昨天在项目开发中,发现一个问题,就是一些脚本已经被废弃,但是这些废弃脚本还是被绑定在某些预制体中,这时候运行就会产生很多Missing Script的警告信息,这些警告虽不影响代码的实际运行,但是一个大项目肯定不能出现的N多的警告信息,并且这里通过手动去找肯定不现实,所以这里我们就同一个脚本去实现自动去遍历所有的prefab然后移除Missing的组件,下面是具体的代码信息。
1.首先在工程中创建一个Editro文件夹,将脚本放在Editor文件夹下
2.通过选中文件,通过编辑器实现遍历该文件夹下的所有prefab:
[MenuItem("工具/对象移除丢失脚本")]
static void GetAllGo()
{
//寻找你选中文件夹下的所有文件
object[] obj = Selection.GetFiltered(typeof(object), SelectionMode.DeepAssets);
for (int i = 0; i < obj.Length; i++)
{
//获取文件的后缀信息
string ext = System.IO.Path.GetExtension(obj[i].ToString());
//这里筛选出不是预制体的物体
if (!ext.Contains(".GameObject"))
{
continue;
}
GameObject go = (GameObject)obj[i];
// 移除子物体下的脚本丢失
foreach (Transform trans in go.GetComponentsInChildren<Transform>(true))
{
CleanMissingScript(trans.gameObject, go);
}
}
}
3.找到prefab,去遍历她的所有子物体,并实现直接移除相应的空组件:
static void CleanMissingScript(GameObject go, GameObject parentGO)
{
var components = go.GetComponents<Component>();
var serializedObject = new SerializedObject(go);
var prop = serializedObject.FindProperty("m_Component");
int r = 0;
for (int j = 0; j < components.Length; j++)
{
if (components[j] == null)
{
prop.DeleteArrayElementAtIndex(j - r);
MyDebug.Log("成功移除丢失脚本,gameObject name: " + go.name + " ---父类prefab name:" + parentGO.name);
r++;
}
}
serializedObject.ApplyModifiedProperties();
}
4.如果还要做其他操作,比如我们写了一个扩展的button脚本,这时候我们不可能通过手动去把所有之前的button换成新的butonPlus,所以这时候就需要去代码自动实现:
static void CleanMissingScript(GameObject go, GameObject parentGO)
{
var components = go.GetComponents<Component>();
//如果当前组件有按钮
if (go.GetComponent<UnityEngine.UI.Button>() != null)
{
Button btn = go.GetAddComponent<Button>();
//copy之前的组件信息
UnityEditorInternal.ComponentUtility.CopyComponent(btn);
//移除组件信息
GameObject.DestroyImmediate(btn);
//TODO:添加新的组件信息
}
serializedObject.ApplyModifiedProperties();
}
5.下面是完整脚本:
using UnityEngine;
using UnityEditor;
using UnityEngine.UI;
/// <summary>
/// 移除项目中go上丢失的脚本
/// </summary>
public class RemoveMissingScript
{
[MenuItem("SlgTool/程序工具/对象移除丢失脚本")]
static void GetAllGo()
{
object[] obj = Selection.GetFiltered(typeof(object), SelectionMode.DeepAssets);
for (int i = 0; i < obj.Length; i++)
{
string ext = System.IO.Path.GetExtension(obj[i].ToString());
Debug.Log("name:" + ext);
if (!ext.Contains(".GameObject"))
{
continue;
}
GameObject go = (GameObject)obj[i];
// 移除子物体下的脚本丢失
foreach (Transform trans in go.GetComponentsInChildren<Transform>(true))
{
CleanMissingScript(trans.gameObject, go);
}
}
}
static void CleanMissingScript(GameObject go, GameObject parentGO)
{
var components = go.GetComponents<Component>();
var serializedObject = new SerializedObject(go);
var prop = serializedObject.FindProperty("m_Component");
int r = 0;
for (int j = 0; j < components.Length; j++)
{
if (components[j] == null)
{
prop.DeleteArrayElementAtIndex(j - r);
MyDebug.Log("成功移除丢失脚本,gameObject name: " + go.name + " ---父类prefab name:" + parentGO.name);
r++;
}
}
serializedObject.ApplyModifiedProperties();
}
}
这里就是一个完整的代码自动查找prefab下的空组件,然后移除的代码。
