PICS) Proforma (Subclause 8.8) | 9 Dec. 1996 | superseded | A Protocol Implementation Conformance Statement (PICS) proforma for Type 10BASE5 Medium Attachment Unit (MAU) (clause 8) is provided. The PICS proforma is used to evaluate the conformance of a particular implementation of the standard. Scope: The supplier of a protocol implementation that is claimed to conform to Type 10BASE5 MAU (clause 8) specifications shall complete the following PICS proforma. A completed PICS proforma is the PICS for the implementation in question. The PICS is a statement of which capabilities and options of the protocol have been implemented. The PICS can be used for a variety of purposes by various parties. |
| 69 | 802.3u-1995 | IEEE Standards for Local and Metropolitan Area Networks: Supplement - Media Access Control (MAC) Parameters, Physical Layer, Medium Attachment Units, and Repeater for 100Mb/s Operation, Type 100BASE-T (Clauses 21-30) | 26 Oct. 1995 | superseded | Superseded by 802.3aa-1998. The ISO/IEC CSMA/CD Media Access Control (MAC) is coupled with a family of new Physical Layer specifications to achieve 100 Mb/s operation. Known collectively as 100BASE-T, this family of Physical Layer specifications includes 100BASE-T4, which uses four pairs of ISO/IEC 11801: 1995 Category 3, 4, or 5 balanced cable; 100BASE-TX, which uses two pairs of Category 5 balanced cable or 150 ohm shielded balanced cable; and 100BASE-FX, which uses two multi-mode fibers. The two 100BASE-X specifications (100BASE-TX and 100BASE-FX) reused portions of the 100 Mb/s physical signaling specifications originally developed for Fibre Distributed ... Scope: 1. The CSMA/CD access method of IEEE 802.3 will be retained without change. Therefore, the only change to Clause 4 Media access Control and Clause 6 PLS Service Specifications will be to add a subclause 4.4.2.3 containing the parameterized values for 100 Mb/s operation of the MAC. Management definitions will be provided that build upon the existing set with minimal changes. 2. The link segment phyical layer specification and the multiport repeater specification will be optimized for operation over 100 meter TP links supporting one or more of the horizontal wiring schemes specified in EIA/TIA-568:1991 and TSB-36. The architecture will be sufficiently open tha... Purpose: This standard will provide a higher speed capability for 802.3 LANs at 100 Mb/s, made possible by recent developments in high spped signaling, particularly on unshielded twisted pair and advances in silicon technology. It will afford significant performance improvements with minimal vendor and customer investments by leveraging the infrastructure of 802.3 research, development and market deployment. The design focus for Higher Speed CSMA/CD is better performance for existing applications that are characterized by bursty traffic. This standard is also expected to support emerging applications in the market. |
| 70 | 802.3j-1993 | Supplement to 802.3 - Fiber Optic Active and Passive Star-Based Segments, Type 10BASE-F (Sections 15-18) | 12 Oct. 1993 | superseded | Superseded by IEEE Std 802.3-2002 This amendment to IEEE Std 802.3-2002, as amended by IEEE Std 802.3ae-2002 10Gb/s Ethernet and IEEE Std 802.3af-2003 DTE Power via MDI, contains a set of maintenance requests approved for ballot at the November 2002 IEEE 802.3 closing plenary as part of project IEEE P802.3aj Maintenance 7. |
| 71 | 802.3p,q-1993 | IEEE Standards for LMANs: Supplement to IEEE 802.3 - Guidelines for the Development of Managed Objects (GDMO) (IS0 10164-4) Format for Layer-Managed Objects (Section 5) and Layer Management for 10 Mb/s Baseband Medium Attachment Units (MAUs) (Section 20) | 22 Sept. 1993 | superseded | Abstract for IEEE 802.3-1993: This supplement to ISO/IEC 8802-3 : 1993 [IEEE Std 802.3,1993 Edition] defines a set of mechanisms that enable management of ISO/IEC 8802-3 10 MWs integrated Medium Attachment Units (MAUs). The managed objects within this standard are defined as sets of attributes, actions, notifications, and behaviors in accordance with IEEE 802.1 and IS0 standards for network management. Abstract for IEEE 802.3q-1993: Changes are made to Section 5, Lower Management, of ISO/IEC 8802-3 : 1993 [IEEE Std 802.3,1 993 Edition] to bring it into alignment with ISO/IEC 10165-4, Guidelines for the development of managed objects (GDMO). |
