unity 射箭游戏

•  基础分（2分）：有博客；
•  1-3分钟视频（2分）：视频呈现游戏主要游玩过程；
•  地形（2分）：使用地形组件，上面有草、树；
•  天空盒（2分）：使用天空盒，天空可随玩家位置 或 时间变化 或 按特定按键切换天空盒；
•  固定靶（2分）：有一个以上固定的靶标；
•  运动靶（2分）：有一个以上运动靶标，运动轨迹，速度使用动画控制；
•  射击位（2分）：地图上应标记若干射击位，仅在射击位附近可以拉弓射击，每个位置有 n 次机会；
•  驽弓动画（2分）：支持蓄力半拉弓，然后 hold，择机 shoot；
•  游走（2分）：玩家的驽弓可在地图上游走，不能碰上树和靶标等障碍；
•  碰撞与计分（2分）：在射击位，射中靶标的相应分数，规则自定；

用了Classicbow的模型与动画

1、地形不需要设定代码，只需要保证刚体和碰撞就可以完成作业要求

2、天空盒子，我这里下载了免费的allsky资源，3秒轮播

using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class changeskybox : MonoBehaviour
{
    // 天空盒材质的数组
    public Material[] skyboxes;

    // 用于轮播天空盒的计时器
    private float timer = 0f;

    // 每隔多少秒轮播一次天空盒
    public float changeInterval = 3f;

    // 当前显示的天空盒的索引
    private int currentSkyboxIndex = 0;

    // 在游戏开始时初始化天空盒
    void Start()
    {
        if (skyboxes.Length > 0)
        {
            RenderSettings.skybox = skyboxes[0];
        }
    }

    // 每帧更新一次
    void Update()
    {
        // 更新计时器
        timer += Time.deltaTime;

        // 如果计时器超过了更改间隔，那么更改天空盒
        if (timer > changeInterval)
        {
            // 重置计时器
            timer = 0f;

            // 更新天空盒索引
            currentSkyboxIndex = (currentSkyboxIndex + 1) % skyboxes.Length;

            // 更改天空盒
            RenderSettings.skybox = skyboxes[currentSkyboxIndex];
        }
    }
}

3、固定靶，运动靶，用多个圆柱叠在一起了，但后面图实现简单，就先直接使用命中就得分的机制，没有按环给分，之后todo。不需要代码，但还是需要colider，不需要添加刚体，否则会被撞飞。

运动靶就通过简单的动画实现移动：
4、射击位，设定射击次数

using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class SpotController : MonoBehaviour
{
    public int shots;
    // Start is called before the first frame update
    void Start()
    {
        shots = 3;
    }

    // Update is called once per frame
    void Update()
    {

    }
}

5、弩弓动画

用了blend tree，通过检测鼠标的点击控制发射。

using System.Collections;
using System.Collections.Generic;
using UnityEngine;
using UnityEngine.UI;

public class CrossbowController : MonoBehaviour
{
    public float mouseSensitivity = 100.0f;
    float force;
    const float maxForce = 0.5f;
    const float chargeRate = 0.1f;
    Animator animator;
    float mouseDownTime;
    bool isCharging;

    public int speed;
    public bool ready_to_shoot;
    private bool atSpot = false;
    public SpotController[] spots;
    private SpotController inspot;
    string message;

    void Start()
    {
        Debug.Log("Self position: " + this.gameObject.transform.position);
        Cursor.lockState = CursorLockMode.Locked;
        animator = GetComponent<Animator>();
        ready_to_shoot = false;
        inspot = null;
        message = "";
    }

    void Update()
    {

        Debug.Log("Self position: " + this.gameObject.transform.position);

            atSpot = false;  // Set atSpot to false at the start of each update
        ready_to_shoot = false; // Set ready_to_shoot to false at the start of each update

        foreach (SpotController s in spots)
        {
            Vector2 position1 = new Vector2(s.gameObject.transform.position.x, s.gameObject.transform.position.z);
            Vector2 position2 = new Vector2(this.gameObject.transform.position.x, this.gameObject.transform.position.z);
            float distance = Vector2.Distance(position1, position2);

            if (distance <= 3)
            {
                atSpot = true;
                inspot = s;
                ready_to_shoot = inspot.shots > 0 ? true : false;
                break; // If a spot is found where distance <= 5, we break the loop
            }
        }

            if (ready_to_shoot)
        {
            if (Input.GetMouseButtonDown(0))
            {
                Debug.Log("Mouse button down, start charging");
                mouseDownTime = Time.time;
                isCharging = true;

                animator.SetTrigger("pull");
            }

            if (isCharging)
            {
                Debug.Log("Charging");
                float holdTime = Time.time - mouseDownTime;
                force = Mathf.Min(holdTime / 0.3f * chargeRate, maxForce);

                animator.SetFloat("power", force + 0.5f);
            }

            if (Input.GetMouseButtonUp(0) && isCharging)
            {
                Debug.Log("Mouse button up, stop charging and fire");
                isCharging = false;
                float holdTime = Time.time - mouseDownTime;
                force = Mathf.Min(holdTime / 0.3f * chargeRate, maxForce);
                animator.SetFloat("hold_power", force + 0.5f);
                StartCoroutine(DelayedFireCoroutine(force));

                animator.SetTrigger("shoot");
            }
        }
        else
        {
            Debug.Log("Not ready to shoot");
        }
    }

    IEnumerator DelayedFireCoroutine(float f)
    {
        Debug.Log("Ready to fire!!");
        yield return new WaitForSeconds(0f);
        fire(f);
        inspot.shots--;
    }

    public void fire(float f)
    {
        Debug.Log("Firing with force: " + f);
        GameObject arrow = Instantiate<GameObject>(Resources.Load<GameObject>("Prefabs/Arrow"));
        ArrowController aw = arrow.AddComponent<ArrowController>();
        Transform childTransform1 = transform.Find("弦");
        aw.transform.position = childTransform1.position;
        aw.transform.rotation = Quaternion.LookRotation(this.transform.up);
        Rigidbody arrow_db = arrow.GetComponent<Rigidbody>();
        arrow.tag = "Arrow";
        arrow_db.AddForce(100 * f * this.transform.up);
    }

    void OnCollisionEnter(Collision collider)
    {
        this.gameObject.GetComponent<Rigidbody>().isKinematic = true;
    }

    void OnCollisionExit(Collision collision)
    {
        this.gameObject.GetComponent<Rigidbody>().isKinematic = false;
    }

    void OnGUI()
    {
        GUIStyle style = new GUIStyle(GUI.skin.label);
        style.fontSize = 20; // Set the font size to 20
        if (atSpot)
        {
            message = "您已到达射击位,剩余射击次数：" + inspot.shots;
        }
        else
        {
            message = "";
        }
        GUI.Label(new Rect(300, 350, 500, 100), message, style);
    }
}

6、箭

包括了是否射中的检测，发射的速度，以及得分计算，通过一个全局的静态S

using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class ArrowController : MonoBehaviour
{
    //Transform target;
    //Vector3 delta;
    Rigidbody rb;
    private Transform target; // 靶的 Transform 组件
    private Vector3 offset; // 箭与靶的位置偏移
    bool isMove;
    // Start is called before the first frame update
    void Start()
    {
        rb = GetComponent<Rigidbody>();
        isMove = false;
        offset = new Vector3(0,0,0);
    }
    void OnCollisionEnter(Collision collider)
    {
        if (collider.gameObject.tag == "Target")
        {
            this.gameObject.GetComponent<Rigidbody>().isKinematic = true;
            isMove = false;
            //Debug.Log(collider.gameObject.name);
            ScoreController.S += 1;
            Debug.Log("Score: " + ScoreController.S); // 打印得分

        }
        if (collider.gameObject.tag == "MoveTarget")
        {
            this.gameObject.GetComponent<Rigidbody>().isKinematic = true;
            target = collider.gameObject.transform;
            // 计算箭与靶的位置偏移
            offset = this.transform.position - target.position;
            isMove = true;
        }
    }
    // Update is called once per frame
    void Update()
    {
        if (rb.isKinematic == true && isMove == true)
        {
            this.transform.position = target.position + offset;
        }
    }
}

7、 游走与碰撞

using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class Move : MonoBehaviour
{
    //public float speed = 1f;    // 允许设置速度
    public float moveSpeed = 3.0f;
    public float rotateSpeed = 90f;
    bool canMove = true;

    void Start()
    {

    }
    private void OnCollisionEnter(Collision collision)
    {
         // 阻止角色穿越树木
         canMove = false;
         Debug.Log("Player collided with a tree and stopped moving!");
    }

    private void OnCollisionExit(Collision collision)
    {
        // 允许角色继续移动
        canMove = true;
        Debug.Log("Player is no longer colliding with a tree and can move again!");
    }
    void Update()
    {
        if (canMove)
        {
            float x = Input.GetAxis("Horizontal");
            float y = Input.GetAxis("Vertical");

            Vector3 moveDirection = transform.right * x + transform.up * y;
            transform.position += moveDirection * Time.deltaTime * moveSpeed;
        }
    }
}