| 72 | 802.3k-1992 | Supplement to 802.3 - Layer Management for 10 Mb/s Baseband Repeaters (Section 19) | 9 Nov. 1992 | superseded | The supplement to ISO/IEC 8802-3: 1992 [ANSI/IEEE Std 802.3, 1992 Edition] defines a set of mechanisms that enable management of ISO/IEC 8802-3 10 Mb/s baseband repeater units. The managed objects are defined in accordance with IEEE 802.1 and ISO/IEC standards for network management. |
| 73 | 802.3i-1990 | IEEE Standard for Local and Metropolitan Area Networks - System Considerations for Multisegment 10 Mb/S Baseband Networks (Section 13) and Twisted-Pair Medium Attachment Unit (MAU) and Baseband Medium, Type 10BASE-T (Section 14) | 30 Dec. 1990 | superseded | This Local Area Network standard specifies the Type 10BASE-T Medium Attachment Unit (MAU) and one specific unshielded twisted-pair medium for use with the MAU. This MAU is specified for use in a 10 Mb/s baseband CSMA/CD LAN. Guidelines for its application in a repeatered multisegment hetergeneous CSMA/CD network are included. |
| 74 | 802.3a,b,c,e-1988 | IEEE Standards for Local Area Networks: Supplements to Carrier Sense Multiple Access with Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications | 28 Dec. 1987 | superseded | This report contains four supplements to IEEE 802.3: 802.3a Type 10BASE2 Coaxial Medium Specification (Section 10); 802.3b Type 10BROAD36 Medium Specification (Section 11); 802.3c Repeater Unit Specification; and 802.3e Type 1BASE5 Twisted Pair Medium Specification (Section 12). ANSI/IEEE Std 802.3-1985, Sections 1-7 form the base specification for these supplements. Supplements a, b, and c are specifications for an alternate medium to be used in the CSMA/CD access method. Supplement c completes the necessary specification for a Receiver Unit implementation. |
| 75 | 802.3-1985 | IEEE Standards for Local Area Networks: Carrier Sense Multiple Access With Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications | 1985 | superseded | The carrier sense multiple access with collision detection (CSMA/CD) media access method is the means by which two or more stations share a common bus transmission medium. This is a comprehensive standard for local area networks employing CSMA/CD as the access method. This standard encompasses several media types and techniques for signal rates from 1 Mb/s to 20 Mb/s. IEEE Std 802.3-1985 provides the necessary specifications and related parameter values for a 10 Mb/s baseband implementation. In order to achieve greater clarity and flexibility, this document is organized along architectural lines, i.e. emphasizing the logical divisions of the system and how they fit together. It describes the large-scale separation of the system into two parts: the media access control (MAC) sublayer of the data link layer, and the physical layer. These layers correspond closely to the lowest layers of the ISO Model for Open System Interconnection (OSI). The LLC sublayer and the MAC sublayer together encompass the functions intended for the data link layer as defined in the OSI model.< > |
| 76 | 802.3-1985 | IEEE Standards for Local Area Networks: Carrier Sense Multiple Access With Collision Detection (CSMA/CD) Access Method and Physical Layer Specifications | 1985 | superseded | The carrier sense multiple access with collision detection (CSMA/CD) media access method is the means by which two or more stations share a common bus transmission medium. This is a comprehensive standard for local area networks employing CSMA/CD as the access method. This standard encompasses several media types and techniques for signal rates from 1 Mb/s to 20 Mb/s. IEEE Std 802.3-1985 provides the necessary specifications and related parameter values for a 10 Mb/s baseband implementation. In order to achieve greater clarity and flexibility, this document is organized along architectural lines, i.e. emphasizing the logical divisions of the system and how they fit together. It describes the large-scale separation of the system into two parts: the media access control (MAC) sublayer of the data link layer, and the physical layer. These layers correspond closely to the lowest layers of the ISO Model for Open System Interconnection (OSI). The LLC sublayer and the MAC sublayer together encompass the functions intended for the data link layer as defined in the OSI model.< > |
4 END
